User's Manual
SUN-OPM200 Series
Fiber Optic Power Meter
English
Table: SUN-UM-TE-OPM004
Version: A/0
All the trademarks mentioned in this manual are registered property of Sun Telecom.
The right to interpret this manual is reserved by Sun Telecom.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SUN-OPM200 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sun Microsystems SUN-OPM200 Series

Summary of Contents for Sun Microsystems SUN-OPM200 Series

  • Page 1 User’s Manual SUN-OPM200 Series Fiber Optic Power Meter English Table: SUN-UM-TE-OPM004 Version: A/0 All the trademarks mentioned in this manual are registered property of Sun Telecom. The right to interpret this manual is reserved by Sun Telecom.
  • Page 3 F i b e r O p t i c S o l u t i o n s P r o v i d e r NOTICE Safety Sign: When using the optical power meter, always take bask safety precautions to reduce the harm for the testers, and injury to persons.
  • Page 4 F i b e r O p t i c S o l u t i o n s P r o v i d e r battery leakage. If leakage occurred, Please do not touch. 3. To prevent electric shock, do not open the product case, only the authorized qualified professionals can do the maintenance;...

  • Page 5: Table Of Contents

    F i b e r O p t i c S o l u t i o n s P r o v i d e r Contents Chapter 1: Standard configuration ...............1 Chapter 2: Overview ....................1 Chapter 3: Specifications ..................2 Chapter 4: Function .....................3 Chapter 5 OPM Software ...................14 Chapter 6 Operation Instruction and Notes ............31...

  • Page 6: Chapter 1: Standard Configuration

    ST Adapter Chapter 2: Overview SUN-OPM200 Series Handheld Optical Power Meter is a newly designed fiber optic tester, which aims at the installation, engineering acceptance and maintenance of fiber network. Compared with other usual power meters, this power meter has more...

  • Page 7: Chapter 3: Specifications

    F i b e r O p t i c S o l u t i o n s P r o v i d e r 2/54  Up to 200hrs battery life Chapter 3: Specifications Model SUN-OPM200-TC SUN-OPM200-BC Calibration Wavelength (nm) 850/1300/1310/1490/1550/1625 Detector type...

  • Page 8: Chapter 4: Function

    F i b e r O p t i c S o l u t i o n s P r o v i d e r 3/54 Chapter 4: Function 4.1 Front Power Key ON/OFF the instrument Power Saving setting: the unit will automatically shut off after 15 minutes idle time, whatever in the condition of battery power supply or AC power supply.
  • Page 9 F i b e r O p t i c S o l u t i o n s P r o v i d e r 4/54 Wavelength Selection/Wavelength Identify Short press this key to switch the wavelength and display it on the top left of the LCD screen, 1310nm is the default wavelength Press the for 2 seconds, enter into wavelength auto-identify, on the...
  • Page 10 F i b e r O p t i c S o l u t i o n s P r o v i d e r 5/54 the default mode back light control key mode. Press to on/off the back light Saving/Data-view Key.
  • Page 11 F i b e r O p t i c S o l u t i o n s P r o v i d e r 6/54 Delete/Cancel Key. (1) Data Deletion. When view the data, press to delete the record. (2) Cancel the saving.
  • Page 12 F i b e r O p t i c S o l u t i o n s P r o v i d e r 7/54 mW, uW and nW conversion: 1mW=103uW=106nW REF Setting: To store the current power value as the reference value which will be displayed on the top right of the LCD screen, at the same time the “Ref “...
  • Page 13 F i b e r O p t i c S o l u t i o n s P r o v i d e r 8/54 (8) “B/L SET” Backlight Indicator Indicate backlight control mode. Green light indicate that “LDR” intelligent backlight control mode, Red light indicate that key-control mode (9) “LDR “...
  • Page 14 F i b e r O p t i c S o l u t i o n s P r o v i d e r 9/54 Notice: Please only use the power supply unit supplied with the tester, use other kind of PSU may cause damage to the instruments.
  • Page 15 F i b e r O p t i c S o l u t i o n s P r o v i d e r 10/54 4.3 Top (1) Dust Cap In order to protect the optical connector, avoid damage on the connector, as a result of that, when the tester not in use, please make sure that you place the dust cap over the connectors.
  • Page 16 F i b e r O p t i c S o l u t i o n s P r o v i d e r 11/54 4-8 Φ2.5mm universal connectors 4-7 FC connector Notice: When change the optical connector, take care for the connector and the end-face.
  • Page 17 F i b e r O p t i c S o l u t i o n s P r o v i d e r 12/54 4-10 4.4 Backside 4-11 (1) Label Content include the function, and the instrument information (2) Bracket Collapsible metal bracket, 0 ~ 90 degree can adjust.
  • Page 18 F i b e r O p t i c S o l u t i o n s P r o v i d e r 13/54 (3) Battery Pack: 3 pieces of 1.5V AA batteries. Notice: When insert the batteries, take a note of their positive (+) and negative (-) connector orientation.

