- Page 1 User Manual PCE-PWT 10 Water Analysis Meter User manuals in various languages (français, italiano, español, português, nederlands, türk, polski, русский, 中文) can be found by using our product search on: www.pce-instruments.com Last change: 18 April 2018 v1.0 © PCE Instruments...
-
Page 2: Table Of Contents
17 Electrode Replacement ..............12 18 Replacing the Batteries ..............12 19 Troubleshooting .................. 13 20 Specifications ..................13 21 Delivery Content .................. 14 22 Optional accessories ................14 23 Warranty ....................14 24 Disposal ....................14 © PCE Instruments... -
Page 3: Safety Notes
We expressly point to our general guarantee terms which can be found in our general terms of business. If you have any questions please contact PCE Instruments. The contact details can be found at the end of this manual. © PCE Instruments... -
Page 4: Introduction
Introduction Thank you for selecting the PCE-PWT 10 pocket salinity tester. This manual provides a step-by- step guide to help you operate the meter, please carefully read the following instructions before use. The following list describes the standard accessories of the tester. After unpacking, please check that all accessories are complete. -
Page 5: Display
Indicates the measured value has been frozen Indicates temperature compensation is enabled Prior to Use ● Remove the electrode protective cap from tester. ● Soak the electrode for a few minutes in tap water to remove dirt and oil stains on the electrode. © PCE Instruments... -
Page 6: Power On/Off
3 points Temperature Degrees Celsius ● Unit Degrees Fahrenheit Enters the temperature calibration Temperature mode Calibration Auto-Hold Automatically freezes a stable reading Disable ● Auto-Off Automatically turns off the tester ● Disable Reset Restore factory settings Disable ● © PCE Instruments... -
Page 7: Setting The Default Parameters
If you do not want to perform temperature calibration, press ENTER key, the tester goes to the next option. If needed, press CAL key to enter the temperature calibration mode, the display shows current temperature reading. © PCE Instruments... - Page 8 Press CAL key to enable or disable the reset function. Press ENTER key to confirm, the tester returns to measurement mode. Setting is completed. EXIT THE SETUP MENU: During the setup mode, press MEAS key, the tester will return to measurement mode immediately. © PCE Instruments...
-
Page 9: Conductivity Calibration
Conductivity Calibration PCE-PWT 10 pocket salinity tester allows up to 3 points calibration in the conductivity mode. To ensure higher accuracy, we recommend that you perform 3 points calibration or select a standard value close to the sample value you are measuring. The tester will automatically detect these conductivity standard solutions and prompt the user to calibrate the meter. -
Page 10: Single Point Calibration
Enter 1.6 Press ENTER key to start the calibration. Wait for the reading to stabilize, the display shows “END”. The tester returns to measurement mode automatically. Single point calibration is completed. © PCE Instruments... -
Page 11: 10 2 Point Calibration
Press ENTER key to start the calibration. Wait for the reading to stabilize, the display shows “END”. The tester returns to measurement mode. Second point calibration is completed. © PCE Instruments... -
Page 12: 11 3 Point Calibration
Press ENTER key to confirm, the display shows next option. Press MEAS key, the tester returns to measurement mode. Calibration is completed. EXIT THE CALIBRATION: During the calibration process, press MEAS key, the tester will return to measurement mode. © PCE Instruments... -
Page 13: Switching The Measurement Mode
Wait for the reading to stabilize and record the measured value on the display. Hold Function PCE-PWT 10 pocket salinity tester contains two data hold modes. When the Auto-Hold function is enabled, the tester will automatically sense a stable endpoint reading and freeze it, “HOLD”... -
Page 14: Electrode Replacement
Twist the electrode collar counter clockwise, pull the electrode module out from the tester. Insert two “AAA” batteries into the battery compartment, note polarity. Align the slot on the electrode module, push the module into the tester. Twist the electrode collar clockwise until it is tight. © PCE Instruments... -
Page 15: Troubleshooting
Using the fresh conductivity standard solutions for calibration Setting value does not match Reset the calibration value calibration solution Electrode is broken Replace the electrode module Specifications Salinity Model PCE-PWT 10 Range 0.00~10.00ppt Accuracy ± 1% F.S Resolution 0.01ppt Conductivity Range 0~20.00, 200.0,... -
Page 16: Delivery Content
For countries outside the EU, batteries and devices should be disposed of in accordance with your local waste regulations. If you have any questions, please contact PCE Instruments. © PCE Instruments... - Page 17 PCE Instruments contact information Germany France Spain PCE Deutschland GmbH PCE Instruments France EURL PCE Ibérica S.L. Im Langel 4 23, rue de Strasbourg Calle Mayor, 53 D-59872 Meschede 67250 SOULTZ-SOUS-FORETS 02500 Tobarra (Albacete) Deutschland France España Tel.: +49 (0) 2903 976 99 0 Téléphone: +33 (0) 972 3537 17...
