SPECIAL PROCEDURES

IN CASE OF PROLONGED INACTIVITY
- If the appliance is to stand idle for any length of time (e.g.
holidays or seasonal closing) it must be cleaned thorou-
ghly, leaving not traces of food or dirt.
- Leave the lid open so that air can circulate inside the vat.
- For added care after cleaning, the external surfaces can
be protected by applying a proprietary metal polish.
- Be absolutely certain to shut off all utilities (electrical
power supply and water).
- Air the room appropriately.
SPECIAL PROCEDURES IN CASE
OF FAILURES
- If the appliance should not work properly during use, turn
it off immediately and close or cut off all supplies (electri-
cal power supply and water).
- Apply to a service centre for help.
The manufacturer shall not be held responsible nor
has any warranty commitments for damage caused by
non-compliance with prescriptions or by installation
not in conformity with instructions.
The same applies in case of improper use or different
application by the operator.

HOW TO PROCEED, IF ...

Maintenance operations and repairs must be perfor-
med only by specialists!
Disconnect the appliance. After having removed the con-
trol knob, remove the control panel, the handle of water in-
let tap and the handwheel for tilting of pan.
REPLACEMENT OF HEATING ELEMENTS (FIG. 4.3)
- Disconnect the electric cables to heating elements.
- Remove the front fixed panel and the steady pin of the til-
ting pan lever..
- Rotate the pan in the max. opening.
006 - 03 - Electric tilting cooker
- Remove the insulation protection (Pos. B), unloosing the
fixing screws to the pan.
- Remove the protection panel of heating elements. (Pos. C).
- Remove the heating element support plate (Pos. D) from
damaged heating element.
- Fit the new heating element operating in the opposite order.
REPLACEMENT OF SIGNAL LAMP
- Disconnect the power cables.
- Remove the signal lamp, unscrewing the fixed to the con-
trol pane.
- Fit the new signal lamp in the reverse order of operation.
REPLACEMENT OF WORKING OR SAFETY
THERMOSTAT (FIG. 4.3)
- Disconnect power cables, after having removed the front
panel.
- Remove the insulation protection (Pos. B), unloosing the
fixing screws to the pan.
- Remove the protection panel of heating elements (Pos. C).
- Remove the support plate of central heating element
(Pos. D).
- Remove the central heating element and then the fixing
bulb boss (Pos. H).
- Replacing the new thermostat be careful about tighte-
ning of the boss on the bulbs.
If the bulbs would be squeezed, this would cause the da-
mage of thermostat.
REPLACEMENT OF THE SWITCH
- Disconnect the power cables, after having removed the
front panel.
- Replace the switch uloosing the fixing screws to the sup-
port , after having taken off the coaxial working thermostat.
- Fit the new switch in the reverse order of operation.
Warning!
The tilting bratt pan has not to be used as a fryer. An
incorrect use can cause a fire into the oil tank.
