6. With the cover closed,
insert the Climate Logic
Setup Card into the
Receiver Module slot as
shown. Open the cover
to proceed.
Note: The Home screen
(right) will be displayed
only when a location has not been established, or has been
erased. Press the
SET LOC
7. Establish the site location as follows:
• Press
MENU _ LOCATION _
screen.
Note: The Lat/Lon Location screen will be displayed by default.
To set the location using a 5-digit ZIP code, press the
• Press the or key to adjust the selected value. Press the
key to select the next value in sequence.
NEXT
• When the location information is displayed correctly, press
the key.
SAVE
Note: The Receiver Module will begin transferring specific data
from Setup Card for the defined location. A confirmation screen
will indicate the completed transfer.
• Press the key (two times) to return to the Home screen.
EXIT
8. Remove the Setup Card and stow inside the controller cabinet.
8
Receiver Module Installation
CLIMATE LOGIC
CLIMATE LOGIC
CLIMATE LOGIC
CLIMATE LOGIC CLIMATE LOGIC
TM
TM
69
F F
– – –
No Rain - Irrigation
MUST SET LOCATION
1:15
a
MENU MENU SET LOC
CLIMATE LOGIC CLIMATE LOGIC
SETUP CARD SETUP CARD
THIS SIDE UP
key to display the Location screen.
ENTER to display the Location
ZIP
40% 30%
CLIMATE LOGIC
11/16
F
– – –
CLIMATE LOGIC CLIMATE LOGIC
TM
SETUP CARD SETUP CARD
No Rain - Irrigation
THIS SIDE UP
THIS SIDE UP
MUST SET LOCATION
MENU
Location
LAT
LONG
North America
key.
SAVE CANCEL
Location
SAVE CANCEL
40%
SET LOC
00.0000
-000.0000
ZIP NEXT
ZIP
00000
LAT NEXT
