- Page 1 V-ZUG-Home Install the app, network your appliances and benefit from a wide range of useful functions. Operating instructions AdoraDish V6000 OptiLift Dishwasher...
- Page 2 Validity These operating instructions apply to: Model designation Type Size system AdoraDish V6000 AS6T-41124 EURO 60 AdoraDish V6000 AS6T-41125 EURO 60 Variations depending on the model are noted in the text. © V-ZUG Ltd, CH-6302 Zug, 2021...
-
Page 3: Table Of Contents
EcoManagement........... 39 Instructions for use.......... 7 Information ............. 39 Using for the first time 9 V-ZUG-Home 40 Before using for the first time...... 9 Conditions .............. 40 Setting the door weight ........ 9 Initial set-up............ 40 Appliance description 10... - Page 4 Notes 60 Service & Support 63...
-
Page 5: Safety Warnings
Safety warnings Symbols used General safety precautions Unauthorized repairs could result in unforeseen dangers for the user, for which the manufacturer cannot ac- ▪ Read the operating instruc- cept liability. Repairs should only be tions before using the appli- undertaken by an authorized ser- vice technician, otherwise any sub- ance for the first time. -
Page 6: Appliance-Specific Safety Precautions
1 Safety warnings ently installed electrical install- ▪ No detergent must enter the ation in accordance with the opening of the door lock. This installation regulations. can cause the door lock to ▪ If the mains cable of this ap- malfunction. -
Page 7: Instructions For Use
1 Safety warnings Note on use Instructions for use ▪ Use the childproof locking facility (see Caution: Risk of injury! page 38). When sliding the lower basket out or ▪ If the appliance is visibly damaged, do closing the appliance door, be care- not use it. - Page 8 1 Safety warnings Caution: Risk of burns! How to avoid damaging the appliance ▪ Do not wash objects that are soiled with ▪ Turn off the water tap during longer ab- inflammable or corrosive solvent, paint, sences. wax, chemicals (acids or bases) or iron ▪...
-
Page 9: Using For The First Time
Using for the first time The appliance must be installed and connected to the electricity supply by a quali- fied fitter/electrician in accordance with the separate installation instructions. Before using for the first time Before operating the newly installed appliance for the first time, the following steps should be taken: ▸... -
Page 10: Appliance Description
3 Appliance description Appliance description Construction Rinse agent reservoir «Large» cutlery basket * Detergent dispenser Upper basket with SoftSlide Operating and display elements and SoftClose Salt reservoir 10 Spray arms Swivelling lower basket 11 Filter system OptiLift with SoftClose 12 FunctionLight «Small»... -
Page 11: Operating And Display Elements
3 Appliance description Operating and display elements Main menu Buttons Display Programmes (see page 14) V-ZUG-Home Navigation elements EcoManagement (see page 18) Frequently used user settings (see page 17) Other user settings (see page 41) Programme selected Intensive 1h15 70°... -
Page 12: Functionlight
3 Appliance description Button state Non-selectable functions Function selected Selectable functions Non-selectable navigation elements Action elements Increase value Decrease value Activate user setting Deactivate user setting Cancel entry, confirm message Start permanent mode programme, empty storage tank Navigation elements Go back to the previous menu Display other functions in the menu Display other functions in the menu Display other selection options in the menu... - Page 13 3 Appliance description Final drying phase During the final drying phase, all 6 LEDs illuminate orange and pulsate between dimmed and undimmed. Delayed start / OptiStart When the appliance door is closed and a delayed start is started, all 6 LEDs illuminate dimmed white.
-
Page 14: Functions
4 Functions Functions Selection buttons enable the user to select and start frequently used programmes simply and quickly at the touch of a button. The user can create and change a selection button for any favourite programme and thus adapt it perfectly to their own work processes. Programmes Consumption values The programme time (h), water consumption (l) and energy consumption (kWh) are in-... - Page 15 4 Functions Automatic Programme phases Consumption values Optimum cleaning results with min- ▪ Pre-rinsing (if required): ▪ 0h55–1h45 imal water and energy consump- cold ▪ 5–18 l tion. For normal soiling. Not suit- ▪ Cleaning: 50–60 °C ▪ 0.7–1.3 kWh able for burned-on or heavily dried- ▪...
- Page 16 4 Functions Party Programme phases Consumption values Quick wash programme for lightly ▪ Cleaning: 55 °C ▪ Heating-up phase: soiled dishes that need to be ▪ Rinsing with rinse 0h10–0h25 cleaned quickly, e.g. at a party or agent: 50 °C ▪ Programme time: an aperitif.
