ULTRA FORCE
COMMERCIAL GAS WATER HEATER
• INSTALLATION • OPERATION • SERVICE • MAINTENANCE • LIMITED WARRANTY
WARNING: If the information in these
instructions is not followed exactly, a fire
or explosion may result causing property
damage, personal injury or death.
– Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
– WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch;
do not use any phone in your
building.
• Immediately call your gas supplier
from a neighbor's phone. Follow
the gas supplier's instructions.
• If you cannot reach your gas supplier,
call the fire department.
– Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
Thank you for buying this energy efficient water heater
from State Industries. We appreciate your confidence in
our products.
TEXT PRINTED OR OUTLINED IN RED CONTAINS
INFORMATION RELATIVE TO YOUR SAFETY. PLEASE
READ THOROUGHLY BEFORE INSTALLING AND USING
THIS APPLIANCE.
PLACE THESE INSTRUCTIONS ADJACENT TO HEATER AND NOTIFY OWNER TO KEEP FOR FUTURE REFERENCE.
PRINTED 0307
GAS-FIRED POWER BURNER
FOR DOMESTIC HOT WATER
CAUTION
SUF-130-300 AND 400
500 TENNESSEE WALTZ PARKWAY
ASHLAND CITY, TN 37015

97483-002

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SUF-130-300 and is the answer not in the manual?

Questions and answers

Related Manuals for State Water Heaters SUF-130-300

Summary of Contents for State Water Heaters SUF-130-300

  • Page 1 – Installation and service must be performed by a qualified installer, service agency or the gas supplier. Thank you for buying this energy efficient water heater from State Industries. We appreciate your confidence in our products. CAUTION TEXT PRINTED OR OUTLINED IN RED CONTAINS INFORMATION RELATIVE TO YOUR SAFETY.

  • Page 2: Gas Valve Piping

    GAS VALVE PIPING SUF 130-300 1 1/4" NPT SUF 130-400 1 1/4" NPT TABLE 1 RECOVERY CAPACITIES. TYPE OF INPUT MODEL BTUH Capacity 300,000 130 US Gals. SUF 130-300 NATURAL 492 Litres 300,000 130 US Gals. SUF 130-300 PROPANE 492 Litres 399,900 130 US Gals.

  • Page 3: Table Of Contents

    ROUGH-IN DIMENSIONS ... 2 FOREWORD ... 2 FEATURES ... 3 Water Temperature Control ...3-5 Water Temperature Setpoint Adjustment Procedure ... 5 High Limit Switch (E.C.O.) ... 5 Dishwashing Machine Requirement ... 5 Circulating Pump ... 6 INSTALLATION INSTRUCTIONS ... 6 Required Ability ...
  • Page 4 “AT A GLANCE” QUICK INSTALLATION TIPS Horizontal Sidewall Venting Vertical Rooftop Venting...

  • Page 5: Water Temperature Setpoint Adjustment Procedure

    The temperature may be adjusted from 80°F/27°C to 180°F/82°C. The thermostat was adjusted to 120°F/49°C before the heater was shipped from the factory. It is recommended that lower water temperatures be used to avoid the risk of scalding. It is further recommended, in all cases, that the water temperature be set for the lowest temperature which satisfies your hot water needs.

  • Page 6: Circulating Pump

    CIRCULATING PUMP A circulating pump is used when a system requires a circulating loop or there is a storage tank used in conjunction with the heater. Refer to the piping diagrams at rear of manual for electrical hookup information and install in accordance with the current edition of the National Electrical Code, NFPA 70 or the Canadian Electrical Code, CSA C22..

  • Page 7: Clearances

    CLEARANCES These heaters are approved for installation on combustible flooring in an alcove when the minimum clearances from any combustion construction are followed as indicated in Figure 4. In all installations the minimum combustible clearances from any vent piping shall be 0". Vent piping passing through a combustible wall or ceiling must be a continuous run (no joints).

