Page 1 DL6000/DLM6000 Series Digital Oscilloscope/ Mixed Signal Oscilloscope Communication Interface IM DLM6054-17EN 1st Edition...
Page 2 • Copying or reproducing all or any part of the contents of this manual without the permission of Yokogawa Electric Corporation is strictly prohibited. 1st Edition: October 2009 (YK) All Rights Reserved, Copyright © 2009 Yokogawa Electric Corporation IM DLM6054-17EN...
Page 3 To download sample programs, go to the following Web page, and then browse to the download page. http://tmi.yokogawa.com/service-support/downloads/ Trademarks • DLM is pending trademark of Yokogawa Electric Corporation. • Microsoft, MS-DOS, Visual C++, Windows, and Windows NT are registered trademarks of Microsoft Corporation in the United States and/or other countries.
Page 4: How To Use This Manual
How to Use This Manual Structure of This Manual This user’s manual consists of the following sections. Chapter 1 Overview of the USB Interface Describes the functions and specifications of the USB interface. Chapter 2 Overview of the Ethernet Interface (Optional) Describes the functions and specifications of the Ethernet interface.
Page 5 How to Use This Manual Symbols and Notations Used in This Manual Communication Command Notation In the detailed explanations of the communication commands in chapter 5, DLM6000-specific commands are written in blue italics. These commands are not available on the DL6000. Safety Markings The following markings are used in this manual.
Page 6: Table Of Contents
Contents How to Use This Manual ........................iii Chapter 1 Overview of the USB Interface Part Names and Functions ....................1-1 USB Interface Functions and Specifications ..............1-2 Connection via the USB Interface ..................1-4 Setting the DL6000/DLM6000 (USB) ................1-5 Chapter 2 Overview of the Ethernet Interface (Optional) Part Names and Functions ....................
Page 7 Contents 5.20 REFerence Group ......................5-120 5.21 SEARch Group ......................5-121 5.22 SNAP Group ......................... 5-132 5.23 SSTart Group ........................ 5-133 5.24 STARt Group ........................ 5-134 5.25 STATus Group ......................5-135 5.26 STOP Group ......................... 5-136 5.27 SYSTem Group ......................5-137 5.28 TELecomtest (Mask) Group ..................
Page 8: Chapter 1 Overview Of The Usb Interface
Chapter 1 Overview of the USB Interface Part Names and Functions Front Panel REST CURSOR MEASURE ANALYSIS MATH/REF SHIFT MASK ZOOM PRINT AUTO SETUP SETUP MENU MENU FILE DISPLAY ACQUIRE ZOOM1 ZOOM2 X - Y SYSTEM key UTILITY SEARCH HISTORY RUN / STOP SINGLE Press this key to select...
Page 9: Usb Interface Functions And Specifications
USB Interface Functions and Specifications USB Interface Functions Reception Function You can specify the same settings as those specified by front panel key operations. Receives output requests for measured and computed data, setup parameters of the panel, and error codes. Transmission Function Outputs measured and computed data.
Page 10 1.2 USB Interface Functions and Specifications Switching between Remote and Local Modes When Switching from Local to Remote Mode If the DL6000/DLM6000 receives a “:COMMunicate:REMote ON” command from the PC when it is in the local mode, it switches to the remote mode. •...
Page 11: Connection Via The Usb Interface
Connection via the USB Interface Precautions to Be Taken When Making Connections • Connect the USB cable by inserting the connector firmly into the USB connector. • When connecting multiple devices using USB hubs, connect the DL9710L to the USB hub that is closest to the controller.
Page 12: Setting The Dl6000/Dlm6000 (Usb)
OFF, and then turn the switch back ON. • Install YOKOGAWA’s TMC (Text and Measurement Class) driver into your PC. To obtain YOKOGAWA’ s USB TMC driver, contact your nearest YOKOGAWA dealer or access the following USB driver page at our Web site and download it. http://www.yokogawa.com/tm/tm-softdownload.htm •...
Page 13: Chapter 2 Overview Of The Ethernet Interface (Optional)
Chapter 2 Overview of the Ethernet Interface (Optional) Part Names and Functions Front Panel REST CURSOR MEASURE ANALYSIS MATH/REF SHIFT MASK ZOOM PRINT AUTO SETUP SETUP MENU MENU FILE DISPLAY ACQUIRE ZOOM1 ZOOM2 SYSTEM key X - Y UTILITY SEARCH HISTORY RUN / STOP SINGLE...
Page 14: Ethernet/Vxi-11 Interface Features And Specifications
Ethernet/VXI-11 Interface Features and Specifications Ethernet/VXI-11 Interface Features Reception Feature The DL6000/DLM6000 reception feature allows you to specify the same settings through an Ethernet connection that you can specify using the front panel keys. The DL6000/DLM6000 can receive output requests for measured and computed data, panel setting data, and error codes.
Page 15 2.2 Ethernet/VXI-11 Interface Features and Specifications The following table contains approximate waveform data response times for logic signals. Number of Data Points Double Word Data ASCII Data 2500 Approx. 31 ms Approx. 0.094 s 125000 Approx. 828 ms Approx. 3.906 s 1250000 Approx.
Page 16: Connecting To The Ethernet/Vxi-11 Interface
Connecting to the Ethernet/VXI-11 Interface Connection Procedure Connect a UTP (Unshielded Twisted-Pair) or STP (Shielded Twisted-Pair) cable that is connected to a hub or other network device to the 100BASE-TX port on the DL6000/DLM6000 rear panel. Hub or router that supports 100BASE-TX DL6000/ DLM6000 Straight UTP or STP cable...
Page 17: Setting The Dl6000/Dlm6000 (Network)
Setting the DL6000/DLM6000 (Network) Procedure UTILITY_Remote Control_Network Menu Press UTILITY, the Remote Control soft key, and then the Network or Network(VXI-11) soft key to display the following menu. Select to use the Ethernet interface. Select to use the VXI-11 interface. Set the user name.
Page 18 2.4 Setting the DL6000/DLM6000 (Network) Timeout Value The DL6000/DLM6000 disconnects itself from the controller if it is not accessed for the period of time that you specify using the timeout value. TCP/IP To use the Ethernet interface, you must specify the following TCP/IP settings. •...
Page 19: Chapter 3 Overview Of The Gp-Ib Interface
Chapter 3 Overview of the GP-IB Interface Part Names and Functions Front Panel REST CURSOR MEASURE ANALYSIS MATH/REF SHIFT MASK ZOOM PRINT AUTO SETUP SETUP MENU MENU FILE ZOOM1 ZOOM2 DISPLAY ACQUIRE SYSTEM key X - Y UTILITY SEARCH HISTORY SINGLE RUN / STOP Press this key to select...
Page 20: Connecting The Gp-Ib Card
Connecting the GP-IB Card GP-IB Card Use the NI PCMCIA-GPIB card by National Instruments. GP-IB Cable Use the GP-IB cable that comes with the GP-IB card. Connection Procedure Insert the GP-IB card into the DL6000/DLM6000 PC card slot. To the PC card slot of the DL6000/DLM6000 GP-IB card GP-IB cable Precautions to Be Taken When Making Connections...
Page 21: Gp-Ib Interface Functions
GP-IB Interface Functions GP-IB Interface Functions Listener Capability • All of the information that you can set with the panel keys can be set through the GP-IB interface except for turning ON/OFF the power and setting the communication parameters. • Receives commands from a controller requesting the output of setup information, waveform data, and other information.
Page 22: Gp-Ib Interface Specifications
GP-IB Interface Specifications GP-IB Interface Specifications Electrical and mechanical specifications: Conforms to IEEE St’d 488-1978 Functional specifications: See table below. Protocol: Conforms to IEEE St’d 488.2-1992 Code used: ISO (ASCII) code Mode: Addressable mode Address setting: The address can be set in the range from 0 to 30 on the GP-IB setting screen that is played using the MISC menu.
Page 23: Setting The Dl6000/Dlm6000 (Gp-Ib)
Setting the DL6000/DLM6000 (GP-IB) Procedure UTILITY_Remote Control_GP-IB Menu Press UTILITY, the Remote Control soft key, and then the GPIB soft key to display the following menu. Select GP-IB. Set the address. Note Only the communication interface selected by Remote Control is enabled. The DL6000/DLM6000 does not accept commands that are transmitted to other unselected communication interfaces.
Page 24: Responses To Interface Messages
Responses to Interface Messages Responses to Interface Messages Responses to a Uni-Line Message • IFC (Interface Clear) Clears the talker and listener functions. Stops output if data are being output. • REN (Remote Enable) Switches between the remote and local modes. IDY (Identify) is not supported.
Page 25 3.6 Responses to Interface Messages Multi-Line Messages Eight data lines are used to transmit multi-line messages. The messages are classified as follows: • Address Commands These commands are valid when the instrument is designated as a listener or as a talker. The following five types are available.
Page 26: Chapter 4 Before Programming
Chapter 4 Before Programming Messages Messages Program Message Unit Format Messages are used to exchange information between The program message unit format is shown below the controller and the instrument. Messages that are sent from the controller to the instrument are called <Program header>...
Page 27 4.1 Messages Response Message Unit Format • If a program message containing multiple message The response message unit format is shown belw. units is sent, and the message contains incomplete units, the instrument attempts to execute the ones that are believed to be complete. However, these <Response header>...
Page 28: Commands
Commands Commands • When Concatenating Commands of the Same There are three types of commands (program headers) Group that are sent from the controller to the instrument. The instrument stores the hierarchical level of the They differ in their program header formats. command that is currently being executed, and performs analysis on the assumption that the next Common Command Header...
Page 29 4.2 Commands Upper-Level Query An upper-level query is a query in which a question mark ( ? ) is appended to the highest level command of a group. Execution of an upper-level query allows all settings that can be specified in the group to be received at once.
Page 30: Response
Response Response When the controller sends a message unit that has a question mark ( ? ) in its program header (query), the instrument returns a response message to the query. A response message is returned in one of the following two forms.
Page 31: Data
Data Data <Voltage>, <Time>, <Frequency>, and <Current> A data section comes after the header. A space must be <Voltage>, <Time>, <Frequency>, and <Current> included between the header and the data. The data indicate decimal values that have physical significance. contains conditions and values. Data is classified as below. <Multiplier>...
Page 32 4.4 Data <Register> • If a character string contains a double quotation mark ( ' ), the double quotation mark is replaced by two <Register> indicates an integer, and can be expressed double quotation marks ( "" ). This rule also applies in hexadecimal, octal, or binary as well as a decimal number.
Page 33: Synchronization With The Controller
