CORNING EDGE8-02U Quick Start Manual

Hide thumbs Also See for EDGE8-02U:
Table of Contents

Advertisement

Quick Links

EDGE8™ Solution
P/N 003-1002-AEN
Issue 7
related literature |
003-997-QSG-AEN
003-998-QSG-AEN
003-1000-QSG-AEN
003-1001-QSG-AEN
006-407-AEN
006-407-QSG-AEN

Table of Contents

1.
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2.
Carton Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
3.
Tools and Materials Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
3.1
Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
3.2
Materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
4.
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
4.1
Rack or Frame Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
4.2
Install Trunk Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
4.2.1
Trunk Cable Placement with the Pulling Grip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4.2.2
Pulling Grip Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4.3
(OPTIONAL) Install CDF Bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
4.4
Install Trunk Cables from Either Side of the Housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4.4.1
Installing Trunk Cable Using Keyhole Cradle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
4.4.2
Installing Trunk Cable with Keyhole Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
4.5
Install Trunk Cables from Rear of Housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4.6
(OPTIONAL) Remove Housing Trunk Plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4.7
Install EDGE8™ Standard Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.7.1
Into EDGE8-01U-SP, EDGE8-02U, and EDGE8-04U Housings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.7.2
Into EDGE8-01U Housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.8
Install EDGE8™ Port Breakout Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
4.8.1
Into EDGE8-01U-SP, EDGE8-02U, and EDGE8-04U Housings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.8.2
Into EDGE8-01U Housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.9
Connect Jumpers to EDGE8™ Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
4.10
4.10.1
Initial MTP Adapter Panel Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.10.2
5.
Recordkeeping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
5.1
Hardware Labeling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
5.2
Cable/Jumper Labeling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Instruction, EDGE8-01U Quick Start Guide
Instruction, EDGE8-01U-SP Quick Start Guide
Instruction, EDGE8-02U Quick Start Guide
Instruction, EDGE8-04U Quick Start Guide
Instruction, Field Tool for MTP® PRO Connectors Installation
Instruction, Field Tool for MTP® PRO Connectors Quick Start Guide
Adapter Panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
®
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EDGE8-02U and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CORNING EDGE8-02U

Summary of Contents for CORNING EDGE8-02U

  • Page 1: Table Of Contents

    Into EDGE8-01U-SP, EDGE8-02U, and EDGE8-04U Housings........

  • Page 2: General

    Troubleshooting and Maintenance ............... . 22 Testing .

  • Page 3: Installation

    Installation Rack or Frame Mounting Step 1: Identify the position on the rack where the housing will be installed and partially install screws to rest the mounting brackets on Figure 2. Step 2: Move brackets forward or backward for desired frontal projection and rest the mounting brackets behind the screw heads just installed in the rack.
  • Page 4 Weather Precautions • Always follow the recommended storage temperature guidelines for the cable when storing a trunk/pigtail. Each cable type will have a storage temperature rating that can be found on the product speci cation sheets. Storage outside of these ranges can cause damage to the cables.

  • Page 5: Trunk Cable Placement With The Pulling Grip

    CAUTION: Fiber optic cable is sensitive to excessive pulling, bending, and crushing forces. Consult the cable speci cation sheet for the cable you are installing. Do not bend the cable more sharply than the minimum recommended bend radius. Do not apply more pulling force to the cable than speci ed. Do not crush the cable or allow it to kink.
  • Page 6 Step 4: With the grip lying on a work surface, grasp the coupler at the cable-end of the trunk cable. With a slight twisting motion, pull the corrugated tube away from the coupler with your other hand (Figure 7). Figure 7 — Grip Disassembly Step 5: Slowly slide the tubing away from the coupler and its connector legs (Figure 8).

  • Page 7: Optional) Install Cdf Bracket

    (OPTIONAL) Install CDF Bracket An optional CDF bracket may be installed external to the housing on the frame to provide additional cable trunk installation positions and/or strain-relief. It supports incoming cable installation from the top or bottom of the frame into the housing. The bracket can hold keyhole cradles or U-clip furcation trunk holders (ordered separately) and is available in three sizes: •...

  • Page 8: Install Trunk Cables From Either Side Of The Housing

    Install Trunk Cables from Either Side of the Housing If necessary to install trunk cables from the rear of a housing, refer to Section 4.5 for details on reorienting the backplates to accommodate rear cable entry. In a 4U housing, trunk cables may be installed into the backplates in the top of the housing in an upside-down orientation, if desired or necessary, to accommodate additional cables.

  • Page 9: Install Trunk Cables From Rear Of Housing

    Step 3: Once the groove is aligned, slide down and back until furcation body is completely mounted on the keyhole adapter. Step 4: Align keyhole adapter with mounting plate. Push down and slide keyhole adapter back until it locks into place. Figure 14 –...

  • Page 10: Optional) Remove Housing Trunk Plate

    (OPTIONAL) Remove Housing Trunk Plate If cable entry strain-relief is accomplished in a location external to the housing, the trunk plate may be removed to allow more room behind the housing (Figure 16). Step 1: (For 4U housing only) Remove side panel from each side of the housing. Step 2: Remove any screws holding the access panels to the housing.

