Anchoring instructions
X-rAcKs AnD X-LABs ArE hEAVY PiEcEs oF EQuiPMEnt. thEY ArE
intEnDED to suPPort signiFicAnt WEight During routinE
usE AnD shouLD BE sEcurELY AssEMBLED AnD FAstEnED
to A suPPorting surFAcE oF suitABLE construction.
FAiLurE to tAKE ProPEr cArE in sitE sELEction, AssEMBLY
or instALLAtion cAn LEAD to sErious PErsonAL inJurY
AnD ProPErtY DAMAgE.
these setup instructions are not
intended to be exhaustive,
but are only intended for illustrative
purposes and to be used as guidelines
to provide to your contractor.
Professional installation
is required.
Electrical wires, water pipes etc. can
be running underneath a floor so
understand what is below before
drilling.
read these instructions carefully
before proceeding and follow the
installation directions carefully
to minimize the risk of injury or
property damage.
Advertisement
Table of Contents
Related Manuals for Torque Fitness X-Series
Summary of Contents for Torque Fitness X-Series
- Page 1 Anchoring instructions X-rAcKs AnD X-LABs ArE hEAVY PiEcEs oF EQuiPMEnt. thEY ArE intEnDED to suPPort signiFicAnt WEight During routinE usE AnD shouLD BE sEcurELY AssEMBLED AnD FAstEnED to A suPPorting surFAcE oF suitABLE construction. FAiLurE to tAKE ProPEr cArE in sitE sELEction, AssEMBLY or instALLAtion cAn LEAD to sErious PErsonAL inJurY AnD ProPErtY DAMAgE.
- Page 2 rEQuirED tooLs AnD hArDWArE For Anchoring to concrEtE FLoors hammer Drill socket Wrench and socket Masonary drill bit (reference anchors for correct size) 3/8” x 3” concrete anchors 3/8” Washers Level...
- Page 3 Anchoring LocAtions X-Lab Upright X-Rack Upright notes: complete assembly of entire frame and position the X-Lab or X-rack where desired prior to starting the anchoring procedure. some attachments such as the step-up, ground rotational trainers, or Accessory trays may interfere with the drilling operation and should be left off or removed prior to anchoring.
- Page 4 Anchoring instructions using a concrete drill bit (reference your hardware for the correct size), drill a 3” hole through the anchoring hole in the base plate. (to prevent the drill from contacting the upright, place a piece of cardboard between the drill casing and the upright) Vacuum all concrete dust from the hole, then using a socket wrench, fully tighten a con- crete bolt and washer to the recommended torque specifications of the bolts being used.
- Page 5 For additional questions, contact torque Fitness at: email: service@torquefitness.com Phone: 763-754-7533...