  • Page 19: Chapter 5 Opm Software

    F i b e r O p t i c S o l u t i o n s P r o v i d e r 14/54 Chapter 5 OPM Software 5.1Install the device Run the software in the PC, find the “Driver.exe” as show in the below Double click that “exe”...
  • Page 20 F i b e r O p t i c S o l u t i o n s P r o v i d e r 15/54 Press “OK” to exit this install interface. However the driver still haven’t install yet, continue the following operation: Use USB cable connect with power meter and the PC, switch on the instrument, and pop up 5-3...
  • Page 21 F i b e r O p t i c S o l u t i o n s P r o v i d e r 16/54 Wait for a second, pop up 5-5. www.suntelecom.cn • +86-21-60138638 • ics@suntelecom.cn...
  • Page 22 F i b e r O p t i c S o l u t i o n s P r o v i d e r 17/54 Press “Finish”, complete the deriver Installation. Please check if the installing is complete or not, to avoid the communication problem when power meter connect with the PC.
  • Page 23 F i b e r O p t i c S o l u t i o n s P r o v i d e r 18/54 www.suntelecom.cn • +86-21-60138638 • ics@suntelecom.cn...
  • Page 24 F i b e r O p t i c S o l u t i o n s P r o v i d e r 19/54 After success install the devices, can switch off the power meter, and disconnect the USB.
  • Page 25 F i b e r O p t i c S o l u t i o n s P r o v i d e r 20/54 Press “Next “, and pop up 5-9. www.suntelecom.cn • +86-21-60138638 • ics@suntelecom.cn...
  • Page 26 F i b e r O p t i c S o l u t i o n s P r o v i d e r 21/54 Choose “I accept …… “, Click “Next ", pop up 5-10. www.suntelecom.cn • +86-21-60138638 • ics@suntelecom.cn...
  • Page 27 F i b e r O p t i c S o l u t i o n s P r o v i d e r 22/54 5-10 Choose “I accept ……” click “Next”, pop up 5-11. www.suntelecom.cn • +86-21-60138638 • ics@suntelecom.cn...
  • Page 28 F i b e r O p t i c S o l u t i o n s P r o v i d e r 23/54 5-11 Click “Next “, pop up5-12. www.suntelecom.cn • +86-21-60138638 • ics@suntelecom.cn...
  • Page 29 F i b e r O p t i c S o l u t i o n s P r o v i d e r 24/54 5-12 Wait for a seconds, Pop up 5-13. www.suntelecom.cn • +86-21-60138638 • ics@suntelecom.cn...
  • Page 30 F i b e r O p t i c S o l u t i o n s P r o v i d e r 25/54 5-13 Click “Finish” to complete the installation. 5.3 Software function instruction This software has two functions: data processing, and the instrument setting. After finish the software, find the short cuts icon for this software.
  • Page 31 F i b e r O p t i c S o l u t i o n s P r o v i d e r 26/54 5.3.1 Data Processing 5-14 Data Processing interface include 4 parts. (1) Manual a) Port Option.
  • Page 32 F i b e r O p t i c S o l u t i o n s P r o v i d e r 27/54 b) Connect icon, Connect the PC with the power meter, and communicate. c) Language option, Drop-down the selection, Find the right language for the user preference, Chinese/ English.
  • Page 33 F i b e r O p t i c S o l u t i o n s P r o v i d e r 28/54 (2) Testing information form Fill the information in blank (3) Printing button to print the measurement value. (4) Data process button a) Upload the data to the PC;...
  • Page 34 F i b e r O p t i c S o l u t i o n s P r o v i d e r 29/54 5.3.2 Power Meter setting 5-15 The Power Meter setting interface, pic. 5.3.2, which include 4 parts: (1) Manu bar (Please refer description in data process interface) (2) Calibration, the user can do the self-calibration.
  • Page 35 F i b e r O p t i c S o l u t i o n s P r o v i d e r 30/54 (3) Time Setting. (4) Recover the factory default setting. Power meter calibration recovers the factory default setting.

