ZTW Turbo Series Brushless Speed Controller for 1:10 &1:12 scale Car or Truck
Thank you for your purchasing the ZTW Brushless Electronic Speed Controller (ESC). The ZTW
electronic speed controller is specifically designed for operating Sensored/Sensorless brushless
motors. High power systems for RC model can be very dangerous and we strongly suggest that
you read this manual carefully. ZTW Model have no control over the correct use, installation,
application or maintenance of these products, thus no liability shall be assumed nor accepted for
any damages, losses of costs resulting from the use of this item. Any claims arising from the
operating, failure or malfunction etc. will be denied. We assume no liability for personal injury,
property damage or consequential damages resulting from our product or our workmanship. As
far as is legally permitted, the obligation for compensation is limited to the invoice amount of
product in question.
Features
◆ Enhanced throttle response, excellent acceleration, linearity and driveability.
◆ Using advanced PC interface to set up or update the firmware.
◆ Using LCD program card to make adjustments.
◆ Throttle curve and punch rate adjustment
◆ Dynamic boost timing and turbo timing adjustment.
◆ Brake curve and brake rate adjustment.
◆ Dynamic running data log.
◆ Multiple protection features: Low voltage cut-off protection, over-heat protection and throttle
signal loss protection.
Turbo Series Brushless System specification
Model
PN#Model
Cont.Current
Brust Current
Suitable Car
Battery cell
BEC Output
Dimension(l*w*h)
Weight(g)
120A & 160A & 220A
Beast Pro 120A
6212020
120A
760A
1:10/1:12 Car
2-3s Lipo/ 5-10s NiMH
6V/3A
41.5*37*21mm
102g
User Manual
Beast Pro 160A
6216020
160A
760A
1:10/1:12 Car
2-3s Lipo/ 5-10s NiMH
6V/3A
41.5*37*21mm
102g
Beast Pro 220A
4222032
220A
1000A
1:8 Car
8-18NC/3-6s Lipo
6.0V/7.4V Adjustable/8A
55*40*34mm
140g
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ZTW Beast Pro 120A
Summary of Contents for ZTW Beast Pro 120A
- Page 1 High power systems for RC model can be very dangerous and we strongly suggest that you read this manual carefully. ZTW Model have no control over the correct use, installation, application or maintenance of these products, thus no liability shall be assumed nor accepted for any damages, losses of costs resulting from the use of this item.
- Page 2 Using Turbo Series ESC for the debut Please attend to each connections and make sure each assignment is correct. Sensored Mode When using a Sensored Brushless motor, the Blue motor wire A, Yellow motor wire B and Orange motor wire C of the ESC must be connected with the Sensored motor wire A,B,C respectively. It is necessary to connect the Sensor wire to the “Sensor”...
- Page 3 Throttle Range Calibration ◆ Set up the ESC at the Throttle Range Calibration for the debut. ◆ For the first time using transmitter or changing the transmitter you must set up Throttle Range Calibration. 1. Switch off the ESC, then connect ESC with the battery packs and turn on the transmitter; set the direction of the throttle channel to REV;...
- Page 4 Programmable Value Section Programmable Item Run Mode Forward/Brake Forward/Brake/Reverse Forward/Reverse Cut-off voltage Disable Auto（3.0V/Cell) 3.0-11.1V(step 0.1V) ESC Overheat Protection 85℃ 105℃ 125℃ Disable Motor Rotation Normal Reverse Punch Rate1 1-30（step 1） Punch Rate2 1-30（step 1） Reverse Speed 100% 1%-99%（step 1%） Switch Point Throttle Curve Linear...
- Page 5 2 seconds of continuous neutral from the transmitter prior to allowing reverse to operate. Note: There is automatic protection within the ZTW ESC. Only after you have stopped and returned the trigger to neutral reverse will become available. If while traveling in reverse, pull the trigger to go forward.
- Page 6 adjustable part and back adjustable part. The punch rate has 30 programmable options. When to be set ‘1’, the punch rate is slow and there are lots of limit on the output of punch rate; the larger the settings is, the faster the punch rate is, the fewer the limit is. Reverse Speed Provide the strongest reverse speed when the throttle trigger is pushed to the max position in reverse, the reverse speed rely on the option you selected.
- Page 7 throttle range consists of 100 parts, which include the front adjustable part and back adjustable part. The punch rate has 20 programmable options. When to be set ‘1’, there’re lots of limit on the brake level; the larger the setting is, the fewer the limit of brake throttle is. Brake Curve The function adjusts the brake strength relating to the throttle range.
- Page 8 Turbo timing The function is just used in the long straightaway generally. Activation Method Including 3 activation methods. The turbo is just allowed to be activated when meeting the activation condition; the turbo is not allowed to be activated when not meeting the activation condition.
- Page 9 Turbo LCD Program Card Turbo LCD program card is only applied to Turbo series brushless ESC produced by ZTW Model. Users can choose their desired parameter at any time. It has 2 use methods as follows: 1. Working as an individual device to set the parameters; 2.Working as an USB adapter to update the firmware and set the parameters on PC.
- Page 10 1900 3.8-4.5 21.5T 1600 SHENZHEN ZTW MODEL SCIENCE & TECHNOLOGY CO., LTD ADD: 2/F, Block 1, Guanfeng Industrial park, The second Industrial Estate,Jiuwei new village, Xixiang, Baoan, Shenzhen, China, 518126 TEL: +86 755 29120026, 29120036, 29120056 FAX: +86 755 29120016 E-mall: sales@ztwoem.com / support@ztwoem.com...
