Tektronix Phaser 550 Service Manual

Hide thumbs Also See for Phaser 550:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
Enlarged version
Service Manual
®
Phaser
550 Color Printer
Warning
The following servicing instructions are for
use by qualified service personnel only. To
avoid personal injury, do not perform any
servicing other than that contained in
operating instructions unless you are qualified
to do so.
This printing February 1996
070-9322-00

Advertisement

Table of Contents
loading

Related Manuals for Tektronix Phaser 550

Summary of Contents for Tektronix Phaser 550

  • Page 1 Service Manual ® Phaser 550 Color Printer Warning The following servicing instructions are for use by qualified service personnel only. To avoid personal injury, do not perform any servicing other than that contained in operating instructions unless you are qualified to do so.
  • Page 3 1996 by Tektronix, Inc., Wilsonville, Oregon. Printed in the United States of America. All rights reserved. Contents of this publication may not be reproduced in any form without permission of Tektronix, Inc. This instrument, in whole or in part, may be protected by one or more U.S. or foreign patents or patent applications.
  • Page 4 Users safety summary Terms in manual: CAUTION Conditions that can result in damage to the product. WARNING Conditions that can result in personal injury or loss of life. Power source: Does not apply more than 250 volts RMS between the supply conductors or between either supply conductor and ground.
  • Page 5 Service safety summary For qualified service personnel only: Refer also to the preceding Users Safety Summary. Do not service alone: Do not perform internal service or adjustment of this product unless another person capable of rendering first aid or resuscitation is present. Use care when servicing with power on: Dangerous voltages may exist at several points in this product.

  • Page 7: Table Of Contents

    Contents General Information The Phaser 550 Color Printer 1-2 RAM and printer capabilities 1-3 Print engine assemblies 1-4 Front panel 1-7 Rear panel 1-9 Network card LEDs 1-10 Test print button 1-11 Health LED 1-12 Media tray type sensing 1-12...
  • Page 8 Installing a printer driver for Microsoft Windows 95 2-22 Installing the Tektronix driver for Windows 3.1 2-24 If you have other Tektronix printer drivers already installed 2-24 Configuring the Tektronix Windows printer driver 2-25 Updating the standard Microsoft Windows PostScript driver 2-27 Installing the printer driver for OS/2 Version 2 2-28 Setting the printer’s IP address using the front panel 2-30...
  • Page 9 Warranty information 4-6 Service support 4-6 Supplies ordering 4-7 If you need help 4-7 Using the automated fax systems 4-7 Tektronix Color Printer Information Server 4-10 Customer Support Hotline 4-10 Service support 4-11 Electronic bulletin board service 4-11 Theory of Operation...
  • Page 10 Left-side door open when it is not 6-16 High temperature error 6-17 Low temperature error 6-17 High voltage error 6-17 Thermistor open error 6-18 Power supply fan does not run 6-18 Front Panel Cycling between READY and WARMING UP 6-18 viii Phaser 550 Color Printer...
  • Page 11 Error messages 6-19 Print engine error codes 6-19 Printing and print quality problems 6-24 Blank print 6-24 All-black print 6-24 Missing primary color 6-25 Light print 6-25 Repeated spots or lines on print in-line with each other 6-26 Dark vertical line in print 6-26 Missing primary color on one side of print 6-26 White horizontal line or band in all the colors of a print 6-27 White vertical lines in the print 6-27...
  • Page 12 Engine control board 8-14 Engine driver board 8-14 Charger sensor board 8-15 Main motor 8-16 Paper feed motor 8-16 Cleaning board 8-16 Toner cartridge drive unit 8-18 Home position sensor assembly and the left door opened switch 8-18 Phaser 550 Color Printer...
  • Page 13 High-voltage board 8-20 Pre-exposure lamp 8-21 Pre-transfer lamp 8-21 Toner auto-density sensor 8-21 Image processor board 8-23 Installing RAM SIMMs 8-24 Installing an Extended Features SIMM 8-26 Installing a network card 8-28 Replacing the code ROM SIMM 8-29 Checks and Adjustments Required tools 9-1 Front panel menu 9-2 Printing test prints 9-4...
  • Page 14 Tray switch sensors and actuators 1-13 Figure 2-1 The Phaser 550 and its packaging 2-6 Figure 2-2 Connecting a SCSI hard disk drive to the Phaser 550 2-11 Figure 2-3 Connecting a CopyStation to the Phaser 550 2-12 Figure 5-1...
  • Page 15 Figure 8-1 Removing cabinet covers 8-3 Figure 8-2 Removing cabinet covers 8-5 Figure 8-3 Removing the paper feeder and the paper tray sensor board 8-7 Figure 8-4 Removing the cartridge selector/eject unit 8-8 Figure 8-5 Removing the laser scanner 8-9 Figure 8-6 Removing the laser modulation board 8-10 Figure 8-7...
  • Page 16 FRU part list of the printer cabinet A-3 Table A-3 FRU parts list of the exploded printer A-4 Table A-4 Supplies and accessories A-6 Table D-1 Test Pattern Generator DIP Switch settings for Phaser 550 D-2 Phaser 550 Color Printer...
  • Page 17 The Test Pattern Generator contains PostScript scripts to start test patterns for a number of Tektronix color printers. It allows you to test a printer as if it were receiving a file from a host computer. The test patterns are generated by the printer's image processor and then printed by the print engine.
  • Page 18 Additionally, the Test Pattern Generator lets you set up a printer for printing from a 4511A Network Interface. To do so, just select the appropriate DIP switch setting. Table D-1 Test Pattern Generator DIP Switch settings for Phaser 550 Pattern or function Print quality test pattern On...

  • Page 19: General Information

    field replaceable units (FRU) list and assembly/disassembly procedures for selected FRUs. To ensure complete understanding of the product, we recommend participation in Phaser 550 service training. 9013-01 Figure 1-1 The Phaser 550 Color Printer Service Manual...

  • Page 20: The Phaser 550 Color Printer

    The PCL printer language is optionally supported and is activated with a downloadable authorization code. The Phaser 550 comes standard with 8 Mbytes of RAM which can be supplemented with one or two additional 16- or 32-Mbyte RAM SIMMs;...

  • Page 21: Ram And Printer Capabilities

    General Information After being idle for one hour the printer switches into its Energy Star mode where it consumes less than 45 watts of power. It “awakens” upon receiving data at any of its ports. The printer also features a closed-loop image density sensor system that allows it to auto-calibrate its color imaging so printing output remains consistent over the life of the print engine and its consumable supplies.

  • Page 22: Print Engine Assemblies

    The imaging unit may contain a removable pre-transfer corona unit. The pre-transfer corona unit makes the imaging unit backwards compatible with the Phaser 540 Color Laser Printer. Unlike the Phaser 540, the Phaser 550 does not use a pre-transfer corona.

  • Page 23: Figure 1-3 Print Engine Components (Continued)

    General Information Ozone fan Toner cartridge motor Laser motor drive board Toner cartridge drive unit Power supply fan Power supply unit Engine control board Fuser fan Image processor board Charger sensor board High voltage board Cleaning board Main motor Paper feed motor Engine driver board 9322-86 Figure 1-3 Print engine components (continued)

  • Page 24: Figure 1-4 Print Engine Sensor, Switch And Solenoid Locations

    The photoconductive belt position sensor is not illustrated. This optical sensor marks the home position of the photoconductive belt. It is mounted inside the customer-replaceable imaging unit. The logic state of the paper low sensor is not monitored nor used by the image processor. Phaser 550 Color Printer...

  • Page 25: Front Panel

    General Information Front panel These front panel features are found on the printer: A two-line, 24-character LCD and two LEDs Four push buttons LCD The LCD serves two purposes: displaying current controller and print engine status information and displaying an interactive menu. Status information includes controller status such as Ready , Receiving data and Printing .

  • Page 26: Figure 1-5 The Front Panel And Its Functions

    Paper Jam at Output , is displayed on the LCD. Error codes are listed and explained in the Section 6 topic, “Error messages” on page 6-19. Power Error Exit Exit Button 1 Button 2 Button 3 Button 4 9013-06 Figure 1-5 The front panel and its functions Phaser 550 Color Printer...

  • Page 27: Rear Panel

    General Information Rear panel Connectors The rear panel of the Phaser 550 printer features the host interface connectors to the printer. It includes the following connectors: Standard parallel (high-density connector). SCSI high-density connector (font hard disk drive or Phaser CopyStation only).

  • Page 28: Network Card Leds

    Option Option SCSI 9013-05a Figure 1-6 The Phaser 550 rear panel Network card LEDs The Ethernet network card has two LED indicators: TX indicator (yellow); blinks while data is transmitted to the host. The LED is off while no data is being sent.

