SUPERVISOR II and
SUPERVISOR
CONTROLLER
SEQUENCING & PROTOCOL
MANUAL
™
OPERATOR'S
MANUAL AND
PARTS LIST
KEEP FOR
FUTURE
REFERENCE
Part Number 02250139-197
©Sullair Corporation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SUPERVISOR II Series and is the answer not in the manual?

Questions and answers

Tony Emerson Marim
April 8, 2025

I would like to know which register addresses can be used for the re-485 module.

0

Subscribe to Our Youtube Channel

Related Manuals for Sullair SUPERVISOR II Series

Summary of Contents for Sullair SUPERVISOR II Series

  • Page 1 SUPERVISOR II and SUPERVISOR CONTROLLER ™ SEQUENCING & PROTOCOL MANUAL OPERATOR’S MANUAL AND PARTS LIST KEEP FOR FUTURE REFERENCE Part Number 02250139-197 ©Sullair Corporation...
  • Page 2 Sullair Air Care Seminars are 3-day courses that provide hands-on instruction in the proper operation, mainte- nance and service of Sullair equipment. Individual seminars on Industrial compressors and compressor electrical systems are presented at regular intervals throughout the year at a dedicated training facility at Sullair’s corporate headquarters in Michigan City, Indiana.

  • Page 3: Table Of Contents

    Section 2 SUPERVISOR II SEQUENCING Modes of Sequencing Remote Control Mode or Digital Inputs For Remote Sequencing Description of Typical Compressor System in Sullair Sequencing Mode MACHINE PREPARATION PRIOR TO SEQUENCING SYSTEM OPERATION System Setup and Tuning Changing Sequence Parameters...

  • Page 4: Supervisor Ii

    Philosophy of Sequencing Modes of Sequencing Remote Enable/Disable Keypad Feature Remote Control Mode or Digital Inputs For Remote Sequencing Description of Typical Compressor System in Sullair Sequence Mode MACHINE PREPARATION PRIOR TO SEQUENCING SYSTEM OPERATION System Setup and Tuning Changing Sequence Parameters...
  • Page 5 TABLE OF CONTENTS Section 4 VARIABLE SPEED DRIVE (CONT.) SEQUENCING WITHOUT AUTO ROTATION OF FIXED-SPEED MACHINES SYSTEM SETUP WITH ONE VSD COMPRESSOR AND OTHER FIXED-SPEED COMPRESSORS II. SYSTEM SETUP WITH ONLY VSD COMPRESSORS Section 5 SEQUENCING TIMERS Recovery Time & Delayed Start Timer Example 1: Recovery Timer- Unload Operation Example Example 2: Recovery Timer- Load...
  • Page 6 NOTES...

  • Page 7: Section 1.1 Supervisor Ii Protocol Ver 3.0

    Section 1 SUPERVISOR PROTOCOL SECTION 1.1 SUPERVISOR II PROTOCOL VER 3.0 This document describes features that are more technical in nature than the normal opera- tion of the machine, in particular sequencing and communication. The Supervisor II communications link is a RS-485 (two wire) serial line. The following three parameters must be set correctly to be able to communicate through this link.

  • Page 8: Broadcast Mode Offers Several Advantages

    Section 1 SUPERVISOR PROTOCOL Supervisor will not start, stop, load or unload unless a message commands the action. If the sequence parameter is set to HOURS or COM ID# then the broadcast mode is enabled. In this mode the machines send the net status message periodically. Approximately once a second, all machines that are on line will send a net status message.

  • Page 9: Message Types

    Section 1 SUPERVISOR PROTOCOL MESSAGE TYPES The following messages sent by the sequencing master to slaves: MESSAGE TYPE FORMAT EXAMPLE Q - Quick status ##Qxx 01Q4E S - Stop ##Sxx 01S4C U - Unload ##Uxx 01U4A L - Load (Modulate) ##Lxx 01L53 F - Full load...
  • Page 10 Section 1 SUPERVISOR PROTOCOL The following messages are sent by the monitor: MESSAGE TYPE FORMAT EXAMPLE G - Get parameter ##Gn,xx 01G3,58 P - Change parameter ##Pn,v,xx 01P3,4,90 D - Display message ##Dxx 01D5B I - Status info ##Ixx 01I56 A - Auto run mode ##Axx 01A5E...
  • Page 11 Section 1 SUPERVISOR PROTOCOL (Continued from page 4) 46 T6 CAL (-7 to +7) 47 P2 CAL (-7 to +7) 48 P3 CAL (-7 to +7) 49 P4 CAL (-7 to +7) 50 dP1 CAL(-20 to +10) 51 P3 MAX (-7 to +7) 70 Parameter Protection (0 = NOT Protected, 1 = Protected)

  • Page 12: Analog Shutdown Table

    Section 1 SUPERVISOR PROTOCOL ANALOG SHUTDOWN TABLE 1 = P1 6 =dP2 11 = T4 2 = P2 7 = dP3 12 = T5 3 = P3 8 = T1 13 = T6 4 = P4 9 = T2 5 = dP1 10 = T3 RS-485 SERIAL CHANNEL The RS-485 is a party line type channel, ie.

