- Page 1 Autorisierter Distributor DSX-PCxx Patch Cord Adapters Users Manual February 2014, Rev. 1 3/2018 ©2014, 2018 Fluke Corporation All product names are trademarks of their respective companies.
- Page 2 Fluke Networks authorized resellers shall extend this warranty on new and unused products to end-user customers only but have no authority to extend a greater or different warranty on behalf of Fluke Networks. Warranty support is available only if product is purchased through a Fluke Networks authorized sales outlet or Buyer has paid the applicable international price.
-
Page 3: Table Of Contents
Introduction .....................1 Kit Contents ......................1 DSX-PC5ES ....................1 DSX-PC6S ..................... 1 DSX-PC6AS ....................1 Contacting Fluke Networks ................2 Additional Resources for Cable Testing Information ........2 Safety Information ..................2 DSX Software Requirements ................3 Characterize the Performance of the Adapters ..........3 How to Do Tests on Patch Cords ..............3 How to Set Up the Tester ................ - Page 4 DSX-PCxx Patch Cord Adapters Users Manual Replacement Parts ..................11 How to Replace the Jacks ................12 Specifications ....................13 Appendix A: How to Characterize and Verify the Adapters’ Performance .. 15...
-
Page 5: Introduction
ANSI/TIA and ISO/IEC standards. The adapters have RJ45 jacks that Fluke Networks selects specifically for tests on Cat 5e and 6 patch cords as specified in TIA-568-C.2 and IEC 61935-2, and Cat 6 patch cords as specified in IEC 61935-2. -
Page 6: Contacting Fluke Networks
1-800-283-5853, +1-425-446-5500 Fluke Networks 6920 Seaway Boulevard, MS 143F Everett WA 98203 USA Fluke Networks operates in more than 50 countries worldwide. For more contact information, go to our website. Additional Resources for Cable Testing Information For more information on the DSX CableAnalyzer, see the Versiv Series manuals available on the Fluke Networks website. -
Page 7: Dsx Software Requirements
2 Turn on both testers. 3 On the main tester tap TOOLS, then Version Information. The latest DSX software version is available at no charge on the Fluke Networks web site. Download the update file from the website, then use LinkWare ™... - Page 8 HDTDR/HDTDX: Fail/Pass* only. If you want time-domain reflectometry and time-domain crosstalk plots for all the patch cords you test, select All Autotests. For more information about the HDTDR and HDTDX tests, see the Versiv Series Technical Reference Handbook available on the Fluke Networks website. ...
-
Page 9: How To Do The Patch Cord Test
How to Do Tests on Patch Cords How to Do the Patch Cord Test Note For DSX-PC6A adapters: Typically, you can move an RJ45 plug slightly in or out of the jack even when the latch engages. For Cat 6 patch cords, the two positions can give slightly different results for a patch cord test. -
Page 10: Patch Cord Test Results
DSX-PCxx Patch Cord Adapters Users Manual Patch Cord Test Results Patch cord tests evaluate these characteristics: Wire map Return loss NEXT The patch cord test specifications assume that insertion loss (attenuation), ACR-F (ELFEXT), DC resistance, length, propagation delay, and delay skew requirements are met by the patch cord's design, thus, test limits for these measurements are not required. -
Page 11: Wire Map Failures
Patch Cord Test Results Wire Map Failures Wire map failures are typically caused by these problems: Wires connected to wrong pins at plug Faulty connections Damaged plug Damaged cable Wrong Outlet Configuration selected on the TEST SETUP screen ... -
Page 12: Is The Cable Bad Or Is The Plug Bad
DSX-PCxx Patch Cord Adapters Users Manual Is the Cable Bad or is the Plug Bad? You can use the HDTDX and return loss plots to see if a patch cord failed because of bad cable or a plug that is bad or poorly installed. See Figures 2 and 3. C02.EPS HDTDX plots for a bad cable show high Bad cable often causes return loss failures at... - Page 13 Patch Cord Test Results C05.EPS HDTDX plots for a bad plug show high A bad plug often causes return loss failures crosstalk at the plug. at high frequencies. Typically, the test fails or has the worst margin at the end with the bad plug.
-
Page 14: Mechanical Stress Tests For Patch Cords
DSX-PCxx Patch Cord Adapters Users Manual Mechanical Stress Tests for Patch Cords Every patch cord design should be evaluated for changes in performance, especially return loss performance, under mechanical stress. Refer to the ANSI/ TIA or ISO/IEC standards for more information about stress tests. Since it is not practical to do the stress tests on every patch cord produced, you can do tests on samples of your patch cords to ensure quality. -
Page 15: How To Monitor The Number Of Insertions For A Jack
Reset Series. How to Order Replacement Jacks Table 1 shows the replacement parts available for the DSX-PCxx Patch Cord Adapters. To order replacement jacks, contact Fluke Networks as described on page 2. Replacement Parts Table 1. Replacement Parts... -
Page 16: How To Replace The Jacks
DSX-PCxx Patch Cord Adapters Users Manual How to Replace the Jacks Caution To prevent damage to the adapters and to make sure that your test results are as accurate as possible: The DSX-PCxx adapters have static-sensitive components. When you replace the RJ45 jack, obey rules to prevent electrostatic discharge (ESD). -
Page 17: Specifications
Level IIIe requirements at ISO/IEC Cat 6 patch cord test limits. For more DSX-PCxx Patch Cord Adapter specifications, contact Fluke Networks. For DSX CableAnalyzer specifications, refer to the Versiv Series Technical Reference Handbook available on the Fluke Networks website. - Page 18 DSX-PCxx Patch Cord Adapters Users Manual...
-
Page 19: Appendix A: How To Characterize And Verify The Adapters' Performance
Appendix A: How to Characterize and Verify the Adapters’ Performance Introduction This appendix tells how to characterize the performance of the DSX-PCxx adapters. Later, you can do the test again to see if the adapters are operating correctly. How to Characterize the Adapters When you first get the patch cord adapters, do this procedure to characterize their performance. - Page 20 DSX-PCxx Patch Cord Adapters Users Manual 6 Mark the reference patch cord ends with “main” and “remote” as it was connected for the test. Keep the reference patch cord to use later for performance tests on the adapters. Caution For consistent return loss measurements from the reference patch cord, do not put mechanical stress on the cord during tests or storage.
- Page 21 Note If you replaced the jacks on the adapters, the difference between the old and new margins can be more than 0.5 dB. If the difference is more than a few dB, make sure the new jacks are installed correctly and the adapters show no damage.
- Page 22 DSX-PCxx Patch Cord Adapters Users Manual Autorisierter Distributor...