  • Page 29: Test Print Button

    General Information The Token Ring network card has two LED indicators: Connection (yellow); off when the printer is not inserted into the Token Ring, blinks while the printer is attempting to insert itself into the Token Ring, on when the printer is properly inserted in the ring. Ring Speed (green);...

  • Page 30: Health Led

    Tray type Closed Open Open Letter (A-size) paper Closed Closed Open Letter (A-size) transparency film Open Open Closed Metric Letter (A4-size) paper Closed Open Closed Metric Letter (A4-size) transparency film Open Closed Open Legal size paper 1-12 Phaser 550 Color Printer...

  • Page 31: Figure 1-7 Tray Switch Sensors And Actuators

    General Information Sensor actuators Middle Left Right Tray sensors 9013-40 Figure 1-7 Tray switch sensors and actuators Service Manual 1-13...

  • Page 32: Specifications

    15.3 cm (6 in.) for connecting computer cable and power cord Bottom: No obstruction under printer that could block its cooling vents. Mounting surface Within 2 degrees of horizontal with all four feet in contact with flatness: the table surface. 1-14 Phaser 550 Color Printer...

  • Page 33: Table 1-5 Functional Specifications

    General Information Table 1-5 Functional specifications Characteristic Specification Printing process Electro-photographic, four color (CMYK) transfer printing Color medium Four toner cartridges each contain one of four colors: cyan, magenta, yellow or black. The toner is a nonmagnetic, monocomponent contact medium. Addressability Standard, Fast Color and Presentation mode: 600 x 600 dots-per-inch text and graphics...

  • Page 34: Table 1-6 Electrical Specifications

    50 Hz. Non-operating (shock) 30 g, trapezoidal flared pulse, 20 msec each axis. Acoustic Noise Average sound level (LEQ) is less than 53 dbA. Peak noise in (operating) standby mode is 47 dbA. 1-16 Phaser 550 Color Printer...

  • Page 35: Regulatory Specifications

    General Information Regulatory specifications The printer is a recognized component in conformance with the following regulatory standards: The packaged product meets ASTM D4169-86 and ASTM D4728-87 Transportation Standards. Listed UL 1950 Information Processing and Business Equipment. Certified CSA C22.2 No. 950 Safety of Information Technology Equipment, Including electrical Business Equipment.

  • Page 37: Installing The Printer And Drivers

    Drivers This chapter discusses installing the printer and its drivers as a part of the S0 printer installation option. Tektronix Service Option S0 consists of three main functions detailed in this and the next two chapters of this manual: Chapter 2 “Installing the Printer and Drivers.” The first portion of installation instructions, this chapter, consists of five basic processes:...

  • Page 38: Pre-Install Questions For Customers

    Some applications require special printing utility files. _____________________________________________ Will the application(s) and sample files be available at the time of the installation to send test files to the printer?________ Will a SCSI font disk be installed on the printer? ______________________________________ Phaser 550 Color Printer...
  • Page 39 _______ Swiss Option A5 (161-0154-00) Customers must provide the particular interface cable they need to use with the printer. Customers can purchase the following from the Tektronix Graphics Supplies Order Desk by calling 1-800-835-6100. Parallel cable, DB25 male to Centronics 1284C 012-1468-00 Serial, 9-pin to 9-pin, 3 m (10 ft.), null modem...
  • Page 40 750 kbyte hard disk space for files Based on the results of the pre-install interview with the customer, you may wish to access the Tektronix Highly Automated Library (HAL) at 1 800 835-6100 or EuroHAL for articles that may help with installing the printer into a customer's network.

  • Page 41: Unpacking

    Optional Phaser Share network user manual and diskettes Accessory box Standard paper tray, A or A4 Output tray Four toner cartridges (cyan, magenta, yellow and black) Imaging unit Fuser Phaser 550 media sampler Note Interface cables must be ordered separately. Service Manual...

  • Page 42: Figure 2-1 The Phaser 550 And Its Packaging

    Installing the Printer and Drivers 9013-07 Figure 2-1 The Phaser 550 and its packaging Phaser 550 Color Printer...

  • Page 43: Setting Up The Printer

    Setting up the printer Installing SIMM memory The standard configuration for a Phaser 550 includes 8 Mbytes of memory. Two optional SIMMs can be added for a total of 72 Mbytes of memory. The optional SIMM installation order is as follows:...

  • Page 44: Cabling The Printer

    Turn off the printer. EtherTalk protocol requires you to attach the Ethernet cable with the printer powered off. Attach the network cable (ThinNet or TwistedPair) to the printer’s appropriate Ethernet connector. Use only one connector. Phaser 550 Color Printer...

  • Page 45: Connecting The Printer To A Pc

    Turn on the printer. Networked connection using the Token ring port Note For Token Ring networks, the Phaser 550 must have the optional Token Ring network card installed. Turn off the printer. Connect the interface cable to the printer’s appropriate Token Ring connector.

  • Page 46: Connecting The Printer To A Workstation

    Turn on the printer. Networked connection using the Token Ring port Note For Token Ring networks, the Phaser 550 must have the optional Token Ring network card installed. Turn off the printer. Ensure the transmission speed jumper on the printer’s Token Ring network card is set for the speed of the token ring network.

  • Page 47: Connecting An Optional Scsi Hard Disk Drive To The Printer

    SCSI cable SCSI drive 9013-09 Figure 2-2 Connecting a SCSI hard disk drive to the Phaser 550 Select the desired SCSI address (0 through 6) on the SCSI drive. The printer’s SCSI address is 7. Turn on the disk drive first, and then turn on the printer.

  • Page 48: Connecting The Optional Copystation To The Printer

    Attach the other end of the SCSI cable to the CopyStation’s SCSI port. CopyStation SCSI cable 9013-59 Figure 2-3 Connecting a CopyStation to the Phaser 550 Note The CopyStation uses two SCSI address: 5 and 6. Make sure that any connected SCSI hard drive does not use these addresses.

  • Page 49: Turning On The Printer

    Ports (serial, parallel, LocalTalk, Ethernet, Token Ring) Ethernet protocols available TekColor corrections and print quality mode Pages printed Amount of RAM installed Tektronix version firmware level Print engine firmware level Adobe version software level Printer SCSI ID Authorization code SCSI disk attached...
  • Page 50 Color settings such as Finepoint and Vivid Color. Serial port settings Parallel port settings LocalTalk port settings EtherTalk settings Token Ring settings TCP/IP settings Novell NetWare settings Table 2-1 Configuration page settings for the Phaser 550 Parameter Description Saved Default Limits or alternate choices NVRAM Printer type The name of the product.
  • Page 51 Installing the Printer and Drivers Table 2-1 Configuration page settings for the Phaser 550 (cont'd.) Parameter Description Saved Default Limits or alternate choices NVRAM Authorization A unique number downloaded to the <not authorized> Valid code number in the code printer (in the field or at the factory) to format enable TCP/IP protocols.
  • Page 52 Installing the Printer and Drivers Table 2-1 Configuration page settings for the Phaser 550 (cont'd.) Parameter Description Saved Default Limits or alternate choices NVRAM Firmware Firmware version of the installed version Ethernet card LocalTalk port Indicates the type of interpreter in use at...
  • Page 53 Installing the Printer and Drivers Table 2-1 Configuration page settings for the Phaser 550 (cont'd.) Parameter Description Saved Default Limits or alternate choices NVRAM TokenTalk Indicates the type of interpreter in use at PostScript Not installed, Disabled, interpreter the port.
  • Page 54 Installing the Printer and Drivers Table 2-1 Configuration page settings for the Phaser 550 (cont'd.) Parameter Description Saved Default Limits or alternate choices NVRAM TCP/IP port Indicates the type of interpreter in use at Not authorized, Disabled interpreter the port.
  • Page 55 Installing the Printer and Drivers Table 2-1 Configuration page settings for the Phaser 550 (cont'd.) Parameter Description Saved Default Limits or alternate choices NVRAM AppSocket The buffer size on the printer in which to 1024 to 59392 Receive receive data. The actual window size is...
  • Page 56 Installing the Printer and Drivers Table 2-1 Configuration page settings for the Phaser 550 (cont'd.) Parameter Description Saved Default Limits or alternate choices NVRAM Boot Delay Number of seconds the printer waits Any positive integer before booting up the attached hard drive.

  • Page 57: Driver And Communication Set Up

    Mac’s Printer Description folder. Otherwise, the LaserWriter 8 driver must be installed on the computer as well at the Phaser 550 PPD file. Refer to the Phaser 550 Drivers and Utilities Printing Reference for more details on drivers.

