- Page 1 08.2018 New as of: SiroCam UAF Plus Operating Instructions English...
-
Page 2: Table Of Contents
Table of contents Dentsply Sirona Operating Instructions SiroCam UAF Plus Table of contents General information ....................Dear customer ..................... Contact information..................About this user manual ................1.3.1 General information ............... 1.3.2 Conventions ................... 1.3.3 Identification of the danger levels .......... - Page 3 Dentsply Sirona Table of contents Operating Instructions SiroCam UAF Plus 4.10 Video window controls ................. 4.11 Video options ....................Cleaning........................Handpiece....................Lens surface ....................Cleaning products ..................Technical data ......................Optical......................Physical......................Electrical ...................... Ambient......................Specifications....................Electromagnetic Emissions................Electromagnetic Immunity................
-
Page 4: General Information
● Easily portable between operatories. These Operating Instructions are designed to assist you prior to initial use and whenever you require information later on. We wish you a great deal of success with the SiroCam UAF Plus. Your SiroCam UAF Plus Team Contact information... -
Page 5: About This User Manual
Dentsply Sirona 1 General information Operating Instructions SiroCam UAF Plus 1.3 About this user manual About this user manual 1.3.1 General information Read the document Use this manual to become familiar with the software before using it. It is essential that you observe the warning and safety information specified in this manual. -
Page 6: Conventions
1 General information Dentsply Sirona 1.3 About this user manual Operating Instructions SiroCam UAF Plus 1.3.2 Conventions Example Meaning Click A single click down and releasing of the left mouse button. Double-click Clicking and releasing of the left mouse button twice in quick succession. -
Page 7: Identification Of The Danger Levels
“Command / menu item” Indicates commands / menu items or quotations. Intended use SiroCam UAF Plus is intended for intraoral use by dental professionals. It is not intended to be used for any kind of diagnosis. 66 90 643 D3762 D3762.201.01.01.02 08.2018... -
Page 8: Requirements
Operating Instructions SiroCam UAF Plus Requirements 1.5.1 Operating systems SiroCam UAF Plus is compatible with Sidexis 4.2 or higher. Sidexis 4.2 is compatible with the following operating systems: ● Windows 10 Professional (64-bit) ● Windows 8.1 Professional (64-bit) ● Windows 7 Professional SP1 (32- and 64-bit) 1.5.2... -
Page 9: Safety
Dentsply Sirona 2 Safety Operating Instructions SiroCam UAF Plus 1.5 Requirements Safety Check the Camera before Using It There are no customer-serviceable components in the camera. However, before each usage, check the outer surface of the camera for any signs of physical damage or defect. The surface of the camera should have a smooth finish, with no evidence of chipping or damage to either the handpiece housing or the lens section. -
Page 10: Symbols
2 Safety Dentsply Sirona 2.1 Symbols Operating Instructions SiroCam UAF Plus which extends from the patient for a distance of 1.5m. To comply with these standards, do not operate non-medical equipment (such as a PC workstation) inside the patient area. Outside the patient area, the... -
Page 11: Weee
Dentsply Sirona 2 Safety Operating Instructions SiroCam UAF Plus 2.2 WEEE WEEE Background The European Union’s Waste Electrical and Electronic Equipment (WEEE) Directive (2002/96/EC) has been implemented in member states as of August 13, 2005. This directive, which seeks to reduce the waste of electrical and electronic equipment through re-use, recycling, and recovery, imposes several requirements on producers. -
Page 12: Installation
ü The camera is not connected to the PC. 1. Log onto your PC with an administrator account. 2. Insert the "SiroCam UAF Plus" CD into your PC's CD/DVD drive. 3. Browse for the "Sidexis Video Modules" setup folder and open it. - Page 13 Dentsply Sirona 3 Installation Operating Instructions SiroCam UAF Plus 3.1 Install Sidexis 4 video modules 7. When setup is complete, click Finish. 66 90 643 D3762 D3762.201.01.01.02 08.2018...
-
Page 14: Install Sirona Uaf Plus Module
ü The camera is not connected to the PC. ü You are logged into your PC with an administrator account. ü The “SiroCam UAF Plus” CD is in your PC’s CD/DVD drive. 1. Browse for the “Sirona UAF Plus Module” setup folder and open it. - Page 15 Dentsply Sirona 3 Installation Operating Instructions SiroCam UAF Plus 3.2 Install Sirona UAF Plus module 5. When setup is complete, click Finish. 66 90 643 D3762 D3762.201.01.01.02 08.2018...
