3Com Baseline Switch 2952-SFP Plus
Front Panel
Figure 1-5 3Com Baseline Switch 2952-SFP Plus front panel
(1) 10/100/1000Base-T auto-sensing Ethernet
port
(3) Console port
(5) 1000Base-X SFP interface
Rear Panel
Figure 1-6 3Com Baseline Switch 2952-SFP Plus rear panel
(1) AC receptacle
Power Supply System
AC power input:
Rated voltage range: 100 VAC to 240 VAC, 50 Hz or 60 Hz
Input voltage range: 90 VAC to 264 VAC, 47 Hz or 63 Hz
Cooling System
The 3Com Baseline Switch 2952-SFP Plus is equipped with one fan for heat dissipation.
(2) 10/100/1000Base-T auto-sensing Ethernet
port status LED
(4) Power LED (Power)
(6) 1000Base-X SFP interface status LED
(2) Grounding screw
1-5