-
Page 17: Setting Options
4 Functions Setting options Energy saving The wash temperature is reduced by 5 °C, lowering energy consumption by approx. 10 %. The programme time is shortened slightly. «Energy saving» is also gentle on glasses. SteamFinish During final rinsing, steam is generated, which settles on the glasses and leads to op- timum drying results. -
Page 18: Ecomanagement
5 Loading EcoManagement EcoManagement Only active if «EcoManagement» is turned on in the user settings (see page 41). EcoManagement provides information on the energy consumption and water con- sumption of the appliance and supports the sustainable use of energy. The following consumption information can only be retrieved when no programme is running: ▪... - Page 19 5 Loading ▸ Pull the lower basket upwards until it audibly engages. To ensure safe loading, the lower basket must be raised into the loading position and audibly engage! ▸ Load the lower basket. ▸ Make sure the spray arms are not ob- structed in any way.
- Page 20 5 Loading Folding down the tines for larger loading area The tines can be folded down to create a larger loading area. ▸ Pull up the locking grip 1 at the side. ▸ Fold the tines down. ▸ Fold the tines down on the right-hand side of the basket.
- Page 21 5 Loading Stabilizing drinking vessels with easy prongs ▸ Put easy prongs 1 over basket prongs. ▸ Arrange drinking glasses, baby bottles, vases and carafes. ▸ Use two easy prongs for wider vessels. Loading the cutlery drawer * * Depending on model Risk of injury from being loaded incorrectly! Place knives and cutlery with sharp edges or points into the cutlery basket with the points facing downwards.
-
Page 22: Loading Tips For The Upper Basket
5 Loading Risk of water leakage! When closing the appliance door, ensure no items of cutlery are sticking out of the tub or are trapped. The leak tightness of the appliance cannot otherwise be as- sured. Loading tips for the upper basket Overloading the basket can damage the appliance! Do not exceed the maximum loading weight for the upper basket of 9 kg. - Page 23 5 Loading Loading tall glasses For tall glasses, use glass holders and racks for greater stability. Remove the racks to accommodate tall glasses. Glass holder ▸ Pull the glass holders 1 gently up until they engage. ▸ Rest tall glasses on the glass holder. Rack ▸...
- Page 24 5 Loading Adjusting the upper basket Depending on the model, the height of the upper basket can be adjusted by around 2–4 cm. It can be inclined in various ways. ▸ Hold the upper basket at the sides by the grips 1 and raise it into the desired engaged position.
-
Page 25: Hints On Loading The Cutlery Drawer
5 Loading Inserting the upper basket ▸ Extend the rails 1 as far as they will go. ▸ Push the upper basket gently against the right rail 1. ▸ Insert the safety bolts 2 on the right-hand side and then on the left. ▸... -
Page 26: Operation
6 Operation Inserting the cutlery drawer ▸ Extend the rails 1 as far as they will go. ▸ Position the back corners 2 of the cutlery drawer frame in the fixture 3 and press down gently until they click into place. Operation Dish washing tips General note... -
Page 27: Selecting Detergent
6 Operation Selecting detergent General note Do not use washing-up liquid! Strong foaming can cause the appliance to malfunc- tion. Follow the dosage instructions printed on the detergent packaging exactly. Should you have any questions, please contact the detergent manufacturer. Using too high or too low a dosage can cause damage to the appliance. -
Page 28: Adding The Detergent
6 Operation Adding the detergent Ensure no cleaning agent gets into the opening of the door lock. This can cause the door lock to malfunction. Powder ▸ Open the detergent dispenser 2 by push- ing the release catch 1 in the direction of the arrow. -
Page 29: Operating The Display
6 Operation Operating the display Programmes, setting options, user settings, permanent mode and favourites can be se- lected by touching or depressing and holding the relevant buttons. Touching a button Briefly touch a selectable or selected button to ▪ change from one menu into the next highest level. ▪... -
Page 30: Selecting And Starting A Programme
6 Operation Selecting and starting a programme The following work steps apply to all programmes with the exception of the «Party» programme. To start the «Party» programme, see the «Programme, Party» section (see page 31). Selecting a programme ▸... -
Page 31: Party" Programme
6 Operation «Party» programme Loading With the «Party» programme, the basket can be fully loaded. It is only suitable for lightly soiled dishes: ▪ wine, champagne and drinking glasses ▪ slightly greasy plates ▪ coffee and tea cups ▪ cutlery. Not suitable for dishes with dried-on food or moderately to heavily soiled dishes! Heating up the appliance ... -
Page 32: Adding Extra Dishes
6 Operation Performing further wash cycles The water from the first wash cycle remains in the appliance – if the appliance door is closed, it is kept hot for up to 5 hours – and can be used for 4 more wash cycles. Scalding hazard! If the appliance has a hot water connection, the water between the wash cycles can be hotter than 50 °C. -
Page 33: Aborting A Programme Before Time
6 Operation Aborting a programme before time The dishes and water may be hot. Scalding hazard! ▸ Open the appliance door carefully. – This interrupts the programme. – The interrupted programme alternates in the display with the «Close the door» mes- sage. -
Page 34: Programme Options
7 Programme options Programme options Delayed start The delayed start allows you to wash during off-peak hours (e.g. at off-peak electricity rates). It can be set briefly after selecting a programme. A delayed start of between 30 minutes and 24 hours can be set. Setting the delayed start duration ▸... -
Page 35: Favourites
7 Programme options Saving a programme as permanent mode ▸ On the start screen, touch the button repeatedly until the desired programme ap- pears. ▸ Hold the button for the desired programme, e.g. , depressed until the buttons appear in the display next to the programme selected. ▸... - Page 36 7 Programme options Creating favourites with setting options ▸ Select a programme along with setting options (see page 30). ▸ Touch the button in the setting options menu. – The buttons appear in the display. ▸ Touch the button and confirm the prompt with «YES». –...