  • Page 8: Installation Requirements For The Commonwealth Of Massachusetts

    INSTALLATION REQUIREMENTS FOR THE COMMONWEALTH OF MASSACHUSETTS For all side wall terminated, horizontally vented power vent, direct vent, and power direct vent gas fueled water heaters installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above finished grade in the area of the venting, including...
  • Page 9 US DIRECT VENT CAUTION TO PREVENT EXHAUSTING PRODUCTS FROM CIRCULATING TO THE AIR INTAKE IN WINDY/COLD AREAS, THE MAXIMUM PRACTICAL DISTANCE BETWEEN THESE TWO TERMINALS IS RECOMMENDED. CANADIAN DIRECT VENT FIGURE 5.
  • Page 10 US HORIZONTAL VENT CAUTION TO PREVENT EXHAUSTING PRODUCTS FROM CIRCULATING TO THE AIR INTAKE IN WINDY/COLD AREAS, THE MAXIMUM PRACTICAL DISTANCE BETWEEN THESE TWO TERMINALS IS RECOMMENDED. CANADIAN HORIZONTAL VENT FIGURE 6.

  • Page 11: Vent Pipe Termination

    WARNING NEVER OPERATE THE HEATER UNLESS IT IS VENTED TO THE OUTDOORS AND HAS ADEQUATE AIR SUPPLY TO AVOID RISKS OF IMPROPER OPERATION, FIRE, EXPLOSION OR ASPHYXIATION. VENT PIPE TERMINATION NOTE: Before installing venting, determine place of vent pipe termination. See Figure 5 and 6 before proceeding. CAUTION DO NOT TERMINATE THE VENTING WHERE NOISE FROM THE EXHAUST OR INTAKE WILL BE OBJECTIONABLE.

  • Page 12: Installation Sequence

    2. The horizontal centerline of the intake vent terminal may not be located lower than the horizontal centerline of the exhaust vent terminal (see Figure 9). FIGURE 9. INSTALLATION SEQUENCE For installations in the City of Los Angeles, California Category IV PVC Pipe such as that manufactured by Brownline Pipe Company, must be used as vent pipe material.

  • Page 13: Installation Of Vent System

    2. Drill a pilot hole approximately 1/4" (6 mm) outside of the marked circle. This pilot hole is used as a starting point for a saws- all or sabre saw blade. Cut around the marked circle staying approximately one quarter inch outside the line. (This will allow the vent pipe to easily slide through the opening).

  • Page 14: Vent Pipe Preparation

    WELL-VENTILATED AREA. CONTROLS AND SWITCHES The SUF-130-300 and 400 are equipped with four pressure switches. These switches are essential to the safe and proper operation of the unit. All switches are wired in series. The controller is set up to shut the unit down whenever there is a failure of any of the switches.

  • Page 15: Hot Surface Igniter

    CAUTION THE WATER HEATER IS POLARITY SENSITIVE. BEFORE APPLYING ELECTRICITY TO THIS HEATER BE CERTAIN THAT SUPPLY NEUTRAL WIRE TO GROUND CHECK INDICATES ZERO VOLTAGE. HOT SURFACE IGNITER The Hot Surface Igniter is a device that ignites the main burner by high temperature (>1800°F or >982°C).

  • Page 16: Purging

    To prevent damage, care must be taken not to apply too much torque when attaching gas supply pipe to gas valve inlet. Apply joint compounds (pipe dope) sparingly and only to the male threads of pipe joints. Do not apply compound to the first two threads. Use compounds resistant to the action of liquefied petroleum gases.

  • Page 17: Water (Potable) Heating & Space Heating

    codes or contact the water supplier or local plumbing inspector on how to control this situation. WATER (POTABLE) HEATING AND SPACE HEATING 1. All piping components connected to this unit for space heating applications shall be suitable for use with potable water. 2.
  • Page 18 SUF 130-300 WIRING DIAGRAM FIGURE 15.
  • Page 19 SUF 130-400 WIRING DIAGRAM FIGURE 16.

  • Page 20: Sequence Of Operation

    OPERATION SEQUENCE OF OPERATION Typical Control/Appliance Operating Sequence When the control is powered, it should display the unit model, water temperature, setting temperature and heater status. If the control determines that the actual water temperature inside the tank is below the programmed temperature setpoint less the differential, a call for heat is activated.

  • Page 21: Adjusting The Operating Set Point

    3. Adjusting the Operating Set Point The Operating Set Point of this water heater determines the regulated temperature for the water in the tank. This parameter is adjusted in the Temperature menu. Items in this menu allow you to monitor different temperature readings in the tank along with adjusting the Operating Set Point and Differential.