Synchronization with the Controller Overlap Commands and Sequential Commands • Using the COMMunicate:OVERlap command The COMMunicate:OVERlap command enables (or There are two types of commands, overlap commands and sequential commands. In the case of overlap disables) overlap operation. Example :COMMunicate:OVERlap #HFFBF;: commands, the execution of the next command may FILE:LOAD:SETup: start before the execution of the previous command is...
Page 34 4.5 Synchronization with the Controller • Using the *OPC? Query • Using the Extended Event Register The *OPC? query generates a response when an The changes in the condition register can be overlap operation is completed. reflected in the extended event register (page 6-5). Example :COMMunicate:OPSE #H0040;:FILE: Example :STATus:FILTer1 FALL;: LOAD:SETup:EXECute "CASE1";...
Page 35: Chapter 5 Commands
Chapter 5 Commands List of Commands Commnd Function Page ACQuire Group :ACQuire? Queries all settings related to the waveform acquisition. 5-35 :ACQuire:AVERage? Queries all settings related to averaging and the waveform acquisition count. 5-35 :ACQuire:AVERage:COUNt Sets the waveform acquisition count of averaging mode or queries the 5-35 current setting.
Page 36 5.1 List of Commands Commnd Function Page :ANALysis:AHIStogram<x>: Sets the ΔV cursor position of the accumulated histogram or queries the 5-38 MEASure:CURSor:HPOSition<x> current setting. :ANALysis:AHIStogram<x>: Turns ON/OFF the ΔT cursor link of the accumulated histogram or queries 5-38 MEASure:CURSor:VLINkage the current setting. :ANALysis:AHIStogram<x>: Sets the ΔT cursor position of the accumulated histogram or queries the 5-38...
Page 37 5.1 List of Commands Commnd Function Page :ANALysis:FFT<x>:HORizontal: Sets the horizontal mode of the FFT computation or queries the current 5-42 MODE setting. :ANALysis:FFT<x>:LENGth Sets the number of FFT points of the FFT computation or queries the current 5-42 setting. :ANALysis:FFT<x>:MEASure? Queries all settings related to the automated measurement of the FFT 5-42...
Page 38 5.1 List of Commands Commnd Function Page :ANALysis:FFT<x>:MEASure:PEAK[: Turns ON/OFF the frequency value between peak values of the FFT 5-45 BASic]:DFRequency:STATe computation or queries the current setting. :ANALysis:FFT<x>:MEASure:PEAK[: Queries the frequency value between peak values of the FFT computation. 5-45 BASic]:DFRequency:VALue? :ANALysis:FFT<x>:MEASure:PEAK[: Queries all settings related to the power value between peak values of the...
Page 39 5.1 List of Commands Commnd Function Page :ANALysis:WPARameter<x>: Queries all settings related to the histogram display of the waveform 5-49 HISTogram? parameter measurement. :ANALysis:WPARameter<x>: Queries all settings related to the automated measurement of the histogram 5-49 HISTogram:MEASure? display of the waveform parameter measurement. :ANALysis:WPARameter<x>: Queries all settings related to the cursor measurement on the histogram of 5-49...
Page 40 5.1 List of Commands Commnd Function Page :ANALysis:WPARameter<x>:TRENd? Queries all settings related to the trend display of the waveform parameter 5-52 measurement. :ANALysis:WPARameter<x>:TRENd: Executes the auto scaling of the trend display of the waveform parameter 5-53 ASCale[:EXECute] measurement. :ANALysis:WPARameter<x>:TRENd: Sets the target window for trend display of measured waveform parameters 5-53 HRANge or queries the current setting.
Page 41 5.1 List of Commands Commnd Function Page :ANALysis:XY<x>:MEASure: Sets the integration mode of the XY display or queries the current setting. 5-57 XYINteg:LOOP :ANALysis:XY<x>:MEASure: Sets the integration polarity of the XY display or queries the current setting. 5-57 XYINteg:POLarity :ANALysis:XY<x>:MEASure: Queries the integral value of the XY display.
Page 42 5.1 List of Commands Commnd Function Page CLEar Group :CLEar Clears traces. 5-62 COMMunicate Group :COMMunicate? Queries all settings related to communications. 5-63 :COMMunicate:HEADer Sets whether to add a header to the response to a query (example 5-63 CHANNEL1:VOLTAGE:PROBE 10) or not add the header (example 10) or queries the current setting.
Page 43 5.1 List of Commands Commnd Function Page :CURSor:MARKer:CALCulation: Turns ON/OFF the calculation item of the marker cursors or queries the 5-67 STATe<x> current setting. :CURSor:MARKer:CALCulation: Queries the measured value of the calculation item of the marker cursors. 5-67 VALue<x>? :CURSor:MARKer:CM<x>? Queries all settings related to the marker cursor.
Page 44 5.1 List of Commands Commnd Function Page :CURSor:VERTical[:BASic]: Turns ON/OFF the ΔT cursor link or queries the current setting. 5-70 LINKage :CURSor:VERTical[:BASic]:PERDt? Queries all settings related to the 1/∆T measurement of the ΔT cursors. 5-70 :CURSor:VERTical[:BASic]:PERDt: Turns ON/OFF the 1/∆T measurement of the ΔT cursors or queries the 5-71 STATe current setting.
Page 45 5.1 List of Commands Commnd Function Page DISPlay Group :DISPlay? Queries all settings related to the display. 5-74 :DISPlay:ACCumulate? Queries all settings related to the accumulated display of waveforms. 5-74 :DISPlay:ACCumulate:GRADe Sets the accumulate mode or queries the current setting. 5-74 :DISPlay:ACCumulate:MODE Turns ON/OFF the accumulate mode or queries the current setting.
Page 46 5.1 List of Commands Commnd Function Page FILE Group :FILE? Queries all settings related to the specified storage medium or internal 5-77 memory. :FILE:DIRectory? Queries all settings related to the specified storage medium. 5-77 :FILE[:DIRectory]:CDIRectory Sets the current directory or queries the current setting. 5-77 (Change Directory) :FILE[:DIRectory]:FREE?
Page 47 5.1 List of Commands Commnd Function Page GONogo Group :GONogo? Queries all settings related to GO/NO-GO determination. 5-81 :GONogo:ABORt Aborts the GO/NO-GO determination. 5-81 :GONogo:ACTion? Queries all settings related to the action taken when the determination result 5-81 is NO-GO and the criteria values. :GONogo:ACTion:BUZZer Sets whether to sound a buzzer when the determination result is NO-GO or 5-81...
Page 48 5.1 List of Commands Commnd Function Page :GONogo:ZPARameter:SELect<x>: Sets the upper and lower limits of the calculation item of the FFT 5-84 PARameter:FFT<x>:CALCulation<x> determination or queries the current setting. :GONogo:ZPARameter:SELect<x>: Queries all settings related to the peak value of the FFT determination. 5-84 PARameter:FFT<x>:PEAK? :GONogo:ZPARameter:SELect<x>:...
Page 49 5.1 List of Commands Commnd Function Page :GONogo:ZPARameter:SELect<x>: Sets the source window of the zone determination or queries the current 5-89 WINDow setting. HCOPy Group :HCOPy? (Hard COPY) Queries all settings related to the output of screen data. 5-90 :HCOPy:ABORt Aborts data output and paper feeding.
Page 50 5.1 List of Commands Commnd Function Page HISTory Group :HISTory? Queries all settings related to the history function. 5-92 :HISTory:CURRent? Queries all settings related to the history function of the current waveform 5-92 (CH1 to 4, M1 to 8). :HISTory[:CURRent]:DISPlay Sets the start number and end number of the display record of the history 5-92 waveform or queries the current setting.
Page 51 5.1 List of Commands Commnd Function Page :HISTory[:CURRent][:SEARch]: Queries all settings related to each area of measure search. 5-95 SELect<x>:PARameter:MEASure: BIT<x>:AREA<x>? :HISTory[:CURRent][:SEARch]: Queries all settings related to logic waveform parameters of measure search. 5-95 SELect<x>:PARameter:MEASure: BIT<x>:AREA<x>:TYPE? :HISTory[:CURRent][:SEARch]: Sets the upper and lower limits of the logic waveform of measure search or 5-96 SELect<x>:PARameter:MEASure: queries the current setting.
Page 52 5.1 List of Commands Commnd Function Page :HISTory:REFerence<x>:RECord? Queries the minimum record number of the history waveform of the 5-99 MINimum reference. :HISTory:REFerence<x>:REPLay? Queries all settings related to the replay function of the history function of the 5-99 reference. :HISTory:REFerence<x>:REPLay: Jumps to the specified record number of the history waveform of the 5-99 JUMP...
Page 53 5.1 List of Commands Commnd Function Page LOGic Group :LOGic? Queries all settings related to the logic. 5-103 :LOGic:AWINdow? Queries all settings related to analog waveform display. 5-103 :LOGic:AWINdow[:DISPlay] Turns ON/OFF the analog waveform display or queries the current setting. 5-103 :LOGic:AWINdow:RATio Sets the analog waveform display ratio or queries the current setting.
Page 54 5.1 List of Commands Commnd Function Page MATH Group :MATH<x>? Queries all settings related to the computation. 5-106 :MATH<x>:DA? Queries all settings related to the D/A conversion. 5-106 :MATH<x>:DA:ARANging Executes the auto range of the D/A conversion. 5-106 :MATH<x>:DA:BFORmat Sets the binary format of D/A conversion or queries the current setting. 5-106 :MATH<x>:DA:HISTory:ABORt Aborts the history computation of the D/A conversion.
Page 55 5.1 List of Commands Commnd Function Page :MATH<x>:USERdefine:DEFine Sets a user-defined math equation or queries the current setting. 5-110 :MATH<x>:USERdefine:FILTer<y>? Queries all filter settings for user-defined computation. 5-110 :MATH<x>:USERdefine:FILTer<y>: Sets or queries the filter band (frequency band) for user-defined computation. 5-110 BAND :MATH<x>:USERdefine:FILTer<y>: Sets or queries the cutoff frequency for user-defined computation.
Page 56 5.1 List of Commands Commnd Function Page :MEASure:CONTinuous:RESTart Restarts the continuous statistical processing. 5-114 :MEASure:CYCLe? Queries all settings related to the cycle statistical processing. 5-114 :MEASure:CYCLe:ABORt Aborts the execution of the cycle statistical processing. 5-114 :MEASure:CYCLe:EXECute Executes the cycle statistical processing. This is an overlap command. 5-114 :MEASure:CYCLe:TRACe Sets the cycle source trace of the continuous statistical processing count or...
Page 57 5.1 List of Commands Commnd Function Page :MEASure:TRACe<x>:DPRoximal: Sets the distal and proximal values in the specified unit or queries the current 5-119 UNIT setting. :MEASure:TRACe<x>:METHod Sets the method for detecting the High/Low level for automated 5-119 measurement of waveform parameters or queries the current setting. :MEASure:TRANge<x>...
Page 58 5.1 List of Commands Commnd Function Page :SEARch<x>:SLOGic:SPATtern: Sets the latch trace for the logic serial pattern search or queries the current 5-124 LATCh:TRACe setting. :SEARch<x>:SLOGic:SPATtern[: Queries all settings related to the setup for the logic serial pattern search. 5-124 SETup]? :SEARch<x>:SLOGic:SPATtern[: Sets the bit rate for the logic serial pattern search or queries the current...
Page 59 5.1 List of Commands Commnd Function Page :SEARch<x>:SPATtern:SETup? Queries all settings related to setup of the serial pattern search. 5-129 :SEARch<x>:SPATtern[:SETup]: Sets the bit rate of the serial pattern search or queries the current setting. 5-129 BITRate :SEARch<x>:SPATtern[:SETup]: Clears the entire pattern of the serial pattern search (to don’t care). 5-129 CLEar :SEARch<x>:SPATtern[:SETup]:...
Page 60 5.1 List of Commands Commnd Function Page STOP Group :STOP Stops the waveform acquisition. 5-136 SYSTem Group :SYSTem? Queries all settings related to the system. 5-137 :SYSTem:CLICk Turns ON/OFF the click sound or queries the current setting. 5-137 :SYSTem:CLOCk? Queries all settings related to the date, time, and time difference with respect 5-137 to GMT.
