D-1. Parallel Interface

Be sure to turn the power to both the printer and host computer off before
changing the setting of the DIP switches.
Power off
1
ON
OFF
DIP switch 1
DIP switch 1
SW
1-1
Reset input conditions or Enable/disable
1-2
conditions IEEE1284 reverse mode
1-3
Always ON
1-4
Auto Cutter *1
1-5
Printing width *2
1-6
Automatic status function *3
1-7
Should not be change
1-8
Command emulation

Appendix D: DIP Switch Setting

8
Fig. D-1 DIP switch array
Function
– 159 –
Factory presetting: All on
ON
See table below
Should be set on
Invalid
210 dots
(420 half dots)
(400 half dots)
Invalid
(Should be set on)
Star
*1
OFF
Valid
200 dots
Valid
ESC/POS
