EZ Way SMART LIFT Quick Reference Manual

EZ Way, Inc.
Product Overview
1. Fit the the sling to the resident, ensuring correct size
is used. Ensure the sling is attached properly following
the instructions for that sling.
2. Position the Smart Lift in front of the person, open the
lift legs, if necessary, to get around obstacles.
3. Lower the boom and position green nose cone over
person's torso. Do not lock the rear wheels.
4. With the hanger bars parallel to the person's body,
attach the sling loops to the hanger bar hooks using
the same length and color of loop on each side.
This quick Reference guide has been created to assist healthcare professionals
and other users with only the functional aspects of the system. The guide
does not replace the general safety warnings, cautions and recommendations
provided in the product instructions for using the EZ Way Smart Lift.
REFER TO THE PRODUCT INSTRUCTIONS FOR USE BEFORE
USING THIS PRODUCT.
QUICK REFERENCE GUIDE
SMART LIFT
5. Using the hand control, raise the person to to the
needed height for the transfer.
6. Close-up legs and transfer person to desired location.
7. Position the person over the chair, bed or toilet
and lower to a sitting position or supine position,
dependent on the transfer.
8. Lower the boom enough to remove the sling loops
from the hanger bar hooks and move the unit away
from the person.
9. Remove the sling from around the person, unless the
sling designed to remain under the person.
Attach sling loops to
the hanger bar hooks
using the same length
and color of loop on
each side.
Use the hand control to
operate.
Only for emergency,
use the emergency
lowering handle to
lower the person on
the 500 lb. & 600 lb.
models. Turn the red
collar clockwise on the
1,000 lb. lift.
