350/400 Watt ATX12V 2.01 Dell
Replacement Computer Power Supply
ATXPW350DELL
ATXPW400DELL
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 07/05/2013
*actual product may vary from photos
Advertisement
Related Manuals for StarTech.com ATXPW350DELL
Summary of Contents for StarTech.com ATXPW350DELL
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 07/05/2013...
- Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
-
Page 3: Table Of Contents
Table of Contents Introduction ....................1 Features ................................ 1 Packaging Contents ..........................1 Compatibility .............................. 2 Installation ....................3 Specifications ..................5 Technical Support ..................7 Warranty Information ................7 Instruction Manual... -
Page 4: Introduction
Introduction Thank you for your purchase of a StarTech.com ATX 12V Dell replacement Power Supply. Designed for extra-long life in personal and industrial computers, this Power Supply is a suitable replacement for compatible Dell computers (Please see compatibility chart on Page 2), and features an 8cm fan to provide quiet operation and superior performance. -
Page 5: Compatibility
Compatibility CAUTION: ATXPW350DELL and ATXPW400DELL should not be used with any PCs other than those included in the following list of compatible systems. ATXPW350DELL Series Compatible Models 3000 / 3100 / 4600 / 4700 / 9100 / Dell™ Dimension® E310 / E510 Dell™... -
Page 6: Installation
1. Installation of a power supply requires some mechanical skill and requires that you open your computer case to disconnect and reconnect wires. If you are unfamiliar with this kind of work, consider bringing your computer and new StarTech.com power supply to your local computer store for help. - Page 7 correct; all four holes must be aligned. Support the power supply with one hand while threading a mounting screw through the back of the case and into the power supply. The screw should thread smoothly and should not require effort. Do not force it or you could damage the mounting holes.
-
Page 8: Specifications
Specifications L x W x H: 140 x 150 x 86mm Dimensions/Weight ATXPW350DELL: 1.9 kg (4.2lbs) ATXPW400DELL:: 2.15kg (4.74lbs) ATXPW350DELL: 115V (8A) or 230V (4A), 50-60Hz (Manual Switching) AC Input Voltage ATXPW400DELL: 115V (10A) or 230V (5.5A), 50-60Hz (Manual Switching) ATXPW350DELL: 350W Output Power (max.) - Page 9 ATXPW350DELL +3.3V +12V1 +12V2 -12V +5SB PS-ON Output 0.8A 2.5A Remote Return Max. 350 130W 300W 9.6W 12.5W 327.9W ATXPW400DELL +3.3V +12V1 +12V2 -12V +5SB PS-ON Output 2.5A Remote Return Max. 400 140W 348W 12.5W 375.5W Instruction Manual...
-
Page 10: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 11 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
