  • Page 1 ACTIVATE SOFTWARE UPDATES BEFORE FIRST TEST https://www.mybacharach.com/support/warranty-registration/ 456 Creamery Way, Exton, PA 19341, USA Phone: +1 610.524.8800 • Fax: +1 610.524.8807 • Email: info@refrigerantid.com www.mybacharach.com...
  • Page 2 LEGEND SERIES  REFRIGERANT ANALYZER OPERATION MANUAL Manual Part Number: Manual File: Page II 5-06-7000-81-1, 7-08-1234- 069706 Rev. A 40-0...
  • Page 3 Manual Part Number: Manual File: Page III 5-06-7000-81-1, 7-08-1234- 069706 Rev. A 40-0...
  • Page 4: Table Of Contents

    Table of Contents TABLE OF CONTENTS FOR YOUR SAFETY/ANALYZER WARNINGS GENERAL CAUTIONS WELCOME 1 INTRODUCTION AND OVERVIEW 1 GENERAL 1.1 FEATURES 1.2 Legend Series™ HFC COMPONENTS 1-10 Legend Series™ HFC Base Unit 1-10 Legend Vapor Sample Hose 1-10 ¼” Flare Coupler 1-11...
  • Page 5: For Your Safety/Analyzer Warningsv

    For Your Safety: BEFORE PLEASE READ THIS MANUAL IN ITS ENTIRETY ATTEMPTING INSTALLATION OR OPERATION! Attempting to operate this tool without fully understanding its features and functions may result in unsafe conditions. Analyzer Warnings o REFRIGERANT BLEND WARNING: This refrigerant analyzer is approved for specific refrigerant testing and should not be used with substances outside the scope of the device.
  • Page 6: General Cautions

    General Cautions ALWAYS wear eye and skin protection when working with refrigerants. • Escaping refrigerant vapors will present a freezing danger. Do NOT direct refrigerant escaping from the sample hose toward exposed skin or toward the face. ALWAYS turn the compressor or power source OFF before connecting the •...
  • Page 7: Welcome

    Copyright ©2020 Bacharach Inc. This work is protected under Title 17 of the US Code and is the sole property of Bacharach Inc. No part of this document may be copied or otherwise reproduced, or stored in any electronic information retrieval system, except as specifically permitted under US copyright law, without the prior written consent of Bacharach Inc.
  • Page 8: Introduction And Overview

    The Bacharach Legend Series™ HFC Refrigerant Analyzer will provide a fast, easy and accurate means to determine refrigerant purity in refrigerant storage cylinders or directly in an HVAC/R system.
  • Page 9: Features

    Features The Legend Series™ HFC Refrigerant Analyzer is the most precise portable instrument ever manufactured for field applications to determine the purity of gaseous refrigerants in the HVAC/R market. Features Include: Quickly and accurately determines refrigerant purity • • Advanced ergonomic design Analyzes percentage purity •...
  • Page 10: Legend Series™ Hfc Components

    Legend Series HFC Base Unit The Legend Series™ HFC unit houses the Full Color Graphic LCD, Infrared Bench, Electrical Connections, and Rechargeable Battery. The device is factory calibrated and completes an air calibration to confirm infrared signals before testing. These components require no maintenance, therefore there are no serviceable components internal to the instrument, and disassembly will void the warranty.
  • Page 11: ¼" Flare Coupler

    ¼” Flare Coupler The ¼” Flare coupler is designed for easy connection to a cylinder or HVAC/R system. The coupler can be used for vapor or liquid sampling. Liquid sampling will require the use of the liquid sample hose and liquid sample syringe. Sample Hose Extensions The liquid sample trap is designed as a barrier to oil or liquid refrigerant entering the analyzer.
  • Page 12: Liquid Sample Hose

    Restrictor AC Power Adapter The Legend Series™ is powered via a rechargeable Lithium-Ion battery. You can also power the unit with the AC Power Adapter which converts a standard 100-240VAC 50/60Hz wall outlet to 12VDC, 1.6A. This AC Power Adapter will charge the battery when connected to the analyzer.
  • Page 13: Control Panel

    Control Panel The Control Panel serves as the main user interface. The Control Panel features three soft key buttons. The current function for each button is displayed above the Soft Key Buttons on the full color graphic LCD. A Home button and a Power button are also found at the top of the control panel.
  • Page 14: Hard Shell Storage/Carrying Case