  • Page 58: Installing A Printer Driver For Microsoft Windows 95

    Windows 95 and may cause printing problems in the new operating system. Start Windows 95. Insert the Phaser 550 CD-ROM in the computer’s CD-ROM drive, or insert the Printer Software for Windows diskette in the host computer’s disk drive.
  • Page 59 Windows diskette. Type in the name of the drive that the CD-ROM or diskette is in, and click OK. A list of Tektronix printers should appear. Select the printer in the list, then click Next. Select Tektronix Phaser 550 if you have the standard configuration of the printer.

  • Page 60: Installing The Tektronix Driver For Windows 3.1

    2-25. If you have other Tektronix printer drivers already installed If you still have an earlier version of the Tektronix Windows driver, you can use the INSTALL.EXE program on that diskette to remove the older driver software.

  • Page 61: Configuring The Tektronix Windows Printer Driver

    Drivers and Utilities Printing Reference to delete the files. When you are finished removing the old driver files, restart Windows. Go on to the topic “Installing the Tektronix driver” in this chapter, to install all of your Tektronix printers with the latest driver software.
  • Page 62 Color box is checked to print in color. From the Options dialog box, choose the Advanced button to see the Advanced Options dialog box. Make sure that the Use PostScript Level 2 Features check box is checked on. 2-26 Phaser 550 Color Printer...

  • Page 63: Updating The Standard Microsoft Windows Postscript Driver

    This option is only available to applications that use this Tektronix driver with Tektronix PostScript Level 2 printers, such as the Phaser 550. When this box is checked, the Compress Bitmaps option is unavailable (grayed-out).

  • Page 64: Installing The Printer Driver For Os/2 Version 2

    Installing the Printer and Drivers When prompted, insert the Tektronix–provided Windows 3.1 Printer Driver diskette into your computer’s disk drive. Choose your printer (without (TekColor) after the name) then click the OK button. When asked to insert a disk with the updated PSCRIPT.DRV file, enter system as the location so the current PSCRIPT.DRV file is used.
  • Page 65 Select Options and make sure that it is properly set to Phaser 550; if not, repeat the previous steps. While in this screen, set Job and Wait to 0, if they aren't already. Click OK on the Options and Device Defaults dialogs for Printer Properties.

  • Page 66: Setting The Printer's Ip Address Using The Front Panel

    Use button 2 to increment a digit and button 3 to shift to the next digit. When the displayed address is correct, press button 4 Set. The printer will now return to its Ready state. 2-30 Phaser 550 Color Printer...

  • Page 67: Configuring The Printer's Serial Port For A Pc

    Installing the Printer and Drivers Configuring the printer's serial port for a PC Use the PostScript command file DEVPARAM.PS (located on the Printers Utilities diskette) to modify the printer’s serial port settings. The following example sets flow control to Xon/Xoff, parity to none, data bits to 8, stop bits to 2 and the baud rate to 9600.
  • Page 68 Use a text editor or word processor to modify the DEVPARAMS.PS file. (Be sure to save the file as a text-only file.) Substitute the values you want for the values used in the sample DEVPARAM.PS. The possible values for each parameter are listed in the following table. The values are case-sensitive;...

  • Page 69: Using Printcap To Configure A Workstation For The Printer's Serial Port

    Installing the Printer and Drivers Using printcap to configure a workstation for the printer's serial port The printcap file configures the workstation's lpr queues. The file is usually found in the workstation's /etc. directory. Use a null modem cable since the printer is set up as a DTE device.

  • Page 70: Configuring A Novell Netware Server For The Printer

    You can have a total of 32 queues on up to eight file servers. After all file servers have been configured, save the configuration file and restart the print server. 2-34 Phaser 550 Color Printer...

  • Page 71: Configuring Tcp/Ip On A Unix Host

    Installing the Printer and Drivers Alternately, you can use a utility called PCONSOLE to perform the same configuration. However, using PCONSOLE, you will not “see” and select the printer on the network as you did in Step 4. Instead, you must enter the print server name (TEKxxxxxx) of the printer as it is shown on the printer’s configuration page.

  • Page 73: Verifying The Printer And Host Connections

    Displayed on the right side of the dialog box are a list of printers that the selected driver will print to. Select the newly installed printer Phaser 550 . (If, for example, a Phaser 550 is already on the network with the name Phaser 550 , then the newly installed printer will be named Phaser 5501 .)
  • Page 74 Press the Setup.. . button. The LaserWriter driver will automatically select the correct PPD file for the Phaser 550. The Phaser 550 is now your chosen printer. Close the Chooser by clicking on the small box in the upper-left corner of the dialog box.

  • Page 75: Printing The Directory From A Macintosh

    Verifying the Printer and Host Connections Printing the directory from a Macintosh Make sure that you have an open window displayed on the screen (such as the hard disk drive's window). At the Macintosh desktop, click and hold on the File menu bar item. For System 7 or higher : Scroll down the File pull-down menu and select the item Print Window...

  • Page 76: Verifying That An Application Communicates To The Printer

    Contact the Customer Support Hotline 1-800-835-6100. Using the Error Handler utility If the Macintosh does not print to the Phaser 550 printer, download the Tektronix Error Handler. Place the printer's Macintosh Printer Utilities diskette in the disk drive.

  • Page 77: Pc Verification

    Type in a line of text such as THIS IS A TEST . Click the File menu item and select Printer Setup... from the menu list. Select Phaser 550 from the displayed list of available printer drivers. Click OK .

  • Page 78: Windows 3.1 Driver Verification

    Type in a line of text such as THIS IS A TEST . Click the File menu item and select Printer Setup... from the menu list. Select Phaser 550 from the displayed list of available printer drivers. Click OK. Click File and select Print. A print file will be transmitted to the printer.

  • Page 79: Novell Netware Verification

    files created and sent for printing from other workstations on the network. The Phaser 550, in turn, finds all file servers with Phaser 550 queues and extracts the print files from them. You must determine if a PC can send a print file to the file server.

  • Page 80: Using The Error Handler Utility

    Using the Error Handler utility If a PC has trouble printing directly to the Phaser 550, download the Tek Error Handler utility file to the printer. The Tek Error Handler (TEKEHAND.PS) is for PostScript Level 1 and Level 2 printers.

  • Page 81: Workstation Verification

    The printer accepts files from networked UNIX and VMS workstations using TCP/IP communications. The printer supports BSD UNIX 4.3, AT&T's UNIX System V with BSD 4.3 lpr extensions, and DEC VMS with Tektronix PhaserSym software. The printer conforms to Ethernet IEEE 802.3 network specifications.

  • Page 82: Using The Error Handler Utility

    From the host, issue the SHOW QUEUE /full command to list all the available printer queues. Ensure that the Phaser 550’s queue is listed. Print to the printer by sending this command: print/queue=<queue name> <file.nam>...

  • Page 83: Key Operator Training

    Chapter Key Operator Training This chapter covers the last portion of the Tektronix Service Option S0 installation: training the printer's key operator. The steps you follow here place an emphasis on encouraging the key operator to read and use the printer's customer manual and to clean and care for the printer.

  • Page 84: Printer Controls And Indicators

    Show and explain the customer how to observe the flashing health LED through the grill behind the manual feed tray. Show and explain to the customer the RX (receive) and TX (transmit) LEDs on the rear panel of the network card (if installed). Phaser 550 Color Printer...

  • Page 85: Loading Media

    Bond: 61 to 90 g/m (16 to 24 lbs.) Follow these guidelines when you make transparencies: Use only Tektronix transparencies . Be sure to load transparencies with the printing side down. When using the tray, load the transparencies so that the notched end of the transparency is in the lower-right corner of the tray.

  • Page 86: Customer-Replaceable Consumables

    Show customers the transfer roller waste toner bin and how to properly handle and dispose of it. Fuser Demonstrate how to properly handle and install the fuser. Warn customers of the hot rollers on the side of the fuser. Phaser 550 Color Printer...

  • Page 87: Clearing Paper Jams

    Key Operator Training Clearing paper jams Paper input (pick jam): Show how to remove the tray to clear a paper-pick jam. Show where this is explained in the user manual. Point out the paper empty flag (inside the paper feeder). Point out the pick rollers.

  • Page 88: Warranty Information

    The customer fills out the agreement and attaches a copy of the invoice or shipping memo for the printer and sends the agreement to Tektronix within 90 days of printer shipment. This starts the service agreement, its duration dating from the printer ship date.

  • Page 89: Supplies Ordering

    Using the automated fax systems As an alternative to the Customer Support Hotline, and to provide up-to-date information quickly, Tektronix has set up HAL (Highly Automated Library) and EuroHAL, two interactive, automated fax systems. These automated fax systems provide Macintosh, PC, and workstation users with the latest technical hints and...
  • Page 90 EuroHAL answers and asks which language customers want to use. For English Press 1 For French Press 2 For German Press 3 The first time customers use EuroHAL, they should order a catalog; this lists all the documents that are available and is continually updated. Phaser 550 Color Printer...
  • Page 91 Key Operator Training EuroHAL asks customers for their fax machine number. If calling from outside the UK, customers must add their country code first, as shown in the following table. Press # Customers area code and when Country Country code fax number finished Austria...