  • Page 36: Chapter 6 Operation Instruction And Notes

    F i b e r O p t i c S o l u t i o n s P r o v i d e r 31/54 Chapter 6 Operation Instruction and Notes 6.1 Powering the Optical Power Meter The optical power meter can be battery powered or AC adaptor powered, giving total flexibility for most testing sites and situations 6.1.1 AA battery...
  • Page 37 F i b e r O p t i c S o l u t i o n s P r o v i d e r 32/54 Press the clip fastener on the battery compartment cover down. Remove the battery compartment cover;...
  • Page 38 F i b e r O p t i c S o l u t i o n s P r o v i d e r 33/54 When use the AC adaptor, connect the power plug as pic 6-4, and insert to the AC socket.
  • Page 39 F i b e r O p t i c S o l u t i o n s P r o v i d e r 34/54 to open the tester, 6-5 is the opening interface When the tester is standby, press key can cancel or choose auto-off function.
  • Page 40 F i b e r O p t i c S o l u t i o n s P r o v i d e r 35/54 6.3.2 Choose the key control backlight mode. , “B/L SET “indicator turns to red (6-7), enter into key control Long press backlight mode, after 10 seconds the indicator off, short press ON/OFF the backlight.
  • Page 41 F i b e r O p t i c S o l u t i o n s P r o v i d e r 36/54 6.4.3 Unit Switch Press to switch between the absolute measurement (dBm) and relative measurement (dB) and xW of the optical power.
  • Page 42 F i b e r O p t i c S o l u t i o n s P r o v i d e r 37/54 the screen display the “ref “and setting dBm value 6-10) 6-10 6.4.5 Data processing: Data storage and deletion. The power meter has 1000 data records saving memory.
  • Page 43 F i b e r O p t i c S o l u t i o n s P r o v i d e r 38/54 6-12 6.5 Data Communication Note: Before proceed the data communication, make sure the driver and application software are installed successfully (Details of installation please refer to chapter 5) 6.5.1 Open the software...
  • Page 44 F i b e r O p t i c S o l u t i o n s P r o v i d e r 39/54 6-13 Connect Optical power meter with computer via USB cable, turns on the power meter.
  • Page 45 F i b e r O p t i c S o l u t i o n s P r o v i d e r 40/54 6-14 Therefore, choose “COM4” port shown as below figure (6-15) 6-15 Next click “Connect” as shown in below figure 6-16, will pop up a successful connection window shown as 6-17, click “OK”...
  • Page 46 F i b e r O p t i c S o l u t i o n s P r o v i d e r 41/54 6-17 6.5.2 Data edit Firstly, input the following basic information as shown on figure 6-18. 6-18 Then click “Upload data “, the saved data in the unit will be uploaded into computer and shown as on below figure (6-19).
  • Page 47 F i b e r O p t i c S o l u t i o n s P r o v i d e r 42/54 6-19 Data edit at data display area, including data delete, data save and data printing.
  • Page 48 F i b e r O p t i c S o l u t i o n s P r o v i d e r 43/54 6-20 www.suntelecom.cn • +86-21-60138638 • ics@suntelecom.cn...
  • Page 49 F i b e r O p t i c S o l u t i o n s P r o v i d e r 44/54 6-21 Click “Delete all “pop up a window shown as figure 6-22, click “OK “ to delete all data, also will clear all saved data from the unit.
  • Page 50 F i b e r O p t i c S o l u t i o n s P r o v i d e r 45/54 6-22 Click “Save” pop up a window shown as figure 6-23, input the file name, choose the save path and press “ok”...
  • Page 51 F i b e r O p t i c S o l u t i o n s P r o v i d e r 46/54 6-24 Click on the software, you can print testing report directly; you can also print the testing report from Excel.
  • Page 52 F i b e r O p t i c S o l u t i o n s P r o v i d e r 47/54 6-26 There are there items can be set on the unit: (1) Optical Power Calibration 6-27 Input the corresponding optical power and click “calibration “, users can recalibrate the optical power by themselves.
  • Page 53 F i b e r O p t i c S o l u t i o n s P r o v i d e r 48/54 (2) Time setting 6-28 Input the corresponding date and time, and then click “Set “to modify the time and date accordingly.
  • Page 54 F i b e r O p t i c S o l u t i o n s P r o v i d e r 49/54  Enable light source be Under “Wave ID” operation mode: press light source to emerge light output from light source. Hold down for few seconds, light source will be enter into Wave ID mode, also “—AU”...
  • Page 55 F i b e r O p t i c S o l u t i o n s P r o v i d e r 50/54 6.7 Frequency detection When use tone detection function, following requirements have to be taken into account: For A: Tone detection will be effective only with measurement range between +6 ~ -40dBm.

  • Page 56: Chapter 7 Troubleshooting

    F i b e r O p t i c S o l u t i o n s P r o v i d e r 51/54 6-32 Note: Frequency ID and wave ID cannot be operated at the same time. To avoid risk of serious eye damage, please do not look into the optical port of laser source at any time.

  • Page 57: Chapter 8 General Maintenance

    F i b e r O p t i c S o l u t i o n s P r o v i d e r 52/54 Chapter 8 General Maintenance  Always keep the connector ports of your power meter are clean. ...
  • Page 58 F i b e r O p t i c S o l u t i o n s P r o v i d e r 53/54 repair and shipping in conditions of below:  Defects occurred under normal use and service but out of the warranty period.
  • Page 59 F i b e r O p t i c S o l u t i o n s P r o v i d e r 54/54 An important message from Sun Telecom We guarantee that any information you supply will remain confidential. By returning this card, you will automatically be notified about updates, modifications, and recalibration.
  • Page 60 SHANGHAI SUN TELECOMMUNICATION CO., LTD. Building No.145 Lane 666, Xianing Rd. Jinshan Industrial Zone, Jinshan District ShangHai, China 201506 Tel: +86 21 60138638 Fax: +86 21 60138635-401 E-mail: ics@suntelecom.cn http://www.suntelecom.cn/...

This manual is also suitable for:
