Summary of Contents for ZTW Beast SL 45A

  • Page 2 In order to operate this ESC properly please read this manual thoroughly before use. ZTW Model have no control over the correct use, installation, application or maintenance of these products, thus no liability shall be assumed nor accepted for any damages, losses of costs resulting from the use of this item.
  • Page 3 ● Multiple protection features: Low voltage cut-off protection, over-heat protection and throttle signal loss protection. ● Compatible with most of brushless motor. BEAST Series 1:10 ESC Specifications: Model Beast SL 45A Beast SL 60A Beast SL 80A Beast SL 120A PN#Model...
  • Page 4 Begin to Use The New ESC: Please attend to each connections and make sure each assignment is correct. Signal wire Signal wire Blue motor wire A Yellow motor wire B Blue motor wire A Orange motor wire C Switch wire Switch wire Orange motor wire C Power wire(+)

  • Page 5: Led Indication

    Sensorless Mode When using a Sensoreless Brushless motor, the Blue motor wire A , Yellow motor wire B and Orange motor wire C of the ESC can be connected with the motor wires freely. If the motor runs in the opposite direction, please swap any two wire connections. Connection to the Receiver Black wire RX- Red wire...
  • Page 6 Throttle Range Calibration 1. Turn on the transmitter, then connect ESC with the battery packs and set the direction of the throttle channel to REV; set the EPA/ATV value of the throttle channel to 100%. 2. Press and hold the “Set” button and switch on the ESC, release the button when the Blue LED turn solid.
  • Page 7 Forward Forward Forward with pause Running Mode /Reverse then Reverse Reverse Motor timing Very Low High Very High Normal Initial High Very High Medium Acceleration Throttle percent 80% 90% 100% Reverse Throttle Limit 70% 80% 90% Percentage 70% 80% 100% Braking Percentage 25% 30%...

  • Page 8: Cutoff Voltage

    1. Cutoff Voltage ● Automatically detect the number of the cells According to the type of your batteries , set up the type of the batteries and Low Voltage Cutoff Threshold via PC software or program card. The ESC can detect the Voltage of the battery anytime and will lower the output power once the Voltage of the battery is lower than the preset Low Voltage Cutoff Threshold.

  • Page 9: Running Mode

    Speed Controller requires 2 seconds of continuous neutral from the transmitter prior to allowing reverse to operate. Note: There is automatic protection within the ZTW ESC. Only after you have stopped and returned the trigger to neutral will reverse become available. If while traveling in reverse, pull the trigger to go forward.
  • Page 10 “Normal” and is a good starting point to deliver power and provide good run time. ● Very Low Provides maximum efficiency with less power. Higher timing produces significantly more power but at the expense of efficiency (less run time) and typically the motor will generate more heat.
  • Page 11 This is also very tough on the batteries as the amperage draw can be very high. If your vehicle cuts out, hesitates or loses radio control, you should consider setting this at a lower value. ● Low Using this option will provide longer run times and is easiest on the batteries. It is a good choice for beginners.

  • Page 12: Neutral Range

    10%,20%,30%,40%,50%(Default),60%,70%,80%,100% 8. Percentage Drag Brake 0%( Default) 4%,8%,12%,15%,20%,25%,30% The drag brake function provides the driver a set percentage of brake when you have the transmitter resting in neutral. This will create the “feel” of a brushed motor. Drag brake are used in racing to slow a vehicle as you let off approaching a corner versus the driver having to push the brake at every corner.
  • Page 13 2%,3%, 4% (Default) , 5%,6% ,10% LED Program card 1. The ZTW Program card with LED display is easy to use and convenient to carry. All of the programmable functions are shown on the program card. 2. Turn on the ESC. Remove the Signal wire and plug it into the top-socket on the Program card , wait for 2 seconds until the LED is ON.