  • Page 92: Tektronix Color Printer Information Server

    If customers don’t have the means of transferring these files from the PC diskette, they can request files from the Tektronix Color Printer Information Server, an automatic file serving program on the Internet that responds to requests for files.

  • Page 93: Service Support

    Tektronix drivers and software. To access the BBS 24 hours a day, 7 days a week, call (503) 685-4504. Use 9600 baud, 8 bits, 1 stop bit, and no parity.

  • Page 95: Theory Of Operation

    Chapter Theory of Operation Overview This section covers the theory of operation of each subsystem within the printer: Functional block diagram Imaging Fusing The paper path The power supply The image processor Service Manual...

  • Page 96: Functional Block Diagram

    The imaging unit forms the heart of the printer. This customer-replaceable unit contains the photoconductive belt and accumulator belt on which imaging takes place. The laser scanner The laser scanner is the device that “writes” the image onto the imaging unit’s photoconductive belt. Phaser 550 Color Printer...
  • Page 97 Theory of Operation The toner cartridges Four toner cartridges, black, yellow, cyan and magenta, contain the primary color toners that are sequentially transferred onto imaging unit’s photoconductive belt depending on where the laser exposed the belt. Subsequently, the toner is transferred to the imaging unit’s accumulator belt from which it is transferred to a sheet of media.

  • Page 98: Laser Imaging

    This prevent an image from one print contaminating or ”ghosting” on the next print. The blade only comes in contact with the belt once the accumulated toner layers are transferred to the sheet of paper. Phaser 550 Color Printer...

  • Page 99: Figure 5-2 Laser Printing Process Overview

    Theory of Operation Laser scanner Photoconductive belt Toner Scorotron developers charger Erase Black lamp Photo conductive Yellow belt cleaner Magenta Cyan First bias transfer roller Pre-transfer Lamp Accumulator +300 ~ 350 v belt Heated Accumulator roller Toner belt cleaner density On-Off Pressure sensor...

  • Page 100: Pre-Exposure

    The pre-exposure lamp is sometimes called the erase lamp since it “erases” negative charges from the belt. Pre-exposure lamp Light from the Photoconductive pre-exposure belt lamp's (erase lamp's) LEDs removes negative charges from the belt. 9013-13 Figure 5-3 Pre-exposing the photoconductive belt Phaser 550 Color Printer...

  • Page 101: Electrostatic Charging

    Theory of Operation Electrostatic charging The electrostatic potential of the belt is not uniform following pre-exposure. As the belt rotates, it passes a scorotron charger which bombards the belt with negative charges. The scorotron charger behaves somewhat like a vacuum tube. The grid of the charger, held at a potential of between -500 volts (for 1200dpi printing) to -550 volts (for 600 dpi printing) and coupled with the varying voltage potential on any discrete point on the belt’s surface, determine how...

  • Page 102: Laser Exposure

    -550 volts (unexposed) to -10 or -20 volts (fully exposed). Laser scanner The laser beam selectively neutralizes some of the negative charges on the belt surface. 9013-15 Figure 5-5 Laser exposure of the photoconductive belt Phaser 550 Color Printer...

  • Page 103: The Laser Scanner

    Theory of Operation The laser scanner Lenses and mirrors in the laser scanner direct the beam at the photoconductive belt. The beam originates at a laser diode. The beam is made parallel by the collimator lens and is directed at the rotating polygonal mirror. The mirror rotates at a constant 23,000 revolutions per minute.

  • Page 104: Toner Pickup (Development)

    Yellow belt exposed by the laser beam. Magenta Cyan Pre-transfer The pre-transfer lamp lamp removes remaining negative charges from the unexposed portions of the belt. 9322-83 Figure 5-7 Toner pickup 5-10 Phaser 550 Color Printer...

  • Page 105: Toner Transfer To The Accumulator Belt

    Theory of Operation Toner transfer to the accumulator belt As the photoconductive belt rotates, it comes in contact with the accumulator belt, which rotates at the same speed. The first bias transfer roller, located under the accumulator belt at the contact point with the photoconductive belt, carries a charge which varies between +300 and 350 volts based on the humidity, media, and print speed.

  • Page 106: Paper Picking

    Path for paper from optional Lower Tray Assembly 9013-12 Figure 5-9 Paper picking A similar pick and feed operation takes place in the optional lower tray assembly to pick and feed the sheet into the printer’s intermediate rollers. 5-12 Phaser 550 Color Printer...

  • Page 107: Toner Transfer To Paper

    Theory of Operation Toner transfer to paper Once all four layers of toner have been picked up on the accumulator belt, The aligning roller clutch is energized to advance a sheet of paper (which has already been picked) to the second bias transfer roller. (In the user manual the second bias transfer roller is referred to as the transfer roller , a customer-replaceable consumable item.) The movement of the sheet of paper is timed so that the leading edge of the toner image on the accumulator belt meets with the paper...

  • Page 108: Fusing And Exiting

    Reverser the paper rollers Output tray Fuser unit full sensor Heated roller roller Fuser entrance Paper exit sensor sensor Pressure roller Output tray 9013-20 Figure 5-11 Fusing the toner to the paper 5-14 Phaser 550 Color Printer...

  • Page 109: Print Modes

    Theory of Operation Print modes The printer features five print modes: Presentation, Fast Color, Standard, Enhanced, and Premium. Standard, Presentation and Fast Color mode is 600 x 600 dpi printing. Enhanced mode is 1200 x 600 dpi printing. Premium mode is 1200 x 1200 dpi printing.

  • Page 110: Printer Color Correction

    Quick Reference Card and entering value changes through the front panels. This process is described in the Phaser 550 Color Printer User Manua l and well as in the Chapter 9 topic, “Manually setting color corrections”...

  • Page 111: Power Supply

    Theory of Operation Power supply The low voltage power supply generates five DC voltages: +5 VDC for the image processor logic. For short protection., a switching FET in the DC/DC converter monitors the output voltage and in the event of a short, cuts the voltage off. +5VDC for the engine control logic.

  • Page 112: Image Processor

    The control loop, which oversees the operation of the graphics pipeline, routes the color planes to the engine driver that transmits the color plane data to the print engine. The control loop also monitors the control and error signals fed back from the print engine. 5-18 Phaser 550 Color Printer...

  • Page 113: Figure 5-14 The Image Processor Graphics Pipeline

    Theory of Operation Control loop PostScript Rasterizer Engine Parallel Print interpreter driver engine serializer SCSI Ethernet Network Serial card Fonts in LocalTalk Image processor 9013-58 Figure 5-14 The image processor graphics pipeline Service Manual 5-19...

  • Page 115: System Power-Up Sequence

    Chapter Troubleshooting This chapter discusses troubleshooting the printer. Troubleshooting is discussed with two approaches: A step-by-step verification procedure that systematically confirms that particular components of the printer are properly functioning until a problem is found. A symptom/cause scheme that lists particular printer failures and error codes and their possible causes.

  • Page 116: Print Engine Troubleshooting

    If the printer does not make the gray fill print, then a problem exists with the printer. If the printer does not print a test pattern, then a problem exists with the print engine. Proceed with the topic, “Verifying power supply operation” on page 6-3. Phaser 550 Color Printer...

  • Page 117: Verifying Printer Operation By Using Its Self-Test Print

    Troubleshooting Verifying printer operation by using its self-test print If not already on, turn on the printer. If the printer does not power up, or does not initialize, or the printer initializes but the motors do not run properly, go to the next topic “Verifying power supply operation.” When the Ready message is displayed, press the Menu button to enter the menu.

  • Page 118: Inspecting The Power Supply Fuses

    If DC voltages are not being output by the printer, proceed to the next step, “Inspecting the power supply fuses” on page 6-5. If the +5, +12 and -12 VDC voltages measure correctly, but the printer does not operate correctly, then proceed to the topic, “Safety interlocks.” Phaser 550 Color Printer...

  • Page 119: Safety Interlocks

    Troubleshooting Inspecting the power supply fuses The 115 VAC power supply features a 10 A and 6.3 A fuse. The 220 VAC power supply fuse uses a 8 A fuse. Turn off the printer. Remove the power supply as explained in the Chapter 8 topic, “Power supply”...

  • Page 120: Testing For A Shorted Motor

    If the power supply is functional, proceed to the topic, “Testing motor resistances” on page 6-7. If the motors and solenoids are functional, but the power supply still does not function, replace it. Refer to the Chapter 8 topic, “Power supply” on page 8-11. Phaser 550 Color Printer...

