The DTX-PLA002PRP is a set of contact tips and latches that
replace worn tips and latches on DTX-PLA002 permanent link
adapters.
The kit comes with the following:
Two 8-pin modular (RJ45) tips
Two latches
Two screws
Two conductive washers
Installation instructions
PN 2712841 (English) July 2006
