Instrument Setup

Icons - Setup and Other Screens

When you open the Setup Screen or the system screens, you will see the following icons for the control
buttons. Refer to Figures SU-8 and SU-9.
Down Icon - Press this icon to move down
the screen or go to a different page.
Up Icon - Select this icon to move up the
screen or to a different page.
Left Icon - Select this icon to move left on
the screen.
Right Icon - Select this icon to move right
on the screen.
Enter Icon - Select this icon to enter a com-
mand or make a selection.
Plus Icon - Select this icon to increase a
highlighted number on the screen.
Minus Icon - Select this icon to decrease a
highlighted number on the screen.
15180-101 Rev. F
(continued)
Figure SU-08 Control Button Icons for
Setup screen
Figure SU-09 Control Button Icons for
Date/Time Screen