  • Page 121: Testing Motor Resistances

    Troubleshooting Testing motor resistances Required tools #1 Phillips screwdriver With a VOM set for measuring resistance, test each motor's windings for its correct resistance. Rotate the motor's drive shaft slowly while taking the measurement. Table 6-1 Motor and solenoid resistances Motor or solenoid Connector Resistance (approximately)

  • Page 122: Media Jams And The Paper Path

    Is the printer printing within its environmental specifications? Refer to the Chapter 1 topic, “Specifications” on page 1-14. Ensure the corners or the paper are under the tabs in the corners of the tray. Clean the pick rollers. Replace the paper tray. Phaser 550 Color Printer...

  • Page 123: The Printer Is Not Distinguishing Between Paper And Transparency Film

    Troubleshooting The printer is not distinguishing between paper and transparency film Is the paper tray set for the desired media with the appropriate tray sensor actuators? Refer to the Chapter 1 topic, “Media tray type sensing” on page 1-12. Do the tray’s switch actuators properly press the tray sensors? Replace the tray sensor board.

  • Page 124: Paper Tray Indicates Empty When It Is Not

    When the imaging unit is installed, the boss pushes a flag on the charger sensor board. Replace the charger or imaging unit if it is broken. Check the HV terminal connectors for the imaging unit to ensure that they are not damaged. 6-10 Phaser 550 Color Printer...

  • Page 125: Jams

    Troubleshooting Jams Paper mis-picks at the paper tray Is the paper in good condition and appropriate for a laser printer? Is the printer printing within its environmental specifications? Refer to the Chapter 1 topic, “Specifications” on page 1-14. Is the pick-up roller dirty? If so, clean it and try printing again. Does the pick roller rotate? If the roller does not rotate, does the paper feed motor run? Check the motor’s wiring harness and connection (CN306) to the engine driver...

  • Page 126: Paper Jams At The Second Bias Transfer Roller

    1 kg (2.2 lbs). Check the left side door for burrs or foreign obstructions that could block the movement of a sheet of paper. Try printing using a different paper tray. 6-12 Phaser 550 Color Printer...

  • Page 127: Fuser Jams

    Troubleshooting Fuser jams Is the paper in good condition and appropriate for a laser printer? Is the printer printing within its environmental specifications? Refer to the Chapter 1 topic, “Specifications” on page 1-14. Inspect the fuser’s gear train leading to the paper feed motor. Does it rotate properly? Do any of the gears show broken teeth? Does the fuser exit sensor flag properly actuate its sensor? Inspect the wiring harness leading from the cartridge sensor/eject unit...

  • Page 128: Manual Feed Jams

    (connector CN602). Ensure that the wiring harness is not damaged. Check the wiring harness leading from the paper feeder to the engine driver board (connector CN309). Replace the paper feeder circuit board. Replace the engine driver board. 6-14 Phaser 550 Color Printer...

  • Page 129: Other Problems

    Troubleshooting Other problems These problems may be indicated as errors on the front panel. The printer continuously displays “Initializing” The most likely cause is that the image processor has not loaded its EEPROM contents (instructions) into RAM successfully. This is usually indicated by the health indicator (heart beat) being on or off but not flashing.

  • Page 130: No Toner Cartridge Installed When It Is

    Is the left door open switch, located in the lower-left back corner of the printer, properly in place? Does closing the left door actuate the left door open switch? Is the left door properly in place? Replace the door if it does not operate correctly. 6-16 Phaser 550 Color Printer...

  • Page 131: High Temperature Error

    Troubleshooting Is the left door open switch’s wiring harnesses properly connected to the engine driver board (CN312 – 24V interrupt)? In the case of the Lower Tray Assembly, is the printer properly seated onto the Lower Tray Assembly with good electrical connection. Try reseating the printer.

  • Page 132: Thermistor Open Error

    Check the dip switches on the engine drive board; SW301 switch 4 should be up, all the rest should be down. Make sure all connectors to the circuit boards are well seated and make sure that the screws holding the boards’s in place are tight. 6-18 Phaser 550 Color Printer...

  • Page 133: Error Messages

    Troubleshooting Error messages Generally, the top line of the two-line front panel display indicates the printer’s status, such as Ready, Printing, Busy, or Stopped. The bottom line indicates the function of the three buttons located immediately below the LCD. The front panel also displays error codes when it encounters certain system failures.
  • Page 134 3. Inspect the wiring harness leading from the accumulator belt position sensor to CN13 of the engine control board. 4. Replace the imaging unit. 5. Replace the accumulator belt position sensor. 6. Replace the engine control board. 6-20 Phaser 550 Color Printer...
  • Page 135 Troubleshooting Table 6-2 Print engine service error codes (cont'd.) Error code Meaning of error code and what to do about it Positioning error of the photoconductive belt. 1. Ensure that the imaging unit is properly installed and locked in place. 2.
  • Page 136 If not replace the imaging unit. 3. Does the main motor rotate? Check the main motors wiring harness to the engine driver board at CN313. If the wiring checks out, replace the main motor. 4. Replace the engine driver board. 6-22 Phaser 550 Color Printer...
  • Page 137 Troubleshooting Table 6-2 Print engine service error codes (cont'd.) Error code Meaning of error code and what to do about it Program ROM Check sum error. 1. Replace the engine control board. Program SRAM Check sum error. 1. Replace the engine control board. EEPROM read/write error.

  • Page 138: Printing And Print Quality Problems

    Inspect the scorotron charge (main charger) for a broken corona wire. Replace the scorotron charger. Replace the high-voltage board Replace the laser scanner. Margins are white, print is black. Replace the image processor board Replace the engine control board. 6-24 Phaser 550 Color Printer...

  • Page 139: Missing Primary Color

    Troubleshooting Missing primary color Replace the toner cartridge of the missing color. Determine if the cartridge selector is pushing the toner cartridges into contact with the photoconductive drum. Check the wiring harness leading from the cartridge selector/eject unit to CN308 of the engine control board. Replace the toner cartridge drive unit.

  • Page 140: Repeated Spots Or Lines On Print In-Line With Each Other

    Missing primary color on one side of print Replace the toner cartridge above the toner cartridge whose color is missing. The bottom latch of the upper toner is preventing the protective cover of the toner cartridge below from opening. 6-26 Phaser 550 Color Printer...

  • Page 141: White Horizontal Line Or Band In All The Colors Of A Print

    Troubleshooting White horizontal line or band in all the colors of a print Replace the imaging unit. Replace the second bias transfer roller. Inspect it for loose roller contacts. Grease the end of the roller shaft with conductive grease. White vertical lines in the print Inspect the path the laser beam travels for foreign matter that could block the beam from striking the photoconductive belt.

  • Page 142: Dark, Irregular Steaks In All Colors

    Chapter 1 topic, “Specifications” on page 1-14. Ensure that the paper feeder is properly installed. Inspect its paper pick roller. Clean the intermediate and aligning rollers. Replace the paper feeder. Replace the engine control board. 6-28 Phaser 550 Color Printer...

  • Page 143: Stains On The Back Of The Print

    Troubleshooting Stains on the back of the print Clean the second bias transfer roller with a dry, lint free cloth. Clean the paper path of the paper feeder. Replace the paper feed unit. Inspect the fuser rollers for contamination. Replace the fuser. No printing on edge of print Check the bottom latch of the toner cartridge above the cartridge with the missing color operates correctly.

  • Page 144: The Print Is Wrinkled

    If the print is exiting the printer with “dog-ears” (the corners folded down, check the paper separators metal tabs in the corners of paper tray. Bend the tabs slightly to correct the problem or replace the tray. 6-30 Phaser 550 Color Printer...

  • Page 145: Macintosh Printing Problems

    In the print dialog box, make sure that the Color/Grayscale option has been selected. Make sure that the Phaser 550 icon was selected in the Chooser. Try printing the job again. Check the version of your LaserWriter driver to ensure that it is version 6.0.x or higher.

  • Page 146: Printer Isn't In The Chooser

    Check and add, if necessary, the following line to the AUTOEXEC.BAT file: mode = LPT1,,,p (If your port is not LPT1, substitute LPT2: or COM1: for the correct port). The character p turns on printer retry indefinitely. 6-32 Phaser 550 Color Printer...
  • Page 147 PRINT button to print an internal test print. Is the printer in PostScript mode? Check this by printing the configuration page. Refer to Phaser 550 Drivers and Utilities Printing Reference for complete instructions on sending a utility file to the printer to set the port to PostScript mode.

  • Page 148: Windows Printing Problems

    (CMY), blue is often printed as purple. To adjust blue from within Microsoft Windows: Within the Tektronix PostScript Windows driver you have an option, Vivid Color, that alters the blue colors that are appearing purple.

