- Page 1 CHARGER OPERATOR’S MANUAL 56 VOLT CHARGER MODEL NUMBER CHX5500E WARNING: To reduce the risk of injury, the user must read and understand the Operator’s Manual before using this product. Save these instructions for future reference.
- Page 2 1. Power Cord 6. 3# LED (Red) 5. 2# LED (Green) 4. 1# LED (Green) 2. Output Interface 3. Button 8. Wall Mounting Hole 9. Cooling Air Port 7. Input Interface...
-
Page 3: Safety Symbols
Be sure to read and understand all ◾ safety instructions in this Operator’s Manual, including all Do not operate the EGO charger in explosive safety alert symbols such as “DANGER,” “WARNING,” environments, such as in the presence of and “CAUTION” before using this tool. Failure to follow all flammable liquids, petrols, or dust. -
Page 4: Safety Rules For Charger
EGO Service Center. ◾ ◾ The EGO charger can charge the EGO lithium-ion Do not disassemble the charger. Take it to an battery packs listed below: authorized service technician when service or repair is required. Incorrect reassembly may result in a risk of... -
Page 5: Specifications
2# LED on the charger will flash. If keep the green button pressed for at least 1 second, the normal charging will transform to rapid charging and green 2# LED goes out with green 1# LED flashing. 56 VOLT CHARGER — CHX5500E... -
Page 6: Wall-Mount Holes
If the LEDs still read charging while the charger confirmed as a defective one, “failure” a second time, contact the EGO center to repair it can cause electric shock or even serious injury. your charger. -
Page 7: General Maintenance
Use of any other parts may create a hazard or cause product damage. To ensure safety and reliability, all repairs should be performed by a qualified service technician at an EGO Service Center. 56 VOLT CHARGER — CHX5500E... -
Page 8: Troubleshooting
◾ Charger doesn’t work Allow the battery pack to reach normal temperature. Battery pack is too hot or and 3# LED shines Charging will begin when battery pack returns to normal too cold. red. temperature. 56 VOLT CHARGER — CHX5500E... -
Page 9: Service / Warranty
New Zealand 0508 000 EGO (0508 000 346) any time you have questions or warranty claims. SERVICE WARRANTY FOR ONE YEAR from the date of original retail purchase, the EGO Power+ System Battery Pack and Charger are warranted against defects in material or workmanship. Defective product will receive free repair.