-
Page 16: Operation
4 Operation Dentsply Sirona 4.1 Prior to initial use Operating Instructions SiroCam UAF Plus Operation Prior to initial use Before using the camera for the first time, make sure you have cleaned it thoroughly. Procedures for cleaning the camera handpiece and the lens surface can be found in the “Cleaning”... -
Page 17: Camera Options
Dentsply Sirona 4 Operation Operating Instructions SiroCam UAF Plus 4.4 Camera options Camera options 4.4.1 Turning the camera on or off If the camera is off, perform any of the following actions to turn the camera ON: ● Remove the camera from its holder. -
Page 18: Protective Sheaths
4 Operation Dentsply Sirona 4.5 Protective sheaths Operating Instructions SiroCam UAF Plus Protective sheaths To place protective camera sheaths, perform the following steps: ü New camera sheath is available. 1. Holding the camera with the lens surface facing down, insert the camera into the protective hygienic sleeve. -
Page 19: Operate The Camera
Sidexis 4. 3. Click on the SiroCam UAF Plus image in the Status bar. SiroCam UAF Plus highlighted 66 90 643 D3762... -
Page 20: Stream Live Images
2. Press and hold the camera handpiece button down for about one second. 3. Click on the SiroCam UAF Plus image in Sidexis 4. Ä The camera will auto-focus automatically during operation. When positioning the camera, find an optimal distance from the object or image area. -
Page 21: Save Or Discard Images In Sidexis
Dentsply Sirona 4 Operation Operating Instructions SiroCam UAF Plus 4.9 Save or discard images in Sidexis 4 Save or discard images in Sidexis 4 As still images are captured, they accumulate in a vertical column next to the video window. Depending on the Video Plugin setting for marking images, they are set initially to be saved or discarded. -
Page 22: Discarding Images
4 Operation Dentsply Sirona 4.9 Save or discard images in Sidexis 4 Operating Instructions SiroCam UAF Plus 4.9.2 Discarding images To select images to be discarded, perform the following step: ü Captured still images are available. ➢ If the images are already selected to be discarded, meaning that they are shown with “X”... - Page 23 Dentsply Sirona 4 Operation Operating Instructions SiroCam UAF Plus 4.9 Save or discard images in Sidexis 4 One image selected to be saved; the others to be discarded 66 90 643 D3762 D3762.201.01.01.02 08.2018...
-
Page 24: Video Window Controls
4 Operation Dentsply Sirona 4.10 Video window controls Operating Instructions SiroCam UAF Plus Video window controls 4.10 The video window controls, and the settings in Video Plugin Options, determine how images are saved or discarded at the end of the video session. -
Page 25: Video Options
Dentsply Sirona 4 Operation Operating Instructions SiroCam UAF Plus 4.11 Video options Video options 4.11 Settings are available in Sidexis 4 to provide different ways of managing the video window and saving images. ü Sidexis 4 is running. 1. Click on the Settings (gear) icon. -
Page 26: Cleaning
5 Cleaning Dentsply Sirona 5.1 Handpiece Operating Instructions SiroCam UAF Plus Cleaning Handpiece Before using the camera the first time, and before every new patient, the following protocol is recommended: 1. Remove and discard all protective hygienic barriers and / or sheaths from the camera prior to removing disposable gloves. -
Page 27: Technical Data
Dentsply Sirona 6 Technical data Operating Instructions SiroCam UAF Plus 6.1 Optical Technical data Optical Lighting Lens Auto-focus Sensor technology ¼-inch CMOS Resolution (pixels) 1296 x 796 Depth of field (mm) 2 to 130 Magnification x250 (maximum) Viewing angle (degrees) 90°... -
Page 28: Ambient
6 Technical data Dentsply Sirona 6.4 Ambient Operating Instructions SiroCam UAF Plus Ambient Transport and storage conditions Temperature -40° C to +70° C Relative humidity (%) 10 to 95 Atmospheric pressure (hPa) 500 to 1060 Operating conditions Temperature +10° C to +40° C... -
Page 29: Electromagnetic Immunity
Dentsply Sirona 6 Technical data Operating Instructions SiroCam UAF Plus 6.7 Electromagnetic Immunity Emission measurement Conformity Electromagnetic environment - guidelines RF emissions according to CISPR 11 Group 1 The UNIT uses RF energy only for its internal function. Therefore, its RF emissions are very low and are not likely to cause any interference in nearby electronic equipment. - Page 30 6 Technical data Dentsply Sirona 6.7 Electromagnetic Immunity Operating Instructions SiroCam UAF Plus Interference immunity IEC 60601-1-2 test Compliance level Electromagnetic environment – tests level guidelines Portable and mobile radio equip- ment must not be used within the recommended working clearance...
-
Page 31: Error Messages
Dentsply Sirona 7 Error messages Operating Instructions SiroCam UAF Plus Error messages Problems detected by the setup program during installation may cause an error message to appear. In the event a problem occurs during installation, please refer to the following table for recommended actions. -
Page 32: Troubleshooting
Ensure USB cable is connected nected or is not connected correctly to PC workstation NOTE: If the above actions do not resolve your issue, please contact a Dentsply Sirona support representative or an authorized dealer for further assistance. 66 90 643 D3762 D3762.201.01.01.02 08.2018... -
Page 33: Accessories And Consumables
Dentsply Sirona 9 Accessories and consumables Operating Instructions SiroCam UAF Plus Accessories and consumables Accessories Illustration Designation Lot size Purchase order number SiroCam UAF 1 pc. 6679810 Plus holster Consumables Illustration Designation Lot size Purchase order number SiroCam UAF 1 box (300 pcs) - Page 34 We reserve the right to make any alterations which may be required due to technical improvements. © Sirona Dental Systems GmbH Sprache: englisch Printed in Germany D3762.201.01.01.02 08.2018 Ä.-Nr.: 000 000 Sirona Dental Systems GmbH 66 90 643 D3762 Fabrikstr. 31 Order No ...
