Description of control panel

(page 3 - B)
A number of buttons on the panel have a dou-
ble function. This is indicated in brackets in the
description.
B1. Display: guides the user in using the
appliance.
B2. Coffee taste button
B3. One/two cups short coffee button
B4. One/two cups standard coffee button
B5. One/two cups long coffee button
B6. Menu button to activate or deactivate
menu parameter setting mode
B7. Pre-ground coffee button
(When you access the MENU: NEXT button
to display the next menu parameter).
B8. Rinse button
heat the infuser.
(When you access the MENU: "CHANGE"
button to modify menu parameters).
B9. button: to deliver hot water or confirm.
(When you access the MENU: OK button to
confirm menu parameters).
PRELIMINARY CHECKS
Controls after transport
After removing the packaging, make sure the
product is complete and undamaged and that
all accessories are present. Do not use the ap-
pliance if it is visibly damaged. Contact Custo-
mer Services.
Installing the appliance
Important! When installing the appliance,
respect the following safety warnings:
• Installation must be performed by a qualified
professional in compliance with legislation in
force in the country of installation (see Bu-
ilt-in installation).
• The packing elements (plastic bags, poly-
styrene foam, etc.) should be kept out of
reach of children as they are a safety hazard.
• Do not install the appliance in rooms where
the temperature may drop to 0°C or lower
.
.
: performs a brief rinse to
(the water in the appliance could freeze and
cause damage).
• You should customise the water hardness as
soon as possible following the instructions
in the "SETTING WATER HARDNESS" chap-
ter.
Connecting the appliance
.
Danger! Check that the mains power sup-
.
ply voltage corresponds to the value indicated on
.
the appliance rating plate.
Connect the appliance to an efficiently earthed
and correctly installed socket with a minimum
current rating of 10A only.
If the power socket does not match the plug on
the appliance, have the socket replaced with a
suitable type by a qualified professional.
To comply with safety directives, an omnipolar
switch with a minimum contact distance of 3
mm must be installed.
Do not use multiple sockets or extensions.
To learn to use the appliance correctly, the first
time you use it follow the detailed instructions in
the following paragraphs.
Important! Safety cutout devices must
be included in the mains power supply in com-
pliance with the installation regulations in the
country concerned.
AUTOMATIC CUP TRAY
LIGHT
When the appliance is turned on, the lights (A6)
automatically light up the spout and cup tray.
The lights stay on until the appliance is turned
off.
While coffee, steam or hot water is being delive-
red, the cooling fan comes on.
At the end of the function, the cooling fan re-
mains on to avoid condensation forming inside
the cabinet. After several minutes, the fan goes
off automatically.
N.B.: The appliance completes this cycle
6
