  • Page 1 Operating instructions Adora S integrated Dishwasher...
  • Page 2 41024 SMS 55 Adora 55 S GS55SGi 41026 SMS 55 Adora 60 S GS60Si 41034 EURO 60 Adora 60 S GS60SGi 41016 EURO 60 Variations depending on the model are noted in the text. © V-ZUG Ltd, CH-6302 Zug, 2019...

  • Page 3: Table Of Contents

    Contents 6.12 Interrupting a programme ........  29 Safety precautions  4 6.13 Aborting a programme ........  29 Symbols used............ 4 6.14 End of programme ..........  30 General safety precautions........ 4 6.15 Operation with childproof lock activated..  30 Appliance-specific safety precautions ....

  • Page 4: Safety Precautions

    Safety precautions Symbols used Cleaning and user mainten- ance shall not be undertaken Denotes important safety precau- tions. by children without supervi- Failure to observe said precautions sion. can result in injury or in damage to ▪ If an appliance is not the appliance or fittings! equipped with a mains cable Information and precautions that...

  • Page 5: Instructions For Use

    1 Safety precautions ▪ Children under 3 years of age Instructions for use must be kept away from the Before using for the first time appliance unless they are ▪ The appliance must be in- constantly supervised. stalled and connected to the ▪...
  • Page 6 1 Safety precautions Children in the home ▪ Do not use the appliance without any or too little deter- ▪ The water in the appliance is gent – risk of causing dam- not to be used as drinking age to the appliance! water.
  • Page 7 1 Safety precautions ▪ Avoid opening the appliance Refill the salt reservoir with regener- ation salt when the refill indicator door unnecessarily during op- eration. The dishes and water illuminates, even if using deter- gent. may be hot – scalding haz- ard! The steam that escapes ▪...

  • Page 8: Disposal

    Disposal Packaging ▪ All packaging materials (cardboard, plastic film (PE) and polystyrene (EPS)) are marked and should be collected for recycling and disposed of in an environmentally friendly way. Disconnection ▪ Disconnect the appliance from the mains. With a fixed appliance, this is to be carried out by a qualified electrician! Safety ▪...

  • Page 9: Your Appliance

    3 Your appliance Your appliance Appliance description ▪ Load capacity – 12 international place settings (SMS 55) – 13 international place settings (EURO 60) ▪ 8 programmes – «Automatic» – «Quick» – «Glass» – «Intensive» – «Fondue/Raclette» – «Hygiene» – «Pre-rinsing» –...

  • Page 10: Appliance Construction

    3 Your appliance Appliance construction Spray arm Basket Cutlery basket Rinse agent reservoir Quick operating instructions Detergent dispenser Salt reservoir Filter system «Small» cutlery basket Door handle Operating and display elements...

  • Page 11: Operating And Display Elements

    3 Your appliance Operating and display elements Programme buttons Programme selection Economy programme End of programme Additional functions (buttons) Energy saving Partial load Delayed start Programme symbols Automatic Fondue/Raclette Quick Hygiene Glass Pre-rinsing Intensive Additional functions/indicators (symbols) Energy saving «All in 1» detergent Partial load Rinse agent refill indicator Drying Plus...

  • Page 12: Programme Overview

    4 Programme overview Programme overview Programmes Automatic Optimum cleaning results with minimal water and energy consumption. For normal soiling. Not suitable for burned-on or heavily dried-on soiling. Quick Quick programme for light soiling (aperitif dishware and tea and coffee cups and saucers).

  • Page 13: Additional Functions

    4 Programme overview Economy programme Most efficient programme in terms of water and energy consumption for nor- mally soiled tableware (declaration programme). Additional functions Energy saving Reduces the wash temperature during cleaning by 5 °C, providing energy sav- ings of about 10% and gentle washing for glassware. Partial load With partial load, the programme is adapted to the smaller load.

  • Page 14: User Settings

    5 User settings User settings Adjusting user settings User settings can only be changed when no programme is running. The procedure is generally the same for all settings. Changing user settings ▸ Hold the button depressed for 5 seconds. – Display: ▸...
  • Page 15 5 User settings Possible settings The following diagram gives an overview of the possible user settings. Hold the button depressed for 5 seconds Off * All in 1 Off * Childproof lock French degree of water hardness * Water hardness unit German degree of water hardness Automatic * Automatic *...