  • Page 149: Workstation Printing Problems

    Troubleshooting The MODE command disables DOS timeouts. The LPT1.OS2 selection forces Windows to print through DOS instead of directly to the printer. The Option #1 solution does not allow customers to spool documents using the Print Manager. To use the Print Manager as well as correcting time-out problems, edit the following line in the win.ini file: TransmissionRetryTimeout=45 to: TransmissionRetryTimeout=995...

  • Page 151: Cleaning And Maintenance

    Chapter Cleaning and Maintenance Service preventive maintenance procedure Whenever you check, service, or repair a printer, you should perform the following procedures. Cleaning the printer, as outlined in the following steps, assures proper operation of the printer and reduces the probability of having to service the printer in the future.

  • Page 152: Cleaning

    Vacuum out the interior of the printer. Lubrication Molybdenum-based (brown) grease, part number 006-7436-00 For all metal-to-metal, metal-to-plastic, and plastic-to-plastic gears. High-temperature, electrically-conductive grease, part number 006-7056-00 For the plastic gears of the fuser and the end of the transfer roller shaft. Phaser 550 Color Printer...

  • Page 153: Required Tools

    Chapter Disassembly/Assembly This chapter explains how to remove and replace many of the printer's Field Replaceable Units (FRUs). This chapter covers procedures for FRUs that are difficult to remove or require special handling or precautions. Refer to Appendix A for a list of the printer's FRUs. Required tools Magnetic tip screwdrivers;...

  • Page 154: The Printer Cabinet

    Remove the four screws securing the left side cover to the print engine. Tilt forward and remove the cover. Manual feed tray Tilt the tray up slightly and squeeze the tray’s retaining pins inward to free it from the print engine frame. Phaser 550 Color Printer...

  • Page 155: Figure 8-1 Removing Cabinet Covers

    FRU Disassembly/Assembly Top cover Upper rear cover Left side cover Manual feed tray Left door Lower rear cover 9013-27 Figure 8-1 Removing cabinet covers EMI shields EMI shielding on the printer may change as the printer is refined. Initial printers feature many metal plates and shields. Later models may have fewer or no shields.

  • Page 156: Front Door

    Remove the top cover. Remove the imaging unit. Cover the imaging unit to protect its photconductive belt from light. Remove the three screws securing the toner level sensor board in place. Disconnect the sensor board’s wiring harness. Remove the sensor. Phaser 550 Color Printer...

  • Page 157: Right Side Covers (Front, Rear And Lower)

    FRU Disassembly/Assembly Right side covers (front, rear and lower) Remove the front and rear right side covers before removing the right side lower cover. Remove the paper tray. Remove the two screws securing each of the three right side cover in place.

  • Page 158: Paper Feeder

    Slide the paper feeder off the rails. Paper tray sensor board Remove the paper feeder as explained in the previous procedure. Remove the paper tray. Disconnect the wiring harness leading to the paper tray sensor board. Phaser 550 Color Printer...

  • Page 159: Figure 8-3 Removing The Paper Feeder And The Paper Tray Sensor Board

    FRU Disassembly/Assembly Remove the two screws securing the sensor board to the printer. (Lift the paper empty sensor flag out of the way while you lift the paper tray sensor board out.) Paper tray sensor board Paper feeder Back-out stop screws 9013-29 Figure 8-3 Removing the paper feeder and the paper tray sensor board...

  • Page 160: Cartridge Selector/Eject Unit (Right Door)

    Remove the shaft and then remove the cartridge selector/eject unit. Cartridge selector/ eject unit (right door) Disconnect wiring harness Remove E-ring Remove E-ring and bushing from each end of the cartridge selector/eject unit 9013-30 Figure 8-4 Removing the cartridge selector/eject unit Phaser 550 Color Printer...

  • Page 161: Laser Scanner

    FRU Disassembly/Assembly Laser scanner Remove the top cover as explained in the earlier topic, “Top cover” on page 8-2. Disconnect the four wiring harnesses connected to the laser scanner. Remove the three screws securing the laser scanner in place. Lift and remove the laser scanner.

  • Page 162: Laser Motor Drive Board

    Remove the four screws securing the laser motor drive board. Lift and remove the laser motor drive board. Remove screw Remove three push pins Disconnect the two wiring harnesses 9322-69 Figure 8-6 Removing the laser modulation board 8-10 Phaser 550 Color Printer...

  • Page 163: Power Supply

    FRU Disassembly/Assembly Power supply Remove the upper and lower rear covers and the rear right side cover as explained in the earlier topic, “The printer cabinet” on page 8-2. Disconnect the wiring harnesses connected to the power supply. Remove the four screws securing the power supply in place. Lift and remove the power supply.

  • Page 164: Figure 8-7 Removing The Power Supply And The Fuser Installed Switch

    Power supply Disconnect the wiring harnesses Power supply frame tabs For reassembly: Route AC wiring harness through top of grommet AC wiring harness 9013-33 Figure 8-7 Removing the power supply and the fuser installed switch 8-12 Phaser 550 Color Printer...

  • Page 165: Power Supply Fuse

    FRU Disassembly/Assembly Power supply fuse Caution To avoid damaging the printer, only replace the power supply fuse with a fuse of the same type and rating. Remove the power supply as explained in the previous procedure, “Power supply” on page 8-11. Remove the power supply’s cover.

  • Page 166: Printer Rear Assemblies

    When installing a new board ensure that DIP Switch SW301, switch four (4) is in the up position, and that all other switches are down. This allows the print engine to read the Gamma Correction Density from the print engine control board NVRAM (IC2). 8-14 Phaser 550 Color Printer...

  • Page 167: Charger Sensor Board

    FRU Disassembly/Assembly Charger sensor board Remove the upper rear cover as explained in the earlier procedure, “Upper rear cover” on page 8-2. Remove the engine control board as explained in the previous procedure, “Engine control board” on page 8-14. Disconnect the wiring harnesses leading to the charger sensor board. Remove the two screws securing the board in place.

  • Page 168: Main Motor

    Disconnect the cleaning board’s wiring harness. Remove the three screws securing the cleaning board in place. Remove the cleaning board. If necessary, to remove the cleaning board bracket, remove the two screws securing the bracket in place. 8-16 Phaser 550 Color Printer...

  • Page 169: Figure 8-10 Removing The Main Motor, Paper-Feed Motor And Cleaning Board

    FRU Disassembly/Assembly Cleaning board Engine driver board bracket Paper feed motor Main motor 9013-36 Figure 8-10 Removing the main motor, paper-feed motor and cleaning board Service Manual 8-17...

  • Page 170: Toner Cartridge Drive Unit

    Left door opened switch. Open the left door. Squeeze the interlock switch’s cover to release it. Move it out of the way. Disconnect the wiring harness leading to the interlock switch. Remove the two screws securing the interlock switch in place. Remove the switch. 8-18 Phaser 550 Color Printer...

  • Page 171: Figure 8-11 Removing The Toner Cartridge Drive Unit, Home Position Sensor And The Left Door Interlock Switch

    FRU Disassembly/Assembly Toner cartridge Left door-opened drive unit interlock switch Home position sensor Interlock switch cover 9013-37 Figure 8-11 Removing the toner cartridge drive unit, home position sensor and the left door interlock switch Service Manual 8-19...

  • Page 172: High-Voltage Board

    Remove the four screws and the ground wire securing the high-voltage board to the printer. Remove the board. Wiring harness High-voltage board Card cage 9013-38 Figure 8-12 Removing the high-voltage board 8-20 Phaser 550 Color Printer...

  • Page 173: Pre-Exposure Lamp

    FRU Disassembly/Assembly Pre-exposure lamp Turn off the printer. Remove the imaging unit. Remove the screw securing the pre-exposure lamp in place. Disconnect the pre-exposure lamp’s wiring harness. Remove the lamp. Pre-transfer lamp Turn off the printer. Remove the imaging unit. Remove the E-ring securing the front end of the cleaning cam roller.

  • Page 174: Figure 8-13 Removing The Pre-Exposure Lamp, Pre-Transfer Lamp And Toner Auto-Density Sensor

    FRU Disassembly/Assembly Toner auto-density sensor Pre-exposure lamp Pre-transfer lamp Cleaning cam roller 9013-39 Figure 8-13 Removing the pre-exposure lamp, pre-transfer lamp and toner auto-density sensor 8-22 Phaser 550 Color Printer...

  • Page 175: Image Processor Board

    FRU Disassembly/Assembly Image processor board Power down the printer. Disconnect all host interface cables. Remove the upper rear cover as explained in the earlier topic, “Upper rear cover” on page 8-2. Disconnect the image processor’s data wiring harness from the engine control board.

  • Page 176: Installing Ram Simms

    FRU Disassembly/Assembly Installing RAM SIMMs Note The printer only uses Tektronix proprietary 16-Mbyte and 32-Mbytes RAM SIMMs. Installing a second RAM SIMM. If you are installing a second RAM SIMM in the printer, the larger capacity RAM SIMM must be installed in the SIMM 1 connector.

