Sinteso™ Cerberus™ PRO
FDA241, FDA221
ASD Aspirating smoke detector
A6V10331032_j_en_--
2019-01-24
Siemens aspirating smoke detector (ASD) for the addressed FDnet/C-NET
detector line or for standalone operation
●
Patented technology
●
Early detection of a wider spectrum of particle sizes in the air
●
Configuration using the USB interface or the control panel via FDCC221S
(optional)
●
'ASD Asyst-Tool' software to assist with pipe configuration
●
Unique dust-resistant detection chamber
●
Intuitive front indicator for airflow and smoke value
●
Access to service functions
●
Different event protocols
●
Offline/online configuration supported
●
Cleaning function (FDA241)
●
4...20 mA output
Building Technologies
Control Products and Systems
Advertisement
Related Manuals for Siemens Sinteso Cerberus PRO FDA221
Summary of Contents for Siemens Sinteso Cerberus PRO FDA221
- Page 1 Sinteso™ Cerberus™ PRO FDA241, FDA221 ASD Aspirating smoke detector Siemens aspirating smoke detector (ASD) for the addressed FDnet/C-NET detector line or for standalone operation ● Patented technology ● Early detection of a wider spectrum of particle sizes in the air ●...
- Page 2 Properties ● Extended optical detection thanks to dual wavelengths (blue and infrared): The aspirating smoke detectors FDA241 and FDA221 use dual-wavelength technology to trigger an alarm at the earliest possible moment. They are designed to protect small and medium-sized business-critical environments for monitoring areas of up to 800 m (FDA241) or 500 m (FDA221).
- Page 3 Applications with a filter box ● Rooms with polluted air, in which the pollution has impaired the performance of optical point detectors ● Mounting lines ● Recycling facilities ● Cement factories ● Mining industry ● Subway stations ● Agricultural operations ●...
- Page 4 Legend for the response indicators Operation Flow warnings Smoke alarm Info alarm High flow Blowing Fire 2 No smoke Normal flow Low flow Error Fire 1 Fault/test Pre-alarm Dust Opening the detector CAUTION Damage to the connection cable In order to prevent damage to the connection cable when positioning the housing cover, make sure that the connection cable has been routed correctly.
- Page 5 Service LED indicators and buttons Flow OK As soon as the selftest for normal operation has been completed successfully, the 'Flow OK' LED starts to flash. Smoke OK As soon as the selftest for normal operation has been completed successfully, the 'Smoke OK' LED starts to flash.
- Page 6 Reset button Use the reset button to reset all of the detector's status indicators. These indicators can refer to fire alarms or airflow events. Resetting the fire alarm also resets the associated relay. If the detector is operated on the FDnet/C-NET, the alarms and the associated relays are not reset.
- Page 7 Accessories Communication interface FDCC221S ● For connecting the aspirating smoke detector to FDnet/C-NET ● Integrated 'line separator' function ● Additional MC link interface (port for 3.5 mm jack) ● Tool-free mounting on a designated PCB slot ● Supplied with: – 2x spacers with thread –...
- Page 8 Battery FA2005-A1 (12 V, 17 Ah, VdS) ● For supplying fire control panels and aspirating smoke detectors with power ● Compatible with: – Fire control panels for the 'Sinteso' and 'Cerberus PRO' product lines – External power units for the aspirating smoke detectors FDA241 and FDA221 FDAZ291 aspirator (FDA241/FDA221) ●...
- Page 9 A6V10916591 Installation Aspirator (FDA241/FDA221) FDAZ291 Related documents such as environmental declarations, CE declarations, etc., can be downloaded at the following Internet address: http://siemens.com/bt/download Notes Disposal The device is considered an electronic device for disposal in accordance with the European Guidelines and may not be disposed of as domestic garbage.
- Page 10 Monitoring area (dependent on local Up to 800 m² Up to 500 m² provisions and standards) System compatibility Compatible with all Siemens FC20/FC720 (FS20/FS720 systems) Relay alarm outputs Can be selected with/without lock Nominal current 2.0 A at DC 30 V. Contact: NO/NC...
- Page 11 FDA241 FDA221 Indication ● 4x alarm status indicators (FDA241) ● 3x alarm status indicators (FDA221) ● Faults ● Blowing out (FDA241) ● Dust (FDA241) ● Smoke density and flow indicator Service area ● LED 'Status OK' ● ● Settings for reset functions ●...
- Page 12 The declared performance and conformity can be seen in the Declaration of Performance (DoP) and the EU Declaration of Conformity (DoC), which is obtainable via the Customer Support center: Tel. +49 89 9221-8000 or http://siemens.com/bt/download DoP No.: 0786-CPR-21270; DoC No.: CED-FDA221/FDA241...
