MAX9276A/MAX9280A
Evaluation Kits
General Description
The MAX9276A/MAX9280A coax evaluation kits (EV
kit) provide a proven design to evaluate the MAX9276A/
MAX9280A high-bandwidth gigabit multimedia serial link
(GMSL) deserializers with spread spectrum and full-
duplex control channel with the use of a standard FAKRA
coaxial cable. The EV kit also includes Windows XP
®
Windows Vista -, and Windows 7-compatible software
that provides a simple graphical-user interface (GUI) for
exercising the features of the device. The EV kit comes
with a MAX9276A or MAX9280A installed.
For complete GMSL evaluation, using a standard FAKRA
coaxial cable, order the MAX9276A/MAX9280A coax EV
kit and a companion serializer board (MAX9275/MAX9279
coax EV kit referenced in this document). For evaluating
with STP cable, also order the MAXCOAX2STP-HSD
adapter kit and refer to its data sheet. Only one adapter kit
is required per link, connecting the serializer and deserial-
izer (SerDes) boards.
Ordering Information appears at end of data sheet.
Items Included in the EV Kit Package
MAX9276A coax EV kit or MAX9280A coax EV kit board
USB cable
MAX9276A/MAX9280A EV Kit Files
FILE
MAXSerDesEV-D_Vxxxx_Install.EXE
MAXSerDesEV-D.EXE
CDM20600.EXE
USB_Driver_Help_200.PDF
Windows, Windows XP, and Windows Vista are registered trademarks and registered service marks of Microsoft Corporation.
19-7735; Rev 0; 9/15
DESCRIPTION
Installs the EV kit files in your computer
Graphical user interface (GUI) application
Installs the USB device driver
USB driver installation help file
Evaluate: MAX9276A/MAX9280A
Features
● Accepts 24-Bit or 32-Bit Parallel Video
● Windows XP-, Windows Vista-, and Windows
7-Compatible Software
● USB-PC Connection (Cable Included)
®
● USB Powered
-,
● Proven PCB Layout
● Fully Assembled and Tested
Note: In the following sections, MAX9276A/80A and the
term "deserializer" refer to the MAX9276A and MAX9280A
ICs and MAX9275/79 and the term "serializer" refer to the
MAX9275 and MAX9279 ICs. The term SerDes refers to
serializer/deserializer.
Note: This document applies to both coax and STP EV
kits. This document covers coax cables, but the informa-
tion provided applies equally to STP cables.
DESCRIPTION
QTY
1
1