Page 61 5.1 List of Commands Commnd Function Page :TELecomtest:MASK:ELEMent<x>: Queries the settings related to the number of sampled data points for the 5-141 SPCount? (Sample Point Count) element that results in error. :TELecomtest:MASK:ELEMent<x>: Turns ON/OFF the measurement of the number of sampled data points for 5-141 SPCount:STATe the element that results in error or queries the current setting.
Page 62 5.1 List of Commands Commnd Function Page :TRIGger:EDGE:HYSTeresis Sets or queries the noise rejection setting for the edge trigger source trigger 5-146 level. :TRIGger:EDGE:LEVel Sets or queries the edge trigger source trigger level. 5-146 :TRIGger:EDGE:PROBe Sets or queries the external trigger source probe setting for edge triggering. 5-146 :TRIGger:EDGE:SLOPe Sets or queries the trigger source trigger slope (the polarity when window is 5-146...
Page 63 5.1 List of Commands Commnd Function Page :TRIGger:EINTerval:EVENt<x>: Sets the latch trace for the logic serial pattern trigger or queries the current 5-151 LOGic:SPATtern:LATCh:SOURce setting. :TRIGger:EINTerval:EVENt<x>: Sets the pattern of the logic serial pattern trigger in binary notation, or 5-152 LOGic:SPATtern:PATTern queries the current setting.
Page 64 5.1 List of Commands Commnd Function Page :TRIGger:EINTerval:EVENt<x>: Sets the pattern of the serial pattern trigger in hexadecimal notation. 5-156 SPATtern:HEXA :TRIGger:EINTerval:EVENt<x>: Queries all settings related to latch of the serial pattern trigger. 5-156 SPATtern:LATCh? :TRIGger:EINTerval:EVENt<x>: Sets the polarity of the latch trace of the serial pattern trigger or queries the 5-156 SPATtern:LATCh:POLarity current setting.
Page 65 5.1 List of Commands Commnd Function Page :TRIGger:ENHanced:SPATtern: Sets the latch trace of the serial pattern trigger or queries the current setting. 5-160 LATCh:SOURce :TRIGger:ENHanced:SPATtern: Sets the pattern of the serial pattern trigger in binary notation or queries the 5-160 PATTern current setting.
Page 66 5.1 List of Commands Commnd Function Page :TRIGger:LOGic:SPATtern:CLOCk: Sets the polarity of the clock trace of the logic serial pattern trigger or queries 5-164 POLarity the current setting. :TRIGger:LOGic:SPATtern:CLOCk: Sets the clock trace for the logic serial pattern trigger or queries the current 5-164 SOURce setting.
Page 67 5.1 List of Commands Commnd Function Page :TRIGger:SOURce:CHANnel<x>: Sets the trigger level of the channel or queries the current setting. 5-168 LEVel :TRIGger:SOURce:CHANnel<x>: Sets the condition to be satisfied of the channel or queries the current 5-168 STATe setting. :TRIGger:SOURce:CHANnel<x>: Sets the window trigger width of the channel or queries the current setting.
Page 68 5.1 List of Commands Commnd Function Page ZOOM Group :ZOOM? Queries all settings related to the waveform zoom. 5-173 :ZOOM:ALLocation<x>? Queries all settings related to the zoom source waveform. 5-173 :ZOOM:ALLocation<x>:ALLon Sets all waveforms to be zoomed. 5-173 :ZOOM:ALLocation<x>:TRACe<x> Turns ON/OFF the trace you wish to zoom or queries the current setting. 5-173 :ZOOM:FORMat<x>...
Page 69 ACQuire Group :ACQuire? :ACQuire:REPetitive Function Queries all settings related to the waveform Function Turns ON/OFF the repetitive sampling or queries the acquisition. current setting. :ACQuire:REPetitive {<Boolean>} Syntax :ACQuire? Syntax :ACQuire:REPetitive? :ACQuire:AVERage? :ACQUIRE:REPETITIVE ON Example :ACQUIRE:REPETITIVE? -> :ACQUIRE: Function Queries all settings related to averaging and the REPETITIVE 1 waveform acquisition count.
Page 70 ANALysis Group :ANALysis? :ANALysis:AHIStogram<x>:MEASure: CURSor[:BASic]:ALL Function Queries all settings related to the analysis function. :ANALysis? Function Turns ON/OFF all basic items of the cursor of the Syntax accumulated histogram. :ANALysis:AHIStogram<x>? :ANALysis:AHIStogram<x>:MEASure: Syntax CURSor[:BASic]:ALL {<Boolean>} Function Queries all settings related to the accumulated <x>...
Page 71 5.3 ANALysis Group :ANALysis:AHIStogram<x>:MEASure: :ANALysis:AHIStogram<x>:MEASure: CURSor[:BASic]:DC? CURSor:CALCulation:DEFine<x> Function Queries all settings related to measured values Function Sets the equation of the calculation item of the cursor between cursors of the accumulated histogram. of the accumulated histogram or queries the current :ANALysis:AHIStogram<x>:MEASure: Syntax setting.
Page 72 5.3 ANALysis Group :ANALysis:AHIStogram<x>:MEASure: :ANALysis:AHIStogram<x>:MEASure: CURSor:HLINkage CURSor:VPOSition<x> Function Turns ON/OFF the ΔV cursor link of the accumulated Function Sets the ΔT cursor position of the accumulated histogram or queries the current setting. histogram or queries the current setting. :ANALysis:AHIStogram<x>:MEASure:CURSor: :ANALysis:AHIStogram<x>:MEASure:CURSor: Syntax Syntax HLINkage {<Boolean>}...
Page 73 5.3 ANALysis Group :ANALysis:AHIStogram<x>:MEASure: :ANALysis:AHIStogram<x>:MEASure: PARameter:AREA<x>:ALL PARameter:AREA<x>:<Parameter>:VALue? Function Turns ON/OFF all waveform parameters of the Function Queries the automated measured value of the accumulated histogram. waveform parameter of the accumulated histogram. :ANALysis:AHIStogram<x>:MEASure: Syntax :ANALysis:AHIStogram<x>:MEASure: Syntax PARameter:AREA<x>:ALL {<Boolean>} PARameter:AREA<x>:<Parameter>:VALue? <x> of AHIStogram<x> = 1 or 2 <x>...
Page 74 5.3 ANALysis Group :ANALysis:AHIStogram<x>:MEASure: :ANALysis:AHIStogram<x>:MEASure: PARameter:CALCulation:STATe<x> PARameter:VRANge<x> Function Turns ON/OFF the calculation items of the waveform Function Sets the vertical range of the waveform parameter parameter of the accumulated histogram or queries of the accumulated histogram or queries the current the current setting.
Page 75 5.3 ANALysis Group :ANALysis:AHIStogram<x>:WINDow :ANALysis:FFT<x>:HORizontal:CSPan: Function Sets the measurement target window of the CENTer accumulated histogram or queries the current setting. Function Sets the horizontal center of the FFT computation or :ANALysis:AHIStogram<x>:WINDow {MAIN| Syntax queries the current setting. Z1|Z2} :ANALysis:FFT<x>:HORizontal:CSPan: Syntax :ANALysis:AHIStogram<x>:WINDow? CENTer {<Frequency>}...
Page 76 5.3 ANALysis Group :ANALysis:FFT<x>:HORizontal:MODE :ANALysis:FFT<x>:MEASure: MARKer[:BASic]:DFRequency? Function Sets the horizontal mode of the FFT computation or queries the current setting. Function Queries all settings related to the frequency value :ANALysis:FFT<x>:HORizontal:MODE {AUTO| Syntax between marker cursors of the FFT computation. CSPan|LRIGht} :ANALysis:FFT<x>:MEASure: Syntax :ANALysis:FFT<x>:HORizontal:MODE?
Page 77 5.3 ANALysis Group :ANALysis:FFT<x>:MEASure: :ANALysis:FFT<x>:MEASure: MARKer[:BASic]:DV:STATe MARKer[:BASic]:FREQuency<x>:VALue? Function Turns ON/OFF the power value between marker Function Queries the frequency value of the marker cursor of cursors of the FFT computation or queries the current the FFT computation. :ANALysis:FFT<x>:MEASure: setting. Syntax :ANALysis:FFT<x>:MEASure: MARKer[:BASic]:FREQuency<x>:VALue? Syntax...
Page 78 5.3 ANALysis Group :ANALysis:FFT<x>:MEASure: :ANALysis:FFT<x>:MEASure:MARKer: MARKer[:BASic]:V<x>:VALue? CALCulation:STATe<x> Function Queries the power value of the marker cursor of the Function Turns ON/OFF the calculation items of the marker FFT computation. cursor of the FFT computation or queries the current :ANALysis:FFT<x>:MEASure: Syntax setting.
Page 79 5.3 ANALysis Group :ANALysis:FFT<x>:MEASure: :ANALysis:FFT<x>:MEASure: PEAK[:BASic]:ALL PEAK[:BASic]:DV:STATe Function Turns ON/OFF all basic items of the peak value of the Function Turns ON/OFF the power value between peak values FFT computation. of the FFT computation or queries the current setting. :ANALysis:FFT<x>:MEASure: :ANALysis:FFT<x>:MEASure:PEAK[:BASic]: Syntax Syntax...
Page 80 5.3 ANALysis Group :ANALysis:FFT<x>:MEASure: :ANALysis:FFT<x>:MEASure: PEAK[:BASic]:FREQuency<x>:VALue? PEAK[:BASic]:V<x>:VALue? Function Queries the peak frequency value of the FFT Function Queries the peak value of the FFT computation. :ANALysis:FFT<x>:MEASure:PEAK[:BASic]: computation. Syntax :ANALysis:FFT<x>:MEASure:PEAK[:BASic]: V<x>:VALue? Syntax FREQuency<x>:VALue? <x> of FFT<x> = 1 or 2 <x> of FFT<x> = 1 or 2 <x>...
Page 81 5.3 ANALysis Group :ANALysis:FFT<x>:MEASure:PEAK: :ANALysis:FFT<x>:RPOSition (Ref CALCulation:STATe<x> Position) Function Turns ON/OFF the calculation items of the FFT Function Sets the center point of magnification of the vertical computation or queries the current setting. axis of the FFT computation or queries the current :ANALysis:FFT<x>:MEASure:PEAK: Syntax setting.
Page 82 5.3 ANALysis Group :ANALysis:FFT<x>:VERTical? :ANALysis:FFT<x>:WINDow Function Queries all settings related the vertical axis of the Function Sets the window function of the FFT computation or FFT computation. queries the current setting. :ANALysis:FFT<x>:VERTical? :ANALysis:FFT<x>:WINDow {FLATtop| Syntax Syntax HANNing|RECTangle} <x> = 1 or 2 :ANALYSIS:FFT1:VERTICAL? ->...
Page 83 5.3 ANALysis Group :ANALysis:WPARameter<x>:HISTogram? :ANALysis:WPARameter<x>:BIT<x>? Function Queries all settings related to each logic bit of logic Function Queries all settings related to the histogram display waveform parameter measurement. of the waveform parameter measurement. : ANALysis:WPARameter<x>:BIT<x>? :ANALysis:WPARameter<x>:HISTogram? Syntax Syntax <x> of WPARameter<x> = 1 or 2 <x>...
Page 84 5.3 ANALysis Group :ANALysis:WPARameter<x>:HISTogram: :ANALysis:WPARameter<x>:HISTogram: MEASure:CURSor:C<x>:POSition MEASure:CURSor:DC? Function Sets the cursor position on the trend of the waveform Function Queries all settings related to the measurement parameter measurement or queries the current between cursors on the histogram of the waveform setting.
Page 85 5.3 ANALysis Group :ANALysis:WPARameter<x>:HISTogram: :ANALysis:WPARameter<x>:HISTogram: MEASure:MODE MEASure:PARameter:<Parameter>:STATe Function Sets the automated measurement mode of the Function Turns ON/OFF the histogram parameter of the histogram display of the waveform parameter waveform parameter measurement or queries the measurement or queries the current setting. current setting.
Page 86 5.3 ANALysis Group :ANALysis:WPARameter<x>:LIST:MODE :ANALysis:WPARameter<x>:TRACe<x>? Function Sets the list display mode of the waveform parameter Function Queries all settings related to the trace of the measurement or queries the current setting. waveform parameter measurement. :ANALysis:WPARameter<x>:LIST: :ANALysis:WPARameter<x>:TRACe<x>? Syntax Syntax MODE {STATistic|TRENd} <x>...
Page 87 5.3 ANALysis Group :ANALysis:WPARameter<x>:TRENd: :ANALysis:WPARameter<x>:TRENd: ASCale[:EXECute] MEASure:CURSor:ALL Function Executes the auto scaling of the trend display of the Function Turns ON/OFF all cursors of the trend of the waveform parameter measurement. waveform parameter measurement. :ANALysis:WPARameter<x>:TRENd: :ANALysis:WPARameter<x>:TRENd:MEASure: Syntax Syntax ASCale[:EXECute] CURSor:ALL {<Boolean>} <x>...
