Removing Quick-Disconnects - Automated Logic T-Line Series Technical Instructions

the wire using a crimper as shown in Figure 30.
4. Terminate the wire by firmly pushing the connector
onto the desired quick-disconnect terminal, as shown
in Figure 31.

Removing Quick-Disconnects

When removing connectors from the quick-disconnect
terminals, rock the connectors from side-to-side while
pulling, as shown in Figure 32.
