Summary of Contents for Drive DeVilbiss sidhil Innov8

  • Page 1 Innov8 Low General Ward Bed Instructions for use...
  • Page 4: Table Of Contents

    CONTENTS 1. INTRODUCTION 2. CONTACT INFORMATION 3. PRODUCT DESCRIPTION 3.1 Environment 3.2 Intended Patient Group 3.3 Intended Use 3.4 Product Overview 3.5 Features 4. SAFETY 4.1 Warnings & Cautions 4.2 Risk Assessment 4.3 Contraindications 4.4 Bed Loading 4.5 Training 4.6 General Warnings 5.
  • Page 5 9.12.13 Patient Handset 10. ADDITIONAL FEATURES 10.1 Equipotential Stud 10.2 Corner Sockets 11. DECONTAMINATION 11.1 Cleaning & Disinfection Guidelines 11.2 Steam Cleaning 12. MAINTENANCE 12.1 General Inspection 12.2 Fault Finding 12.3 General Maintenance 13. DISPOSAL OF PARTS & ENVIRONMENTAL CONSIDERATIONS 14.
  • Page 6: Introduction

    2. 2. CONTACT INFORMATION For any service, warranty, sales or customer service information on this product please contact your provider or if in doubt contact Drive DeVilbiss Healthcare Ltd. at the following address: Drive DeVilbiss Healthcare Ltd.
  • Page 7: Product Description

    3. PRODUCT DESCRIPTION 3.1 Environment The Innov8 Low bed is intended for use in a hospital where acute/intensive care is provided and medical supervision and monitoring is required. 3.2 Intended Patient Group The bed frame is intended for an adult who is up to 190kg in weight. A lower (or upper) age limit is not defined as it depends on the physical size of the patient in relation to the various proportions and gaps around the bed frame.
  • Page 8: Product Overview

    3.4 Product Overview The Innov8 Low bed is intended to be plugged into a permanent mains supply however it also has a battery backup system for such times that a mains supply is not available. The bed has two separate handsets, one for the carer with full control capability and one for the patient with limited functionality and limited height adjustment.
  • Page 9: Safety

    4. SAFETY 4.1 Warnings & Cautions Warnings in this user manual highlight potential hazards that if disregarded could lead to injury or death. Warning Cautions in this user manual highlight potential hazards that if disregarded could lead to equipment damage or failure. Caution 4.2 Risk Assessment Before a patient uses the bed a risk assessment must be performed on a patient by...
  • Page 10: Contraindications

    4.3 Contraindications Patient conditions for which the use of the bed is a contraindication are as follows: • Cervical or skeletal traction – If bed functions remain unlocked. • Unstable spinal fractures – If bed functions remain unlocked. • General skeletal fractures – If relevant bed functions remain unlocked. •...
  • Page 11: Training

    For further information in regards to training options please contact Drive DeVilbiss Healthcare Ltd. or your local provider (see section 2).
  • Page 12: Transport & Storage

    5. TRANSPORT & STORAGE The following conditions should be followed when transporting and storing the Innov8 Low bed. Note, this does not apply to the transfer of the bed between wards and / or when the bed is in use (see section 9.4). •...
  • Page 13: Symbol Definition

    6. SYMBOL DEFINITION The following symbols are found on this bed: (See section 9.12 for handset symbols) Symbol Description Warning Beware of potential hazard Caution Beware of potential product damage Refer to instructions for use - Recommended Failure to read the instructions for use could introduce a hazard Refer to instructions for use - Mandatory Failure to read the instructions for use could introduce a hazard Maximum patient weight...
  • Page 14 Symbol Description Equipotential stud Minimum patient weight 40 kg Minimum patient BMI BMI 17 Minimum patient height 146 cm Type B applied part Lot number Product code Date of manufacture Manufacturer W.E.E.E Label - Found on individual parts of electrical system (Waste Electrical and Electronic Equipment) Refer to section 13...
  • Page 15: Parts Identification

    7. PARTS IDENTIFICATION Accessory Removable Mattress Safety side mounting points mattress panels retainers rails Removable head and foot ends Carer handset Patient handset Manual CPR handle Bed extension release plunger Brake bar...
  • Page 16: Installation & Preparing For Use

    A CE marked extension cable must only be used when it is not possible to reach a wall socket with the mains cable – Contact Drive DeVilbiss Healthcare Ltd. for detail with regards to the safe use of extension cables.
  • Page 17 • If an extension cable is used never overload it by plugging in appliances that together will exceed the maximum current rating stated for the extension cable. • Block adaptors are not to be used. • Ensure socket outlets are not positioned under the bed frame. •...
  • Page 18: Operation Of The Bed

    9. OPERATION OF THE BED 9.1 Operational Limits • Ambient temperature: +5°C to +40°C • Humidity: 20% - 90% at 30°C - not condensing • Atmospheric pressure: 70kPa to 106kPa (altitude ≤ 2000m) 9.2 General Safety • Before operating the bed ensure the patient is positioned appropriately and limbs are clear of moving parts.
  • Page 19: Brake & Steering System

