- Page 1 Lo-Carbon Quadra SELV Installation and Wiring Instructions Stock Ref. N° Quadra SVTP 442865 Quadra SVHTP 442866 Quadra SVTM 442867 Safety Extra Low Voltage IPX7 PLEASE READ INSTRUCTIONS IN CONJUNCTION WITH ILLUSTRATIONS. PLEASE SAVE THESE INSTRUCTIONS.
- Page 2 G. Ensure that the mains supply (Voltage, Frequency, and Phase) complies with the rating label. H. The Fan should only be used in conjunction with the appropriate Vent-Axia products. It is recommended that the connection to the fan connector terminals is made with flexible cable.
-
Page 3: Installation
Wall Kit (25 41 02 White / 25 41 00 Brown) can be used. Please see our catalogue or web site (www.vent-axia.com) for more information on alternative ducting and termination options. A Filter (439927) is also available as an accessory. - Page 4 Remove the small Internal Cover that covers the Terminal Block in the top right corner (fig 3). Using the Fan Chassis as a template, carefully sliding the spigot into the Wall Liner, mark the fixing hole centres on the wall. Drill and plug the wall using the fixings provided.
-
Page 5: Timer Adjustment
Setting all of those 3 switches to the left (off positions) will switch off the constant trickle option (i.e the fan will normally be off and will switch to boost when the Pullcord, PIR, LS or Humidity Sensor are activated). 2. - Page 6 Remove the Impeller (fig.3) by pressing the two clips together in the middle and pulling it off the Motor. Wipe the outside of the fan with a damp (not dripping wet) cloth until clean. Wash the Filter, Cover Assembly and Impeller in warm, soapy water if they are dirty. Do not use abrasive cleaners.
- Page 7 Fig.3. Internal Terminal Block Cover. Spigot. Cover Assembly. Chassis Assembly. Impeller. Optional Filter. Fig.4. Internal Terminal Block Cover. Cable Clamp. Terminal Block. Timer and Humidity Adjustment. Speed and Installation Type Switches.
- Page 8 Fig.5. Frame from optional Flush Mount Kit. Back Box. Fig.6. Panel Clip Screw (4 off). Panel Clip (4 off).
- Page 9 Fig.7. Timer adjustment. Turn clockwise to increase overrun timer. Humidity Setpoint Adjustment. Turn clockwise to raise set point. Boost Speed (l/s) Speed Selection Switches. (Example shown is boost speed of 15 l/s and normal/trickle speed of 6 Normal/Trickle Speed (l/s) l/s.) Installation Type Selection Switches: ...
- Page 10 Fig 8. Siting of the fan. Fig 9. Wiring diagram without LS connection. SELV Supply (24V DC) Controller Fig 10. Wiring diagram with LS connection. SELV Supply (24V DC) Controller...
-
Page 11: Product Fiche
PRODUCT FICHE For Residential Ventilation Units (Complying Commission Delegated Regulation (EU) 1254/2014) Name: Vent‐Axia Vent‐Axia Vent‐Axia Lo‐Carbon Quadra Lo‐Carbon Quadra Lo‐Carbon Quadra Model ID (Stock Ref.) : SVTP ‐ 442865 SVHTP ‐ 442866 SVTM ‐ 442867 SEC Class SEC Value ('Average') 26.23 26.23 26.23 SEC Value ('Warm') 11.86 11.86 11.86 SEC Value ('Cold') 51.31 51.31 51.31 Label Required? (Yes/No=Out of scope) Declared as: RVU or NRVU/UVU or BVU RVU‐UVU RVU‐UVU RVU‐UVU Speed Drive 2‐Speed... - Page 12 IF CLAIMING UNDER TERMS OF GUARANTEE Please return the complete product, carriage paid to your original supplier or nearest Vent-Axia Centre, by post or personal visit. Please ensure that it is adequately packed and accompanied by a letter clearly marked “Guarantee Claim”...
