Wilo-Drain TM 32, TMW 32, TMR 32
de Einbau- und Betriebsanleitung
en Installation and operating instructions
fr
Notice de montage et de mise en service
nl
Inbouw- en bedieningsvoorschriften
el Οδηγίες εγκατάστασης και λειτουργίας
tr Montaj ve kullanma kılavuzu
2 036 885-Ed.07 / 2015-06-Wilo
sv Monterings- och skötselanvisning
da Monterings- og driftsvejledning
hu Beépítési és üzemeltetési utasítás
pl Instrukcja montażu i obsługi
ru Инструкция по монтажу и эксплуатации
lt
Montavimo ir naudojimo instrukcija
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Wilo Drain TM 32
Summary of Contents for Wilo Drain TM 32
- Page 1 Pioneering for You Wilo-Drain TM 32, TMW 32, TMR 32 de Einbau- und Betriebsanleitung sv Monterings- och skötselanvisning en Installation and operating instructions da Monterings- og driftsvejledning Notice de montage et de mise en service hu Beépítési és üzemeltetési utasítás Inbouw- en bedieningsvoorschriften pl Instrukcja montażu i obsługi...
- Page 2 Fig. 1: Fig. 2: Fig. 3: 1~230 V, 50 Hz...
-
Page 3: Useful Information
WARNING! product/unit be complied with. The user can suffer (serious) injuries. 'Warning' implies that (serious) injury to persons is proba- ble if this information is disregarded. Installation and operating instructions Wilo-Drain TM/TMW/TMR... -
Page 4: Transport And Interim Storage
Speed: 2900 rpm (50 Hz) Max. current consumption: See name plate Power consumption P See name plate Max. flow rate: See name plate Max. delivery head: See name plate Operating mode S1: 200 operating hours a year WILO SE 06/2015... -
Page 5: Description And Function
Rotary shaft seal switchgear (accessory), increases the operating Float swich O-ring reliability if the 1st pump develops a fault. Screw Non-return valve Screw Pressure port Rp 1¼ Handle Impeller Grooved hose connector Whirl system (TWISTER function) Installation and operating instructions Wilo-Drain TM/TMW/TMR... - Page 6 If the mechanical represent a guaranteed backflow seal. seal is damaged, small amounts of oil may • The attached non-return valve should be installed escape into the pumped fluid. if the pump is installed permanently. WILO SE 06/2015...
-
Page 7: Maintenance
Adjusting the switching level of the float switch approx. 2000 operating hours by a specialist or The perfect functioning of the level control sys- Wilo After-sales Service, mainly in order to check tem is guaranteed if the details according to the the seals. -
Page 8: Spare Parts
Remove the suction strainer and rinse the suction strainer / impeller under running water. If the fault cannot be remedied, please contact the trade or your nearest Wilo-After-sales Service or agent. 11 Spare parts Spares should be ordered through local trade out- lets and/or the Wilo-After-sales Service. -
Page 10: Ey-Vaatimustenmukaisuusvakuutus
EZ IZJAVA O SUKLADNOSTI WILO SE vakuuttaa, että tässä vakuutuksessa kuvatut tuotteet ovat seuraavien eurooppalaisten direktiivien määräysten sekä niihin WILO SE izjavljuje da su proizvodi navedeni u ovoj izjavi u skladu sa sovellettavien kansallisten lakiasetusten mukaisia: sljedećim prihvaćenim europskim direktivama i nacionalnim zakonima: Matala Jännite 2006/95/EY ;... - Page 11 (SV) - Svenska ES-IZJAVA O SKLADNOSTI EG-FÖRSÄKRAN OM ÖVERENSSTÄMMELSE WILO SE izjavlja, da so izdelki, navedeni v tej izjavi, v skladu z določili WILO SE intygar att materialet som beskrivs i följande intyg naslednjih evropskih direktiv in z nacionalnimi zakonodajami, ki jih överensstämmer med bestämmelserna i följande europeiska direktiv och...
- Page 15 Burton Upon Trent WILOPumpsLtd. PortugalLda. 28806AlcaládeHenares ZIPCode:13.213-105 WILOVietnamCoLtd. 618-220Gangseo,Busan 4050-040 Porto (Madrid) T +55 11 2923 (WILO) DE14 2WJ HoChiMinhCity,Vietnam T +351 22 2080350 T +34 91 8797100 9456 T +44 1283 523000 T +82 51 950 8000 T +84 8 38109975 wilo.iberica@wilo.es...
- Page 16 WILO SE Nortkirchenstraße 100 D-44263 Dortmund Germany T +49(0)231 4102-0 F +49(0)231 4102-7363 wilo@wilo.com Pioneering for You www.wilo.com...