Page 88 5.3 ANALysis Group :ANALysis:WPARameter<x>:TRENd: :ANALysis:WPARameter<x>:TRENd:MEASure: MEASure:CURSor:C<x>:STATe CURSor:DC:VALue? Function Turns ON/OFF the cursor of the trend of the Function Sets the measured value between cursors on the waveform parameter measurement or queries the trend of the waveform parameter measurement or current setting. queries the current setting.
Page 89 5.3 ANALysis Group :ANALysis:WPARameter<x>:TRENd: :ANALysis:XY<x>:GATE:LEVel<x> VERTical Function Sets the level of the gate of the XY display or queries Function Sets the vertical range of the trend of the waveform the current setting. :ANALysis:XY<x>:GATE:LEVel<x> {<NRf>,<V parameter measurement or queries the current Syntax oltage>,<Current>} setting.
Page 90 5.3 ANALysis Group :ANALysis:XY<x>:MEASure:CURSor:X<x>? :ANALysis:XY<x>:MEASure:CURSor:Y<x>? Function Queries all settings related to the ΔV cursor of the XY Function Queries all settings related to the ΔT cursor of the XY display. display. :ANALysis:XY<x>:MEASure:CURSor:X<x>? :ANALysis:XY<x>:MEASure:CURSor:Y<x>? Syntax Syntax <x> of XY<x> = 1 or 2 <x>...
Page 91 5.3 ANALysis Group :ANALysis:XY<x>:MEASure:XYINteg:LOOP :ANALysis:XY<x>:XTRace Function Sets the integration mode of the XY display or queries Function Sets the X-axis trace of the XY display or queries the the current setting. current setting. :ANALysis:XY<x>:MEASure:XYINteg:LOOP :ANALysis:XY<x>:YTRace {<NRf>} Syntax Syntax {CLOSe|OPEN} :ANALysis:XY<x>:YTRace? :ANALysis:XY<x>:MEASure:XYINteg:LOOP? <x>...
Page 92: Asetup Group
ASETup Group :ASETup:EXECute Function Execute auto setup. :ASETup:EXECute Syntax :ASETUP:EXECUTE Example :ASETup:UNDO Function Cancels auto setup that has been executed. :ASETup:UNDO Syntax :ASETUP:UNDO Example 5-58 IM DLM6054-17EN...
Page 93: Calibrate Group
CALibrate Group :CALibrate? Function Queries all settings related to the calibration. :CALibrate? Syntax :CALIBRATE? -> :CALIBRATE:MODE AUTO Example :CALibrate:EXECute Function Executes calibration. :CALibrate:EXECute Syntax :CALIBRATE:EXECUTE Example :CALibrate:MODE Function Turns ON/OFF the auto calibration or queries the current setting. :CALibrate:MODE {AUTO|OFF} Syntax :CALibrate:MODE? :CALIBRATE:MODE AUTO...
Page 94: Channel Group
CHANnel Group :CHANnel<x>? :CHANnel<x>:INVert Function Queries all settings related to the channel. Function Turns ON/OFF the inverted display of the channel or :CHANnel<x>? Syntax queries the current setting. :CHANneL<x>:INVert {<Boolean>} <x> = 1 to 4 Syntax :CHANneL<x>:INVert? :CHANnel<x>:BWIDth <x> = 1 to 4 :CHANNEL1:INVERT ON Function Sets the input filter of the channel or queries the...
Page 95 5.6 CHANnel Group :CHANnel<x>:LSCale:BVALue :CHANnel<x>:PROBe? Function Sets or queries an offset B value. Function Queries all settings related to the probe attenuation :CHANnel<x>:LSCale:BVALue {<NRf>} Syntax of the channel. :CHANnel<x>:LSCale:BVALue? :CHANneL<x>:PROBe? Syntax <x> = 1 to 4 <x> = 1 to 4 :CHANNEL1:PROBE? ->...
Page 96: Clear Group
CLEar Group :CLEar Function Clears traces. :CLEar Syntax :CLEAR Example 5-62 IM DLM6054-17EN...
Page 97: Communicate Group
COMMunicate Group The commands in this group deal with communications. There are no front panel keys that correspond to the commands in this group. :COMMunicate? :COMMunicate:OVERlap Function Queries all settings related to communications. Function Sets the commands to operate as overlap commands :COMMunicate? Syntax or queries the current setting.
Page 98 5.8 COMMunicate Group :COMMunicate:STATus? Function Queries line-specific status. :COMMunicate:STATus? Syntax :COMMUNICATE:STATUS? -> :COMMUNICATE: Example STATUS 0 Description The meaning of each status bit is as follows: GP-IB Unrecoverable transmission error Always 0 Always 0 3 or greater Always 0 For USB and Ethernet communications, 0 is always returned.
Page 99: Cursor Group
CURSor Group :CURSor? :CURSor:HORizontal:BASic? Function Queries all settings related to the cursor Function Queries all settings related to basic items of the ΔV measurement. cursors. :CURSor? :CURSor:HORizontal:BASic? Syntax Syntax :CURSor:DISPlay :CURSor:HORizontal[:BASic]:ALL Function Turns ON/OFF the cursor or queries the current Function Turns ON/OFF all basic items of the ΔV cursors.
Page 100 5.9 CURSor Group :CURSor:HORizontal[:BASic]:V<x>? :CURSor:HORizontal:CALCulation? Function Queries all settings related to the ΔV cursor. Function Queries all settings related to calculation items of the :CURSor:HORizontal[:BASic]:V<x>? Syntax ΔV cursors. :CURSor:HORizontal:CALCulation? <x> = 1 or 2 Syntax :CURSor:HORizontal:CALCulation:ALL :CURSor:HORizontal[:BASic]:V<x>:JUMP Function Turns ON/OFF all calculation items of the ΔV cursors. Function Jumps the ΔV cursor to the center position of the :CURSor:HORizontal:CALCulation:...
Page 101 5.9 CURSor Group :CURSor:HORizontal:TRACe :CURSor:MARKer:CALCulation:VALue<x>? Function Sets the source trace of the ΔV cursor or queries the Function Queries the measured value of the calculation item of current setting. the marker cursors. :CURSor:HORizontal:TRACe {<NRf>} :CURSor:MARKer:CALCulation:VALue<x>? Syntax Syntax :CURSor:HORizontal:TRACe? <x> = 1 to 4 :CURSOR:MARKER:CALCULATION:VALUE1? <NRf>...
Page 102 5.9 CURSor Group :CURSor:MARKer:CM<x>:DV<x>:STATe :CURSor:MARKer:CM<x>:T:VALue? Function Turns ON/OFF the ∆V measurement of the maker Function Queries the time value at the marker cursor position. :CURSor:MARKer:CM<x>:T:VALue? cursor or queries the current setting. Syntax :CURSor:MARKer:CM<x>:DV<x>:STATe Syntax <x> = 1 to 4 {<Boolean>} :CURSOR:MARKER:CM1:T:VALUE? ->...
Page 103 5.9 CURSor Group :CURSor:SERial:SCURsor<x>? :CURSor:SERial:SCURsor<x>:FORMat Function Queries all settings related to the serial cursor. Function Sets the display format of the serial cursor or queries :CURSor:SERial:SCURsor<x>? Syntax the current setting. :CURSor:SERial:SCURsor<x>:FORMat <x> = 1 or 2 Syntax {BINary|HEXa} :CURSor:SERial:SCURsor<x>:ACTive :CURSor:SERial:SCURsor<x>:FORMat? Function Sets the active level of the serial cursor or queries the <x>...
Page 104 5.9 CURSor Group :CURSor:SERial:SCURsor<x>:POSition :CURSor:VERTical? Function Sets the serial cursor position or queries the current Function Queries all settings related to the ΔT cursors. :CURSor:VERTical? setting. Syntax :CURSor:SERial:SCURsor<x>: Syntax :CURSor:VERTical:BASic? POSition {<NRf>} :CURSor:SERial:SCURsor<x>:POSition? Function Queries all settings related to basic items of the ΔT <x>...
Page 105 5.9 CURSor Group :CURSor:VERTical[:BASic]:PERDt:STATe :CURSor:VERTical[:BASic]:T<x>:VALue? Function Turns ON/OFF the 1/∆T measurement of the ΔT Function Queries the time value at the ΔT cursor. :CURSor:VERTical[:BASic]:T<x>:VALue? cursors or queries the current setting. Syntax :CURSor:VERTical[:BASic]:PERDt:STATe Syntax <x> = 1 or 2 {<Boolean>} :CURSOR:VERTICAL:BASIC:T1:VALUE? Example :CURSor:VERTical[:BASic]:PERDt:STATe? ->...
Page 106 5.9 CURSor Group :CURSor:VT? :CURSor:VT[:BASic]:GROup<x>:VALue? Function Queries all settings related to the VT cursor. Function Queries the measured value of the logic group of the :CURSor:VT? Syntax VT cursor. :CURSor:VT[:BASic]:GROup<x>:VALue? Syntax :CURSor:VT:BASic? <x> = 1 to 5 :CURSOR:VT:BASIC:GROUP1:VALUE? Function Queries all settings related to basic items of the VT Example ->...
Page 107 5.9 CURSor Group :CURSor:VT[:BASic]:V<x>:VALue? Function Queries the voltage value at the VT cursor. :CURSor:VT[:BASic]:V<x>:VALue? Syntax <x> = 1 to 8 :CURSOR:VT:BASIC:V1:VALUE? -> :CURSOR: Example VT:BASIC:V1:VALUE 0.000E+00 :CURSor:VT:CALCulation? Function Queries all settings related to calculation items of the VT cursor. :CURSor:VT:CALCulation? Syntax :CURSor:VT:CALCulation:ALL Function...
Page 108 5.10 DISPlay Group :DISPlay? :DISPlay:ACCumulate:PERSistence:MODE Function Queries all settings related to the display. Function Sets the persistence mode or queries the current :DISPlay? Syntax setting. :DISPlay:ACCumulate:PERSistence:MODE Syntax :DISPlay:ACCumulate? {COUNt|TIME} :DISPlay:ACCumulate:PERSistence:MODE? Function Queries all settings related to the accumulated :DISPLAY:ACCUMULATE:PERSISTENCE: display of waveforms. Example :DISPlay:ACCumulate? MODE COUNT...
Page 109 5.10 DISPlay Group :DISPlay:BLIGht:LCD :DISPlay:GRATicule Function Turns ON/OFF the backlight or queries the current Function Sets the graticule (grid) or queries the current setting. setting. :DISPlay:BLIGht:LCD {<Boolean>} :DISPlay:GRATicule {CROSshair|FRAMe| Syntax Syntax :DISPlay:BLIGht:LCD? GRID|LINE} :DISPLAY:BLIGHT:LCD ON :DISPlay:GRATicule? Example :DISPLAY:BLIGHT:LCD? -> :DISPLAY: :DISPLAY:GRATICULE CROSSHAIR Example BLIGHT:LCD 1...
Page 110 5.10 DISPlay Group :DISPlay:MAPPing[:MODE] Function Sets the waveform mapping mode for the split screen or queries the current setting. :DISPlay:MAPPing[:MODE] {AUTO|MANual} Syntax :DISPlay:MAPPing[:MODE]? :DISPLAY:MAPPING:MODE AUTO Example :DISPLAY:MAPPING:MODE? -> :DISPLAY: MAPPING:MODE AUTO :DISPlay:MAPPing:TRACe<x> Function Sets the mapping of the waveform to the split screen or queries the current setting.
Page 111: File Group
5.11 FILE Group :FILE? :FILE[:DIRectory]:FREE? Function Queries all settings related to the specified storage Function Queries the free disk space in bytes on the specified medium or internal memory. storage medium. :FILE? :FILE[:DIRectory]:FREE? Syntax Syntax :FILE:DIRECTORY:FREE?-> :FILE: Example :FILE:DIRectory? DIRECTORY:FREE 65536 Function Queries all settings related to the specified storage Description •...
Page 112 5.11 FILE Group :FILE:INTernal:STORe:SETup:COMMent<x> :FILE:LOAD:{BINary|MASK|SETup|SNAP| SYMBol|ZPOLygon|ZWAVe}:ABORt Function Sets the comment to the setup data to be saved to the internal memory or queries the current setting. Function Aborts the loading of specific data. :FILE:INTernal:STORe:SETup: :FILE:LOAD:{BINary|MASK|SETup|SNAP| Syntax Syntax COMMent<x> {<String>} SYMBol|ZPOLygon|ZWAVe}:ABORt :FILE:INTernal:STORe:SETup:COMMent<x>? Example (The following is an example for binary data.)
Page 113 5.11 FILE Group :FILE:SAVE:{AHIStogram|ASCii|BINary| :FILE:SAVE:ANAMing FFT|FLOat|SBUS|ZWAVe}? Function Sets the type of auto naming of file names of the Function Queries all settings related to the saving of specific saved data or queries the current setting. :FILE:SAVE:ANAMing {DATE|NUMBering|OFF} data. Syntax :FILE:SAVE:{AHIStogram|ASCii|BINary| :FILE:SAVE:ANAMing? Syntax FFT|FLOat|SBUS|ZWAVe}?
Page 114 5.11 FILE Group :FILE:SAVE:ASCii:RANGe Function Sets the ASCII data saving range or queries the current setting. :FILE:SAVE:ASCii:RANGe {MAIN|Z1|Z2} Syntax :FILE:SAVE:ASCii:RANGe? :FILE:SAVE:ASCII:RANGE MAIN Example :FILE:SAVE:ASCII:RANGE? -> :FILE:SAVE:ASCII:RANGE MAIN :FILE:SAVE:{ASCii|BINary|FLOat}:TRACe Function Sets the trace of specific data to be saved or queries the current setting.
Page 115 5.12 GONogo Group :GONogo? :GONogo:ACTion:MAIL:MODE Function Queries all settings related to GO/NO-GO determination. Function Sets whether to send mail when the determination is :GONogo? Syntax NO-GO or queries the current setting. :GONogo:ACTion:MAIL:MODE {<Boolean>} Syntax :GONogo:ABORt :GONogo:ACTion:MAIL:MODE? :GONOGO:ACTION:MAIL:MODE ON Function Aborts the GO/NO-GO determination. Example :GONogo:ABORt :GONOGO:ACTION:MAIL:MODE? ->...
