5.8 Error messages/warnings
Display
%
92
Description
No sensor is con-
nected
An auxiliary sensor is
connected.
Sensor recognition in-
terrupted (cable break
or input defect)
Measurement range
overflow
The measured pres-
sure is outside of the
measurement range
Overflow
ZERO
The zero point offset
value exceeds the
tolerance
Overflow IN1 = IN2
Differential value
alignment
The alignment value
exceeds the tolerance
DISP LINE IN1 = IN2
Wrong setting
Overflow IN1 - IN2:
Differential value
alignment
Measured value
memory full
What action to take?
Turn off the measuring instrument
Connect sensor
Turn on the measuring instrument
Carry out settings in the menu
SET- AUX.SENSOR
Send measuring instrument,
sensor and connection cable to
Webtec.
Release pressure from the system
Use sensor with wider measure-
ment range
Check only when no pressure is
applied
Test system pressure
Use sensors with wider measure-
ment range
Configure IN1-IN2
Measured variables (sensors)
must be the same
IN1 / IN2 = bar
IN1 / IN2 = L/min
IN1 / IN2 = °C
Download measured values to PC
Delete measured value memory
