- Page 1 ACTIVATE SOFTWARE UPDATES BEFORE FIRST TEST www.refrigerantid.com/activate 456 Creamery Way, Exton, PA 19341, USA Phone: +1 610.524.8800 • Fax: +1 610.524.8807 • Email: info@refrigerantid.com www.refrigerantid.com...
- Page 2 Manual Part Number: Manual File: Page II 5-06-7000-80-0 012476 Rev. A...
- Page 3 LEGEND ID Model RI-2018 Series AUTOMOTIVE REFRIGERANT ANALYZER OPERATION MANUAL Manual Part Number: Manual File: Page III 5-06-7000-80-0 012476 Rev. A...
-
Page 4: Table Of Contents
Table of Contents TABLE OF CONTENTS FOR YOUR SAFETY/ANALYZER WARNINGS GENERAL CAUTIONS WELCOME 1 INTRODUCTION AND OVERVIEW 1-08 1 GENERAL 1-08 1.1 FEATURES 1-09 1.2 Legend ID™ COMPONENTS 1-10 Legend ID™ Base Unit 1-10 Legend R-1234yf Sample Hose 1-10 Legend R-134a Sample Hose 1-11 Legend Sample Hose Extensions 1-11... -
Page 5: For Your Safety/Analyzer Warningsv
For Your Safety: BEFORE PLEASE READ THIS MANUAL IN ITS ENTIRETY ATTEMPTING INSTALLATION OR OPERATION! Attempting to operate this tool without fully understanding its features and functions may result in unsafe conditions. Analyzer Warnings o REFRIGERANT BLEND WARNING: Operate this unit with vehicles or cylinders marked to contain R-1234yf, R-134a or R-12 refrigerant. -
Page 6: General Cautions
General Cautions ALWAYS wear eye and skin protection when working with refrigerants. Escaping refrigerant vapors will present a freezing danger. Do NOT direct refrigerant escaping from the sample hose toward exposed skin or toward the face. ALWAYS turn the compressor or automobile engine OFF before connecting the instrument to an air conditioning system. -
Page 7: Welcome
WELCOME Thank you for purchasing the LEGEND ID Refrigerant Analyzer. The Legend ID™ Refrigerant Analyzer is designed for use independently or in conjunction with an SAE J2843 or J3030 approved A/C Service Machine to determine the purity of gaseous R-134a or R- 1234yf refrigerant. -
Page 8: Introduction And Overview
NTRODUCTION AND VERVIEW General Contamination of refrigerants either in storage cylinders or vehicle air conditioning systems can lead to component corrosion, elevated head pressures and system failures when utilized by unsuspecting technicians. The ability of the technician to determine refrigerant type and purity is severely hampered by the presence of air when attempting to utilize temperature-pressure relations. -
Page 9: Features
Features The Legend ID™ Refrigerant Analyzer is the most precise handheld instrument ever manufactured for determining the purity of R-1234yf, R-134a and R-12 in the automotive market. Features Include: Quickly and accurately determines refrigerant purity Advanced ergonomic design ... -
Page 10: Legend Id™ Components
Components Legend ID Base Unit Legend ID The Legend ID™ base unit houses the Full Color Graphic LCD, Infrared Bench, Electrical Connections, and Rechargeable Battery. These components require no maintenance, therefore there are no serviceable components internal to the instrument, and disassembly will void the warranty. -
Page 11: Legend R-134A Sample Hose
Legend R-134a Sample Hose The 6.5-foot (2 meter) R-134a Sample Hose is constructed of polyurethane ether. The hose is provided with an instrument inlet port mating connector on one end and a brass flow restrictor on the other end. The brass flow restrictor screws into the R-134a Low Side Coupler. The sample hose is considered a consumable maintenance part. -
Page 12: Usb Cord
USB Cord The USB Cord is provided to connect the refrigerant analyzer with an SAE J2843 or J3030 approved A/C Service Machine. If connecting to an approved A/C service machine follow the instructions on this machine to operate the refrigerant analyzer. R-1234yf Tank Adapter Fitting The R-1234yf Tank Adapter Fitting will provide the user with an adapter to allow connection of the R-1234yf Sample Hose to the ½”... -
Page 13: Ac Power Adapter
AC Power Adapter The Legend ID™ is powered via a Lithium Ion battery. You can also power the unit with the AC Power Adapter which converts a standard 100-240VAC 50/60Hz wall outlet to 12VDC, 1.6A. This AC Power Adapter will also charge the battery when connected to the analyzer. NOTE: Use of any other power source may cause damage to the unit and void the warranty. -