-
Page 37: Permanently Selecting Setting Options
7 Programme options Permanently selecting setting options Assigning setting option to each programme ▸ On the start screen, touch the button repeatedly until «User settings» appears. ▸ Select the «Setting options Permanent selection» user setting. – The «Setting options Permanent selection» user setting appears. -
Page 38: Childproof Lock
7 Programme options Childproof lock Activating ▸ On the start screen, touch the button repeatedly until the user setting «Childproof lock» appears. ▸ Touch the button. ▸ Touch the button. – The following appears in the display: «To activate or unlock the childproof lock, please enter the code 3221 backwards.»... -
Page 39: Wipe Protection
7 Programme options Deactivating ▸ On the start screen, touch the button repeatedly until the user setting used «All in 1» appears. ▸ Touch the button. – «All in 1» is deactivated. ▸ Touch the button to access the start screen. Wipe protection ▸... -
Page 40: Zug-Home
– A 6-digit PIN appears in the display of the household appliance. ▸ Enter the 6-digit PIN in the V-ZUG App and confirm the bluetooth pairing request. – The name of the active WLAN/Wi-Fi appears in the V-ZUG App and then you are prompted to enter the WLAN/Wi-Fi password. -
Page 41: User Settings
9 User settings User settings Changing the user settings The user settings can be changed at any time. ▸ On the start screen, touch the button repeatedly until «User settings» appears. ▸ Touch the button. – The user settings menu appears in the display. ▸... - Page 42 9 User settings Rinse agent dosage Selection The rinse agent dosage is automatically ▪ Automatic (factory setting) justed to the load and the water hardness. If ▪ Level 1–12 the drying result is unsatisfactory, the dosage ▪ can be set manually to one of 12 levels.
- Page 43 : Deactivated (factory setting) trieve and change the user settings or retrieve various statistics about your household appli- ances. Further information about V-ZUG-Home and availability can be found at home.vzug.com or in the Operating instructions for V-ZUG-Home. EcoManagement Selection If the user setting is activated, EcoManage- ▪...
-
Page 44: Care And Maintenance
10 Care and maintenance Hot water connection Selection If the appliance has a hot water connection ▪ : Activated and the setting is activated, optimum use is ▪ : No heating made of the hot water available. ▪ : Deactivated (factory setting) For the «No heating»... -
Page 45: Cleaning The Spray Arms
10 Care and maintenance 10.2 Cleaning the spray arms Upper spray arm ▸ Remove the upper basket. ▸ Release the bayonet fastener 1 in an anti-clockwise direction and remove. ▸ Remove the spray arm 2 from the shaft and rinse well under running water. -
Page 46: Refilling With Regeneration Salt
10 Care and maintenance 10.4 Refilling with regeneration salt Never fill the salt reservoir with detergent! When the supply of regeneration salt is exhausted, the refill indicator flashes and the following appears in the display: Refill regeneration salt. Lorem ipsum Lorem ipsum Lorem ipsum Then run the Pre-rinsing... - Page 47 10 Care and maintenance ▸ Close the cover 3 on the salt reservoir and en- gage the latch. ▸ Push the lower basket 1 all the way back in. ▸ Run the «Pre-rinsing» programme without dishes to protect the appliance from corrosion from any excess salt.