  • Page 13: Time Slicing Of The Rs-485 Serial Channel

    Section 1 SUPERVISOR PROTOCOL TIME SLICING OF THE RS-485 SERIAL CHANNEL When the sequencing mode is set to HOURS or COM ID# the machines will broadcast their status (net status message) about once a second. To keep machines from sending mes- sages simultaneously, time is sliced into periods (up to 9 maximum), one for each machine and one for a monitor.
  • Page 14 Section 1 SUPERVISOR PROTOCOL Let’s start this example at time slot 1. Machine 1 sends a net message. Machine 2 receives the message and establishes the time slot as 2. Machine 2 immediately sends it’s net sta- tus message establishing the slot at 3. Since machine 3 is off line no message will be sent and after .125 sec.

  • Page 15: Modes Of Sequencing

    Section 2 SUPERVISOR II SEQUENCING Modes of Sequencing REMOTE - Enables three digital inputs for Remote Start/Stop, Unload/Load and Master Control. These inputs are normally controlled by remote relay contacts or a PLC controller. A customer may then interface with custom sequencing panels which provide signals for a 2-wire stop/start operation.

  • Page 16: Description Of Typical Compressor System In Sullair Sequencing Mode

    The Local/Master Output is a relay contact that can handle 110VAC at 6 amperes. (J1-14 & J1-15) Description of Typical Compressor System in Sullair Sequence Mode MACHINE PREPARATION PRIOR TO SEQUENCING 1. Complete all machine startup procedures for stand-alone operation for the machines that are to be sequenced together per the compressor operators manual.

  • Page 17: System Setup And Tuning

    Section 2 SUPERVISOR II SEQUENCING others will be forced to "FULL LOAD". The modulating (trim) machine will load at 2psig (.14 bar) above the load pressure parameter, 102 psig (7.03 bar) in this example, and unload at 2 psig (.14 bar) below unload pressure parameter, 108 psig (7.4 bar) in this example. The reason for this narrower load/unload band is to keep all machines from loading and unload- ing at the same time.

  • Page 18: Changing Sequence Parameters

    Section 2 SUPERVISOR II SEQUENCING Decisions to load, unload or start another machine are deferred until the timer reaches the RECOVER time setpoint. Note that the timer starts when a machine is added or taken away from the system. If the pressure recovers within the RECOVER time, and then at a later time the pressure drops below the Trim Low setpoint, another machine will load immediately.

  • Page 19: System Display

    Section 2 SUPERVISOR II SEQUENCING sure drops below this limit then the machine with the lowest SEQ HRS or COM ID is start- ed immediately. A machine will also start if the pressure is below the Trim Low Setpoint for a period of time.

  • Page 20: Removing A Machine From Sequence For Maintenance

    Section 2 SUPERVISOR II SEQUENCING If the up arrow key is pushed the system line pressure is displayed. If the up arrow key is pushed again the line pressure and run hours of the first machine is displayed, if the arrow key is pushed again the second machine is displayed and so on.
  • Page 21 Section 2 SUPERVISOR II SEQUENCING and the white or black wire is on J2-17. Both wires of the other twisted pair is connected to J2-18. The shield should be connected to ground at one end only. COMMON HEADER It is best if the P2 (line pressure) transducers of all machines are connected to a common header, down stream of dryers, etc.
  • Page 22 NOTES...

  • Page 23: Philosophy Of Sequencing

    SUPERVISOR CONTROLLER SEQUENCING Philosophy of Sequencing All Sullair sequencing methods except base-load sequencing and sequencing with a VSD trim machine work under the same assumption. The most efficient use of compressors is either fully loaded or not running at all. Therefore, any time more than one machine is run- ning, all but the last one started is forced to operate at full load.

  • Page 24: Description Of Typical Compressor System In Sullair Sequence Mode

    E-stop or Stop. The Local/Master Output is a relay contact that can handle 110VAC at 6 amperes. Description of Typical Compressor System in Sullair Sequence Mode MACHINE PREPARATION PRIOR TO SEQUENCING 1. Complete all machine startup procedures for stand-alone operation for the machines that are to be sequenced together per the compressor operators manual.

