AIR CONDITIONER
Compact Wall Mounted Type
KEEP THIS MANUAL FOR FUTURE REFERENCE
DIESE ANLEITUNG BITTE SORGFÄLTIG AUFBEWAHREN
CONSERVEZ CE MODE D'EMPLOI AFIN DE POUVOIR VOUS Y RÉFÉRER ULTÉRIEUREMENT
GUARDE ESTE MANUAL PARA PODERLO CONSULTAR EN EL FUTURO
CONSERVARE QUESTO MANUALE PER OGNI EVENTUALE FUTURO RIFERIMENTO
ΚΡΑΤΗΣΤΕ ΤΟ ΕΓΧΕΙΡΙΔΙΟ ΓΙΑ ΜΕΛΛΟΝΤΙΚΗ ΑΝΑΦΟΡΑ
GUARDE ESTE MANUAL PARA CONSULTA POSTERIOR
СОХРАНИТЕ НАСТОЯЩЕЕ РУКОВОДСТВО ДЛЯ БУДУЩИХ ССЫЛОК
BU KILAVUZU, DAHA SONRA BAfiVURMAK ÜZERE SAKLAYIN
OPERATING MANUAL
BEDIENUNGSANLEITUNG
MANUAL DE FUNCIONAMIENTO
MANUALE DI ISTRUZIONI
ΕΓΧΕΙΡΙΔΙΟ ΛΕΙΤΟΥΡΓΙΑΣ
MANUAL DE INSTRUÇÕES
РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ
KULLANIM KILAVUZU
MODE D'EMPLOI
P/N9319356013-02
T
Advertisement
Table of Contents
Related Manuals for Fujitsu LT WALL Series
Summary of Contents for Fujitsu LT WALL Series
- Page 1 OPERATING MANUAL AIR CONDITIONER Compact Wall Mounted Type BEDIENUNGSANLEITUNG MODE D’EMPLOI MANUAL DE FUNCIONAMIENTO MANUALE DI ISTRUZIONI ΕΓΧΕΙΡΙΔΙΟ ΛΕΙΤΟΥΡΓΙΑΣ MANUAL DE INSTRUÇÕES РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ KULLANIM KILAVUZU KEEP THIS MANUAL FOR FUTURE REFERENCE DIESE ANLEITUNG BITTE SORGFÄLTIG AUFBEWAHREN CONSERVEZ CE MODE D’EMPLOI AFIN DE POUVOIR VOUS Y RÉFÉRER ULTÉRIEUREMENT GUARDE ESTE MANUAL PARA PODERLO CONSULTAR EN EL FUTURO CONSERVARE QUESTO MANUALE PER OGNI EVENTUALE FUTURO RIFERIMENTO ΚΡΑΤΗΣΤΕ...
-
Page 2: Table Of Contents
CONTENTS P/N9319356013-02 SAFETY PRECAUTIONS .........En-1 10 °C HEAT OPERATION ........En-11 FEATURES AND FUNCTIONS ........En-2 OUTDOOR UNIT LOW NOISE OPERATION ..En-11 NAME OF PARTS ............En-3 MANUAL AUTO OPERATION ........En-11 PREPARATION ............En-5 ON/OFF TIMER OPERATION ........En-12 OPERATION .............En-6 PROGRAM TIMER OPERATION ......En-13 ADJUSTING THE DIRECTION OF SLEEP TIMER OPERATION ........En-14 AIR CIRCULATION ..........En-8... -
Page 3: Features And Functions
FEATURES AND FUNCTIONS ■ Energy saving and Comfortable function INVERTER SLEEP TIMER At the start of operation, large amount of power is used to When the SLEEP button is pressed during Heating mode, the bring the room quickly to the desired temperature. Afterward, indoor unit’s temperature setting is gradually lowered during the the air conditioner automatically switches to a low power set- period of operation;... -
Page 4: Name Of Parts
NAME OF PARTS INDOOR UNIT Open Panel Intake Grille It opens at the same time of operation, and shuts when operation stops. ● Please do not touch by hand or put your fi nger into it during the open panel opening/shutting operation. - Page 5 : See page ► REMOTE CONTROLLER SENSOR button ► 9 Signal Transmitter MODE button ► 6 FAN button ► 6 SWING button ECONOMY button ► 8 ► 10 10 °C HEAT button OUTDOOR UNIT ► 11 LOW NOISE button SET button ►...
-
Page 6: Preparation
PREPARATION CAUTION! Turn on the Power ● Take care to prevent infants from acciden- tally swallowing batteries. Turn on the circuit breaker ● When not using the Remote Controller for an extended period, remove the batteries to Load Batteries (R03/LR03 × 2) avoid possible leakage and damage to the unit. -
Page 7: Operation
OPERATION To Start Operation Press the START/STOP button The indoor unit’s OPERATION Indicator Lamp (green) will light. The air conditioner will start operating. To Select Mode Operation Press the MODE button to select the desired mode. Each time the button is pressed, the mode will change in the following order. AUTO COOL HEAT... - Page 8 OPERATION About AUTO CHANGEOVER Operation ● When AUTO CHANGEOVER operation fi rst selected, the fan will operate AUTO: at very low speed for about a few minutes, during which time the indoor unit detects the room conditions and selects the proper operation mode. If the difference between temperature setting and actual room tempera- ture is more than +2 °C →...