-
Page 48: Filling With Rinse Agent
10 Care and maintenance 10.5 Filling with rinse agent Never put detergent in the rinse agent reservoir! Wipe away any spilt rinse agent. Risk of foaming. Follow the manufacturer’s safety instructions and warnings. Rinse agent prevents water spotting after final rinsing (rinsing with rinse agent). When the supply of rinse agent is exhausted, the refill indicator flashes and the fol- lowing appears in the display:... -
Page 49: Trouble-Shooting
11 Trouble-shooting Trouble-shooting You may be able to trouble-shoot the following errors yourself. If not, note down the error message in full and the serial number (SN), which can be found on the identification plate, and call Customer Services. 11.1 Error messages In the event of error messages follow the instructions on the operating panel. -
Page 50: Other Possible Problems
11 Trouble-shooting Display Possible cause Solution F… /E… ▪ Various situations can ▸ Cancel the error message by press- lead to an «F» mes- ing the button. see instructions / sage. SN XXXXX XXXXXX If the error message persists: ▸ Switch the power supply off for about 1 minute. -
Page 51: Unsatisfactory Washing Results
11 Trouble-shooting Problem Possible cause Solution An unpleasant ▪ There could be several ▸ Clean the filter system (see page smell tends to reasons for this. 45). come from the ap- ▸ Add dishwasher cleaner and run the pliance. «Machine care» programme. -
Page 52: In The Event Of A Power Failure
11 Trouble-shooting Problem Solution There is a white ▸ Clean the appliance with dishwasher cleaner. film on the dishes. ▸ Refill the salt reservoir with regeneration salt (see page 46) and run the «Pre-rinsing» programme without dishes. ▸ Use the correct amount of detergent or use a different kind of detergent (see page 27). -
Page 53: Accessories And Spare Parts
12 Accessories and spare parts Accessories and spare parts Please give model designation, model number and type of appliance when ordering parts. 12.1 Accessories «Small» cutlery basket «Large» cutlery basket Racks Set of 4 easy prongs Vario cutlery basket insert 12.2 Spare parts Filter system... -
Page 54: Technical Data
13 Technical data Technical data Dimensions SMS 55 SMS 55 EURO 60 EURO 60 Extra height Extra height Appliance height 756 mm 827 mm 756 mm 827 mm (incl. slide plate 3 mm) Appliance height – 845–893 mm 780–828 mm 845–893 mm (incl. adjustable plinth) Appliance width 546 mm 546 mm 596 mm 596 mm... -
Page 55: Overflow Protection
13 Technical data 13.2 Overflow protection The overflow protection system does not function during a power failure. Turn off the water tap during longer periods of inactivity. The electronic control unit monitors the water level in the appliance. In the event of a malfunction, the drain pump turns on, stopping the supply of water to the appli- ance. -
Page 56: Disposal
14 Disposal Disposal 14.1 Packaging Never allow children to play with packaging material due to the danger of injury or suffocation. Store the packaging material in a safe location or dispose of it in an environmentally-friendly way. 14.2 Safety Render the appliance unusable to prevent accidents caused by improper use (e.g. through children playing): ▸... -
Page 57: Index
Index Adding ............ 28 Combination .......... 17 A messages ............49 Selecting............ 27 Aborting Detergent dispenser......... 10, 28 Programme ........... 33 Display ............... 10 Acoustic signal ..........41 Operating ............ 29 All in 1............17, 27 Unlocking ............ 38 Activating............ 38 Wipe protection.......... - Page 58 Hot water connection ........44 Rack ............23, 53 Hygiene.............. 16 Raclette.............. 16 Regeneration salt Consumption .......... 47 Identification plate..........63 Refilling ............ 46 Information ..........29, 39 Rinse agent Intensive............. 15 Adding ............ 48 Interior ..............10 Dosing............ 42 Cleaning ............
- Page 59 Upper basket ............ 10 User settings..........11, 41 Adjusting............ 41 Using for the first time........9 Validity..............2 Vario cutlery basket insert......53 V-ZUG App ............40 V-ZUG-Home............. 40 Activating............ 43 Warranty claim..........54 Water hardness ..........42 Regeneration salt......... 47 Wipe protection ..........
- Page 60 Notes...
- Page 63 Your repair order Call the free service number 0800 850 850 to contact your nearest V-ZUG service centre. You can arrange an on-site visit by us by phone if you wish. General queries, accessories and service agreement V-ZUG will be happy to help you with any general administrative or technical queries, to accept your orders for accessories and spare parts and to inform you about our pro- gressive service agreements.
- Page 64 Select programme Close appliance door: At end of final drying: programme starts unload dishes 1065822-05 V-ZUG Ltd, Industriestrasse 66, CH-6302 Zug Tel. +41 58 767 67 67, Fax +41 58 767 61 61 info@vzug.com, www.vzug.com Service Centre: Tel. 0800 850 850...