    Hard-Shell Storage/Carrying Case The hard-shell storage/carrying case is custom fit to the Legend Series™. It provides rugged protection for the instrument, as well as convenient storage for all components. The enclosure is general purpose and is not watertight. Factory power port...
  • Page 15: Legend Series

    PERATION First Use The Legend Series™ HFC has a built in Lithium-Ion battery. Prior to first use charge the battery for a minimum of 2 hours with the included AC Power Supply. The analyzer will function and charge the battery when the AC Power Supply is connected.
  • Page 16: Calibration

    Figure 4 Calibration Each time the Legend Series™ HFC begins a new test cycle it must complete an air calibration. The calibration takes 30 seconds and pulls fresh air into the unit via an internal pump. This fresh air purges any excess refrigerant from the unit and ensures accurate test results.
  • Page 17: Testing The Refrigerant

    ‘Test.’ Viewing the Test Results Upon completion of analysis, the Legend Series™ HFC will display (Figure 9). Close the refrigerant source valve if equipped, and then disconnect the coupler from the refrigerant source.
  • Page 18: Understanding The Test Results

    Understanding Test Results The Legend Series™ HFC is designed to analyze or identify a wide array of refrigerants. Before sampling a gas, you should select the refrigerant you anticipate testing to accurately align the calibration (Figure 12). If the wrong base refrigerant is selected the analyzer will still provide accurate single component refrigerant outputs but may not confirm the refrigerant matches the refrigerant selected (Figure 13).
  • Page 19 Expected Refrigerant: Refrigerant analyzed and found to be within an acceptable composition range of the selected gas will define the results as that refrigerant and display a green screen (Figure 14). In this example, R-410A is confirmed with some slight composition shift. The R-410A is still within composition specification of AHRI Standard 700 which qualifies it as R-410A.
  • Page 20 Figure 16 Diluted Refrigerant: Refrigerant analyzed and found to be diluted will have the expected base components with any level of Air present in the sample. This refrigerant would have a yellow screen to indicate the Air has contaminated the sample (Figure 17). Air can be removed from refrigerant but can be harmful if present inside a system.
  • Page 21 Unknown Refrigerant: Refrigerant analyzed and found to be an Unknown gas is a gas that does not match any of the refrigerants directly measured by the device. A yellow screen will appear to indicate caution as the gas is unknown (Figure 19). If you believe the sampled refrigerant should be measured by the device restart the analysis and confirm you select the appropriate refrigerant before calibration.
  • Page 22: Maintenance & Troubleshooting

    & T AINTENANCE ROUBLESHOOTING Replacing the Sample Hose Assembly. In the event the analyzer displays an Error #3 or Error #5 this may be an indication the sample hose needs replacing. This will occur when the integrated flow restrictor becomes clogged with oil, debris, or sealant.
  • Page 23: Software Updates

    The Legend Series™ HFC has a USB update port located on the Back-Panel Connections. This port should not be used for any other purpose other than to install factory updates or when saving test data to an external USB Drive.
  • Page 24: Error Messages

    Error #7: The gas pressure is out of range • Solution: Verify the SAMPLE EXHAUST port is not obstructed. If an Error message reappears, contact Bacharach or your local service department. Bacharach Inc. 456 Creamery Way Exton, PA 1934, USA Tel: +1 610.524.8800...
  • Page 25: Appendices

    PPENDICES 4.1 Spare Parts List PART NUMBER DESCRIPTION 5-06-7000-81-1 Operating Manual 6-01-6000-74-0 AC Power Supply 6-01-6001-23-1 Liquid Sample Hose 6-02-6001-17-0 Liquid Sample Trap 6-02-6001-41-1 Sample Hose Extensions 6-02-6001-42-0 Vapor Sample Hose 6-02-6001-54-0 ¼” Flare Coupler 4.2 Specifications SAMPLE PARAMETERS: Vapor or Liquid depending on hose configuration, oil-free PRESSURE: Max Pressure 500 psig (35 Bar) Low Pressure samples <30 psig (2 Bar) will require additional flow...
  • Page 26: Warranty

    Buyer, therefore, agrees to indemnify BACHARACH from and against all losses and claims to or by any person or property caused in any manner by the goods or the use of the goods, including any expenses and attorney’s fees in connection with all claims, demands, proceedings, or other expenses.
