Wiring Diagrams - Whirlpool AGB 505/WP Installation, Operating And Maintenance Instructions

mA Line input terminal board
B1
Switch
B2 Microswitch
C1 Safety contactor
C2 Adjusting contactor
F1 Adjusting thermostat
F2 Safety thermostat
Green pilot lamp
H1
H2 Orange pilot lamp
Resistance
R
006 - 03 - Electric tilting cooker

Wiring diagrams

C1
B1
1 2 3 4 5
6
m A
L1 L 2 L 3 N
T
1 2 3 4 5
m A
L1 L 2 L 3
230 V 3~
CBRE
CBREIN
4 5 6
R
1 2 3
12 14 16
C2
11 13 15
B2
F2
F1
H2
400 V 3N~
8 kW
4 5 6
1 2 3
6
12 14 16
T
10
H1
mC