  • Page 11: Install Edge8™ Standard Modules

    Install EDGE8™ Standard Modules 4.7.1 Into EDGE8-01U-SP, EDGE8-02U, and EDGE8-04U Housings Step 1: Remove MTP connector and adapter dust caps. Clean connectors and adapters using the MTP ® cleaning tool (p/n 2104466-01). Follow the instructions provided with the tool. Step 2: Mate the MTP connector(s) into the adapter(s) at the back of the module (Figure 17) with the MTP key down/opposite the module label.

  • Page 12: Into Edge8-01U Housing

    4.7.2 Into EDGE8-01U Housing CAUTION: When removing the trays, position yourself in the center of the rack and use both hands to pull the tray out. Failure to so may damage the tray guides or cause shelf movement past the detents. Step 1: Press latches down to open and lower front door.

  • Page 13: Install Edge8™ Port Breakout Modules

    Figure 19 — Install EDGE8™ Standard Module Install EDGE8™ Port Breakout Modules 4.8.1 Into EDGE8-01U-SP, EDGE8-02U, and EDGE8-04U Housings Step 1: Starting with lower right corner (Tray 1, slot A), insert port breakout module from the rear until it locks into place.

  • Page 14: Into Edge8-01U Housing

    4.8.2 Into EDGE8-01U Housing CAUTION: When removing the trays, position yourself in the center of the rack and use both hands to pull the tray out. Failure to so may damage the tray guides or cause shelf movement past the detents. Step 1: Press latches down to open and lower front door (Figure 18).

  • Page 15: Install Mtp ® Adapter Panels

    Figure 22 — Mate Jumpers and Route Legs 4.10 Install MTP Adapter Panels ® The MTP adapter panel comes in con gurations to support both single-mode (SM) and multimode (MM) applications. Adapters have been clearly labeled identifying port (1, 2, 3, etc.). Each tray within the housing will support a maximum of six MTP panels.

  • Page 16: Connecting Mtp ® Jumper, Harness, Or Extender Trunk To Front Of Mtp Adapter Panels

    Figure 24 — Insert Adapter Panels into Rear of Housing 4.10.2 Connecting MTP Jumper, Harness, or Extender Trunk to Front of MTP Adapter Panels ® NOTE: All MTP® harnesses and jumpers are manufactured with MTP PRO connectors. Refer to the MTP PRO instructions in the related literature section for details on how to use the MTP PRO eld tool.

  • Page 17: Recordkeeping

    Step 5: Clean the connectors at the end of the harness, jumper, or trunk and mate in the electronics equipment as illustrated in Figure 26 per instructions provided with that equipment or according to your installation plan. Figure 26 — Typical Harness Con gurations Recordkeeping Detailed and accurate recordkeeping enables users to logically “map”...
  • Page 18 Figure 27 — Recommended Labeling Guidelines Step 1: Frame/Cabinet Location (Figure 28) Identify location of frame or cabinet within the oor space grid coordinate system. Preprint labels and adhere to front and back of frame or cabinet at the top and bottom. Figure 28 —...
  • Page 19 Step 2: Housing/Chassis Location (Figure 29) Identify location within the frame or cabinet (in rack units from the bottom) by locating the top/left corner of the housing/chassis. Print two labels and adhere one to the front chassis door using the crop mark for alignment.
  • Page 20 Step 4: Module Location with Fiber or Port Range (Figure 31) Each tray comes pre-labeled A through F to identify module position within the tray. Figure 31 — Module Label Location Step 5: Documentation (Figure 32) Identify remote location termination and determine code to be printed. It should only be necessary to print the remote location.

  • Page 21: Cable/Jumper Labeling

    Cable/Jumper Labeling Fiber termination identi cation is equally important in mapping the data center network. Individual bers (such as jumpers) must be clearly labeled to identify local and remote location. Typically a single jumper will contain two labels on each end of the ber near the termination point identifying the speci c local ID and the remote ID the jumper is patching to.

  • Page 22: Troubleshooting And Maintenance

    Troubleshooting and Maintenance Testing Use the Fluke MultiFiber™ Pro Optical Power Meter and Test Kits for testing the MTP connections. Follow the ® Fluke Networks manual which can be found on-line at http://download. ukenetworks.com/Download/Asset/MultiFiberPro_9827313_ENG_A_W.PDF. A sample test procedure can be seen in Figure 33. Figure 33 * —...

  • Page 23: Replace Edge8™ Module

    Replace EDGE8™ Module Step 1: Open front door and pull tray out. Step 2: Press latch on LC connector and pull connector out (Figure 34). If jumper is equipped with MTP ® connector, simply grasp connector body and pull connector out of the adapter. (NOTE: only LC connectors shown in Figure 34.) Step 3: Press lever on right side of module and pull module out.

  • Page 24: Cable In U-Clip Cradle

    6.3.2 Cable in U-Clip Cradle Step 1: Push in on the latch as shown in Figure 36. Step 2: Lift cradle and cable up. Step 3: At the same time, push the trunk cable forward. Step 4: Then lift up to remove the cradle from the plate as shown. Step 5: To remove furcation body from the cradle, push the body up from the bottom using your fore nger.

  • Page 25: Connector Care And Cleaning

    A complete listing of the trademarks of Corning Optical Communications is available at www.corning.com/opcomm/trademarks. All other trademarks are the properties of their respective owners. Corning Optical Communications is ISO 9001 certi ed. © 2015, 2019 Corning Optical Communications. All rights reserved.
