Omcan PE-IT-0024-S Instruction Manual

Pizza oven
Hide thumbs Also See for PE-IT-0024-S:
Table of Contents

Advertisement

Quick Links

Download this manual
Pizza Ovens
Models PE-IT-0024-S, 0048-D, 0049-D, 0049-DD
Items 40637, 40638, 40641, 40643
Instruction Manual
QPS
Revised - 06/29/2017
approved
Toll Free: 1-800-465-0234
Fax: 905-607-0234
Email: service@omcan.com
www.omcan.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PE-IT-0024-S and is the answer not in the manual?

Questions and answers

Related Manuals for Omcan PE-IT-0024-S

Summary of Contents for Omcan PE-IT-0024-S

  • Page 1 Pizza Ovens Models PE-IT-0024-S, 0048-D, 0049-D, 0049-DD Items 40637, 40638, 40641, 40643 Instruction Manual Revised - 06/29/2017 approved Toll Free: 1-800-465-0234 Fax: 905-607-0234 Email: service@omcan.com www.omcan.com...

  • Page 2: Table Of Contents

    Table of Contents Model PE-IT-0024-S / Model PE-IT-0048-D Model PE-IT-0049-D / Model PE-IT-0049-DD Section Page General Information ------------------------------------------------------------------------------------------------- 3 - 4 Safety and Warranty ------------------------------------------------------------------------------------------------- 4 - 6 Technical Specifications ------------------------------------------------------------------------------------------------ 6 Installation ------------------------------------------------------------------------------------------------------------- 6 - 7 Operation ------------------------------------------------------------------------------------------------------------- 8 - 14...

  • Page 3: General Information

    If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents.

  • Page 4: Safety And Warranty

    Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia.
  • Page 5 Disconnect electrical power before intervening on electrical or electronic parts and connectors. 1 YEAR PARTS AND LABOUR WARRANTY Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule an Omcan authorized service technician to repair the equipment locally. Unauthorized maintenance will void the warranty. Warranty covers electrical and part failures, not improper use.

  • Page 6: Technical Specifications

    In any case, for suitable recycling, we suggest disposing of the products separately (differentiated waste) according to the current norms. DO NOT DISCARD ANY PACKAGING MATERIALS IN THE ENVIRONMENT! Technical Specifications Model PE-IT-0024-S PE-IT-0048-D PE-IT-0049-D PE-IT-0049-DD Maximum 842°F / 450°C...

  • Page 7: Installation

    Installation avoiding to use tools which can damage the surfaces. EQUIPMENT HOOK-UP Electrical connection The oven is not provided with power supply cable. When connecting the appliance electrically, an automatic RCD must be interposed with an opening distance between contacts of at least 3 mm. To connect the appliance electrically it is essential to proceed in the following way: •...

  • Page 8: Operation

    Operation DIGITAL OVEN START UP AND USE COMMAND PANEL DESCRIPTION Digital control panel Main switch Cooking chamber light switch The digital control panel allows the separate setting of top heating’s elements and bottom heating’s elements, furnishing in real time the information on the temperatures. It also allows the activation and set point of the timer, and the delay of lighting.
  • Page 9 Operation pushing once the touch Programme 2 is taken back and “P2” is shown. A minimum three seconds lasting push enables the modification of the bottom temperature (of the selected programme). INCREMENT VALUE KEY / VISUALIZATION TOP TEMPERATURE When the display shows the average baking chamber temperature, pushing once the touch top temperature is shown.
  • Page 10 Operation TOP TEMPERATURE ICON: It is active when the top probe temperature is showed on the display. This icon flashes during the variation of the top temperature set point. BOTTOM TEMPERATURE ICON: It is active when the bottom probe temperature is showed on the display.
  • Page 11 Operation GENERAL INDICATIONS FOR A GOOD COOKING Generally for the food products it is not advisable to give precise temperature and baking time, because of their different characteristics. Particularly, regarding pizza and similar products, time and temperatures depend on the shape and thickness of the dough, as well as on the quantity and typology of the additional ingredients. For those reasons it is always advisable to carry out previously some baking tests, (particularly when it is an absolute new oven), with the aim of understanding as much as possible the characteristics and the functioning of the oven.
  • Page 12 Operation SETTING THE DATE AND TIME The date and time must be set when the expansion with RTC is used for delayed start (parameter P20 = 2). With the card OFF, press the CLOCK key for 3 seconds, and the display will show the label dd followed by the day of the week from 1 to 7 (1= Monday, 7 = Sunday).
  • Page 13 Operation MECHANICAL OVEN START UP AND USE COMMAND PANEL DESCRIPTION Top heating elements Thermostat for the regulation function pilot light of top temperatures Digital control thermometer Bottom heating elements function pilot light Thermostat for the regulation of bottom temperatures Cooking chamber light switch Main switch FIRST LIGHTING OF THE OVEN At the first use of the appliance it is advisable to heat the empty oven to eliminate bad smells caused by the...
  • Page 14 Operation the shape and thickness of the dough, as well as on the quantity and typology of the additional ingredients. For those reasons it is always advisable to carry out previously some baking tests, (particularly when it is an absolute new oven), with the aim of understanding as much as possible the characteristics and the functioning of the oven.