  • Page 16: All In 1» Detergent

    5 User settings «All in 1» detergent The «All in 1» setting adapts the programme for use with detergent with integrated salt and rinse agent function in an optimal way. If the refill indicators illuminate, still refill with regeneration salt or rinse agent.

  • Page 17: Rinse Agent Dosage

    5 User settings Levels of water hardness Possible settings in °fH (French degree of water hardness) Level Auto °fH Auto- matic – – – – – – – – – – – – – Possible settings in °dH (German degree of water hardness) Level Auto °dH...

  • Page 18: Hot Water Connection

    5 User settings Hot water connection The available hot water is used optimally. If the water intake is still too cold, a short pre-rinse is carried out. The cleaning phase with hot water follows. If the additional energy saving function is selected, the water is heated up further electrically to only a minimum temperature, reducing energy consump- tion further.

  • Page 19: Operation

    6 Operation Operation Preparing the appliance Opening the appliance door ▸ Pull the door handle forwards. – Any programme that is running will be automatically interrup- ted. Before using for the first time ▸ Switch the power on. ▸ Turn on the water tap. ▸...

  • Page 20: Loading The Baskets

    6 Operation General note ▪ To prevent damage to glass and water spots, arrange glasses in such a way that they do not touch. ▪ Do not overload the baskets. ▪ Load beverage and food containers such as cups, glasses, pots, etc. with the opening facing downwards so that the water can drain off.
  • Page 21 6 Operation Glass holder The glass holders 1 are particularly suitable for tall glasses. They can be folded down or up. ▸ Push the glass holders gently down or, alternatively, pull them up until they engage. Racks The racks 1 can be used as glass holders. Remove the racks to accommodate tall glasses.
  • Page 22 6 Operation Fold-down tines Swing the fold-down tines 1 to the right to create an ad- ditional loading area for cups and glasses. Adjustable upper basket The height of the upper basket can be adjusted to 2 or 3 levels by a total of approxim- ately 2-4 cm.* It can be inclined in various ways.

  • Page 23: Loading Tips For The Lower Basket

    6 Operation Loading tips for the lower basket ▸ Pull the lower basket out as far as it will go and load. ▸ Load larger items such as plates, bowls, platters, pots and pans. ▸ Load wide dishes (soup plates, lids, etc.) at the back on the right. Put plastic bowls in the upper basket.
  • Page 24 6 Operation In order to fold the tines down, the locking grip 2 at the side must be pulled up. Easy prongs The easy prongs 1 can be placed over the prongs any- where in the basket. By using the easy prongs, drinking glasses, baby bottles, vases and carafes can be placed anywhere in the basket.
  • Page 25 6 Operation Cutlery basket * * Depending on model To avoid injury, place knives and cutlery with sharp edges or points into the cut- lery basket in such a way that they do not stick out (points facing downwards). Do not insert any knives, forks or other pointed objects into the door lock opening or drop them into the opening.

  • Page 26: Adding The Detergent

    6 Operation Adding the detergent Ensure no cleaning agent gets into the door lock opening. This can cause the door lock to malfunction. Powder ▸ Open the detergent dispenser by pushing the release catch in the direction of the arrow. ▸...

  • Page 27: Selecting A Programme

    6 Operation Choice of detergent Do not use washing-up liquid. It can cause excessive foaming, causing your appli- ance to malfunction. Follow the dosage instructions printed on the detergent package carefully. Using too high a dosage can cause damage to the appliance. ▸...

  • Page 28: Selecting The Economy Programme

    6 Operation Selecting the economy programme ▸ Close the appliance door. ▸ Press the button. – flashes. – The programme starts in 15 seconds. – illuminates. Selecting additional functions After selecting a programme, it is possible – within 15 seconds and while the pro- gramme symbol is flashing –...

  • Page 29: Delayed Start

    6 Operation 6.11 Delayed start The delayed start allows you to wash during off-peak hours (e.g. at off-peak electricity rates). The setting range lies between 1 and 24 hours. The delayed start duration last entered is shown as a suggestion. Setting ▸...

  • Page 30: End Of Programme

    7 Care and maintenance 6.14 End of programme The door must not be closed when appears in the display, otherwise the door opener can get damaged. At the end of the programme: – The symbols remain illuminated for about 90 minutes (final drying). –...

  • Page 31: Cleaning The Exterior

    7 Care and maintenance Cleaning the exterior ▸ Do not use abrasive or caustic cleaning agents. ▸ Do not use scouring pads, wire wool, etc. - damage to the surface. ▸ Remove any soiling or excess cleaning solution immediately. ▪ Detergent: washing-up liquid, glass cleaner ▸...

