Vivax Metrotech vLocCam2 User Manual

vLocCam2 User Guide V1.2
Sonde Controls on vCam-5 Control Module
Compass (line direction indicator)
Sonde Operation
1. Press the F10 Menu twice to bring up the "Setup" menu.
2. Use the Down arrow key to scroll down to the Sonde Frequency
selection.
3. Use the Right arrow key to bring up choices of 512Hz or 640Hz.
4. Use the Up/Down arrow keys to make your selection and press
the Enter key .
5. Use the Left arrow key or ESC key to return to the Setup Menu.
(See the vCam-5 user handbook for full functions of the control module.)
WARNING
Check the distance reading on the counter of the vCam-5 and start the
search for a signal approximately 10m before the suapected position of
the camera head.
P/N: 4.04.000024