  • Page 177: Figure 8-15 Installing Ram Simms

    FRU Disassembly/Assembly Reinstall the EMI shield and the SIMM access cover. Close the manual feed tray. Print a startup page to check its listing of the printer's memory and options. Image processor board RAM SIMM access cover Manual feed tray RAM SIMM SIMM 2 SIMM 1...

  • Page 178: Installing An Extended Features Simm

    SIMM to lock it in place. Reinstall the EMI shield and the SIMM access cover. Close the manual feed tray. Print a startup page to check its listing of the printer's font capacity; it should read 39 fonts available. 8-26 Phaser 550 Color Printer...

  • Page 179: Figure 8-16 Installing An Extended Feature Simm

    FRU Disassembly/Assembly Image processor board EMI shield RAM SIMM access cover Manual feed tray Extended Features SIMM connector Extended Features SIMM RAM SIMM connectors 9322-80 Figure 8-16 Installing an Extended Feature SIMM Service Manual 8-27...

  • Page 180: Installing A Network Card

    Connect the appropriate host interface cable to the network card. Turn on the printer and print the startup page. It lists the installed memory and options. Network card 9013-43 Figure 8-17 Installing a network card in the printer 8-28 Phaser 550 Color Printer...

  • Page 181: Replacing The Code Rom Simm

    FRU Disassembly/Assembly Replacing the code ROM SIMM Turn off the printer. Do not unplug the printer; this preserves a ground path to dissipate static charges. Open the manual feed tray on the left side of the printer. Loosen the two thumbscrews securing the RAM access cover. Remove the EMI shield.

  • Page 183: Checks And Adjustments

    Chapter Checks and Adjustments This chapter discusses using the front panel’s interactive mode to review and change the printer’s operation. It also contains the procedures to calibrate the printer after you replace key Field Replaceable Units and to evaluate the printer's functionality.

  • Page 184: Front Panel Menu

    Transfer Kit TekColor:Display reference page Fuser TekColor: SWOP Startup Page Fast Color Adjust cyan TekColor: Euroscale Configuration Page Presentation Service Print 1 Adjust magenta TekColor: Commercial Service Print 2 Adjust yellow Monochrome Adjust black Reset Adjustments Phaser 550 Color Printer...

  • Page 185: Figure 9-2 Menu Map

    Checks and Adjustments Figure 9-2 Menu map Printer defaults menu Serial settings* Network settings** Language menu Default tray Baud Rate TCP/IP*** Language: English Upper Baud Rate: 300 TCP/IP: enabled Language: Español Middle Baude Rate: 600 TCP/IP: disabled Language: Français Lower Baud Rate: 1200 Language: Deutsch EtherTalk...

  • Page 186: Printing Test Prints

    Press and hold for 2 seconds the Test Print button in the center of the upper rear cover. This verifies the print engine’s ability to print independent of the image processor. Do not use this print to verify print quality. Phaser 550 Color Printer...

  • Page 187: Image Processor Normal Indicators

    Checks and Adjustments Image processor normal indicators There are three indications that the print engine and its image processor are powered-up and operating normally: the front panel POWER LED is on (steady), Ready is displayed on the front panel LCD display and the image processor health light is blinking (the flashing health light is viewable through the grill behind the manual feed tray).

  • Page 188: Printer Self-Diagnostics

    Pressing and holding Button 1 and 4, as you turn on the printer, allows you to reset the NVRAM to its factory-default values. Refer to the later topic, “Resetting NVRAM” on page 9-31. This also reset the NVRAM of an installed network card. Phaser 550 Color Printer...
  • Page 189 Checks and Adjustments Normal power-up self-tests. This test requires no paper or customer interaction. If a problem is encountered with the image processor's expansion memory or other options, then the information is printed on the printer's startup page. Normal power-up tests take slightly longer than one minute to complete. The health LED, located on the image processor board, flashing in a regular, one flash-per-second rate means no errors were detected and the image processor's CPU is running.

  • Page 190: Table 9-1 Print Engine Service Test Descriptions

    Indicates the state of the three tray sensor switches of the lower tray in the optional feeder. Pull out the tray and then Opt1TraySwitch 2 open the left door to access and manually push the switches. Opt1TraySwitch 3 Switch one is the rear-most switch. Phaser 550 Color Printer...
  • Page 191 Checks and Adjustments 50 Sensor Group B Output Tray Indicates the state of the output tray full sensor. Manually lift the sensor’s flag to see if the sensor detected the change. This test group automatically Manual Feed Indicates if the manual feed sensor is closed by a sheet of enters the engine’s paper.
  • Page 192 Quit the diagnostic mode and restart the printer. The printer will execute it power-up self-tests and then start PostScript. The printer must exit Engine Diagnostic mode (Test 57) before restarting the system or starting PostScript. Otherwise the printer will “hang.” 9-10 Phaser 550 Color Printer...

  • Page 193: Service Mode Status Code Meanings

    Checks and Adjustments Service mode status code meanings Service diagnostics test 41 Engine Status . Table 9-2, “Status code meanings,” on page 9-12 lists status codes displayed on the front panel when the print engine is in service mode and the test selected is 41 Engine Status. When the print engine detects a valid command or byte without parity error, the print engine controller board sends back the status of its condition in 35 different status buffers to the image processor board.
  • Page 194 The engine is also warming up and initializing or is ready for toner patch and gamma table data exchange. There is no print data re-transmit request. The printer is in standby condition. The NPRINT signal will start the printing action. There is no communication error. 9-12 Phaser 550 Color Printer...
  • Page 195 Checks and Adjustments Table 9-2 Status code meanings (cont'd.) Status Front Binary Meaning/Description State Panel . . . Status - 1 This status buffer shows the error condition when Status - 0 Bit 1 is 1. General 0. Odd parity. Error 1.
  • Page 196 Example There is no toner warning. The printer is not in a test state. The print engine has consumables life warning information. See Status - 44 for details. There is no communication error. 9-14 Phaser 550 Color Printer...
  • Page 197 Checks and Adjustments Table 9-2 Status code meanings (cont'd.) Status Front Binary Meaning/Description State Panel . . . Status - 5 This status shows whether the electrophotographic process parts are installed. It shows the details when Status - 0 Bit 1 and Status - 1 Bit 6 are 1. Unit Absent 0.
  • Page 198 The selected tray is set as a paper source mode. Example The printer is in paper mode. There is no optional tray 2. There is no optional tray 1. The printer is using the standard tray mode. There is no communication error. 9-16 Phaser 550 Color Printer...
  • Page 199 Checks and Adjustments Table 9-2 Status code meanings (cont'd.) Status Front Binary Meaning/Description State Panel . . . Status - 8 This status shows the paper jam condition when Status - 0 Bit 1 and Status - 1 Bit 3 are 1.
  • Page 200 0 = Always set to 0. 7. 1 = A communication error has occurred. 0 = There is no communication error. Status - 12 0000 0001 The installed tray is letter size. Example There is no communication error. 9-18 Phaser 550 Color Printer...
  • Page 201 Checks and Adjustments Table 9-2 Status code meanings (cont'd.) Status Front Binary Meaning/Description State Panel . . . Status - 14 This status shows the details of the printing process errors identified in the Status - 0 Bit 1, Status - 1 Bit 1, and Status - 2 Bit 6. Process Unit Error 0.
  • Page 202 0 = The print engine is in another mode. 6. 1 = The printer is in HHS operation mode. 0 = The print engine is in another mode. 7. 1 = A communication error has occurred. 0 = There is no communication error. 9-20 Phaser 550 Color Printer...
  • Page 203 Checks and Adjustments Table 9-2 Status code meanings (cont'd.) Status Front Binary Meaning/Description State Panel . . . Status - 17 0001 0000 The print engine is in diagnostic mode. Example Paper past test is in the other mode. The HHS operation is in the other mode. <tbd - what is HHS?> There is no communication error.
  • Page 204 A fuser thermistor has an open error. Example A fuser high temperature condition has not occurred. A fuser temperature “not increasing” has not occurred. A fuser low temperature condition has not occurred. There is no communication error. 9-22 Phaser 550 Color Printer...
  • Page 205 Checks and Adjustments Table 9-2 Status code meanings (cont'd.) Status Front Binary Meaning/Description State Panel . . . Status - 23 This status shows the details of errors that can occur with the laser scanner. This also relates to the detailed status of Status - 0 Bit 1, Status-1 Bit 1, and Status - 2 Bit 3. Laser Scanner 0.
  • Page 206 There is sufficient cyan toner in the toner cartridge. Example There is sufficient magenta toner in the toner cartridge. There is sufficient yellow toner in the toner cartridge. There is sufficient black toner in the toner cartridge. There is no communication error. 9-24 Phaser 550 Color Printer...
  • Page 207 Checks and Adjustments Table 9-2 Status code meanings (cont'd.) Status Front Binary Meaning/Description State Panel . . . Status - 32 This status shows the details of the warning mode concerning low paper and missing trays. Low paper refers to approximately 30 sheets, depending on the paper thickness. Empty/ If the optional paper feeder is not installed, Bits 1,2,4,5, = 0.
  • Page 208 The resolution is 1200 dots per inch. The power-up default is 1200 dpi. Example The 600 dots per inch mode command has not been received. The 1200 dots per inch mode command has not been received. There is no communication error. 9-26 Phaser 550 Color Printer...
  • Page 209 Checks and Adjustments Table 9-2 Status code meanings (cont'd.) Status Front Binary Meaning/Description State Panel . . . Status - 41 This status details the energy star mode (ESM) entry. This is not linked to any other status. Energy Start 0.
  • Page 210 The existing imaging unit is OK. Example The existing pre-transfer charger unit is OK. The existing second bias transfer roller is OK. The existing fuser is OK. The imaging unit’s waste toner bin is full. There is no communication error. 9-28 Phaser 550 Color Printer...
  • Page 211 Checks and Adjustments Table 9-2 Status code meanings (cont'd.) Status Front Binary Meaning/Description State Panel . . . Status - 45 This status shows details of the paper exit mode for the next print. This status is not linked to any other status. Eject Mode 0.
  • Page 212 7. 1 = A communication error has occurred. 0 = There is no communication error. Status - 47 0000 0010 The print engine is currently recalibrating its toner density sensor. Example There is no communication error. 9-30 Phaser 550 Color Printer...