Page 14: Back Panel Connections
Back Panel Connections The connections located on the back panel are illustrated below. CAUTION: The sample outlet port should never be obstructed. Keep the sample outlet port free and clear at all times. Do not operate near open flame. USB Port Factory Sample Inlet power port... -
Page 15: Legend Id
EGEND PERATION First Use The Legend ID™ has a built in Lithium Ion battery. Prior to first use charge the battery for a minimum of 2 hours with the included AC Power Supply. The analyzer will function and charge the battery when the AC Power Supply is connected. Power On the Analyzer For use with an SAE J2843 or J3030 certified AC Service Machine, connect one end of the provided USB cable to the USB port on the back of the analyzer and connect the other end... -
Page 16: Calibration
Once the analyzer warms up, the screen in (Figure 3) will appear offering the option to change settings or start an analysis. If you wish to adjust factory ‘Settings’, select the left soft key and refer to section Maintenance & Troubleshooting. To begin an analysis, select the right ‘Start’... -
Page 17: Testing The Refrigerant
Testing the Refrigerant After the air calibration is complete, the instrument is ready for testing. The analyzer will direct you to connect the hose to a refrigerant source as shown in (Figure 7). Connect the hose to the vehicles Low Side Schrader valve, or connect it to the Low Side Port on a refrigerant cylinder, and open the valve. -
Page 18: Understanding The Test Results
If the refrigerant analyzed is 98.0% pure or better, the refrigerant is deemed suitable for standard recovery and reuse. Should the refrigerant be less than 98.0% pure, the refrigerant is not suitable for standard recovery and should not be reused. In either case, verify the hose is disconnected from the refrigerant source and press ‘Exit’... - Page 19 The refrigerant analyzer is designed to provide visual cues after analysis is complete. When the refrigerant sampled is found to be 98% pure or greater the analyzer will display a Green background indicator (Figure 14). Figure 14 Figure 15 When the sampled refrigerant is found to be between 95% - 98% pure a Yellow background indicator will appear (Figure 15).
-
Page 20: Maintenance & Troubleshooting
& T AINTENANCE ROUBLESHOOTING Replacing the Sample Hose Assembly. In the event the analyzer displays an Error #3 or Error #5 this may be an indication the sample hose needs replacing. This will occur when the integrated flow restrictor becomes clogged with oil, debris or sealant. -
Page 21: Software Updates
Software Updates Software updates may be made available to improve operating performance or add additional features. Some updates will be provided at no charge to improve operating efficiencies while others will be optional, paid upgrades, to add new refrigerants or functions. The Legend ID™... -
Page 22: Error Messages
Error Messages In the unlikely event an Error message is displayed on the screen, follow the on-screen prompt associated to the Error. Error messages that will appear include: Error #1: The air or gas readings were unstable. Solution: Move the unit away from sources of EMF or RFI such as radio transmitters and arc welders. -
Page 23: Appendices
PPENDICES 4.1 Spare Parts List PART NUMBER DESCRIPTION 4-03-5004-07-0 R-134a Tank Adapter 4-04-5500-00-6 R-12 Low Side Coupler 5-03-1000-08-1 Printer Paper Roll 5-06-7000-80-0 Operating Manual 6-01-6000-74-0 AC Power Supply 6-02-6001-37-0 R-1234yf Tank Adapter 6-02-6001-42-0 Legend R-134a Replacement Hose 6-02-6001-43-0 Legend R-1234yf Replacement Hose 6-02-6001-56-0 Legend R-134a Hose Kit 6-02-6001-57-0... -
Page 24: Warranty
Warranty NEUTRONICS warrants, subject to the terms listed below, that the goods will be free from defects in design, materials, and workmanship for a period of (1) one year from the date that the goods are shipped to the buyer. THE SOLE LIABILITY OF NEUTRONICS FOR ALL PURPOSES SHALL BE TO REPAIR OR REPLACE, AT THE SOLE OPTION OF NEUTRONICS, DEFECTS APPEARING WITHIN THE (1) ONE YEAR PERIOD.
