- Page 1 EZ Ceiling Lift System CL650 PM Portable Ceiling Lift Owner’s Manual • Use and features • Warranty • Specifications EZ Way, Inc. PO Box 89 Clarinda, IA 51632 1-800-627-8940 www.ezlifts.com Form #2-221 Rev. 7/26/18 WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
-
Page 3: Safety Notes
All washable EZ Way slings are capable of bearing a 1,000 lb. weight load, but must only be used to hold the amount of weight dictated by the EZ Way Ceiling Lift capacity. The EZ Way Portable Ceiling Lift has a lifting capacity of 650 lbs. -
Page 4: Lcd Display
Services covered under warranty include any labor that takes place at EZ Way Inc. Cost of Labor incurred while installing the warranty part at the place of ownership is not covered by this warranty. EZ Way Inc.’s obligation is limited to the replacement of parts that have been returned and are determined by EZ Way Inc. -
Page 5: Operating Controls
Transporting the Lift Letting out the Strap EZ Way recommends using a storage cart for To let out the strap, set the unit down on a transporting the lift from room to room. convenient surface and turn the lift on. (See the Hooking up the Lift next section.) Pull the strap taut and press the... - Page 6 Push the power button on the remote control. The EZ Way Ceiling Lift will display a greeting message while several diagnostic functions are performed. Down The EZ Way Ceiling Lift has a built-in timer that Button automatically shuts the unit off after a period of Charger inactivity.
- Page 7 Sling Information and Diagram EZ Way Slings are designed to be applied or removed with a minimum amount of handling of the patient. As patients do vary in size, shape, weight and temperament, these conditions must be taken into consideration when deciding which EZ Way Sling is suitable for each patient’s needs.
- Page 8 7) Repeat above step for right thigh. Step 2 Moving the Lift to the Patient 1) Move the EZ Way Ceiling Lift until the spreader hanger bar is centered over the patient’s torso. 2) Using the Down button, lower the hanger bar so it is positioned a few inches over the body of the patient.
- Page 9 NOTE: Do not use the hand control as a tether for out from behind the patient. (See FIG. 12) moving the EZ Way Ceiling Lift. Step 6 Lower Patient into Wheelchair, Toilet or Chair 1) Position the wheelchair under the patient and lock the wheels of the wheelchair.
- Page 10 Transferring Patient from Chair, Step 2 Moving the Lift to the Patient Wheelchair, or Toilet 1) Move the EZ Way Ceiling Lift until the spreader Step 1 hanger bar is centered over the patient’s lap. Position Sling 2) Using the Down button, lower the hanger bar so...
- Page 11 2) When the patient’s weight is supported by the bed continue lowering the lift to release the tension on the loops. (See FIG. 16) 3) Unhook sling from EZ Way Ceiling Lift and Figure 17 - Transferring from Floor move the lift away from the patient.
-
Page 12: Low Battery Signals
Charging the EZ Way Ceiling Lift Charger LED green - while the lift is on charge Battery A green charger light, while the lift is on charge, means that the batteries are fully charged. The charger plug should be taken out of the unit before the lift is removed from the charger location. -
Page 13: Emergency Lowering
Alert Messages To move the lift, push the lift along the track. The EZ Way Ceiling Lift has several built-in safety When a patient is in the lift, the operator may devices. An alert message is displayed on the LCD prefer to move the lift by placing a hand on the display whenever a fault is detected. - Page 14 The user must therefore examine the product to ensure its integrity before each use. EZ Way offers a 6-month warranty on slings and harnesses and recommends replacement after one year or if the sling or harness shows any sign of damage or wear.
- Page 15 EZ Way Ceiling Lift Safety & Maintenance Checklist The EZ Way Ceiling Lift was designed to safely operate throughout its life with a minimum amount of service. EZ Way recommends the following items be checked periodically to ensure safe operation of the lift.
- Page 16 With the unit under load, operate the lift in both the up and down directions. The lift should operate smoothly and quietly. If any excessive noise is heard, call EZ Way Service at 800-627-8940. Move the lift along the track. The lift should travel smoothly and quietly.
- Page 17 Mechanical Failure In the event of a motor overload, the EZ Way Ceiling Lift will only operate in the DOWN direction. When the motor overload count is greater than 4, a fault message will display when the unit is turned on, reading ‘MOTOR OVERLOAD…CALL EZ WAY SERVICE’.
- Page 18 Duty Cycle Fault – Helping to Protect EZ Way Ceiling Lift Motor In the unlikely event the EZ Way Ceiling Lift has been run to the extent that it exceeds its duty cycle, the following message will appear; ‘MOTOR DUTY CYCLE FAULT…COOLING’.
- Page 19 30 days, a reminder message will appear when the unit is turned on. The purpose of the inspection reminder is to notify the user that the EZ Way Ceiling Lift needs to be inspected using the EZ Way Safety &...
- Page 20 Demonstrate proper removal of sling from underneath resident/patient. 3. EZ Way Ceiling Lift Operation a) Where should the hanger bars be located when attaching the sling to the unit? For any questions or concerns, please refer to the EZ Way Ceiling Lift operator’s manual or training video.