  • Page 15: Maintenance

    Maintenance Before performing any maintenance operations, including cleaning, take the following precautions: • Ensure that the oven is not working end completely cold. • Ensure that the electrical power is not present. • Make certain that the electrical power cannot be accidentally reinserted. Disconnect the plug from the electrical power socket.

  • Page 16: Troubleshooting

    Troubleshooting WORKING ERRORS SYMPTOM POSSIBLE CAUSE SUGGESTED REMEDY The oven does not switch on. No electric Energy in the net. Check the general contactor, the socket, the plug, and the supply cable. Main switch off (positioned on "0"). Rotate the main switch to position "1".
  • Page 17 REFERENCE Item Number Model Number Description Manufacturer Model Number Pizza Oven Pyralis Series Single 40637 PE-IT-0024-S PYRALIS M4 Chamber 27.5” x 27.5” x 5.9” 220/60/3 Pizza Oven Pyralis Series Double 40638 PE-IT-0048-D PYRALIS M8 Chamber 27.5” x 27.5” x 5.9” 220/60/3...

  • Page 18: Parts Breakdown

    Parts Breakdown Model PE-IT-0024-S 40637 Model PE-IT-0048-D 40638...
  • Page 19 Parts Breakdown Model PE-IT-0024-S 40637 Model PE-IT-0048-D 40638...
  • Page 20 Parts Breakdown Model PE-IT-0024-S 40637 Model PE-IT-0048-D 40638...
  • Page 21 Parts Breakdown Model PE-IT-0024-S 40637 Model PE-IT-0048-D 40638...
  • Page 22 Parts Breakdown Model PE-IT-0024-S 40637 Model PE-IT-0048-D 40638...
  • Page 23 Parts Breakdown Model PE-IT-0024-S 40637 Model PE-IT-0048-D 40638...
  • Page 24 Parts Breakdown Model PE-IT-0024-S 40637 Item No. Description Position Item No. Description Position Item No. Description Position 76630 Complete Oven Door for PYRALIS M4 76650 Block 350x700x14 for PYRALIS M4 76670 Door Fixing Block for PYRALIS M4 76631 Door Assembly for PYRALIS M4...
  • Page 25 Parts Breakdown Model PE-IT-0048-D 40638 Item No. Description Position Item No. Description Position Item No. Description Position 77256 Complete Oven Door for PYRALIS M8 77276 Block 350x700x14 for PYRALIS M8 77296 Door Fixing Block for PYRALIS M8 77257 Door Assembly for PYRALIS M8 77277 Cord for PYRALIS M8 77297...
  • Page 26 Parts Breakdown Model PE-IT-0049-D 40641...
  • Page 27 Parts Breakdown Model PE-IT-0049-D 40641...
  • Page 28 Parts Breakdown Model PE-IT-0049-D 40641...
  • Page 29 Parts Breakdown Model PE-IT-0049-D 40641 Item No. Description Position Item No. Description Position Item No. Description Position 74797 Complete Oven Door for PYRALIS M12L 74818 Cord for PYRALIS M12L 74839 Door Rotation Bush for PYRALIS M12L Complete Oven Assembly for PYRALIS Resistance 400 W 230V for PYRALIS 74798 04.1...
  • Page 30 Parts Breakdown Model PE-IT-0049-DD 40643...
  • Page 31 Parts Breakdown Model PE-IT-0049-DD 40643...
  • Page 32 Parts Breakdown Model PE-IT-0049-DD 40643...
  • Page 33 Parts Breakdown Model PE-IT-0049-DD 40643 Item No. Description Position Item No. Description Position Item No. Description Position 74732 Full Oven Door for PYRALIS D12 74753 Rope for PYRALIS D12 74774 Rotating Socket Port for PYRALIS D12 Together with the Oven Door for Resistance 400 W 230V for PYRALIS 74733 04.1...

  • Page 34: Electrical Schematics

    Electrical Schematics Model PE-IT-0024-S 40637...
  • Page 35 Electrical Schematics Model PE-IT-0048-D 40638...
  • Page 36 Electrical Schematics Model PE-IT-0049-D 40641...
  • Page 37 Electrical Schematics Model PE-IT-0049-DD 40643...

  • Page 38: Notes

    Notes ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________...

  • Page 39: Warranty Registration

    Warranty Registration Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at the perforation and then send to the address specified below. You can also register online by visiting: Merci d’avoir acheté...
  • Page 40 Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North American food service industry. Our success over these many years can be attributed to our commitment to strengthen and develop new and existing relationships with our valued customers and manufacturers.