Page 116 5.12 GONogo Group :GONogo:MODE :GONogo:TELecomtest:SELect<x>: EYEPattern? Function Sets the GO/NO-GO determination type or queries the current setting. Function Queries all settings related to the eye pattern GONogo:MODE {OFF|TELecomtest| Syntax determination of the condition. ZPARameter} :GONogo:TELecomtest:SELect<x>: Syntax :GONogo:MODE? EYEPattern? GONOGO:MODE OFF Example <x>...
Page 117 5.12 GONogo Group :GONogo:TELecomtest:SELect<x>:MASK: :GONogo:TELecomtest:SELect<x>:MASK: ELEMent<x>:PSPCount (Sample Point ELEMent<x>:SPCount (Sample Point Count %) Count) Function Sets the upper and lower limits of the error rate for Function Sets the upper and lower limits of the number of the number of sampled data points of the element or sampled data points for the element that results in queries the current setting.
Page 118 5.12 GONogo Group :GONogo:ZPARameter:SELect<x>:MODE :GONogo:ZPARameter:SELect<x>: PARameter:FFT<x>:CALCulation<x> Function Sets the mode of the condition or queries the current setting. Function Sets the upper and lower limits of the calculation :GONogo:ZPARameter:SELect<x>: Syntax item of the FFT determination or queries the current MODE {PARameter|POLYgon|RECTangle|WAVE} setting.
Page 119 5.12 GONogo Group :GONogo:ZPARameter:SELect<x>: :GONogo:ZPARameter:SELect<x>: PARameter:FFT<x>:PEAK:DV PARameter:FFT<x>:PEAK:V<x> Function Sets the upper and lower limits between the peak Function Sets the upper and lower limits of the peak voltage of voltages of the FFT determination or queries the the FFT determination or queries the current setting. :GONogo:ZPARameter:SELect<x>:PARameter: current setting.
Page 120 5.12 GONogo Group :GONogo:ZPARameter:SELect<x>: :GONogo:ZPARameter:SELect<x>: PARameter:MEASure:CALCulation<x> PARameter:MEASure:BIT<x>:AREA<x>:TYPE? Function Queries all settings related to logic waveform Function Sets the upper and lower limits of the calculation item parameters of measure determination. of the measure determination or queries the current :GONogo:ZPARameter:SELect<x>: Syntax setting.
Page 121 5.12 GONogo Group :GONogo:ZPARameter:SELect<x>: :GONogo:ZPARameter:SELect<x>: PARameter:MEASure:TRACe<x>:AREA<x>? PARameter:MEASure:TRACe<x>:AREA<x>: TYPE:<Parameter> Function Queries all settings related to the area of the measure determination. Function Sets the upper and lower limits of the waveform :GONogo:ZPARameter:SELect<x>:PARameter: Syntax parameter of the measure determination or queries MEASure:TRACe<x>:AREA<x>? the current setting.
Page 122 5.12 GONogo Group :GONogo:ZPARameter:SELect<x>: :GONogo:ZPARameter:SELect<x>: PARameter:XY<x>:XYINteg RECTangle:VERTical Function Sets the upper and lower limits integral value of the Function Sets the vertical position of the rectangle used in the XY determination or queries the current setting. rectangle determination or queries the current setting. :GONogo:ZPARameter:SELect<x>:PARameter: :GONogo:ZPARameter:SELect<x>:RECTangle: Syntax...
Page 123 5.12 GONogo Group :GONogo:ZPARameter:SELect<x>:WAVE: :GONogo:ZPARameter:SELect<x>:WINDow EDIT<x>:PART Function Sets the source window of the zone determination or Function Editing the portion of the zone of the wave queries the current setting. :GONogo:ZPARameter:SELect<x>:WINDow determination. Syntax :GONogo:ZPARameter:SELect<x>:WAVE: {MAIN|XY1|XY2|Z1|Z2} Syntax EDIT<x>:PART {<NRf>,<NRf>,<NRf>,<NRf>} :GONogo:ZPARameter:SELect<x>:WINDow? <x> of SELect<x> = 1 to 4 <x>...
Page 124: Hcopy Group
5.13 HCOPy Group :HCOPy? (Hard COPY) :HCOPy:EXTPrinter:TONE Function Queries all settings related to the output of screen Function Sets the half tone of the external printer output or data. queries the current setting. :HCOPy? :HCOPy:EXTPrinter:TONE {<Boolean>} Syntax Syntax :HCOPy:EXTPrinter:TONE? :HCOPy:ABORt :HCOPY:EXTPRINTER:TONE ON Example :HCOPY:EXTPRINTER:TONE? ->...
Page 125 5.13 HCOPy Group :HCOPy:FILE:SAVE:CDIRectory (Change :HCOPy:NETPrint:TONE Directory) Function Sets the half tone for the network printer or queries Function Sets the save destination directory name or queries the current setting. :HCOPy:NETPrint:TONE {<Boolean>} the current setting. Syntax :HCOPy:FILE:SAVE:CDIRectory {<String>} :HCOPy:NETPrint:TONE? Syntax :HCOPy:FILE:SAVE:CDIRectory? :HCOPY:NETPRINT:TONE ON Example...
Page 126 5.14 HISTory Group :HISTory? :HISTory[:CURRent]:RECord Function Queries all settings related to the history function. Function Sets the target record of the history waveform or :HISTory? Syntax queries the current setting. :HISTory[:CURRent]:RECord Syntax :HISTory:CURRent? {<NRf>|MINimum} :HISTory[:CURRent]:RECord? Function Queries all settings related to the history function of the current waveform (CH1 to 4, M1 to 8).
Page 127: History Group
5.14 HISTory Group :HISTory[:CURRent]:REPLay:STARt :HISTory[:CURRent][:SEARch]: SELect<x>:CONDition Function Starts the replay of the history waveform in the specified direction. Function Sets determination criteria of the history search :HISTory[:CURRent]:REPLay: Syntax condition or queries the current setting. STARt {MAXimum|MINimum} :HISTory[:CURRent][:SEARch]:SELect<x>: Syntax :HISTORY:CURRENT:REPLAY:START MAXIMUM CONDition {DONTcare|IN|OUT} Example :HISTory[:CURRent][:SEARch]:SELect<x>:...
Page 128 5.14 HISTory Group :HISTory[:CURRent][:SEARch]:S :HISTory[:CURRent][:SEARch]: ELect<x>:PARameter:FFT<x>? SELect<x>:PARameter:FFT<x>:PEAK: DFREquency Function Queries all settings related to the FFT search. :HISTory[:CURRent][:SEARch]:SELect<x>: Syntax Function Sets the upper and lower limits between the peak PARameter:FFT<x>? frequencies of the FFT search or queries the current <x> of SELect<x> = 1 to 4 setting.
Page 129 5.14 HISTory Group :HISTory[:CURRent][:SEARch]: :HISTory[:CURRent][:SEARch]:SELect<x>: SELect<x>:PARameter:FFT<x>:PEAK: PARameter:MEASure:BIT<x>? FREquency<x> Function Queries all settings related to each logic bit of Function Sets the upper and lower limits of the peak frequency measure search. :HISTory[:CURRent][:SEARch]:SELect<x>: of the FFT search or queries the current setting. Syntax :HISTory[:CURRent][:SEARch]:SELect<x>: PARameter:MEASure:BIT<x>?
Page 130 5.14 HISTory Group :HISTory[:CURRent][:SEARch]: :HISTory[:CURRent][:SEARch]:SELect<x>: SELect<x>:PARameter:MEASure: PARameter:MEASure:BIT<x>:AREA<x>: TRACe<x>? TYPE:<parameter> Function Sets the upper and lower limits of the logic waveform Function Queries all settings related to the trace of the of measure search or queries the current setting. measure search. :HISTory[:CURRent][:SEARch]:SELect<x>: :HISTory[:CURRent][:SEARch]:SELect<x>: Syntax...
Page 131 5.14 HISTory Group :HISTory[:CURRent][:SEARch]: :HISTory[:CURRent][:SEARch]: SELect<x>:PARameter:MEASure: SELect<x>:PARameter:XY<x>:XYINteg TRACe<x>:AREA<x>:TYPE:<Parameter> Function Sets the upper and lower limits integral value of the Function Sets the upper and lower limits of the waveform XY search or queries the current setting. :HISTory[:CURRent][:SEARch]:SELect<x>: parameter of the measure search or queries the Syntax PARameter:XY<x>:XYINteg {<NRf>,<NRf>} current setting.
Page 132 5.14 HISTory Group :HISTory[:CURRent][:SEARch]: :HISTory[:CURRent][:SEARch]: SELect<x>:RECTangle:VERTical SELect<x>:WAVE:EDIT<x>:PART Function Sets the vertical position of the rectangle used in the Function Sets the editing of the portion of the zone of the wave rectangle search or queries the current setting. search. :HISTory[:CURRent][:SEARch]:SELect<x>: :HISTory[:CURRent][:SEARch]:SELect<x>: Syntax Syntax...
Page 133 5.14 HISTory Group :HISTory[:CURRent][:SEARch]: :HISTory:REFerence<x>:RECord SELect<x>:WINDow Function Sets the source record of the history waveform of the Function Sets the source window of the history search or reference or queries the current setting. :HISTory:REFerence<x>:RECord {<NRf>| queries the current setting. Syntax :HISTory[:CURRent][:SEARch]:SELect<x>: MINimum} Syntax...
Page 134 5.14 HISTory Group :HISTory:REFerence<x>:REPLay:STARt Function Starts the replay of the history waveform of the reference. :HISTory:REFerence<x>:REPLay:STARt Syntax {MAXimum|MINimum} <x> = 1 to 4 :HISTORY:REFERENCE1:REPLAY:START Example MAXIMUM :HISTory:REFerence<x>:REPLay:STOP Function Stops the replay of the history waveform of the reference. :HISTory:REFerence<x>:REPLay:STOP Syntax <x>...
Page 135: Image Group
5.15 IMAGe Group :IMAGe? Function Queries all settings related to the output of screen image data. :IMAGe? Syntax :IMAGe:FORMat Function Sets the output format of the screen image data or queries the current setting. :IMAGe:FORMat {BMP|JPEG|PNG} Syntax :IMAGe:FORMat? :IMAGE:FORMAT BMP Example :IMAGE:FORMAT? ->...
Page 136: Initialize Group
5.16 INITialize Group :INITialize:EXECute Function Execute the initialization. :INITialize:EXECute Syntax :INITIALIZE:EXECUTE Example :INITialize:UNDO Function Cancels the initialization that was executed. :INITialize:UNDO Syntax :INITIALIZE:UNDO Example 5-102 IM DLM6054-17EN...
Page 137 5.17 LOGic Group :LOGic? :LOGic:GROup<x>:BUNDle:FORMat Function Queries all settings related to the logic. Function Sets the display format (bus display) of the bundled :LOGic? Syntax value of the logic group or queries the current setting. :LOGic:GROup<x>:BUNDle: Syntax :LOGic:AWINdow? FORMat {BINary|HEXa|SYMBol} :LOGic:GROup<x>:BUNDle:FORMat? Function Queries all settings related to analog waveform...
Page 138 5.17 LOGic Group :LOGic:GROup<x>:MAPPing :LOGic:LABel:BNAMe:{A<x>|B<x>|C<x>| D<x>} Function Sets the bit mapping of the logic group or queries the current setting. Function Sets the bit name of the logic signal or queries the :LOGic:GROup<x>:MAPPing {<String>} Syntax current setting. :LOGic:GROup<x>:MAPPing? :LOGic:LABel:BNAMe:{A<x>|B<x>|C<x>| Syntax D<x>} {<String>} <x>...
Page 139 5.17 LOGic Group :LOGic:SCLock? :LOGic:THReshold:{PODA|PODB|PODC| PODD}:TYPE Function Queries all settings related to the state clock of the logic signal. Function Sets the type of threshold level of the specified pod :LOGic:SCLock? Syntax (port) or queries the current setting. :LOGic:THReshold:{PODA|PODB|PODC|PODD}: Syntax :LOGic:SCLock:POLarity TYPE {CMOS1|CMOS2|CMOS3|CMOS5|ECL|USER} :LOGic:THReshold:{PODA|PODB|PODC|PODD}:...
Page 140: Math Group
5.18 MATH Group :MATH<x>? :MATH<x>:DA:RESCaling:BVALue Function Queries all settings related to the computation. Function Sets rescaling offset B of the D/A conversion or :MATH<x>? Syntax queries the current setting. <x> = 1 to 4 :MATH<x>:DA:RESCaling:BVALue {<NRf>} Syntax :MATH<x>:DA:RESCaling:BVALue? :MATH<x>:DA? <x> = 1 to 4 Function Queries all settings related to the D/A conversion.
Page 141 5.18 MATH Group :MATH<x>:FILTer:DELay:TIME :MATH<x>:FILTer:IIR:LOWPass:COFF Function Sets the delay value of the delay computation or Function Sets the cutoff frequency of the IIR low pass filter queries the current setting. computation or queries the current setting. :MATH<x>:FILTer:DELay:TIME {<Time>} :MATH<x>:FILTer:IIR:LOWPass:C Syntax Syntax :MATH<x>:FILTer:DELay:TIME? OFF {<Frequency>}...
Page 142 5.18 MATH Group :MATH<x>:IPOint:POSition :MATH<x>:OPERation Function Sets the computation reference point or queries the Function Sets the operator or queries the current setting. :MATH<x>:OPERation {DA,GROup<y>|ECOunt, current setting. Syntax :MATH<x>:IPOint:POSition {<NRf>} <NRf>|FILTer,<NRf>|INTegral,<NRf>| Syntax :MATH<x>:IPOint:POSition? MINus,<NRf>,<NRf>|MULTiple,<NRf>,<NRf>| PLUS,<NRf>,<NRf>|RCOunt,<NRf>,NRf>| <x> = 1 to 4 USERdefine} <NRf>...
