Point Capacity - Automated Logic T-Line Series Technical Instructions

Fault Detection: Hardware watchdog timer.
Temperature: Operating temperature range is 0-130 °F
(-17.8 to 54.4 °C), non-condensing.
Dimensions: (T320, T540) 4" x 4" x 1 1/2"
(T320V, T540V) 5" x 4" x 1 7/8".
A/D Input Resolution: 10 bit.
Processor: Microchip PIC16C57, 11.06 MHz, 2k
ROM, 72 bytes RAM.
Listed by: PAZX (UL 916).
Start/Stop
Pulse Width
Modulation
FM Output 1 -
FM Output 2 -
VAV Flow
Output** -
* - Digital output 5 can only be used for start/stop control.
** - Digital outputs 1 and 2 can only be used for VAV Flow control on the
T540v and T320v.
Rev. (29-JUN-99) • TNI v4.7
Allowable Digital Outputs
T540* T540V*
1,2,3,4,5 3,4,5
1,2,3,4 3,4
Open 1 3
Close 2 4
Open 3 none
Close 4 none
Open none 1
Close none 2
Figure 2: Allowable T-Line Digital Output Configuration

Point Capacity

No. of DO
T320v 3
T320 3
T540v 5
T540 5
Two inputs (the only inputs on the T320 and
*
T320v) may be accessed through the enhanced
sensor port using an Insulation Displacement
Connector (IDC). If used, the Enhanced Zone
Sensor (RSZ+) will require two of the available
inputs.
T320 T320V
1,2,3 3 only
1,2,3 3 only
1 none
2 none
none none
none none
none 1
none 2
©1995-99 Automated Logic Corporation
4
No. of Velocity
AI/DI* Pressure
2 0-2" WC
2 --
4 0-2"WC
4 --