    9.3 Brake & Steering System The brake bar at the foot end of the bed operates all four castors simultaneously. Brake bar down (brake): All four castors are locked - the bed cannot move. Brake bar horizontal (free): All castors swivel freely - the bed can move in any direction.
  • Page 20: Moving The Bed

    The brakes must always be engaged when the bed is stationary. Warning When the pedal is in the tracking position the mattress platform must not be lower than 400mm from the floor. Lowering the mattress platform to the minimum height with the pedal in the tracking position Caution could lead to equipment damage.
  • Page 21 When moving the bed it is advisable to set the steering function to ‘track’ and to push the bed from the foot end of the bed. This way, the person pushing the bed is able to monitor the condition of the patient during transport and can keep the bed moving in a straight line with minimal effort.
  • Page 22: Side Rails & Mattresses

    The side rails available for the Innov8 Low are product specific, no other side rail is to be used with the bed. Drive DeVilbiss Healthcare does not recommend the use of the Innov8 Low side rails (and bed) when caring for individuals who are less than 146cm in length, due to the potential risk of entrapment - It is the equipment provider’s...
  • Page 23: Operating The Side Rails

    9.7 Operating the Side Rails When operating the side rails ensure they are free from obstructions, to prevent injury/entrapment. Warning To Lower: Hold the top rail and pull out the release plunger. Gently lower the side rail towards the foot end of the bed. To Raise: Hold the top rail and lift the side rail until it locks into the vertical position.
  • Page 24: Bed Extension

    9.8 Bed Extension The bed has an integral bed extension which allows the bed to be adjusted in length, according to the patient’s needs. The length extension is typically for patients who exceed 185cm in length and gives the bed compatibility with patients up to 205cm. The length extension is only used for those individuals who require it due to their physical height requirements, it is not to be kept in the extended position as the default for all occupants.
  • Page 25 • Pull out the leg extension to its maximum extent. • If previously removed replace the bed end. To retract the bed extension: • Push the leg extension in. • Pull out the spring loaded plunger located on the side of the bed near the foot end and, whilst holding it out, rotate it by a quarter turn (the plunger should stay out).
  • Page 26: Emergency Cpr Function - Manual

    9.9 Emergency CPR Function - Manual The backrest can be levelled using the manual CPR handles located on both sides of the bed. To flatten the backrest in an emergency, pull one of the red and black handles outwards; the backrest will now drop into a flattened state. CPR handle (both sides) Note: The platform will not level itself or change height when the manual handles...
  • Page 27: Bed Ends

    9.10 Bed Ends The bed has plastic end panels which are easily removable, allowing for fast patient access. To remove, hold the panel with both hands and lift squarely. The head and foot end panels are of different heights, the foot panel is shorter and can be identified by the small foot motif on one side of the panel and must always be placed at the foot end of the bed.
  • Page 28: Electrical Operation Of The Bed

    9.12 Electrical Operation of the Bed 9.12.1 Carer Handset Layout...
  • Page 29 • The carer handset controls all bed functionality; it is to be used only by the carer. The carer handset is intended to be stored at the foot end of the bed by clipping it over the bed end panel, keeping it out of reach of the bed occupant.
  • Page 30: Operating The Carer Handset

    9.12.2 Operating the Carer Handset Green light: To activate a function, press the desired function Function button. A green light will illuminate at the top of the active function button, this indicates the function is now active. Once the function button is active hold down one of the direction buttons, until the required position is reached.
  • Page 31: Platform Height

    9.12.4 Platform Height The platform height button allows adjustment of the mattress platform height. The carer handset can be used to lower the mattress platform to a lower height than can be achieved using the patient handset. When the bed reaches a height of 420mm, a single auditory signal will sound and the platform speed will slow to signify to the carer that the bed is being operated in the low height region and care should be taken to ensure that no equipment is...
  • Page 32: Leg Section

    9.12.6 Leg Section The leg section button on the carer handset allows adjustment of the leg section. When the function on the handset is operated the height or angle of the section is adjusted, depending on whether or not the leg stay bar is engaged. In normal use the leg section operates in angle adjustment mode where the thigh and calf sections angle upwards as the function is operated, as depicted by the graphic on the button.
  • Page 33: Auto Contour

    To minimise the risk of injury, before attempting to lift the calf section either: • Ensure there is no load on the section, or • Support the calf section with a second able bodied person. Warning The leg section is only to be used for the lifting of a patient’s legs – Any other use may damage the bed frame.
  • Page 34: Cardiac Chair

    9.12.9 Cardiac Chair Green lights: The bed can be automatically profiled into a cardiac chair Function active position, where the platform is automatically profiled into the auto contour and foot down tilt positions together. This allows for a comfortable seated position for the patient whilst remaining in the bed.
  • Page 35: Mains Power Indicator

    9.12.11 Mains Power Indicator The carer handset has an amber mains power light in the upper left corner. When illuminated it signifies that the bed is plugged in and operating on mains power. If it is not illuminated the bed is either unplugged or has a fault.
  • Page 36: Patient Handset

