Dimensions; Kx61-3 Dimensions - Kubota KX61-3 Operating Instructions Manual

Description of the excavator

Dimensions

For the dimensions of the KX61-3 and KX71-3, refer to the following figures and the table.

KX61-3 Dimensions

All dimensions in mm
KX61-3 A B C
1* 2490 2050 4360
2* 2740 2290 4540
Arm version
Name
1* Arm 1050 mm
2* Arm 1300 mm
D E F G H
3060 1830
1160 2410 350
3240 1880
I J K L M
3110
310 1560 1990 1290
3150
N O P Q
4350 4480
600 590 1400
4600 4720
Type
A = 1050 mm
A = 1300 mm
R S T
1360 1400
33