  • Page 32: Filling With Regeneration Salt

    7 Care and maintenance Lower spray arm ▸ Hold the spray arm 3 in the middle and pull hard up- wards. ▸ Rinse the spray arm well under running water. ▸ Check the nozzles. Clean the filter system and the coarse filter at the same time. See 'Cleaning the fil- ter system'.

  • Page 33: Filling With Rinse Agent

    7 Care and maintenance Filling with rinse agent Never fill the rinse agent reservoir with detergent. Wipe away any spilt rinse agent (risk of foaming and error messages Follow the manufacturer’s safety instructions and warnings. Rinse agent prevents water spotting after final rinsing (rinsing with rinse agent). The rinse agent is dosed automatically from the reservoir in the appliance door.

  • Page 34: Trouble-Shooting

    8 Trouble-shooting Trouble-shooting What to do if … This section lists faults that can be solved simply by following the instructions given. If another fault is displayed or the fault cannot be remedied, please call Customer Ser- vices. Please note down the error message and the serial number (FN) before calling Customer Services.
  • Page 35 8 Trouble-shooting … alternate Possible cause Solution ▪ Various situations can lead ▸ Cancel the error message by pressing the to a «F...» message.  button. If the error message persists: ▸ Switch the power supply off for about 1 minute. ▸...
  • Page 36 8 Trouble-shooting ... the appliance does not start ▸ Close the appliance door. ▸ Insert the plug into the mains socket. ▸ Check the fuse or circuit breaker. ▸ See the 'Operation with childproof lock activated' section. Possible cause Solution ▪...

  • Page 37: Power Failure

    8 Trouble-shooting … there are rust stains on the items being washed The rust stems from another source e.g. the cutlery, pans, water pipe. The appliance is made of rust-free steel. ▸ After topping up with regeneration salt, select the programme without dishes.

  • Page 38: Accessories And Spare Parts

    9 Accessories and spare parts Accessories and spare parts Please give product family of the appliance and exact description of the accessory or spare part when ordering parts. Accessories «Small» cutlery basket «Large» cutlery basket Vario cutlery basket insert Lower basket for glasses Cup support...

  • Page 39: Power Failure

    10 Power failure Racks Set of 4 easy prongs Spare parts Seal / water inlet filter for Aquastop Filter system Power failure A power failure causes: ▪ the programme that is currently running to stop. After the cause of the power supply failure has been resolved, the programme is resumed.

  • Page 40: Product Fiche

    11.2 Product fiche In accordance with Regulation (EU) No. 1059/2010 Brand – V-ZUG Ltd Model identifier (the first 5 alphanumerics of the – 41014 41010 serial number (SN))

  • Page 41: Consumption Data

    11 Technical data Airborne acoustical noise emissions for... i, …di type dB (A) Energy consumption per year based on 280 standard cleaning cycles using cold water fill and the consumption of the low power modes. Actual en- ergy consumption will depend on how the appliance is used. Annual water consumption based on 280 standard cleaning cycles.

  • Page 42: Index

    Index Accessories ............38 Glass holder............21 Additional function Delayed start .......... 29 Saving ............ 28 Height adjustable ..........22 Selecting............ 28 Hot water ............18 Additional functions ......... 11 All in 1 cleaning products ......27 Appliance construction ........10 Loading ............
  • Page 43 12 Index Refilling ............ 32 Rinse agent Refilling ............ 33 Rinse agent dosage ........17 Safety ..............8 Safety concept..........40 Safety precautions General ............. 4 Serial number (FN) .......... 47 Service & Support........47 Service agreement........... 47 Spare parts ............39 Spray arms Cleaning ............

  • Page 44: Notes

    Notes...

  • Page 47: Service & Support

    Your repair order Call the free service number 0800 850 850 to contact your nearest V-ZUG service centre. You can arrange an on-site visit by us by phone if you wish. General queries, accessories and service agreement V-ZUG will be happy to help you with any general administrative or technical queries, to accept your orders for accessories and spare parts and to inform you about our pro- gressive service agreements.
  • Page 48 ▸ The programme starts in 15 seconds. ▸ When the display goes out, open the appliance door and unload the dishes. J41016013-R05 V-ZUG Ltd, Industriestrasse 66, CH-6302 Zug Tel. +41 58 767 67 67, Fax +41 58 767 61 61 info@vzug.com, www.vzug.com...