    9.12.13 Patient Handset • Ensure a risk assessment is undertaken to ensure the suitability of the occupant or a visitor using the patient handset. • The patient handset cable must also be considered in regards to the risk of accidental strangulation of the bed occupant – If the cable introduces an unacceptable risk it is recommended that the Warning handset and cable are moved out of reach.
  • Page 37: Additional Features

    (using 2 POAG-KBT6DIN connectors) must be connected to the studs between the bed and relevant device. Please contact the Drive DeVilbiss Healthcare customer service team for details of the necessary cable. Only items that have been inspected by a trained electrical professional, and under their advice, should be connected to the Innov8 Low.
  • Page 38: Decontamination

    11. DECONTAMINATION • Always disconnect the bed from the main power supply prior to cleaning. • Ensure all ports on the electrical system (control box and actuators) have cable plugs inserted to maintain the IP rating. • Regular cleaning and disinfection of the bed frame and relevant accessories will help to prevent the risk of infection to the occupant Warning and / or carer.
  • Page 39: Steam Cleaning

    In cases of blood spills or other bodily fluids it is recommended that a 1% Chlorine solution (10,000ppm) is used instead. If any of the stages stated are omitted or combined it will reduce the effectiveness of the clean. The use of neat bleach or similar surface cleaners are not recommended as damage may be caused to the cleaned surfaces.
  • Page 40: Maintenance

    12. MAINTENANCE 12.1 General Inspection Drive DeVilbiss Healthcare recommends that the carer performs frequent visual and operational inspections. If there are any signs of damage or the bed is not performing as it should withdraw it from service until the bed has been repaired and is fit for use again.
  • Page 41: Fault Finding

    12.2 Fault Finding Listed below are a set of electrical faults that may occur within the service life of the bed. If a fault does occur please try the following suggestions, as these may help in diagnosing the fault. Fault Possible cause Remedy Electrical...
  • Page 42: General Maintenance

    DeVilbiss Healthcare Ltd or your local distributor. • Linak battery packs may emit an increased amount of flammable gas as they age – risk of explosion / fire. Drive DeVilbiss Healthcare advise that batteries are replaced every 4 years or sooner. •...
  • Page 43 • Check the castors lock, track and swivel correctly. If in doubt about correct replacement of a component contact Drive DeVilbiss Healthcare Ltd or your local distributor. Refer to the service manual for cable routing diagrams, parts codes / lists, maintenance instructions etc. Copies are available from...
  • Page 44: Disposal Of Parts & Environmental Considerations

    When the bed frame / electrical system has come to the end of its useful life contact your provider or Drive DeVilbiss Healthcare Ltd. (see section 2) to arrange for collection, alternatively follow local recycling and W.E.E.E. (Waste Electrical and Electronic Equipment) policies.
  • Page 45: Electromagnetic Compatibility (Emc)

    The bed is to be installed and put into service according to the information provided within this section to ensure of reliable operation, however if the bed continues to operate abnormally turn off at the mains supply and contact Drive DeVilbiss Healthcare Ltd. or your local distributor (see section 2).
  • Page 46: Specification

    15. SPECIFICATION 15.1 Bed Specification Overall length: 2180mm Integral length extension: 200mm Overall width: 1020mm Mattress platform height: 225mm – 710mm Under bed clearance: 120mm (platform at 400mm) Mattress platform length: 2000mm Mattress platform width: 900mm Head / Foot down tilt: ±...
  • Page 47: Performance Characteristics

    15.2 Performance Characteristics Voltage in: 230V ±10%, ~50/60Hz Current in: 1,25A Mains cable fuse: 3-10A Energy consumption in standby mode: 0.0025kWh Energy consumption at maximum load: 0.27kWh Duty cycle*: 2 mins of continuous use followed by 18 mins not in use. * Electrically operated beds are intended to be operated intermittently rather than continuously.
  • Page 48: Accessories

    Plus II DYN/DIG/PLUS/2 2000mm 880mm 220mm SoloXtra DYN/DIG/SOLO/XTR 2000mm 880mm 160mm Acclaim Flow MAT/ACCL/FLOW 1990mm 880mm 152mm Other Drive DeVilbiss Healthcare mattresses available upon request – Contact your provider or Drive DeVilbiss Healthcare Ltd. to check for compatibility and suitability purposes.
  • Page 49: Mattress / Side Rail Compatibility Chart

    Drive DeVilbiss Healthcare cannot be held responsible for any injury or incident which relates to the use of any product combinations not approved by Drive DeVilbiss Healthcare Ltd. It is the carer’s responsibility for selecting and fitting the products correctly and...
  • Page 50: Warranty

    All replaced parts and products on which a refund is made become the property of Drive DeVilbiss Healthcare Ltd. Repaired or replaced parts and products are warranted for the remainder of the original warranty period.
  • Page 51: Notes

    18. NOTES...
  • Page 52 Drive DeVilbiss Sidhil Ltd. • Sidhil Business Park, Holmfield, Halifax, HX2 9TN • sales@sidhil.com www.sidhil.com • Tel: +44 (0) 01422 233000 Fax: +44 (0) 01422 233010 A member of the Drive DeVilbiss Group of Companies (93/42/EEC) ORIGINAL INSTRUCTIONS INSTRUC/INNOV8/LOW rev14...