-
Page 9: Adjusting The Direction Of Air Circulation
ADJUSTING THE DIRECTION OF AIR CIRCULATION Vertical (up-down) direction of airfl ow is adjusted by pressing the Remote Controller's SET button. Horizontal (right-left) airfl ow direc- tion is adjusted manually, by moving the Airfl ow Direction Louvers. Whenever making horizontal airfl ow adjustments, start air conditioner operation and be sure that the vertical air direction louvers are stopped. -
Page 10: Human Sensor (Energy Saving
HUMAN SENSOR (ENERGY SAVING) This function automatically controls the temperature setting when there is no one in the room for a while, and prevents electricity from being wasted. To enable the ENERGY SAVING ENERGY SAVING is set at the time of purchase. Press the SENSOR button “... -
Page 11: Powerful Operation
POWERFUL OPERATION The product will operate at maximum power, which is convenient when you want to quickly cool down or warm up the room. Begin Air Conditioner operation before performing this procedure. To use POWERFUL Operation Press the POWERFUL button Only as for this button operation, the beep sound is different from the others. -
Page 12: 10 °C Heat Operation
10 °C HEAT OPERATION To use 10 °C HEAT Operation Press the 10 °C. HEAT button While 10 °C HEAT OPERATION is in The ECONOMY indicator lamp (green) will light. progress, only the following operation can be used. To stop 10 °C HEAT Operation •... -
Page 13: On/Off Timer Operation
ON/OFF TIMER OPERATION ● ON TIMER : The air conditioner will start at the time you set. ● OFF TIMER : The air conditioner will stop at the time you set. ● Before using the timer function, be sure that the Remote Controller is set to the cor- rect current time. -
Page 14: Program Timer Operation
PROGRAM TIMER OPERATION ● The program timer allows you to integrate OFF timer and ON timer operations in a single sequence. The sequence can involve 1 transition from OFF timer to ON timer, or from ON timer to OFF timer, within a 24 hour period. ● Before using the timer function, be sure that the Remote Controller is set to the cor- rect current time. -
Page 15: Sleep Timer Operation
SLEEP TIMER OPERATION You can set the OFF TIMER to any time you want when you go to sleep. The product adjusts the temperature to make it suitable for sleeping, which helps you sleep comfortably. Once you set the time you want, you can easy set the timer to run from the next time, simply by pressing the SLEEP button once. -
Page 16: Weekly Timer Operation
WEEKLY TIMER OPERATION Using in these cases of WEEKLY timer The “OFF Timer” at which the operation will be stopped and the “ON Timer” at which the operation will be started can be combined, and up to 4 reservations (program ) can be applied for one day, and 28 reservations for a week. - Page 17 WEEKLY TIMER OPERATION To use WEEKLY timer operation Press the TIMER SETTING button Firstly, since “ ” will be fl ashing. Press the NEXT button Flashing the “ ” . Select the program and the day using the SELECT button Program 1Week Monday Program...
- Page 18 WEEKLY TIMER OPERATION Press the SELECT button to set the desired ON time or OFF time. If you selected OFF in step 3 1. Press the NEXT button to go back to step and confi gure the next setting. 2. Press the SEND button Press the NEXT button The time display / “...
- Page 19 WEEKLY TIMER OPERATION Check the schedule Press the TIMER SETTING button Firstly, since “ ” will be fl ashing. Press the NEXT button Check the program, the day, and the time with the SELECT button Press the TIMER SETTING button to return to the regular screen.
-
Page 20: Cleaning And Care
CLEANING AND CARE 3. Replace the air fi lters. CAUTION! Align the sides of the air fi lter with the panel, and push in ● Before cleaning the indoor unit, be sure to turn it off and fully, making sure the 2 lower tabs are returned properly to disconnect the electrical breaker and so on. - Page 21 CLEANING AND CARE About the Air Cleaning Filters Install or Replace the Air Cleaning Filter ● When Air Cleaning Filters are used, the effect will increased 1. Open the intake grille and remove the air by setting the fan speed to “High”. fi...
-
Page 22: Troubleshooting
TROUBLESHOOTING In the event of a malfunction (burning smell, etc.), immediately stop operation, turn off the electrical WARNING! breaker and consult authorized service personnel. Merely turning off the unit’s power switch will not completely disconnect the unit from the power source. Always be sure to turn off the electrical breaker to ensure that power is completely off. -
Page 23: Operating Tips
TROUBLESHOOTING Symptom Items to check See Page Doesn’t operate at all: ● Has the circuit breaker been turn off? — CHECK ONCE ● Has there been a power failure? MORE ● Has a fuse blown out, or a circuit breaker been tripped? ●...