Page 143 5.18 MATH Group :MATH<x>:SCALe:SENSitivity :MATH<x>:UNIT:MODE Function Sets the vertical sensitivity of the computed waveform Function Sets the automatic/manual addition of the or queries the current setting. computation unit or queries the current setting. :MATH<x>:SCALe:SENSitivity {<NRf>| :MATH<x>:UNIT:MODE {AUTO|USERdefine} Syntax Syntax <Voltage>|<Current>} :MATH<x>:UNIT:MODE? :MATH<x>:SCALe:SENSitivity? <x>...
Page 144 5.18 MATH Group :MATH<x>:USERdefine:CONStant<x> :MATH<x>:USERdefine:FILTer<y>: CUToff<z> Function Sets a user-defined math constant or queries the current setting. Function Sets or queries the cutoff frequency for user-defined :MATH<x>:USERdefine:CONStant<x> {<NRf>} Syntax computation. :MATH<x>:USERdefine:CONStant<x>? :MATH<x>:USERdefine:FILTer<y>:CUToff<z> Syntax {<NRf>} MATH<x>: <x> = 1 to 4 :MATH<x>:USERdefine:FILTer<y>: CONStant<x>: <x>...
Page 145 5.19 MEASure Group :MEASure? :MEASure:BIT<x>:AREA<x>:<parameter>: {MAXimum|MEAN|MINimum|SDEViation}? Function Queries all settings related to the automated measurement of waveform parameters. Function Queries each statistical value of logic waveform :MEASure? Syntax parameters. :MEASure:BIT<x>:AREA<x>:<parameter>: Syntax :MEASure:BIT<x>? MAXimum? Function Queries all settings related to each logic bit. <x>...
Page 146 5.19 MEASure Group :MEASure:BIT<x>:AREA<x>:<parameter>: :MEASure:BIT<x>:AREA<x>:DELay:MEASure: VALue? POLarity Function Queries automatically measured values of logic Function Sets the polarity of the source waveform of delay waveform parameters. measurement between channels or queries the :MEASure:BIT<x>:AREA<x>:<parameter>: Syntax current setting. VALue? {<NRf>} :MEASure:BIT<x>:AREA<x>:DELay:MEASure: Syntax POLarity {FALL|RISE} <x>...
Page 147 5.19 MEASure Group :MEASure:CALCulation? :MEASure:BIT<x>:AREA<x>:DELay: REFerence:POLarity Function Queries all settings related to calculation items. :MEASure:CALCulation? Function Sets the polarity of the reference waveform of delay Syntax measurement between channels or queries the :MEASure:CALCulation:ALL current setting. :MEASure:BIT<x>:AREA<x>:DELay: Syntax Function Turns ON/OFF all calculation items. REFerence:POLarity {FALL|RISE} :MEASure:CALCulation:ALL {<Boolean>} Syntax...
Page 148 5.19 MEASure Group :MEASure:CYCLe:EXECute :MEASure:CALCulation:VALue<x>? Function Executes the cycle statistical processing. This is an Function Queries the automated measured value of the overlap command. calculation item. :MEASure:CYCLe:EXECute Syntax :MEASure:CALCulation:VALue<x>? {<NRf>} Syntax :MEASURE:CYCLE:EXECUTE Example <x> = 1 to 4 Description Continues the operation without clearing the previous <NRf>...
Page 149 5.19 MEASure Group :MEASure:THReshold? :MEASure:THReshold:TRACe<x>: LHYSteresis:HYSTeresis Function Queries all settings related to the threshold levels of the automated measurement of waveform Function Sets the hysteresis of the threshold level or queries parameters. the current setting. :MEASure:THReshold? :MEASure:THReshold:TRACe<x>: Syntax Syntax LHYSteresis:HYSTeresis {<NRf>} EDescription This command is valid when the :MEASure:THReshold:TRACe<x>:...
Page 150 5.19 MEASure Group :MEASure:THReshold:TRACe<x>:ULOWer? :MEASure:TRACe<x>:AREA<x>: <Parameter>? Function Queries all settings related to the upper and lower limits of the threshold level. Function Queries all settings related to the waveform :MEASure:THReshold:TRACe<x>:ULOWer? Syntax parameter. :MEASure:TRACe<x>:AREA<x>:<Parameter>? <x> = 1 to 8 Syntax Description This command is valid when the <Parameter> of <x>...
Page 151 5.19 MEASure Group :MEASure:TRACe<x>:AREA<x>: :MEASure:TRACe<x>:AREA<x>:DELay: <Parameter>:STATe MEASure? Function Turns ON/OFF the waveform parameter or queries Function Queries all settings related to the measurement the current setting. conditions of the source waveform of the delay :MEASure:TRACe<x>:AREA<x>:<Parameter>: Syntax measurement between channels. STATe {<Boolean>} :MEASure:TRACe<x>:AREA<x>:DELay: Syntax :MEASure:TRACe<x>:AREA<x>:<Parameter>:...
Page 152 5.19 MEASure Group :MEASure:TRACe<x>:AREA<x>:DELay: :MEASure:TRACe<x>:AREA<x>:DELay: REFerence:COUNt SOURce Function Sets the edge detection count of the reference Function Sets the reference of the delay measurement waveform of the delay measurement between between channels or queries the current setting. :MEASure:TRACe<x>:AREA<x>:DELay:SOURce channels or queries the current setting. Syntax :MEASure:TRACe<x>:AREA<x>:DELay: {TRACe|TRIGger}...
Page 153 5.19 MEASure Group :MEASure:TRACe<x>:DPRoximal:PERCent :MEASure:TRANge<x> (Time Range) Function Sets the distal and proximal values as a percentage Function Sets the measurement range or queries the current or queries the current setting. setting. :MEASure:TRACe<x>:DPRoximal: :MEASure:TRANge<x> {<NRf>,<NRf>} Syntax Syntax PERCent {<NRf>,<NRf>} :MEASure:TRANge<x>? :MEASure:TRACe<x>:DPRoximal: <x>...
Page 154 5.20 REFerence Group :REFerence<x>? :REFerence<x>:SELect Function Queries all settings related to the reference. Function Sets the waveform (computation or reference) to the :REFerence<x>? Syntax computation channel or queries the current setting. :REFerence<x>:SELect {MATH|REFerence} <x> = 1 to 4 Syntax :REFerence<x>:SELect? :REFerence<x>:LABel? <x>...
Page 155 5.21 SEARch Group :SEARch<x>? :SEARch<x>:CLOCk? Function Queries all settings related to the search function. Function Queries all settings related to the clock channel. :SEARch<x>? :SEARch<x>:CLOCk? Syntax Syntax <x> = 1 or 2 <x> = 1 or 2 :SEARch<x>:ABORt :SEARch<x>:CLOCk:POLarity Function Aborts the search.
Page 156 5.21 SEARch Group :SEARch<x>:EXECute :SEARch<x>:POLarity Function Executes the search. This is an overlap command. Function Sets the search polarity or queries the current setting. :SEARch<x>:EXECute :SEARch<x>:POLarity {ENTer|EXIT|FALL| Syntax Syntax FALSe|NEGative|POSitive|RISE| <x> = 1 or 2 :SEARCH1:EXECUTE TRUE} Example :SEARch<x>:POLarity? :SEARch<x>:HOLDoff <x>...
Page 157: Search Group
5.21 SEARch Group :SEARch<x>:SLOGic:CLOCk:POLarity :SEARch<x>:SLOGic:SOURce Function Sets the polarity of the clock of the logic search or Function Sets the logic search source or queries the current queries the current setting. setting. :SEARch<x>:SLOGic:CLOCk:POLarity :SEARch<x>:SLOGic:SOURce {A<y>|B<y>| Syntax Syntax {FALL|RISE} C<y>|D<y>} :SEARch<x>:SLOGic:CLOCk:POLarity? :SEARch<x>:SLOGic:SOURce? <x>...
Page 158 5.21 SEARch Group :SEARch<x>:SLOGic:SPATtern:CLOCk: :SEARch<x>:SLOGic:SPATtern:LATCh: SOURce POLarity Function Sets the clock trace for the logic serial pattern search Function Sets the polarity of the latch trace of the logic serial or queries the current setting. pattern search or queries the current setting. :SEARch<x>:SLOGic:SPATtern:CLOCk: :SEARch<x>:SLOGic:SPATtern:LATCh: Syntax...
Page 159 5.21 SEARch Group :SEARch<x>:SLOGic:SPATtern[:SETup]: :SEARch<x>:SLOGic:SPATtern[:SETup]: BITRate DATA:TRACe Function Sets the bit rate for the logic serial pattern search or Function Sets the trace of the data for the logic serial pattern queries the current setting. search or queries the current setting. :SEARch<x>:SLOGic:SPATtern[:SETup]: :SEARch<x>:SLOGic:SPATtern[:SETup]: Syntax...
Page 160 5.21 SEARch Group :SEARch<x>:SLOGic:STATe:BIT? :SEARch<x>:SLOGic:STATe:GROup<x>:CLEar Function Queries all settings related to the bits of the logic Function Clears (Don't care) all truth conditions for each group state search. of the logic serial pattern search. :SEARch<x>:SLOGic:STATe:BIT? :SEARch<x>:SLOGic:STATe:GROup<x>:CLEar Syntax Syntax <x> = 1 or 2 <x>...
Page 161 5.21 SEARch Group :SEARch<x>:SLOGic:STATe:GROup<x>:HEXA :SEARch<x>:SLOGic:STATe:TYPE Function Sets the truth conditions for each group of the logic Function Sets the setting method of the logic state search or serial pattern search in hexadecimal notation. queries the current setting. :SEARch<x>:SLOGic:STATe:GROup<x>: :SEARch<x>:SLOGic:STATe: Syntax Syntax HEXA {<string>} TYPE {BIT|GROup}...
Page 162 5.21 SEARch Group :SEARch<x>:SPATtern:CLOCk:SOURce :SEARch<x>:SLOGic:WIDTh:TYPE Function Sets the logic pulse width search type or queries the Function Sets the clock trace of the serial pattern search or current setting. queries the current setting. :SEARch<x>:SLOGic:WIDTh: :SEARch<x>:SPATtern:CLOCk: Syntax Syntax SOURce {<NRf>} TYPE {PQUalify|PSTate|PULSe} :SEARch<x>:SPATtern:CLOCk:SOURce? :SEARch<x>:SLOGic:WIDTh:TYPE? <x>...
Page 163 5.21 SEARch Group :SEARch<x>:SPATtern:LATCh:TRACe :SEARch<x>:SPATtern[:SETup]:DATA: ACTive Function Sets the latch trace of the serial pattern search or queries the current setting. Function Sets the active level of the data trace of the serial :SEARch<x>:SPATtern:LATCh:TRACe {<NRf>| Syntax pattern search or queries the current setting. NONE} :SEARch<x>:SPATtern[:SETup]:DATA: Syntax...
Page 164 5.21 SEARch Group :SEARch<x>:SPOint :SEARch<x>:TRACe<x>:HYSTeresis Function Sets the search start position or queries the current Function Sets the hysteresis of the trace or queries the current setting. setting. :SEARch<x>:SPOint {<NRf>} :SEARch<x>:TRACe<x>:HYSTeresis {<NRf>} Syntax Syntax :SEARch<x>:SPOint? :SEARch<x>:TRACe<x>:HYSTeresis? <x> = 1 or 2 <x>...
Page 165 5.21 SEARch Group :SEARch<x>:WIDTh:TIME<x> Function Sets the pulse width of the pulse width search or queries the current setting. :SEARch<x>:WIDTh:TIME<x> {<Time>} Syntax :SEARch<x>:WIDTh:TIME<x>? <x> of SEARch<x> = 1 or 2 <x> of TIME<x> = 1 or 2 <Time> = 1 ns to 10 s in 500-ps steps :SEARCH1:WIDTH:TIME1 1S Example :SEARCH1:WIDTH:TIME1? ->...
Page 166: Snap Group
5.22 SNAP Group :SNAP Function Executes the snapshot. :SNAP Syntax :SNAP Example 5-132 IM DLM6054-17EN...
Page 167: Sstart Group
5.23 SSTart Group :SSTart? Function Starts the waveform acquisition with the trigger mode set to single. If the waveform acquisition stops within the specified time period, 0 is returned at that point. If not, 1 is returned. :SSTart? {<NRf>} Syntax <NRf>...
Page 168: Start Group
5.24 STARt Group :STARt Function Starts the waveform acquisition. :STARt Syntax :START Example Description Use STOP to stop the waveform acquisition. 5-134 IM DLM6054-17EN...
Page 169 5.25 STATus Group The commands in the STATus group are used to make settings and inquiries related to the communication status function. There are no front panel keys that correspond to the commands in this group. For a description of the status report, see chapter 6. :STATus? :STATus:QENable Function...
Page 170: Stop Group
5.26 STOP Group :STOP Function Stops the waveform acquisition. :STOP Syntax :STOP Example Description Use STARt to start the waveform acquisition. 5-136 IM DLM6054-17EN...
Page 171: System Group
5.27 SYSTem Group :SYSTem? :SYSTem:FORMat:SDELete[:EXECute] (Sure Delete) Function Queries all settings related to the system. :SYSTem? Syntax Function Clears and formats the internal memory. :SYSTem:FORMat:SDELete[:EXECute] Syntax :SYSTem:CLICk :SYSTEM:FORMAT:SDELETE:EXECUTE Example Function Turns ON/OFF the click sound or queries the current :SYSTem:LANGuage setting.
Page 172 5.27 SYSTem Group :SYSTem:USBKeyboard Function Sets the USB keyboard type or queries the current setting. :SYSTem:USBKeyboard {ENGLish|JAPanese} Syntax :SYSTem:USBKeyboard? :SYSTEM:USBKEYBOARD ENGLISH Example :SYSTEM:USBKEYBOARD? -> :SYSTEM: USBKEYBOARD ENGLISH 5-138 IM DLM6054-17EN...
