StarTech.com ATX12V2.2 Instruction Manual page 7

S S p p e e c c i i f f i i c c a a t t i i o o n n s s
ATX2POWR350E
ATX2POWR400E
General Specifications
Output Power
Form Factor
Fan
Connectors
MTBF
AC Input Voltage
Efficiency
Operation
Temperature
Storage Temperature 40° ~ 70° C (104°F ~158°F)
Product Dimensions
(L x W x H)
Product Weight
Instruction Manual
ATX2POWR350E
350W
ATX12V Ver. 2.2
1 x 80mm Sleeve Bearing
1 x (20+4)-pin ATX split
connector
1 x 4-pin extended ATX for
P4
2 x SATA
5 x LP4
1 x SP4
100,000 hours @ 25° C (77° F)
110-115 V (AC); 220-
230V (AC)
65% @230V (AC)
0 ~ 50° C (122° F)
150 x 140 x 86 mm (5.9 x 5.5 x 3.4")
1.3 kg (2.87lbs)
4
ATX2POWR400E
400W
1 x (20+4)-pin ATX split
connector
1 x 4-pin extended ATX
for P4
2 x SATA
1 x PCI-E
5 x LP4
1 x SP4
110-115 V (AC); 220-
230V (AC)
70% @115/230V (AC)
1.52 kg (3.35lbs)