  • Page 25: System Setup And Tuning

    Section 3 SUPERVISOR CONTROLLER SEQUENCING As machines are started and loaded, there will be only one machine that is modulating, the others will be forced to "FULL LOAD". The modulating (trim) machine will load at 2psig (.14 bar) above the load pressure parameter, 102 psig (7.03 bar) in this example, and unload at 2 psig (.14 bar) below unload pressure parameter, 108 psig (7.4 bar) in this example.

  • Page 26: Changing Sequence Parameters

    Section 3 SUPERVISOR CONTROLLER SEQUENCING at the same time. A timer is reset when a machine loads, unloads or loads after a start. Decisions to load, unload or start another machine are deferred until the timer reaches the RECOVER time setpoint. Note that the timer starts when a machine is added or taken away from the system.

  • Page 27: System Display

    Section 3 SUPERVISOR CONTROLLER SEQUENCING in a system, for example, they must be numbered 1, 2 and 3. Up to 16 machines may be sequenced with the Supervisor Controller. BAUD RATE - Serial communications baud rate, almost always set to 9600. LAST COM - Set to total number of machines in a system.

  • Page 28: Calibration Of P2 Pressure Transducers

    Section 3 SUPERVISOR CONTROLLER SEQUENCING The status letters are: E-Stop U Unloaded Manual stop B Standby Loaded F Full Load Trim (loaded and modulating) S Starting Remote or sequence stop The third column displays the capacities of the machines that are running. The fourth col- umn indicates first the highest system P2 value and then P2 for each compressor in the sequence.
  • Page 29 Section 3 SUPERVISOR CONTROLLER SEQUENCING the calibration parameter to make it permanent. Return to the main display by pressing ESC and check to make sure the pressure is correct. NETWORK WIRING The network cable should be Belden 9842 or similar. This cable has two twisted pairs with a shield.
  • Page 30 NOTES...

  • Page 31: Variable Speed Drive Applications

    VARIABLE SPEED DRIVE APPLICATIONS The most efficient use of a VSD machine in sequencing is to make it always be the trim machine and always be running. This can be accomplished using the existing Sullair sequence logic and configuring the machines as follows: I.
  • Page 32 Section 4 VARIABLE SPEED DRIVE SYSTEM SETUP WITH ONE VSD COMPRESSOR AND OTHER FIXED-SPEED COMPRESSORS Target system pressure at discharge of compressors: 100 psi VSD Compressor COM # 1 Fixed-Speed Compressor/s COM # 2/+ VSD Setpoint 101.5 Load Setpoint Unload Setpoint Lowest Pressure Since a fixed-speed L compressor's pressure regulator doesn't begin to throttle until 101- 102 psi, it should have no effect, thereby causing the machine to operate Load/Unload with...
  • Page 33 Section 5 SEQUENCING TIMERS Recovery Timer & Delayed Start Timer The Recovery Timer is used to keep machines from starting, loading or unloading all at the same time. The Delayed Start timer is used to keep machines from starting unnecessarily due to temporary load changes.
  • Page 34 Section 5 SEQUENCING TIMERS The following examples show how the Recovery and Delayed Start timers work. Example 1: Recovery Timer - Unload Operation Example Suppose there are three machines running and loaded, the recovery timer is set to 10 sec- onds and the unload pressure is set at 110 on all three machines.
  • Page 35 Section 5 SEQUENCING TIMERS Example 2: Recovery Timer - Load Operation Example Suppose there are three machines running and with two unloaded and one in trim, the recovery timer is set to 10 seconds and the load pressure is set at 100 on all three machines.
  • Page 36 Section 5 SEQUENCING TIMERS Example 3: Recovery Timer - Starting Example (pressure drops below Lowest Pressure setting) Machines will start when the system pressure drops below the Lowest Pressure setting, or when system pressure drops below the load setting for a period of time determined by the Delayed Start timer.
  • Page 37 Section 5 SEQUENCING TIMERS Example 4: Delay Start Timer - Pressure below Sequencing Load pressure but above Lowest Pressure The Delayed Start timer comes into play only when the system pressure is below the Sequencing Load pressure setting but still above the Lowest Pressure setting. This timer value is prorated between the Sequence Load pressure and Lowest Pressure.
  • Page 38 Section 5 SEQUENCING TIMERS Summary : Unload pressure - All machines unload above this pressure regardless of Recovery timer. 108-110 Recovery timer active - Trim machine will unload after Recovery timer expires. Sequencing unload pressure - Trim machine unloads above this pressure, Recovery timer starts. Sequencing load pressure - Next machine in sequence loads below this pressure, Recovery timer starts.