Page 173: Telecomtest (Mask) Group
5.28 TELecomtest (Mask) Group <Parameter> = {DBERate|EHEight|EWIDth| :TELecomtest? FALL|JITTer<x>|PCROssing|PDUTycycle| Function Queries all settings related to the mask test. QFACtor|RISE|SDBase|SDTop|T1CRossing| :TELecomtest? Syntax T2CRossing|VBASe|VCRossing|VTOP} <x> = 1 or 2 :TELecomtest:CATegory Example (The following is an example for DBERate.) Function Sets the mask test type or queries the current setting. :TELECOMTEST:EYEPATTERN:DBERATE: :TELecomtest:CATegory {EYEPattern|MASK} Syntax...
Page 174 5.28 TELecomtest (Mask) Group :TELecomtest:EYEPattern:TLEVels: :TELecomtest:MASK:ELEMent<x>:ALL PERCent Function Turns ON/OFF all items of the element. :TELecomtest:MASK:ELEMent<x>:ALL Function Sets the threshold level of the eye pattern as a Syntax {<Boolean>} percentage or queries the current setting. :TELecomtest:EYEPattern:TLEVels: Syntax <x> = 1 to 4 PERCent {<NRf>,<NRf>} :TELECOMTEST:MASK:ELEMENT1:ALL ON Example...
Page 175 5.28 TELecomtest (Mask) Group :TELecomtest:MASK:ELEMent<x>: :TELecomtest:MASK:ELEMent<x>: PWCount:STATe SPCount:VALue? Function Turns ON/OFF the measurement of the error rate for Function Queries the number of sampled data points for the the acquisition count of the element or queries the element that resulted in error. :TELecomtest:MASK:ELEMent<x>:SPCount: current setting.
Page 176 5.28 TELecomtest (Mask) Group :TELecomtest:MMODe Function Turns ON/OFF the computed waveform or queries the current setting. :TELecomtest:MMODe {<Boolean>} Syntax :TELecomtest:MMODe? :TELECOMTEST:MMODE ON Example :TELECOMTEST:MMODE? -> :TELECOMTEST: MMODE 1 :TELecomtest:TRACe Function Sets the source trace of the mask test or queries the current setting.
Page 177 5.29 TIMebase Group :TIMebase? Function Queries all settings related to the time base. :TIMebase? Syntax :TIMEBASE? -> :TIMEBASE:TDIV 1.000E-06 Example :TIMebase:SRATe? (Sample RATE) Function Queries the sample rate or queries the current setting. :TIMebase:SRATe? Syntax :TIMEBASE:SRATE? -> :TIMEBASE: Example SRATE 125.0E+06 :TIMebase:TDIV Function Sets the T/div value or queries the current setting.
Page 178 5.30 TRIGger Group :TRIGger? :TRIGger:ACTion:MAIL:MODE Function Queries all settings related to the trigger. Function Sets whether to send mail when an action is activated :TRIGger? Syntax or queries the current setting. :TRIGger:ACTion:MAIL:MODE {<Boolean>} Syntax :TRIGger:ACTion? :TRIGger:ACTion:MAIL:MODE? :TRIGGER:ACTION:MAIL:MODE ON:TRIGGER: Function Queries all settings related to action-on-trigger. Example :TRIGger:ACTion? ACTION:MAIL:MODE? ->...
Page 179 5.30 TRIGger Group :TRIGger:BTRigger:COUNt :TRIGger:CLOCk:POLarity Function Sets or queries the number of times condition B must Function Sets the polarity of the clock channel or queries the be met for the A->B(n) trigger. current setting. :TRIGger:BTRigger:COUNt {<NRf>} :TRIGger:CLOCk:POLarity {ENTer|EXIT| Syntax Syntax :TRIGger:BTRigger:COUNt? FALL|RISE}...
Page 180 5.30 TRIGger Group :TRIGger:EDGE:COUPling :TRIGger:EDGE:PROBe Function Sets or queries the edge trigger source trigger Function Sets or queries the external trigger source probe coupling. setting for edge triggering. :TRIGger:EDGE:COUPling {AC|DC} :TRIGger:EDGE:PROBe {<NRf>} Syntax Syntax :TRIGger:EDGE:COUPling? :TRIGger:EDGE:PROBe? :TRIGGER:EDGE:COUPLING DC <NRf> = 1 or 10 Example :TRIGGER:EDGE:COUPLING?->:TRIGGER:EDGE: :TRIGGER:EDGE:PROBE 1...
Page 181 5.30 TRIGger Group :TRIGger:EDGE:WIDTh :TRIGger:EINTerval:EVENt<x>:CLOCk: POLarity Function Sets or queries the edge trigger source window width. :TRIGger:EDGE:WIDTh {<Voltage>} Syntax Function Sets the polarity of the clock channel of the event or :TRIGger:EDGE:WIDTh? queries the current setting. :TRIGger:EINTerval:EVENt<x>:CLOCk: <Voltage> = See the DL6000/DLM6000 User's Syntax POLarity {ENTer|EXIT|FALL|RISE} Manual for this information.
Page 182 5.30 TRIGger Group :TRIGger:EINTerval:EVENt<x>:CLOCk: :TRIGger:EINTerval:EVENt<x>:LOGic? SOURce Function Queries all settings related to the logic trigger of the Function Sets the source waveform of the clock channel of the event. :TRIGger:EINTerval:EVENt<x>:LOGic? event or queries the current setting. Syntax :TRIGger:EINTerval:EVENt<x>:CLOCk: Syntax <x> = 1 or 2 SOURce {<NRf>|NONE} :TRIGger:EINTerval:EVENt<x>:CLOCk: :TRIGger:EINTerval:EVENt<x>:LOGic:...
Page 183 5.30 TRIGger Group :TRIGger:EINTerval:EVENt<x>:LOGic: :TRIGger:EINTerval:EVENt<x>:LOGic: ESTate:POLarity SPATtern:BITRate Function Sets the polarity of the edge/state trigger of the logic Function Sets the bit rate for the logic serial pattern trigger or or queries the current setting. queries the current setting. :TRIGger:EINTerval:EVENt<x>:LOGic: :TRIGger:EINTerval:EVENt<x>:LOGic: Syntax Syntax...
Page 184 5.30 TRIGger Group :TRIGger:EINTerval:EVENt<x>:LOGic: :TRIGger:EINTerval:EVENt<x>:LOGic: SPATtern:CLOCk:POLarity SPATtern:CS Function Sets the polarity of the clock trace of the logic serial Function Enables/disables the chip select for the logic serial pattern trigger or queries the current setting. analysis pattern trigger or queries the current setting. :TRIGger:EINTerval:EVENt<x>:LOGic: :TRIGger:EINTerval:EVENt<x>:LOGic: Syntax...
Page 185 5.30 TRIGger Group :TRIGger:EINTerval:EVENt<x>:LOGic: :TRIGger:EINTerval:EVENt<x>:LOGic: SPATtern:DATA:SOURce SPATtern:LATCh:POLarity Function Sets the data rate for the logic serial pattern trigger or Function Sets the polarity of the latch trace of the logic serial queries the current setting. pattern trigger or queries the current setting. :TRIGger:EINTerval:EVENt<x>:LOGic: :TRIGger:EINTerval:EVENt<x>:LOGic: Syntax...
Page 186 5.30 TRIGger Group :TRIGger:EINTerval:EVENt<x>:LOGic: :TRIGger:EINTerval:EVENt<x>:LOGic: SPATtern:PATTern STATe:BIT:CLEar Function Sets the pattern of the logic serial pattern trigger in Function Clears the entire condition to be satisfied for the bit of binary notation, or queries the current setting. the logic state trigger (set to don’t care) or queries the :TRIGger:EINTerval:EVENt<x>:LOGic: Syntax current setting.
Page 187 5.30 TRIGger Group :TRIGger:EINTerval:EVENt<x>:LOGic: :TRIGger:EINTerval:EVENt<x>:LOGic: STATe:GROup<x>:CONDition STATe:GROup<x>:SYMBol Function Sets the determination condition for the group of the Function Sets the symbol item for each group of the logic state logic state trigger or queries the current setting. trigger. :TRIGger:EINTerval:EVENt<x>:LOGic: :TRIGger:EINTerval:EVENt<x>:LOGic: Syntax Syntax STATe:GROup<x>:CONDition {DONTcare|...
Page 188 5.30 TRIGger Group :TRIGger:EINTerval:EVENt<x>:SPATtern? :TRIGger:EINTerval:EVENt<x>:LOGic: (Serial Pattern) WIDTh:POLarity Function Sets the polarity of the logic pulse width trigger or Function Queries all settings related to the serial pattern trigger queries the current setting. of the event. :TRIGger:EINTerval:EVENt<x>:LOGic: :TRIGger:EINTerval:EVENt<x>:SPATtern? Syntax Syntax WIDTh:POLarity {FALSe|NEGative| <x>...
Page 189 5.30 TRIGger Group :TRIGger:EINTerval:EVENt<x>:SPATtern: :TRIGger:EINTerval:EVENt<x>:SPATtern: CLOCk:MODE Function Enables/Disables the clock of the serial pattern Function Enables/Disables the chip select of the serial pattern trigger or queries the current setting. trigger or queries the current setting. :TRIGger:EINTerval:EVENt<x>:SPATtern: :TRIGger:EINTerval:EVENt<x>:SPATtern: Syntax Syntax CLOCk:MODE {<Boolean>} CS {<Boolean>} :TRIGger:EINTerval:EVENt<x>:SPATtern: :TRIGger:EINTerval:EVENt<x>:SPATtern:...
Page 190 5.30 TRIGger Group :TRIGger:EINTerval:EVENt<x>:SPATtern: :TRIGger:EINTerval:EVENt<x>:SPATtern: HEXA LATCh:SOURce Function Sets the pattern of the serial pattern trigger in Function Sets the latch trace of the serial pattern trigger or hexadecimal notation. queries the current setting. :TRIGger:EINTerval:EVENt<x>:SPATtern: :TRIGger:EINTerval:EVENt<x>:SPATtern: Syntax Syntax HEXA {<String>} LATCh:SOURce {<NRf>|NONE} :TRIGger:EINTerval:EVENt<x>:SPATtern: <x>...
Page 191 5.30 TRIGger Group :TRIGger:EINTerval:EVENt<x>:STATe: :TRIGger:EINTerval:EVENt<x>:TYPE CHANnel<x> Function Sets the trigger type of the event or queries the Function Sets the condition to be satisfied of the channel or current setting. :TRIGger:EINTerval:EVENt<x>: queries the current setting. Syntax :TRIGger:EINTerval:EVENt<x>:STATe: TYPE {CANBus|EDGE|EQUalify|I2CBus| Syntax CHANnel<x>...
Page 192 5.30 TRIGger Group :TRIGger:EINTerval:EVENt<x>:WIDTh: :TRIGger:EINTerval:EVENt<x>:WIDTh: POLarity TIME<x> Function Sets the polarity of the pulse width trigger or queries Function Sets the pulse width of the pulse width trigger or the current setting. queries the current setting. :TRIGger:EINTerval:EVENt<x>:WIDTh: :TRIGger:EINTerval:EVENt<x>:WIDTh: Syntax Syntax POLarity {FALSe|IN|NEGative|OUT| TIME<x>...
Page 193 5.30 TRIGger Group :TRIGger:EINTerval:TRY:MODE :TRIGger:ENHanced:SPATtern:CLOCk:MODE Function Sets the trial mode or queries the current setting. Function Enables/Disables the clock of the serial pattern :TRIGger:EINTerval:TRY:MODE {<Boolean>} Syntax trigger or queries the current setting. :TRIGger:EINTerval:TRY:MODE? :TRIGger:ENHanced:SPATtern:CLOCk: Syntax :TRIGGER:EINTERVAL:TRY:MODE ON MODE {<Boolean>} Example :TRIGGER:EINTERVAL:TRY:MODE? :TRIGger:ENHanced:SPATtern:CLOCk:MODE? ->...
Page 194 5.30 TRIGger Group :TRIGger:ENHanced:SPATtern:DATA? :TRIGger:ENHanced:SPATtern:LATCh: POLarity Function Queries all settings related to data of the serial pattern trigger. Function Sets the polarity of the latch trace of the serial pattern :TRIGger:ENHanced:SPATtern:DATA? Syntax trigger or queries the current setting. :TRIGger:ENHanced:SPATtern:LATCh: Syntax :TRIGger:ENHanced:SPATtern:DATA:ACTive POLarity {FALL|RISE} :TRIGger:ENHanced:SPATtern:LATCh:...
Page 195 5.30 TRIGger Group :TRIGger:ENHanced:TV:COUPling? :TRIGger:ENHanced:TV:{HDTV|NTSC|PAL| SDTV|USERdefine}:LINE Function Queries the trigger coupling of the TV trigger. :TRIGger:ENHanced:TV:COUPling? Syntax Function Sets the line for activating the TV trigger or queries :TRIGGER:ENHANCED:TV:COUPLING? Example the current setting. -> :TRIGGER:ENHANCED:TV:COUPLING TV :TRIGger:ENHanced:TV:{HDTV|NTSC|PAL| Syntax SDTV|USERdefine}:LINE :TRIGger:ENHanced:TV:CUSTomize :TRIGger:ENHanced:TV:{HDTV|NTSC|PAL| SDTV|USERdefine}:LINE {<NRf>} Function...
Page 196 5.30 TRIGger Group :TRIGger:ENHanced:TV:SGUard :TRIGger:ENHanced:TV:USERdefine: HFRejection (HighFrequencyREJECTION) Function Sets the sync guard of the TV trigger or queries the current setting. Function Sets the user-defined low pass filter (HF rejection) or :TRIGger:ENHanced:TV:SGUard {<NRf>} Syntax queries the current setting. :TRIGger:ENHanced:TV:SGUard? :TRIGger:ENHanced:TV:USERdefine: Syntax HFRejection {<Frequency>|OFF} <NRf>...
Page 197 5.30 TRIGger Group :TRIGger:ESTate:POLarity :TRIGger:LOGic:CLOCk:POLarity Function Sets the polarity of the edge/state trigger or queries Function Sets the polarity of the logic trigger clock or queries the current setting. the current setting. :TRIGger:ESTate:POLarity {ENTer|EXIT| :TRIGger:LOGic:CLOCk:POLarity {FALL| Syntax Syntax FALL|RISE} RISE} :TRIGger:ESTate:POLarity? :TRIGger:LOGic:CLOCk:POLarity? :TRIGGER:ESTATE:POLARITY ENTER...