  • Page 22: Changing The Display Units

    4. Changing the Display Units The display interface to the heater has the option of selecting between degrees and Fahrenheit and degrees Celsius for temperature displays. This can be found in the "Display Settings" menu. Also in this menu, you may adjust how the backlight operates and the contrast of the LCD screen.

  • Page 23: Access To The Current Fault Or Warning

    • Faults: This is a safety related condition that has been detected by the heater. NOTE: When these conditions occur, the water heater will not continue any further heating cycles and the water will no longer be heated until the condition is corrected and, in most cases, power has been cycled. Example of a Fault: Advanced Diagnostics Information When a fault or warning has been declared, advanced information can be found in the control.

  • Page 24: Viewing The Fault History

    7. Viewing the Fault History The controller for this water heater will store a history of ten of the last Fault and Warning conditions that occurred. This is stored in the Fault History. Along with all the information about the fault, including a estimate time of when the fault occurred, information regarding the advanced diagnostics for that fault can be accessed at any time.

  • Page 25: Prior To Start-Up Required Ability

    PRIOR TO START UP - REQUIRED ABILITY INSTALLATION OR SERVICE OF THIS WATER HEATER REQUIRES ABILITY EQUIVALENT TO THAT OF A LICENSED TRADESMAN IN THE FIELD INVOLVED. PLUMBING, AIR SUPPLY, VENTING, GAS SUPPLY AND ELECTRICAL WORK ARE REQUIRED. Before attempting start-up, thoroughly study and familiarize yourself with the exact sequence of operation and all other details on the specific heater being used.

  • Page 26: For Your Safety Read Before Operating

    c. Remove the pressure regulator cover screw (Figure 16) and adjust the pressure by turning the adjusting screw with a small screwdriver. In this example, with heater running on natural gas, do not exceed 4.0" (0.996 kPa) Water Column. Clockwise to increase gas pressure and input rate. Counterclockwise to decrease gas pressure and input rate.

  • Page 27: Cathodic Protection

    WARNING UNDER NO CIRCUMSTANCES SHOULD THE INPUT EXCEED THE RATE SHOWN ON THE HEATER RATING PLATE. OVERFIRING COULD RESULT IN DAMAGE OR SOOTING OF THE HEATER. CATHODIC PROTECTION CAUTION HYDROGEN GAS CAN BE PRODUCED IN A HOT WATER SYSTEM SERVED BY THIS HEATER THAT HAS NOT BEEN USED FOR A LONG PERIOD OF TIME (GENERALLY TWO WEEKS OR MORE).

  • Page 28: Flushing

    FLUSHING 1. Turn off the heater electrical disconnect switch. 2. Open the drain valve and allow water to flow until it runs clean. 3. Close the drain valve when finished flushing. 4. Turn on the heater electrical disconnect switch. DRAINING The heater must be drained if it is to be shut down and exposed to freezing temperatures.

  • Page 29: Powered Anode System

    POWERED ANODE SYSTEM To insure a long, trouble-free operating life, SUF 300 and 400 are factory equipped with a powered anode system. The anodes are of a permanent design and do not need replacing unless damaged. DRAIN VALVE AND ACCESS PANELS The heaters are equipped with a 3/4"...

