  • Page 1 WAVE 200 XL Pool Cleaner User Instructions 8151457 Rev. 02 www.maytronics.com...

  • Page 3: Table Of Contents

    WAVE 200 XL User Instructions Table of Contents 1. IMPORTANT SAFETY INSTRUCTIONS .........2 2. FCC STATEMENT................3 3. SPECIFICATIONS AND WATER CONDITIONS......3 4. INTRODUCTION ................3 5. CONTENTS ...................4 6. ASSEMBLY INSTRUCTIONS ............4 7. GENERAL NOTES .................5 8. MMI ALERTS .................5 9. MMI FUNCTIONS .................6 10.

  • Page 4: Important Safety Instructions

    1. IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS. Please adhere strictly to the following WARNINGS: e allowing people to enter the pool. — ¡ ¢ £ ¡ ¤ ¥ ¦ ¥ ¢ § ¥ ¥ ¨ © ¨ ¡ —  ¡  ¥  ¢ ¥  ¢ £ ¡  ¥ ¥ ¨ ¦ ¡  ¥  WARNING , disconnect the main power supply .

  • Page 5: Fcc Statement

    The WAVE 200 XL is designed to handle four different swimming pool configurations and when these are set by your Maytronics dealer, the pool configurations are stored in the MMI’s memory. The robot is preset in the factory with specific default pool settings, which can be reset.

  • Page 6: Contents

    5. CONTENTS Carefully remove all the items from the shipping box and check them against the packing list. You should have: • Documentation and accessories • Un-assembled Caddy for storing and carrying the WAVE 200 XL • MMI console (includes remote control unit) assembled to the Caddy's handle •...

  • Page 7: General Notes

    • Some options in the MMI (pool profile setup) menus are blocked with a code to prevent erred setting changes. The code sequence for unblocking these options is: 3, 2, and 1. Figure 1: Maytronics Machine Interactive (MMI) console 8. MMI ALERTS The WAVE 200 XL has the following alert LEDs: •...

  • Page 8: Mmi Functions

    9. MMI FUNCTIONS Command Description Menu From the Wave screen, press Menu to access the Main Menu screen  Scroll up  Scroll down  Start  Press both green buttons simultaneously to start pool cleaning Select Press Select to confirm your selection after using the scrolling buttons Modify Press Modify to change settings after making a selection Back...

  • Page 9: Choosing Additional Pool Profiles

    (A,B,C,D) to be cleaned. Note: the configuration of additional pool profiles can only be done by an official Maytronics WAVE technician. In case permisson for configuration is granted - select the pool you want to program (A, B, C, D).
  • Page 10 Manual Configuration of Pool Profiles Figure 6: Manual configuration of pool profiles WAVE 200 XL User Instructions...

  • Page 11: Daily Operation

    12. DAILY OPERATION o operate the WAVE 200 XL: 1. On the MMI, press the POOL button. The robot will start moving towards the pool, while pulling the floating cable, and enter it and position itself on the pool floor. Make sure it straightend itself vertically to the wall of the starting point and that the angle from the wall is less than 45°.

  • Page 12: Remote Control Unit Usage

    13. REMOTE CONTROL UNIT USAGE The remote control unit enables you to manually control the WAVE 200 XL to clean those hard-to- reach spots or places that were skipped during the standard cleaning cycle. Use only with non-rechargeable alkaline LR03 batteries 1.5V AAA. Do not charge non-rechargeable batteries.

  • Page 13: Cleaning The Filter

    Remove any dirt from around the impeller. Reassemble the impeller cover. Imp overload Does the problem reoccur with Contact your Maytronics dealer. every operation? Imp underload Does the problem Contact your Maytronics dealer. reoccur with every operation?
  • Page 14 Move the robot from its position and remove on wall a vertical position of more the obstacle. Reactivate. than 45º? If this reoccurs, contact your Maytronics Is the robot stuck on an dealer. obstacle? Out of water Was the robot operated out...
