Getting to know your cutter

Before you start cutting, you should familiarize yourself
with the cutter along with its basic parts and functions.
LEFT SIDE COVER
CONTROL PANEL
CARRIAGE ARM
PINCH ROLLERS
FEED ROLLERS
POSITIONING LASER
LEFT SIDE COVER
RIGHT SIDE COVER
PINCH ROLLERS
FEED ROLLERS
Used to provide input directly to the cutter. Covered in
detail in the "Control Panel" section of this manual.
Holds the blade (or pen) carriage.
Holds the media tightly to the feed roller below.
Positions the cutting material during operation.
Used by the cutter to determine the location of cut contours
Contains the power cable port, power switch, and fuse
cartridge for the cutter.
Contains the USB and serial cable ports for the cutter.
10
425.481.3555
CARRIAGE ARM
CARRIAGE
POSITIONING LASER
www.uscutter.com
CONTROL PANEL
RIGHT SIDE COVER
