Summary of Contents for EZ Way Smart Lift
- Page 1 EZ Way Smart Lift ® 500, 600 & 1,000 lb. Capacities Operator’s Instructions EZ Way, Inc. PO Box 89 Clarinda, IA 51632 1-800-627-8940 www.ezlifts.com Form 2-174 Rev. 8/10/18 WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
- Page 2 ® ® side of the lift mast from the battery receiver (See FIG. 1) by the model and serial number of the EZ Way Smart Lift and on the side of the control box. (See FIG. 2) ®...
- Page 3 Services covered under warranty include any labor that takes place at EZ Way Inc. Cost of Labor incurred while installing the warranty part at the place of ownership is not covered by this warranty. EZ Way Inc.’s obligation is limited to the replacement of parts that have been returned and are determined by EZ Way Inc.
- Page 4 Legs Insert battery Battery Insert a fully charged battery pack into the battery Receiver receiver on the mast of the EZ Way Smart Lift ® (See FIG. 1) Turn unit on Figure 1 Push the ON/OFF button. The EZ Way Smart...
- Page 5 Sling information and diagram EZ Way Slings are designed to be applied or removed with a minimum amount of handling of the patient. As patients do vary in size, shape, weight and temperament, these conditions must be taken into consideration when deciding which EZ Way Sling is suitable for each patient’s needs.
- Page 6 1) Make sure there are no cords or other objects near the path of the lift or under or near the bed that could obstruct the wheels of the lift. 2) Do not lock the wheels of the EZ Way Smart Lift when lifting or transferring patients.
- Page 7 (motor) as a handle for moving the EZ thigh. Continue on right knee. Way Smart Lift ® 2) Lean patient slightly forward and grasp the side handles or the center handle, pulling the sling...
- Page 8 2) With the sling handles and washing labels toilet or chair. facing the chair back, place the sling behind the 3) Do not lock the wheels of the EZ Way Smart patient, keeping the center handle of the sling Lift when lifting or transferring patients.
- Page 9 3) When the patient’s weight is supported by the bed continue lowering the lift to release the tension on the loops. (See Figure 11) 4) Detach sling from the EZ Way Smart Lift ® move the lift away from the patient.
- Page 10 Lift patient’s legs, pushing lift forward. Keep both legs together, laying the patient’s legs Multi-Purpose Slings over either side of the base of the EZ Way Smart These slings are used primarily for above the knee Lift . Note: While the previous instruction is ®...
- Page 11 Users must accept full responsibility for checking If the battery indicator on the EZ Way Smart Lift ® the condition of all slings and harnesses before each display window says “CHARGE BATTERY” or and every use on a patient.
- Page 12 Emergency lowering procedure Scale usage instructions 500 lb. and 600 lb. Capacity EZ Way Smart Lifts ® The EZ Way Smart Lift s do not require zeroing of ® 1) Position patient over bed or chair. the slings and has a weight-lock feature.
- Page 13 EZ Way Smart Lift Safety & Maintenance Checklist ® The EZ Way Smart Lift requires a minimum of servicing to keep it in good working order. ® Nevertheless, it is important that certain basic checks be periodically made by maintenance staff to ensure on-going safety throughout the life of the device.
- Page 14 Listen for any unusual noises while operating the unit. With the test load applied to the lift, check all structural welds for any signs of stress or fatigue cracks. If any unusual noises or cracks are found, stop using the lift and call the EZ Way Service Department immediately!
- Page 15 ® When an UP or DOWN command is executed the circuit board monitors weight readings from the scale load cell. If the weight measured is higher than the rated capacity of the EZ Way Smart Lift the control will ®...
- Page 16 Duty Cycle Fault – Helping to Protect EZ Way Smart Lift Actuator ® In the unlikely event the EZ Way Smart Lift has been run to the extent that it exceeds its duty cycle, the fol- ® lowing message will appear; ‘ACTUATOR DUTY CYCLE FAULT…COOLING’.
- Page 17 30 days, a reminder message will appear when the unit is turned on. The purpose of the inspection reminder is to notify the user that the EZ Way Smart Lift needs to be inspected using the EZ Way ®...
- Page 18 What are the 3 straps on the back of the sling for? 3. EZ Way Smart Lift - Sling Removal ® a) Demonstrate proper removal of sling from resident/patient. For any questions or concerns, please refer to the operator’s instructions or the EZ Way Smart Lift video. ®...
- Page 20 Form # 2-150 Revised 4/17/2007 Form #2-150 Rev. 7-31-18 EZ Way, Inc • (800) 627 - 8940 • Fax (712) 542 - 1899 • www.ezlifts.com WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov. To order slings, please call 1-800-627-8940. See a complete list of our accessories at...