Page 198 5.30 TRIGger Group :TRIGger:LOGic:SPATtern? (Serial :TRIGger:LOGic:SPATtern:CLOCk:SOURce Pattern) Function Sets the clock trace for the logic serial pattern trigger Function Queries all settings related to logic serial pattern or queries the current setting. :TRIGger:LOGic:SPATtern:CLOCk: trigger. Syntax :TRIGger:LOGic:SPATtern? SOURce {A<x>|B<x>|C<x>|D<x>} Syntax :TRIGger:LOGic:SPATtern:CLOCk:SOURce? :TRIGger:LOGic:SPATtern:BITRate <x>= 0 to 7 :TRIGGER:LOGIC:SPATTERN:CLOCK:SOURCE A0...
Page 199 5.30 TRIGger Group :TRIGger:LOGic:SPATtern:HEXA :TRIGger:LOGic:SPATtern:PATTern Function Sets the pattern of the logic serial pattern trigger in Function Sets the pattern of the logic serial pattern trigger in hexadecimal notation. binary notation, or queries the current setting. :TRIGger:LOGic:SPATtern:HEXA {<string>} :TRIGger:LOGic:SPATtern: Syntax Syntax PATTern {<string>} <string>...
Page 200 5.30 TRIGger Group :TRIGger:LOGic:STATe:GROup<x>? :TRIGger:LOGic:STATe:GROup<x>:PATTern Function Queries all settings related to the group of the logic Function Sets the condition to be satisfied for the group of the state trigger. logic state trigger in binary notation or queries the :TRIGger:LOGic:STATe:GROup<x>? Syntax current setting.
Page 201 5.30 TRIGger Group :TRIGger:SCOunt (Single(N) Count) :TRIGger:LOGic:WIDTh:POLarity Function Sets the polarity of the logic pulse width trigger or Function Sets the number of times the trigger is to be activated queries the current setting. when the trigger mode is Single(N) or queries the :TRIGger:LOGic:WIDTh:POLarity {FALSe| Syntax current setting.
Page 202 5.30 TRIGger Group :TRIGger:SOURce:CHANnel<x>: :TRIGger:SOURce:CHANnel<x>:WIDTh HYSTeresis Function Sets the window trigger width of the channel or Function Sets the hysteresis of the channel or queries the queries the current setting. :TRIGger:SOURce:CHANnel<x>: current setting. Syntax :TRIGger:SOURce:CHANnel<x>: WIDTh {<Voltage>|<Current>} Syntax HYSTeresis {HIGH|LOW} :TRIGger:SOURce:CHANnel<x>:WIDTh? :TRIGger:SOURce:CHANnel<x>:HYSTeresis? <x>...
Page 203 5.30 TRIGger Group :TRIGger:SOURce:EXTernal:PROBe :TRIGger:WIDTh:POLarity Function Sets the probe attenuation of the external trigger or Function Sets the polarity of the pulse width trigger or queries queries the current setting. the current setting. :TRIGger:SOURce:EXTernal:PROBe {<NRf>} :TRIGger:WIDTh:POLarity {FALSe|IN| Syntax Syntax :TRIGger:SOURce:EXTernal:PROBe? NEGative|OUT|POSitive|TRUE} :TRIGger:WIDTh:POLarity? <NRf>...
Page 204 5.31 WAVeform Group The commands in this group deal with acquired waveform data. There are no front panel keys that correspond to the commands in this group. :WAVeform? :WAVeform:LENGth? Function Queries all information about the waveform data. Function Queries the total number of points of the waveform :WAVeform? Syntax specified by ":WAVeform:TRACe".
Page 205 5.31 WAVeform Group :WAVeform:RECord :WAVeform:SEND? Queries the waveform data specified by " : Function Sets the target record number for the commands in Function WAVeform:TRACe ". the WAVeform group or queries the current setting. :WAVeform:RECord :WAVeform:SEND? [{<NRf>}] Syntax Syntax {AVERage|MINimum|<NRf>} <NRf>...
Page 206 5.31 WAVeform Group :WAVeform:SRATe? (Sample RATE) Function Queries the sample rate of the record specified by : WAVeform:RECord. :WAVeform:SRATe? Syntax :WAVEFORM:SRATE? Example -> :WAVEFORM:SRATE 1.25E+09 :WAVeform:STARt Function Sets the first data point of the waveform specified by : WAVeform:TRACe or queries the current setting. :WAVeform:STARt {<NRf>} Syntax :WAVeform:STARt?
Page 207 5.32 ZOOM Group :ZOOM? :ZOOM:HORizontal<x>:ASCRoll? Function Queries all settings related to the waveform zoom. Function Queries all settings related to the auto scroll function. :ZOOM? :ZOOM:HORizontal<x>:ASCRoll? Syntax Syntax <x> = 1 or 2 :ZOOM:ALLocation<x>? :ZOOM:HORizontal<x>:ASCRoll:JUMP Function Queries all settings related to the zoom source waveform.
Page 208 5.32 ZOOM Group :ZOOM:HORizontal<x>:POSition :ZOOM:VERTical<x>:TRACe Function Sets the horizontal zoom center position or queries Function Sets the trace you wish to display on the vertical the current setting. zoom screen or queries the current setting. :ZOOM:HORizontal<x>:POSition {<NRf>} :ZOOM:VERTical<x>:TRACe {<NRf>} Syntax Syntax :ZOOM:HORizontal<x>:POSition? :ZOOM:VERTical<x>:TRACe?
Page 209 Function Queries the instrument model. Function Sets the standard event enable register or queries *IDN? Syntax the current setting. *IDN? -> YOKOGAWA,DLM6054,27E100000, Example *ESE {<NRf>} Syntax F1.10 Index *ESE? Description The information is returned in the following form: <NRf> = 0 to 255 <Manufacturer>,<Model>,<Serial No.>,<Firmware...
Page 210 5.33 Common Command Group *OPC? (OPeration Complete) *RST (ReSeT) Function If *OPC? is transmitted and the specified overlap Function Initializes the settings. *RST command is completed, ASCII code 1 is returned. Syntax *OPC? *RST Syntax Example *OPC? -> 1 Description Also clears *OPC and *OPC? commands that have Example Description •...
Page 211 5.33 Common Command Group *WAI (WAIt) Function Holds the subsequent command until the completion of the specified overlap operation. *WAI Syntax *WAI Example Description • For the description regarding how to synchronize the program using *WAI , see page 4-7. •...
Page 212: Chapter 6 Status Reports
Chapter 6 Status Reports Overview of the Status Report Status Reports The figure below shows the status report that is read by serial polling. This status report is an extended version of the status report defined in IEEE 488.2-1992 Service request enable register &...
Page 213 6.1 Overview of the Status Report Overview of the Registers and Queues Name Functions Writing Reading – Serial polling (RQS) Status byte – *STB?(MSS) *SRE *SRE? Service request Masks status byte enable register – *ESR? Standard event Changes in device status register *ESE *ESE?
Page 214: Status Byte
Status Byte Status Byt Operation of the Status Byte A service request is issued when bit 6 of the status 6 ESB MAV EES EAV 1 byte becomes 1. Bit 6 is set to 1 when any of the other bits becomes a 1 (when the corresponding bit of the service request enable register is also set to 1).
Page 215: Standard Event Register
Standard Event Register Standard Event Registr Operation of the Standard Event Register The standard event register is provided for eight CME EXE DDE QYERQCOPC different kinds of event which can occur inside the instrument. Bit 5 (ESB) of the status byte is set to 1 •...
Page 216: Extended Event Register
Extended Event Register Reading the extended event register tells you whether changes in the condition register (reflecting internal conditions) have occurred. A filter can be applied which allows you to decide which events are reported to the extended event registe. FILTer<x>→...
Page 217: Output Queue And Error Queue
Output Queue and Error Queue Output Queue The output queue is provided to store response messages to queries. For example, if you send the WAVeform:SEND? command, which requests the output of acquired data, the data is stored in the output queue until it is read. As shown below, data are stored in order and read from the oldest ones first.
Page 218: Appendix
Appendix Appendix 1 ASCII Character Codes The following table shows the ASCII character codes. ‘ ” & ’ Index < > (RUBOUT) Address Universal Listener Talker address Secondary commands commands commands address Example Octal GP-IB code ASCII character code Hexadecimal Decimal App-1 IM DLM6054-17EN...
Page 219: Error Messages
However, when the messages are read from a PC or other similar computers, the messages are displayed in English. • If servicing is required, contact your nearest YOKOGAWA dealer for repairs. • Only error messages related to communications are listed here. For other error messages, see User’s Manual IM 701331-01E.
Page 220 Appendix 2 Error Messages Error in Communication Execution (200 to 299) Code Messages Corrective Action Reference Page Setting conflict. Check the relevant settings. Chapter 5 Data out of range. Check the range. Chapter 5 Too much data. Check the length of the data. Chapter 5 Illegal parameter value.
Page 221: Appendix 3 Waveform Parameter Name Table
Appendix 3 Waveform Parameter Name Table Name Displayed on Name Used by Name on the DL9500/DL9700 Screen the Setup Menu of the Communication Commands When Displaying Measured Results DL9500/DL9700 Screen MAXimum MINimum High HIGH High PTOPeak Hi-Low HILow Hi-Low +Over POVershoot +Over -Over...
Page 222: Appendix 4 Eye Pattern Parameter Name Table
Appendix 4 Eye Pattern Parameter Name Table Name Displayed on Name Used by Name on the DL9500/DL9700 Screen the Setup Menu of the Communication Commands When Displaying Measured Results DL9500/DL9700 Screen Crossing % PCROssing Cross% Eye Height EHEight EyeHi Eye Width EWIDth EyeWid Q Factor...
Page 223: Index
Index Index Symbol clock source..............5-105 Page command ................4-3 <boolean>................4-7 command group..............4-3 <current> ................4-6 common command ............... 4-3 <frequency>................4-6 Common Command group ..........5-175 <RMT>.................. 4-1 COMMunicate group ............5-63 <time>................... 4-6 communication status function ......... 5-135 <voltage>...
Page 224 Index horizontal span ............. 5-41 Page marker cursor measurement ........5-42 label .................. 5-104 measurement source window ........5-47 local ..................5-63 peak value measurement ..........5-44 local lockout ................ 5-63 power value ..............5-42 LOGic Group ..............5-103 vertical axis mode ............5-48 logic group ................
Page 225 Index T/div value ................ 5-143 Page target record number ............5-171 read-only................5-78 target waveform ..............5-172 rear panel ................2-1 TCP/IP .................. 2-6 record length............... 5-35 telecom test rectangle search ..............5-97 condition ............... 5-82 REFerence group ............. 5-120 eye pattern ............
Page 226 Index waveform parameter measurement function histogram ..............5-49 list display ..............5-51 mode ................5-52 trace ................5-52 trend display ..............5-52 waveform parameter name..........App-4 waveform zoom ..............5-173 wave search zone edit menu ............. 5-98 window trigger width ............5-168 Page XY display function automated measurement ..........

This manual is also suitable for:

Dl6054 Dl6104 Dl6154 Dlm6054 Dlm6104 Dlm6000 series

YOKOGAWA DL6000 Series User Manual

Chapter 1 Overview of the USB Interface

Chapter 2 Overview of the Ethernet Interface (Optional)

Chapter 3 Overview of the GP-IB Interface

App

Chapter 4 Before Programming

Index

Chapter 5 Commands

Chapter 6 Status Reports

Appendix

Appendix 1 ASCII Character Codes

Appendix 3 Waveform Parameter Name Table

Appendix 4 Eye Pattern Parameter Name Table

Index

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for YOKOGAWA DL6000 Series

Summary of Contents for YOKOGAWA DL6000 Series

This manual is also suitable for:

Table of Contents