  • Page 30: Installation Diagrams

    ONE TEMPERATURE - ONE HEATER VERTICAL STORAGE TANK FORCED CIRCULATION ONE TEMPERATURE - ONE HEATER HORIZONTAL STORAGE TANK FORCED CIRCULATION WITH OR WITHOUT BUILDING RECIRCULATION DANGER TEMPERATURE SETTING SHOULD NOT EXCEED SAFE TEMPERATURE AT FIXTURES. SEE WATER TEMPERATURE CONTROL WARNING ON PAGE 3.
  • Page 31 TWO TEMPERATURE - ONE HEATER HIGH TEMPERATURE DANGER TEMPERATURE SETTING SHOULD NOT EXCEED SAFE TEMPERATURE AT FIXTURES. SEE WATER TEMPERATURE CONTROL WARNING ON PAGE 3. IF HIGHER PREHEAT TEMPERATURES ARE NECESSARY TO OBTAIN ADEQUATE BOOSTER OUTPUT, ADD AN ANTI-SCALD VALVE FOR HOT WATER SUPPLIED TO FIXTURES.
  • Page 32 TWO TEMPERATURE - TWO HEATERS HIGH TEMPERATURE TWO TEMPERATURE - THREE HEATERS (TWO PRE-HEATERS/ONE BOOSTER HEATER) MUST BE IDENTICAL HEATERS FOR MULTIPLE HEATER INSTALLATION SEE MANIFOLD KIT SPECIFICATIONS, PAGE 30. CAUTION: IF BUILDING COLD WATER SUPPLY HAS A BACK- FLOW PREVENTER, CHECK VALVE OR WATER METER WITH CHECK VALVE PROVISIONS FOR THERMAL EXPANSION OF WATER IN THE HOT WATER SYSTEM MUST BE PROVIDED.
  • Page 33 TWO TEMPERATURE - TWO HEATERS (ONE PRE-HEATER/ONE BOOSTER HEATER) DANGER TEMPERATURE SETTING SHOULD NOT EXCEED SAFE TEMPERATURE AT FIXTURES. SEE WATER TEMPERATURE CONTROL WARNING ON PAGE 3. IF HIGHER PREHEAT TEMPERATURES ARE NECESSARY TO OBTAIN ADEQUATE BOOSTER OUTPUT, ADD AN ANTI-SCALD VALVE FOR HOT WATER SUPPLIED TO FIXTURES WITH OR WITHOUT BUILDING RECIRCULATION * PIPE RELIEF VALVE TO OPEN DRAIN...
  • Page 34 TWO TEMPERATURE - ONE HEATER HIGH TEMPERATURE DANGER TEMPERATURE SETTING SHOULD NOT EXCEED SAFE TEMPERATURE AT FIXTURES. SEE WATER TEMPERATURE CONTROL WARNING ON PAGE 3. IF HIGHER PREHEAT TEMPERATURES ARE NECESSARY TO OBTAIN ADEQUATE BOOSTER OUTPUT, ADD AN ANTI-SCALD VALVE FOR HOT WATER SUPPLIED TO FIXTURES.

  • Page 35: Multiple Unit Installations

    MULTIPLE UNIT INSTALLATIONS Proper installation of multiple water heaters assures water flow balance of all units. Without this balance, the full water heating and storage potential of the system cannot be achieved. Plus, the units with the higher water flow may have a shortened life. Dimensions shown are for minimum space occupied by the water heaters assemblies.

  • Page 36: Checklist And Service Information

    CHECKLIST AND SERVICE INFORMATION IMPORTANT The installer may be able to observe and correct certain problems which might arise when the unit is put into operation or when it is re-fired after a prolonged shutdown. HOWEVER, it is recommended that only qualified servicemen, using appropriate test equipment, be allowed to service the heater.

  • Page 37: Motor Will Not Run

    Checking these four (4) items first will often result in a timely solution to the service call. WARNING JUMPING OUT COMPONENTS AND/OR CIRCUITS DURING TROUBLESHOOTING CAN CAUSE SERIOUS PROBLEMS WITH THE UNIT’S OPERATING SEQUENCE AND IGNITION SAFETY. IF YOU DO NOT HAVE THE PROPER TEST EQUIPMENT, I.E. A VOLT-OHM METER AND A MICROMETER, DO NOT ATTEMPT TO TROUBLESHOOT OR REPAIR STATE EQUIPMENT.

  • Page 38: Replacement Parts

    NOTE: Always turn off and disconnect main supply wiring before servicing the unit. 4. Check connecting wire to the flame sensor. Verify that the flame sensor has not been damaged in any way. 5. Verify that the air supply is adequate. The air inlet screen or blower wheel may be restricted.

  • Page 39: Limited Warranty

    MODEL SUF-130-300/400 NEA /PEA LIMITED WARRANTY State Water Heaters, the warrantor, extends the following LIMITED WARRANTY to the owner of this water heater. THE TANK If the glass-lined tank in this water heater shall prove upon examination by the warrantor to have leaked due to natural corrosion from potable water therein, during the first THREE years after initial installation, the warrantor will supply a replacement tank less burner and controls or a complete new heater of equivalent size and current model at the warrantor's option.
  • Page 40 500 TENNESSEE WALTZ PARKWAY ASHLAND CITY, TN 37015 Phone: 800-365-0024 Fax: 800-644-9306 www.statewaterheaters.com...
