OPERATING MANUAL
AIR CONDITIONER
Wall Mounted Type
MODEL:
* Please write down the model name.
(Refer to the rating label.)
R32
REFRIGERANT
This Air Conditioner contains and
operates with refrigerant R32.
THIS PRODUCT MUST ONLY BE INSTALLED OR SERVICED
BY QUALIFIED PERSONNEL.
Refer to Commonwealth, State, Territory and local legislation,
regulations, codes, installation & operation manuals, before
the installation, maintenance or service of this product.
PART No. 9387602029-02
Before using this product, read these instructions
thoroughly. Also, keep this manual for future
reference, together with the installation manuals for
the indoor and outdoor units.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Fujitsu Lifestyle Series
Summary of Contents for Fujitsu Lifestyle Series
- Page 1 OPERATING MANUAL AIR CONDITIONER Wall Mounted Type MODEL: * Please write down the model name. (Refer to the rating label.) REFRIGERANT Before using this product, read these instructions This Air Conditioner contains and operates with refrigerant R32. THIS PRODUCT MUST ONLY BE INSTALLED OR SERVICED thoroughly.
-
Page 2: Table Of Contents
Contents CAUTION This symbol shows that the operating manual should 1. SAFETY PRECAUTIONS .......... 1 be read carefully. 2. PREPARATION ............2 CAUTION 3. NAME OF PARTS ............. 3 This symbol shows that a service personnel should be handling this equipment with reference to the 3.1. -
Page 3: Preparation
WARNING CAUTION • Do not start or stop the operation of this product by • If leaking battery fluid comes in contact with your skin, inserting or pulling out the power plug, or by turning eyes, or mouth, immediately rinse with plenty of clean on or off the circuit breaker. -
Page 4: Name Of Parts
3. NAME OF PARTS 3.2. Remote controller When you use the optional remote controller, the appearance CAUTION and the operation procedure may differ. For details, please refer to the operating manual of each remote For appropriate signal transmission between the remote controller. - Page 5 CAUTION • To prevent malfunction or damage of the remote controller: - Place remote controller at where will not be exposed to direct sunlight or excessive heat. - Remove batteries if the product is not going to be For Powerful operation ....Refer to page 8. used for an extended period.
-
Page 6: Basic Operations
■ Airflow direction range 4. BASIC OPERATIONS Vertical airflow direction ■ 3 steps to start operation 1 ⇄ 2 ⇄ 3 ⇄ 4 ⇄ 5 ⇄ 6 Change by 1. Press to start or stop the operation. Swing operation by 2. -
Page 7: Weekly Timer
■ Examples of Weekly timer 6.1. Weekly timer Example 1 ■ Setting details 7:00 9:00 11:00 17:00 23:00 1. Select Weekly timer in step 2 of "Timer setting procedure". Monday Program Program Program Program 2. Press to select the program number and the day of the week. -
Page 8: Energy Saving Operations
Detection range of Human sensor 7. ENERGY SAVING OPERATIONS Side view Top view 7.1. Economy operation It saves more electricity than other operation modes by changing the set 90° temperature to a moderate setting. 50° 50° Press to activate/deactivate the Economy operation. -
Page 9: Other Operations
(2) Is the air conditioner under the Demand controlling? Contact your electricity supplier. 9. SETTINGS ON INSTALLATION No • Contact Fujitsu General (AUST.) PTY LIMITED. (Refer to your warranty card.) 9.1. Remote controller custom code setting • Visit our website (www.fujitsugeneral.com.au). -
Page 10: Cleaning And Care
2. Remove the air filters. 10. CLEANING AND CARE Lift up the air filters' handle, disconnect the two lower tabs, and pull out. Air filter handle CAUTION • Before cleaning this product, be sure to turn it off and disconnect all the power supply. •... -
Page 11: General Information
9. Install the air cleaning filter holders to the air filters. After extended non-use of the unit Engage the 4 hooks at the rear of the air cleaning filter frame with the latch at both ends of the air filter. If you have shut down the indoor unit for 1 month or more, perform the * Take care that the air cleaning filter does not project beyond the Fan mode operation for half a day to dry the internal parts thoroughly... -
Page 12: Optional Parts
■ Indoor unit temperature and humidity range Setting to use wireless LAN control Permissible ranges of temperature and humidity are as follows: Step 1. Application software installation Indoor temperature Cooling/Dry [°C] 18 to 32 1. Open “Google Play” or “App Store” depending on the type Heating [°C] 16 to 30... - Page 13 ) Register the air conditioner by following the instructions in 3. Select using on the remote the online manual on FUJITSU GENERAL web site. controller. * www.fujitsu-general.com/global/support/ This operating manual describes only the setting procedure of the remote controller.
-
Page 14: Troubleshooting
13. TROUBLESHOOTING Airflow is weak or stops. □ Is the fan speed set to Quiet? ⇒ To change the fan speed, refer to page 5. WARNING □ Has the Fan Control for Energy Saving set? In this case, the indoor unit fan may stop temporarily while the Cooling operation. In the following events, immediately stop operation of ⇒... - Page 15 ■ State of indicator lamps : The instruction is relating to the wireless LAN control (optional). Lighting pattern: Off, Blinking, Any state State Causes and solutions page Automatic defrosting operation ⇒ Please wait until finishing the defrosting (maximum of 15 minutes). Filter indicator ⇒...
