- Solid purple: Controller is on, set as Slave, but not connected to the aircraft
- Solid cyan: Controller is set as Slave and connected to the aircraft
- Blinks red: Error. Use DJI GO
Battery level indicator
Displays the c
Altitude mode
Up: Manual Thrust Control mode, gives direct control over the thrust
Down: Automatic Altitude Control mode, the altitude is automatically maintained.
The altitude of the drone is measured by an on-board pressure sensor. In some cases, the pressure in an
environment will not be stable and Elios will not be able to maintain a constant altitude. To have a better
control, the pilot can disable the Automatic Altitude Control mode to have a direct control on the
stick will regulate the thrust power. Operating in Manual Thrust Control mode is not covered by the
warranty.
Camera pitch
Clockwise, camera looks upward.
Counter clockwise, camera looks downward.
Camera home
Horizontally levels the camera when pressed
Camera mode
Set the camera mode
- A: Camera in automatic mode
- C1: Camera in manual low ISO mode
- C2: Camera in manual high ISO mode
FN button
Press and hold this button while turning the EV/Lighting wheel to turn on the LED lights.
EV/Lighting wheel
Wheel:
- Default:
- Sets the EV if camera in automatic mode
- Sets the Exposure time if the camera is in manual low ISO mode or in manual high ISO mode.
- While the FN button is pressed the wheel sets the onboard lighting intensity
POI Button
Save a point of interest which can be reviewed after flight in the Flyability Inspector software.
SRC Button
Switches the video feed between HD camera and Thermal camera.
Pro Mode
When pressed, Elios is in High-Speed mode. This makes the drone more responsive and increases the
attitude angle limitation to achieve higher flight speeds.
of 6.5m/s (14mph). If Elios needs to fly in higher wind speed conditions the airspeed can be increased
to 9m/s (20mph) by using the PRO Mode. This allows the drone to operate in wind speeds up to 5m/s
(11mph). Operating Elios in PRO mode is not covered by the warranty.
USB port
Connection to the provided tablet
HDMI port
Offers the possibility to connect an external screen to the GCS
Power port
ELIOS USER MANUAL
for futher troubleshooting.
. Each LED corresponds to 25% charge remaining.
3 ELIOS System description
ght, the up/down
