USER MANUAL
Scavenger Transmitter Module
STM 429J
(STEPCODE: DE and later)
Scavenger Transmitter Module
STM 429J
May 21, 2019
Observe precautions! Electrostatic sensitive devices!
Patent protected:
WO98/36395, DE 100 25 561, DE 101 50 128,
WO 2004/051591, DE 103 01 678 A1, DE 10309334,
WO 04/109236, WO 05/096482, WO 02/095707,
US 6,747,573, US 7,019,241
EnOcean GmbH
Phone +49.89.67 34 689-0
Kolpingring 18a
Fax
82041 Oberhaching
info@enocean.com
Germany
www.enocean.com
+49.89.67 34 689-50
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for EnOcean Scavenger STM 429J
Summary of Contents for EnOcean Scavenger STM 429J
- Page 1 WO98/36395, DE 100 25 561, DE 101 50 128, WO 2004/051591, DE 103 01 678 A1, DE 10309334, WO 04/109236, WO 05/096482, WO 02/095707, US 6,747,573, US 7,019,241 EnOcean GmbH Phone +49.89.67 34 689-0 Kolpingring 18a +49.89.67 34 689-50 82041 Oberhaching info@enocean.com...
- Page 2 This information describes the type of component and shall not be considered as assured characteris- tics. No responsibility is assumed for possible omissions or inaccuracies. Circuitry and specifications are subject to change without notice. For the latest product specifications, refer to the EnOcean web- site: http://www.enocean.com.
-
Page 3: Table Of Contents
3.5 QR code ............ Fehler! Textmarke nicht definiert. 3.5.1 Included Information: ......Fehler! Textmarke nicht definiert. AGENCY CERTIFICATIONS ................17 Label Information ..................18 © 2019 EnOcean | www.enocean.com STM 429J User Manual | v3.0 | May 2019 | Page 3/ 19... -
Page 4: General Description
STM 429J (STEPCODE: DE and later) GENERAL DESCRIPTION Basic functionality The radio transmitter modules and 429J from EnOcean enable the implementation of a wireless magnet contact sensor. Powered by a solar cell, it works absolutely mainte- nance-free. An integrated energy store allows operation for several days even in total darkness. -
Page 5: Physical Dimensions
(STEPCODE: DE and later) Physical dimensions PCB dimensions 43±0.2 x 16±0.3 x 1±0.1 mm Module height 6 mm Weight 5.2 g Drawing STM 429J © 2019 EnOcean | www.enocean.com STM 429J User Manual | v3.0 | May 2019 | Page 5/ 19... -
Page 6: References
[2] Dolphin V4 Core Description - http://www.enocean.com/dolphin-v4-core- description/ [3] Dolphin V4 API - http://www.enocean.com/en/enocean-software/ [4] AN509 Explanation of EnOcean security in applications - http://www.enocean.com/en/application-notes/ [5] AN510 Adding Security to EnOcean Receivers - http://www.enocean.com/en/application-notes/ [6] AN511 Advanced security in self-powered wireless applications - http://www.enocean.com/en/application-notes/... -
Page 7: Ordering Information
USER MANUAL Scavenger Transmitter Module STM 429J (STEPCODE: DE and later) Ordering Information Type Ordering Code STM 429J S3061-D429 © 2019 EnOcean | www.enocean.com STM 429J User Manual | v3.0 | May 2019 | Page 7/ 19... -
Page 8: Functional Description
The following diagram illustrates all implemented mode transitions. Short press: 1 s (firmware 0.1 – 3.0 s) Long press: 5 s (firmware 3 – 7 s) © 2019 EnOcean | www.enocean.com STM 429J User Manual | v3.0 | May 2019 | Page 8/ 19... -
Page 9: Block Diagram
Between the wake-up phases, the device is in sleep mode for minimum power consump- tion. Radio telegram 429J transmits a radio telegram according to EnOcean Equipment Profile EEP D5-00-01 as defined in the EnOcean Equipment Profiles specification. © 2019 EnOcean | www.enocean.com... -
Page 10: Secure Radio Telegram
To use PSK teach-in, the PSK must be read by the end-user and entered into the other communication partner. For this purpose the EnOcean radio interface cannot be used. The PSK can be entered trough a user interface or semi-automated by a code reader. -
Page 11: Transmit Timing
Scavenger Transmitter Module STM 429J (STEPCODE: DE and later) For details on the PSK Teach-in please refer to the EnOcean Security Speification. PSK feature is disabled by default. To enable PSK feature the execute configuration in Dol- phin Suite with special adapter. -
Page 12: Energy Consumption
Short wake-up cycles (e.g. 1 s) and transmit intervals (e.g. 1 s) significantly reduce energy storage performance, for this use case an external power supply is recom- mended © 2019 EnOcean | www.enocean.com STM 429J User Manual | v3.0 | May 2019 | Page 12/ 19... -
Page 13: Consumption In Secure Mode
2. With this measure the operation in dark time is even little bit increased. There it is to assume the operation in dark time is not reduced by using enhanced security. © 2019 EnOcean | www.enocean.com STM 429J User Manual | v3.0 | May 2019 | Page 13/ 19... -
Page 14: Applications Information
Scavenger Transmitter Module STM 429J (STEPCODE: DE and later) APPLICATIONS INFORMATION Antenna Details Antenna location recommendation 429J without host PCB 429J with host PCB © 2019 EnOcean | www.enocean.com STM 429J User Manual | v3.0 | May 2019 | Page 14/ 19... -
Page 15: Transmission Range
Lead glass or glass with metal coating, steel furniture The distance between EnOcean receivers and other transmitting devices such as comput- ers, audio and video equipment that also emit high-frequency signals should be at least 0.5 m. A summarized application note to determine the transmission range within buildings is available as download from www.enocean.com. -
Page 16: Mounting 429J Into A Housing
Please make sure that the housing covers 0.5 mm at the solar cell edges. Within 0.5 mm off the edge flaking is possible due to the cutting process. © 2019 EnOcean | www.enocean.com STM 429J User Manual | v3.0 | May 2019 | Page 16/ 19... -
Page 17: Agency Certifications
T108 based on the built-in firmware. When the product is placed on the Japanese market, it must carry the Specified Radio Equipment marking as shown below: © 2019 EnOcean | www.enocean.com STM 429J User Manual | v3.0 | May 2019 | Page 17/ 19... -
Page 18: Label Information
30P<Order code> 1 CHAR 2PDB08 6 CHARS 2P<2 Digit Stepcode><2 Digit Status> 1 CHAR Sxxyyyyyyyyyyyy 15 CHARS S<2 Digit MAN> <12 Digit DMC/Seriennummer> © 2019 EnOcean | www.enocean.com STM 429J User Manual | v3.0 | May 2019 | Page 18/ 19... - Page 19 2 Pixel (UP, Down, Left und Right) Pixel Size: min. 4x4 points per Pixel 600dpi x 600dpi Resolution: 1 Printpoint: 0.0423mm x 0.0423mm 1 Pixel: 0.1693mm x 0.1693mm © 2019 EnOcean | www.enocean.com STM 429J User Manual | v3.0 | May 2019 | Page 19/ 19...
