  • Page 1 Robotic Pool Cleaner W 20 User Instructions ......p. 1-11 Mode d’emploi ......p. 12-22 Istruzioni per l’uso ....p. 23-33 Instrucciones de Uso ....p. 34-44 Gebrauchsanweisung ....s. 45-55 Manual de Instruções ....p. 56-66 8151669...

  • Page 3: Table Of Contents

    Robotic Pool Cleaner W 20 User Instructions Contents 1. INTRODUCTION ................2 2. SPECIFICATIONS .................2 3. WARNINGS AND CAUTIONS ............2 3.1 Warnings ................2 3.2 Cautions ................2 4. POOL CLEANER PARTS ...............3 5. USING THE POOL CLEANER ............4 5.1 Setup ..................4 5.2 Putting the Pool Cleaner into the pool ........5 5.3 Removing the Pool Cleaner from the pool ......5 6.

  • Page 4: Introduction

    Thank you for purchasing a Maytronics Robotic Pool Cleaner. We are sure that your Maytronics Robotic Pool Cleaner will provide you with reliable, convenient and cost effective pool cleaning. Its reliable filtration in all pool conditions and active brushing enhance maximum pool hygiene.

  • Page 5: Pool Cleaner Parts

    4. POOL CLEANER PARTS Robotic Pool Cleaner W 20 Filtration Optional Filtration Bottom lid and filter Bag Cartridge with net filters (x4) Ultra-fine filter (x4) Brush Remote Control PVC Brush Ideal for all pool surfaces Power Supply Caddy Robotic Pool Cleaner W 20 User Instructions...

  • Page 6: Using The Pool Cleaner

    5. USING THE POOL CLEANER The Pool Cleaner is very easy to use. Just follow the simple steps to get started, and your Pool Cleaner is ready to go. 5.1 Setup Before using the Pool Cleaner for the first time perform the following steps: Unwind the cable and stretch it out completely so that it has no kinks.

  • Page 7: Putting The Pool Cleaner Into The Pool

    5.2 Putting the Pool Cleaner into the pool Holding the Pool Cleaner upside down in the water, gently rock it back and forth with your fingers holding the plastic doors on the bottom lid open to release trapped air. Continue until no more bubbles are released. Release the Pool Cleaner and let it sink to the floor of the pool.

  • Page 8: Cleaning The Filter Bag Or Cartridges

    Using the floating cable, bring the Pool Cleaner to the pool’s edge. Using the handle, remove the Pool Cleaner from the pool. DO NOT PULL THE POOL CLEANER FROM THE POOL USING THE CABLE. CAUTION Place the Pool Cleaner on the edge of the pool and let the water drain out. 6.

  • Page 9: Replacing The Filter Bag

    Click Turn the Pool Cleaner upside-down. Open the bottom lid. Remove the filter bag. Clean the filter bag with a hose. We recommend that you periodically wash the filter bag in a washing machine using the gentle cycle program. Periodically clean the brushes with a hose. 6.2 Replacing the filter bag Put the filter bag over the frame so that the...

  • Page 10: Cleaning The Filter Cartridges

    6.3 Cleaning the filter cartridges Note: Don’t let the filter cartridges dry out before cleaning. Click Unplug the power supply. CAUTION With the Pool Cleaner upside down open the bottom lid and pull it out. Open the clips and remove the filter.

  • Page 11: Cleaning The Impeller

    6.4 Cleaning the impeller If you notice debris trapped in the impeller open the impeller and remove the debris. Unplug the power supply. CAUTION Using a screwdriver, remove the screws on the impeller cover and remove it. Clear any debris that may be in the impeller. No.

  • Page 12: Remote Control Unit

    7. REMOTE CONTROL UNIT Maytronics Cycle Selector Remote Control The Remote Control Unit offers two operation modes - Automatic mode and Manual direction mode. In Automatic cleaning mode, the fast or regular cleaning cycle can be selected. In Manual direction mode, the pool cleaner direction can be controlled manually.

  • Page 13: Offseason Storage

    Check if the drive system is blocked Electrical problem (power supply), check power source. If power source is in order, please contact your W 20 distributor Additional troubleshooting is available at our Website: www.maytronics.com Robotic Pool Cleaner W 20 User Instructions...