  • Page 213: Resetting Nvram

    Checks and Adjustments Resetting NVRAM Resetting NVRAM returns all the image processor's NVRAM-stored parameters to their factory defaults except the print counts and the Adobe firmware serial number. Caution Resetting NVRAM will also reset the network card’s NVRAM. If this is not desired, remove the network card from the printer before performing the NVRAM reset.

  • Page 214: Print Engine Calibration

    Press the right arrow so the display reads Calibrate Colors. Press the Menu button to enter the Calibrate Colors menu. Press the right arrow to scroll to the Adjust each color menu item. Press Menu to enter the Adjust each color menu. 9-32 Phaser 550 Color Printer...

  • Page 215: Figure 9-4 Manual Color Correction Reference Print

    9317-53 Figure 9-4 Manual color correction reference print Overlay and compare the pre-printed primary colors on the Phaser 550 Quick Reference Card to the selected colors on the midline of the print. If any primary color does not match, overlay and compare to an alternate color.

  • Page 216: Checking Print Registration

    Checking print registration A simple way to determine if the printer is properly registering (overlaying) the layers of toner is to print and examine the Startup Page. Press the Menu button. With the Help pages menu displayed, scroll to the Startup Page item.

  • Page 217: Field Replaceable Units List

    Field Replaceable Units List This appendix provides a list of field replaceable units for the printer. Changes to Tektronix instruments are made to accommodate improved components as they become available. It is important when ordering parts to include the following information: Component's part number.

  • Page 218: Figure A-1 Cabinet Frus

    118-9203-00 Upper front cover (operation panel) w/display board 118-9206-00 Right side cover rear 118-9208-00 Right side cover front 118-9207-00 Right side cover lower 118-9182-00 Bottom front cover 436-0297-01 Output tray (standard) 9013-44 Figure A-1 Cabinet FRUs Phaser 550 Color Printer...

  • Page 219: Figure A-2 Cabinet Frus

    Upper rear cover (110 VAC) 118-9331-00 Upper rear cover (220 VAC) 118-9198-00 Top cover 118-9200-00 Left side cover 118-9199-00 SIMM access door 118-9184-00 Manual feed tray 118-9183-00 Left door 334-8366-30 Logo, Phaser 550 9013-45 Figure A-2 Cabinet FRUs Service Manual...

  • Page 220: Table A-3 Fru Parts List Of The Exploded Printer

    Toner cartridge drive unit 671-3805-00 Extended Features SIMM, Roman Font 671-3688-00 Extended Features SIMM, Kanji Font 671-3847-00 PostScript Code ROM SIMM (masked) 671-3847-00 Masked ROM, engine control board Z550 118-9174-00 Hardware kit 118-9176-00 Gear kit 650-3170-00 Spring kit Phaser 550 Color Printer...

  • Page 221: Figure A-3 The Internal Printer

    Figure A-3 The internal printer 9322-72 Service Manual...

  • Page 222: Table A-4 Supplies And Accessories

    161-0066-11 Power cord, Australian 070-9317-40 Phaser 550 User Manual (Spanish) 161-0154-00 Power cord, Swiss 070-9117-00 Phaser 550 Drivers and Utilities Printing Reference Manual 016-1318-00 Transfer Kit (Transfer roll and Waste box) 070-9508-00 Phaser Share Network Manual 118-9070-00 Scorotron charger corona unit...
  • Page 223 Appendix Test Prints This appendix illustrates the test prints produced by the print engine. It also illustrates a number of defective prints and the reason for the defects. The Chapter 6 Troubleshooting topic “Printing and print quality problems” on page 6-24 discusses solutions to the problems shown in this appendix. Test Print consists of four 25% tint primary color bands.
  • Page 224 Test Prints Vertical line or scratch in print, single color If the scratch is of one missing primary color, then the trouble can usually be traced to a scratch in the developer roller of the missing toner’s toner cartridge. No toner is transferred from the developer roller to the photoconductive belt at the defect point.
  • Page 225 Test Prints Small, repeating light dot in one color This can usually be traced to a dent-like defect in the developer roller of the toner cartridge in question. The dents should be 1.5 inches (3.4 cm) apart or 1 inch (2.5 cm) for 1200 dpi printing. No toner is transferred from the developer roller to the photoconductive belt at the defect point.
  • Page 226 Test Prints Large, random light smudges Spots such as those illustrated are caused by fingerprints on the photoconductive or accumulator belt. Often, the smudges will gradually fade with additional printing. Alternately, the imaging unit will have to be replaced. Finger prints can be removed by applying some toner (any color) to the fingerprints and rubbing lightly with a cotton-tipped swab.
  • Page 227 Test Prints Faded, pale prints The imaging unit is old or has been exposed to too much room light. Replace the imaging unit. The image density sensors are not properly measuring the amount of toner transferred to the accumulator belt. Clean or replace the sensors.
  • Page 228 Test Prints One primary color faded or pale OR a single color has a dark vertical streak This indicates a problem with a single toner cartridge. Replacing the toner cartridge should fix the problem. If it does not, there may be a problem with the toner cartridge selector/eject unit.
  • Page 229 Test Prints Contamination of one color by another This is most noticeable on solid primary fills. This is caused by a defective photoconductive cleaning blade. The blade is not scraping off all of the untransferred toner from the previous pass of the photoconductive belt to the accumulator belt prior to the next toner’s transfer to the photoconductive belt.
  • Page 230 Test Prints Interpreting Service Print 2 Service Print 2 is useful for evaluating the condition of the imaging unit. With a properly functioning imaging unit and printer, you should see the following: 1. Diagonal lines. These two lines should be smooth and unbroken.
  • Page 231 Index Adobe PostScript Level 2 1-2 Fast Color 1-2 all-black print 6-24 field replaceable units list A-1 antistatic mat 8-1 Font Downloader Utility 2-11 authorization code, TCP/IP 8-29 front panel description 1-7 menu 9-2 messages 6-19 black print 6-24 FRUs blank print 6-24 parts list A-1 block diagram of printer 5-2...
  • Page 232 2-9 resetting NVRAM, image processor 9-31 using the Error Handler Utility 3-8 PC verification 3-5 PCL printer language, optional 1-2 Phaser 550 PPD file, installing 2-21 Phaser 550,description 1-2 photoconductive belt 5-4 PostScript Level 2 1-2 power supply...
  • Page 233 1-12 Standard Windows PostScript driver, white print 6-24 updating 2-28 Windows 3.1 startup page driver verification 3-6 description 2-13 Tektronix driver 2-24 printing 9-4 Windows 95 printer driver 2-22 supplies, ordering 4-7 Windows printer driver configuring 2-25 installing 2-24 TCP/IP workstation configuring 2-35...

  • Page 235: Figure C-1 Wiring Diagram

    Appendix Wiring Diagram Laser driver board CN502 CN 540 Front panel CN 1 Laser scanner CN 11 J219 SCSI J811 Toner cartridge CN 16 CN 570 sub bias board Image J211 Parallel processor CN 4 CN 701 Orange J511 CN 1 High voltage DEV Yellow STR Black...
