Camera Control
The following control inputs can be made either by the Pilot of Camera Operator.
The left wheel of the Controller allows you to change the pitch of the cameras.
Whilst flying, you can set several different parameters on the Full HD optical camera.
ELIOS USER MANUAL
Counter-clockwise makes the camera look downwards.
Clockwise makes the camera look upwards.
Centered, the camera will keep its current pitch.
It is possible to reset the camera position to level with the
Camera home button.
The three way Camera Mode switch sets the camera mode.
Auto You set the Exposure Value (EV) and the camera
changes with the ISO and exposure time. The EV is
equivalent to the overall brightness of the image.
C1: Camera in manual Low ISO mode ISO is set to 50 and
you set the exposure time.
C2: Camera in manual High ISO mode ISO is set
to 1600 and you set the exposure time.
The right wheel
automatic mode)
manual low ISO mode and manual high ISO mode).
Clockwise increases brightness.
Counter-clockwise decreases brightness.
With the FN button on the back side of the controller is
pressed, the right dial sets the onboard lighting LED's
power.
Clockwise increases LED power.
Counter-clockwise decreases LED power.
4 Flying Elios
exposure value (in
(in the
