USCutter LaserPoint3 User Manual & Assembly Instructions page 11

USB CABLE PORT
SERIAL (COM) CABLE PORT
POWER SWITCH
POWER CABLE PORT
FUSE HOLDER SLOT
LOCKING KNOB
RIGHT SIDE VIEW
USB CABLE PORT
SERIAL (COM)
CABLE PORT
NOTE: Only one connection to the PC
is needed,
recommended that you use USB.
LEFT SIDE VIEW
POWER CABLE
POWER SWITCH
FUSE HOLDER
CARRIAGE SLOT
CARRIAGE SLOT
LOCKING KNOB
425.481.3555
Get to know your cutter
Used to connect a USB
cable from the cutter to
a computer. (Best option)
Used to connect a serial
cable from the cutter to a
computer.
either USB or
Used to connect a power
cable from
to a wall outlet or surge
PORT
protector.
Main power switch for
turning the power of the
cutter on (1) or off (0).
Allows access to the fuse
SLOT inside of the cutter.
Holds the blade carriage
in place.
Allows access
blade/pen carriage slots
for exchanging/replacing
carriages.
11
